Geemarc ClearSound CL64 User manual

CL64
Amplified Classic Phone
Téléphone Vintage Amplifié
Lautverstärktes Retrotelefon
English1~12
Français13~24
Deutsch25~36

1
User manual to be read carefully before use!
CAUTION: this telephone is specifically designed for people with
hearing difficulties and is provided with a handset earpiece volume
control for individual requirements. Due care must be taken by all
users that the handset earpiece volume control is set to the lowest
level acceptable by each respective user. Care should therefore be
exercised to ensure that any naive users are familiar with this
requirement.

2
CONTENTS 2
DESCRIPTION 3
General Description 3
SETTING UP 5
1 - Connecting the telephone 5
2 - Ringer volume setting 5
3 - Auto Dial Switch 6
4 –Auto On Hook 6
VOLUME AND TONE ADJUSTMENT 7
1 - Receiving volume and tone adjustment 7
2 - Sending volume adjustment 8
USING THE PHONE 9
1 - Answer a call 9
2 - Making a call 9
3 - Storing telephone numbers 9
4 - Dialing stored numbers 10
GUARANTEE 11
GENERAL INFORMATION 12
CONTENTS

3
General Description
Battery low LED
Ringer LED &
Amplify On LED
&
AMPLIFY On/Off button
Auto Dial SOS number
ON/OFF Switch
Ringer UK/EURO Select
Switch
Amplify ON/OFF
slide switch
Lock the
Battery Door
4XAA Size
Battery
Compartment
Store Button
DESCRIPTION
Auto turn off Switch
Ringer Loud/High/Low/
OFF Switch

4
Slide Volume Control
Send Amplify
-3 / 0 / +3
Slide TONE
Control
DESCRIPTION

5
1 - Connecting the telephone
- Connect the handset cord.
- Open the battery door by turning around the locking tab.
Insert 4 alkaline batteries (type AA 1.5V, not supplied) in the
compartment (*). Batteries are required if you wish to
increase the ringer level up to 10 dB & also use the
“Mechanical Bell” ringer feature.
Replace the battery door and turn the locking tab to the
locked position.
- Connect the line cord plug into the line socket on the rear of
the unit (*).
- Connect the other end of the line cord into the wall PTT
socket (*).
2 - Ringer volume setting
The phone is equipped with “Mechanical Bell” ringers which can be
selected between UK (tring..tring) & European (triiiiiiiiiiiing) style
bells, via the switch located in the battery compartment.
The mechanical bell sound is functional only when the batteries are
inserted and are not run down.
When there are no batteries or the batteries are “low” the Battery
low indicator flashes and the ringer sound is the normal two tone
electronic ring.
A switch located on the right side allows the ringer to be switched to
LOUD Hi, Low or Off:
: Off
: Low
: Hi
: LOUD
SETTING UP
(*) Classified TNV-3 according to EN60950 standard.

6
Note: The ring level will be increased of 10 dB if you insert
batteries.
3 –Auto Dial Switch
When this switch is in ON position ( ), the phone will automatically
dial out the number stored in the SOS memory if no other dial button
is pressed for 4 seconds. Set this switch as per your requirement.
4 –Auto On Hook
When this switch is in the On position ( ), the phone will
automatically go On Hook (disconnect the telephone line) when the
person at the other end disconnects the line, even if the handset is
not replaced on the cradle.
In case the handset is removed from the cradle and there is a phone
call, the phone will still ring as usual. To answer the call, pick up the
handset, press and release the hook button once.
SETTING UP

7
1 - Receiving volume and tone adjustment
You can increase the volume and adjust the receiving tone
according to your own hearing requirements.
When the switch located under the phone is ON ( ), the extra-
receiving and tone functions are automatically activated each time
you use the phone.
When this switch is OFF ( ), you will need to activate the function
by pressing the button .
Pressing the button (AMPLIFY ON/OFF switch) allows extra
receiving and tone functions to be activated during the conversation.
When the function is activated, the red light of extra receiving and
tone function located below the ringer LED lens lights up
Adjust the TONE and VOLUME buttons to fit the levels to your own
hearing requirements.
VOLUME AND TONE ADJUSTMENT

8
Note: When the tone (treble), earpiece volume and sending levels
are set to the maximum, whistling may occur. Then the sending
level settings should be decreased with the switch .
When the switch located in the bottom of the phone base is ON
( ), the extra-receiving and tone functions are automatically
activated each time you use the phone. When this switch is OFF
( ), you will need to activate the function by pressing the button
.
Tone and volume (15dB to 30dB) adjustment is only activated when
the button is set to ON ( ). When this button is set to OFF
() only the volume can be adjusted from 0dB to 15dB.
2 - Sending volume adjustment
If your voice is quiet or called parties have difficulty hearing you, you
can increase the sending level volume with the switch located on
the right side. You can also decrease the sending volume if
required.
VOLUME AND TONE ADJUSTMENT

9
If you are using this telephone with a hearing aid, set your
hearing aid to the T setting.
1 -Answer a call
- When an incoming call is received the phone will ring and the
ringer LED will flash, to answer the call lift the handset and
speak.
- On completion of the call, carefully replace the handset in the
cradle to release the line. See also section on Auto/Manual
switch
2 - Making a call
- Lift the handset.
- Await the dial tone and press the SOS, M1 or M2 buttons
once
- On completion of the call, carefully replace the handset in the
cradle.
See also section on Auto Dial On/Off switch
3 - Storing telephone numbers
Your telephone has a SOS memory button with 112 stored as
default and also two other memory buttons, M1 & M2
This SOS number can be changed to a number of your choice
which can be up to 18 digits. To change the SOS memory:
USING THE PHONE

10
Remove the handset from the cradle
Press the hidden STORE button located inside the battery
compartment
Use the dial keypad to enter the new number
Press SOS memory button
Replace the handset on the cradle
You can also store numbers of your choice (eg. Doctor, Ambulance
etc) in the M1 & M2 locations using the same procedure, only press
M1 of M2 button instead of SOS.
4 - Dialing stored numbers
- Lift the handset and await the dial tone.
- Press SOS, M1 or M2 Button, the stored number will be
dialled automatically.
Note: If Auto Dial On/Off switch is set to ON position ( ), if a
telephone number key is not pressed within 4 seconds of
lifting the handset, the number stored in SOS memory will
automatically dial out.
USING THE PHONE

11
From the moment your Geemarc product is purchased, Geemarc
guarantee it for the period of one year. During this time, all repairs
or replacements (at our discretion) are free of charge. Should you
experience a problem then contact our help line or visit our website
at www.geemarc.com. The guarantee does not cover accidents,
negligence or breakages to any parts. The product must not be
tampered with or taken apart by anyone who is not an authorized
Geemarc representative. The Geemarc guarantee in no way limits
your legal rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR GUARANTEE
AND MUST BE RETAINED AND PRODUCED IN THE EVENT OF
A WARRANTY CLAIM.
Please note: The guarantee applies to
the United Kingdom only
GUARANTEE

12
Recycling directives:
The WEEE (Waste Electrical and Electronic Equipment)
has been put in place for the products in end of life are
recycled in the best way.
When this product is out of order, please do not put it in
your domestic waste bin.
Please use one of the following disposal options:
- Remove the batteries and deposit them in an appropriate
WEEE skip. Deposit the product in a appropriate WEEE skip.
- Or hand the old product to the retailer. If you purchase a new
one, they should accept it.
Thus if you respect these instructions you ensure human health and
environmental protection.
Telephone connection: Voltages present on the
telecommunication network are classified TNV-3
(Telecommunication Network Voltage) according to the EN60950
standard.
The telephone does not operate if the line current is lower than
18mA.
Declaration: Hereby Geemarc Telecom SA declares that this
product is in compliance with the essential requirements and other
relevant provisions of the Radio and Telecommunications Terminal
Equipment Directive 1999/5/EEC and in particular article 3 section
1a, 1b and section 2.
The declaration of conformity may be consulted at
www.geemarc.com.
GENERAL INFORMATION

13
Nous vous conseillons de lire attentivement la notice avant d'utiliser
l'appareil
ATTENTION : ce téléphone a été spécialement conçu pour les
personnes souffrant de troubles de l'audition. Un bouton permet à
chacun de régler le volume de l'écouteur du combiné selon ses
besoins. Avant d'utiliser le téléphone, il est important de vérifier
systématiquement que le niveau du volume de l'écouteur du
combiné est réglé sur le niveau le plus bas acceptable. Ces
consignes devront donc être rappelées à toute personne utilisant
l'appareil pour la première fois.

14
SOMMAIRE 14
DESCRIPTION 15
Vue d'ensemble 15
MISE EN SERVICE 17
1 - Branchement du téléphone 17
2 - Réglage du volume de la sonnerie 17
3 - Interrupteur de numérotation automatique 18
4 - Raccrochage Automatique 18
RÉGLAGE DU VOLUME ET DE LA TONALITÉ 19
1 - Réglage du volume et de la tonalité de réception 19
2 - Réglage du volume du microphone 20
UTILISATION 21
1 - Répondre à un appel 21
2 - Passer un appel 21
3 - Mémoriser le numéro SOS, M1 ou M2 21
4 –Composer le numéro SOS, M1 ou M2 22
GARANTIE 23
INFORMATIONS GÉNÉRALES 24
SOMMAIRE

15
Vue d'ensemble
Voyant d'alerte piles déchargées
Voyant de sonnerie et
Voyant d’activation de
l'amplification
Interrupteur de
numérotation automatique
du numéro SOS
Réglage du rappel d'enregistreur: 100 ms GB /
300 ms EURO /100 ms EURO
Interrupteur
de l'amplificateur
Verrou du couvercle
du compartiment
des piles
Compartiment
pour 4 piles
de type AA
Touche de mémorisation
DESCRIPTION
Sélecteur de raccrochage
Automatique
Sélecteur du volume de
Sonnerie Maxi / Forte /
Faible / Arrêt

16
Réglage du volume
d’écoute
Réglage
d'amplification du
microphone
-3 / 0 / +3
Réglage de la tonalité
DESCRIPTION

17
1 - Branchement du téléphone
- Commencer par brancher le cordon spiralé du combiné.
- Ouvrir le couvercle du compartiment des piles en faisant
pivoter le verrou. Insérer 4 piles alcalines (type AA 1,5V non
fournies) dans le compartiment (*). Les piles permettent
d'augmenter le volume de la sonnerie jusqu'à 10 dB et
d'utiliser la sonnerie de type "mécanique".
Remettre en place le couvercle du compartiment des piles et
faire pivoter le verrou pour le bloquer.
- Brancher le cordon de ligne à la prise correspondante à
l'arrière de l'appareil (*).
- Branchez l'autre extrémité du cordon à la prise téléphonique
murale (*).
2 - Réglage du volume de la sonnerie
Un interrupteur situé en dessous de l'appareil permet de régler la
sonnerie sur quatre positions:
: Coupée
: Faible
: Forte
: MAXI
Remarque: Le volume de la sonnerie augmente de 10 dB si vous
insérez des piles dans l'appareil. La sonnerie sera à ce moment là
une sonnerie mécanique et non plus électronique.
MISE EN SERVICE
(*) Classée TRT-3 selon la norme EN60950

18
3 –Numérotation automatique
Si l’interrupteur de numérotation automatique est sur Marche ( ),
le téléphone compose automatiquement le numéro enregistré dans
la mémoire 'SOS' dès que vous décrochez le combiné (si vous
n'appuyez sur aucune autre touche dans un délai de 4 secondes).
Réglez cet interrupteur sur la position adaptée à votre utilisation.
4 –Raccrochage Automatique
Si l’interrupteur de raccrochage automatique est en position marche
( ), le téléphone raccrochera automatiquement (coupure de la ligne
téléphonique) dès que le correspondant raccrochera de son côté,
même si vous ne reposez pas le combiné sur le berceau de l'appareil.
Si vous recevez un appel alors que le combiné n'a pas été reposé sur
le berceau de l'appareil, le téléphone sonnera tout de même comme à
l'ordinaire. Pour prendre l'appel, prenez le combiné en main. Ensuite,
appuyez une fois sur le bouton de coupure de ligne et relâchez-le.
MISE EN SERVICE

19
1 –Réglage du volume et de la tonalité de
réception
Vous pouvez augmenter le volume d’écoute et adapter la tonalité à
votre audition.
Le bouton (interrupteur marche/arrêt d'amplification) permet
d'activer d'autres fonctions affectant la réception et la tonalité en
cours de conversation.
Si l'interrupteur est en position Marche ( ), le voyant rouge situé
près de la touche de 'Rappel du dernier numéro composé / rappel
du dernier appelant' s'allume.
Réglez les curseurs de TONALITÉ et de VOLUME pour adapter le
son à votre audition :
TONALITÉ
Graves
Aigus
RÉGLER LE VOLUME ET LA TONALITÉ
