Geemarc CL210A User manual

CL210A
TELEPHONE & ANSWERING
MACHINE

CONTENTS 1
INTRODUCTION 3
Unpacking the Telephone 4
DESCRIPTION 5
General Description 5
INSTALLATION 7
Setting Up 7
Wall Mounting 7
SETTINGS 8
Ringer Volume Settings 8
Notification of Incoming Call Settings 8
Receiving Volume and Tone Settings 9
Dialling Mode (Tone/Pulse) Setting 11
USING THE TELEPHONE 12
Making a Call 12
Making a Call – Hands Free 12
Receiving a Call 13
Receiving a Call – Hands Free 13
Last Number Redial 13
R Button on Private Branch Exchanges 13
Headset Use 13
OPTIONAL ACCESSORIES 14
Shaker 14
QUICK DIAL 15
Create a Quick Dial Number 15
Dial a Quick Dial Number 15
ANSWERING MACHINE 16
Switching the Answering Machine On/Off 16
The Outgoing Message 16
Recording an Outgoing Message 17
Checking an Outgoing Message 17
Answering Machine Settings 18
Listening to Messages 19
Delete an Incoming Message 20
Call Screening 20
Operating the Answering Machine Remotely 20
Remote Code 20
Remote Control 21
Remote Control Commands 21
Recording a Memo 22
Recording a Telephone Call 22
Room Monitoring 23
Remotely Activate the Answering Machine 23
Out of Memory 23
TROUBLESHOOTIING 24
SAFETY INFORMATION 25
GUARANTEE 26
RECYCLING DIRECTIVES 28
CONTENTS
2
1
CONTENTS

Congratulations on purchasing your Geemarc CL210A telephone. This is
a multifunction telephone which offers features such as hands free use,
quick dial and an answering machine.
It is important that you read the instructions below in order to use your
Geemarc telephone to its full potential. Keep this user guide in a safe
place for future reference.
This guide explains how to use the following telephone:
CL210A
Unpacking the Telephone
When unpacking the telephone, you should find the following in the box:
•1 CL210A unit
•1 CL210A handset with curly cord
•1 Mains power adaptor
•1 Telephone line cord
•1 User Guide
For product support and help visit our website at www.geemarc.com
Telephone [phone]
Or fax [phone]
INTRODUCTION
4
INTRODUCTION
3

General Description
Rear
Base
DESCRIPTION
6
5
Amplify
R button (for private
exchanges)
Handset
Last Number
Redial/Insert
pause
Hands free
Memory setting
and Quick Dial
locations, M1,
M2 and M3
Delete
messages
Message
indicator
Play messages
Answer
machine
On/Off
Handset volume
slide control
Call
notification
settings
Ringer
volume
settings
Answer
machine
settings
Buttons to
operate answer
machine (under
flap)
Speaker volume
slide control
Handset tone
slide control
DESCRIPTION
Telephone
line socket
Flash
setting
Amplify
default
setting
Dialing
mode
setting
Headset
jack
Shaker
jack
Power
socket
Thread the line cord
through this groove

Setting Up
Connect one end of the curly cord to the handset. The other end of the
curly cord plugs into the socket on the left hand side of the CL210A unit.
Place the handset on the cradle.
Connect the line cord to the socket located at rear of telephone and
then thread it through the groove toward the back of the unit. Connect the
plug at the other end of the line cord into the wall socket (**).
Connect the power supply to the socket located at rear of the telephone
then plug into a 13amp wall socket (*). Please choose a socket near your
telephone to enable you to unplug the mains power quickly in case of a
problem.
Wall Mounting
If you mount the telephone to the wall, you can hang the receiver on the
telephone without hanging up. You will find a small hook for this purpose
at the upper end of the receiver rest.
1. Install 2 screws with anchors into the wall. These should be one above
the other, 83mm apart, and extending 5mm out from the wall to hold the
telephone base securely.
2. Install the long telephone line cord into the jack in the base. Thread it
through the groove and plug it into modular wall socket (**).
3. Hang the base on the screws and pull it down to lock it on.
4. Connect one end of the curly cord to the handset. The other end of the
curly cord plugs into the socket on the left hand side of the CL210A unit
5. Turn the receiver hook 180 degrees so that the receiver can be placed
on-hook.
(*) Classified “hazardous voltage” according to EN60950 standard
(**) Classified TNV-3 according to EN60950 standard.
Ringer Volume Setting
A switch located on the right side of the CL210A allows the ringer to be
switched to HI, LOW or OFF.
Notification of Incoming Calls Settings
A 3 position switch located on the right side of the CL210A allows for the
following types of notification to be selected.
INSTALLATION
SETTINGS
The ringer is
activated
The ringer and shaker are
activated (shaker
needs to be connected – not supplied)
The ringer and strobe are
ac
tivated
7
8

Receiving Volume and Tone Settings
You can alter the receiving volume and tone during a conversation
according to your hearing requirements.
Use the Volume slide control on the front edge of the telephone base to
adjust the level.
The button on the telephone base provides additional amplification
(a further 40dB). When the amplify function is activated, the red light on
the key is lit.
Setting a default for Amplification.
A switch ON/OFF located at the rear allows the amplification facility
to be switched ON or OFF as a default each time you use the telephone.
ON/OFF Switch at ON Position
The additional amplification and tone controls are automatically activated
each time you use the telephone. The LED light next to the amplify button
will be lit.
Pressing the Amplify button during a call will turn off the additional
amplification and tone controls. However, you can still adjust the handset
receive volume with the Volume slide bar.
Irrespective of how many times you press the amplify key throughout a
call, the next time you pick up the handset to make a new call, these
functions will be activated once again.
ON/OFF Switch at OFF Position
The additional amplification and tone controls are turned off each time you
use the telephone. The LED light next to the amplify button will be off.
Pressing the Amplify button once during a call will enable tone control and
additional amplification. The LED light next to the amplify button will turn
on to reflect this change. If you press the amplify button once more, the
additional amplification and tone control features will be turned off once
again. The LED light will turn off to reflect this change.
Irrespective of how many times you press the amplify key throughout a
call, the next time you pick up the handset, these functions will be turned
off once again.
Tone Receiving Adjustment
If the receiver volume has been amplified, the tone control can also be
adjusted. You can adjust and increase the low frequency or high
frequency sounds with the tone slide control on the front edge of the unit.
Note: The tone adjustment function will not be affective when the receiver
volume is set to normal level.
12
SETTINGS
10
SETTINGS
9
8
10

Dialling Mode (Tone/Pulse) Setting
The Tone/Pulse switch is factory pre-set to Tone position (T). In the UK,
all telephone exchanges now use Tone dialing. If your telephone does not
dial out, it is probably being used from an older private switch- board
(PBX). In this case, the Tone/Pulse switch (at rear of the unit) must be
moved to Pulse.
Making a Call
Pick up the handset.
When you hear the dialling tone, dial the number on the keypad.
To end the call simply replace the handset in the cradle
Making a Call – Hands Free
Press . The hands free function will be activated,
Dial the required telephone number. To adjust the volume, use the
volume control VOL located on the right side of the telephone
When the third party answers the call, you may speak with the
telephone in the hands free mode ( handset in the cradle). Speak
towards the microphone located on the front edge of the telephone.
To end the call, press
Note: To deactivate the Hands Free function during a call, lift the handset.
To activate the Hands Free function during the call, press and
replace the handset on the cradle at the same time.
Also, when in hands free mode, only one person may talk at a time. The
switch-over between speaker and microphone is automatic. This is
dependent on the sound level of the incoming call and the microphone
respectively. It is therefore essential that there are no loud noises, e.g.
music, in the immediate vicinity of the telephone, as this will disrupt the
hands free function.
SETTINGS
USING THE TELEPHONE
11
12

Receiving a Call
Lift the handset and speak
To end the call simply replace the handset in the cradle
Receiving a call – Hands Free
Press to speak hands free
To end the call press
Last Number Redial
Lift the handset and press to redial the last number (up to 32 digits).
R Button on Private Branch Exchanges
If the telephone is connected to a private branch exchange, functions such
as transferring calls and automatic call back can be used via the R button.
Please refer to the operating manual supplied with your private branch
exchange to determine whether the telephone will work correctly with the
exchange.
Note: You can select the flash time 100/300ms by using the flash switch
on the rear of the unit.
Headset Use
A headset can be connected at the rear side of the base in the 2.5mm jack
.
Press to get a dial tone.
Note: When using the headset the call is not amplified
Shaker
At the back of the phone, there is a 3.5mm shaker jack marked . You
can connect an optional shaker device. When you are receiving an
incoming call, the shaker will vibrate.
USING THE TELEPHONE
14
13
14
OPTIONAL ACCESSORIES

This telephone has 3 quick dial memory buttons.
Once a number has been stored in a memory location, you only need to
press one button to make the call.
Create a Quick Dial Number
Lift the handset
Press
Enter the telephone number to be stored (maximum of 16 digits)
Press again
Select the quick dial location to store the telephone number (M1, M2
or M3) by pressing the corresponding button
Replace the handset
NOTE: Press if you need to insert a pause in the telephone number
Dial a Quick Dial Number
Lift the handset and wait for a dial tone
Press the quick dial location required (M1, M2 or M3)
The stored telephone number will now be dialed
Switching the Answering Machine On/Off
The answering machine can be switched on and off by using the
button. When switched to ON position, incoming calls will be answered by
the answering machine after a certain number of rings (see Answering
Machine Settings). When the answering machine answers an incoming
call, the caller will hear your outgoing message. After a short beep they
can then leave a message of up to 2 minutes. Should the caller exceed
this limit, the call will be disconnected. If the caller stops speaking for
longer than 7 seconds during the 2 minutes, the answering machine will
disconnect.
The memory will store approximately 14 minutes of incoming messages
(including the outgoing message).
NOTE: IF THE ANSWERING MACHINE IS OFF, NO CALLS WILL BE
ANSWERED AND 2 BARS WILL BE DISPLAYED
Also, if the Answering Machine is OFF, it will answer a call after 10 rings.
This is to allow some features to be accessed remotely.
Your CL210A answering machine can be operated from either:
•the telephone unit
•remotely from any external telephone.
Outgoing Message
Before you use the answering machine you should record an outgoing
message. The outgoing message is your message to an incoming caller
and may be up to 60 seconds in length.
You may want the message to tell the caller that they may start speaking
once the beep is heard.
NOTE: If no outgoing message has been recorded the display will flash
and no messages can be left.
QUICK DIAL
ANSWERING MACHINE
15
16

Recording an Outgoing Message
Press and hold . You will hear a short beep and the display will
show rA
Record your outgoing message. Speak clearly towards the machine
from a distance of 6-8 inches (minimum of 5 seconds and
maximumof 60 seconds)
Release to stop recording
The outgoing message will be repeated after a few seconds. Repeat
this procedure if you want to change the message, any old outgoing
message will automatically be erased when a new one is recorded.
Checking the Outgoing Message
Press . The current outgoing message will now be played.
To stop playing the outgoing message, press on the answering
machine.
Answering Machine Settings
Use the 2\ 6 \TS switch on the right side of the telephone to select the
number of rings before the answering machine is activated and responds
to an incoming call.
• 2 = calls are answered after two rings
• 6 = calls are answered after six rings
• TS (TOLL SAVER) = activates the toll saver function
In Toll Saver mode incoming calls are answered after six rings until the
first new message has been recorded. Once a message has been
recorded the answering machine will answer after approximately two rings.
This is useful when trying to remotely access the answering machine. If
the answering machine has not answered at the fourth ring, no
messages have been recorded and you can hang up before you are
charged for the call. If the machine answers after two rings, new
messages have been recorded.
ANSWERING MACHINE
ANSWERING MACHINE
17
18

Listening to Messages
The display flashes to show how many new messages have been
received. If no new messages have been received the display shows total
messages (old).
Playback will always begin with any new messages. For example if there
are three old messages and two new ones, only the two new ones will be
played back, then the answering machine will return to standby mode.
Press the play button once again to listen to all messages, starting with the
oldest messages.
Press / to start playback.
If you want to pause during playback of a message press and the
message will pause (max. 7 seconds).
Press again to resume playback.
When playback is finished you will hear two short beeps, and the machine
will return to standby mode. All incoming messages are saved (unless you
have erased any during playback, see below), new messages will then be
recorded after the old ones.
Other Functions available during Playback
Skip to next message
Repeats the current message, or hold down until you hear
a beep to step back through the messages
ON/OFF Stop playback
C Erase messages
Playback through handset receiver (+40dB volume)
To playback your messages through the handset, pick-up the handset and
press . You can now you can press to boost the message
volume to 40dB
Delete Incoming Messages
If you want to delete a single incoming message press Cwhile the
message is playing.
To erase all messages after playback, press and hold Cuntil a beep is
heard.
Please note that new messages cannot be deleted until they have been
played.
Call Screening
Incoming messages can be heard through the Speakerphone as they are
received. If there is no sound adjust the volume using the control on the
right hand side of the telephone.
If you want to speak to the caller, lift the handset. If the recording does not
stop automatically, press on the answering machine, or press * (for 2
seconds) on the telephone.
Operating the Answering Machine Remotely
This answering machine can be accessed remotely using the keys of an
ordinary tone dialing telephone. Call the answering machine (using your
telephone number) and enter the remote code while the outgoing message
is playing. Once the code is accepted, several remote control commands
are available.
Remote Code
A confidential three digit code is required to activate/deactivate the
answering machine or listen to your messages from a remote external
telephone. The remote code is printed on the base of the machine.
ANSWERING MACHINE
ANSWERING MACHINE
19
20

Remote Control
Call the answering machine (using your telephone number)
While the outgoing message is playing, enter the remote code. If the
code is accepted you will hear two beeps
Select a remote control command (within 20 seconds) from the list
below
When you have finished accessing the machine replace the
handset.
Remote Control Commands
Command Functions
25 Play new messages
2# Stop playback
During Playback
3# Erase single message during playback
6# Skip to previous message
7# Skip to next message
8# Repeat message
## Stop playback
After Playback
3# Erase all messages
7# Record a new outgoing message, to stop
recording press 7# again
8# Record a MEMO, to stop recording press
8# again
9# Turn the answering machine either On or
Off. Three beeps indicate Off- Two beeps
indicate On
0# Room monitor, press 5# to stop the room
monitoring
When you remotely listen to messages for longer than 2 minutes and
30 seconds, you will hear a tone and you then need to press any key
on your telephone to continue the playback of the messages.
Recording a Memo
You can leave a memo for other answering machine users
Press and hold for 2 seconds
The message rE will be displayed
Start to record your memo after the beep
To end recording, simply release
The message can be played by pressing of the answering
machine or via the remote access function using a normal telephone.
Recording a Telephone Call
You can record a complete conversation i.e. what both you and the caller
say. If any other answering machine function is in progress, press
before beginning to record a call
Lift the handset to take the call
Press once during the call
The message 2r will be displayed. The answering machine then
records the telephone call
To end recording, press
Press to playback the recorded call.
Note: Do not forget to manually end recording otherwise,
the answering machine will continue to record until memory full
ANSWERING MACHINE
ANSWERING MACHINE
22

Room Monitoring
This remote access feature enables you to call your home and turn ON the
answering machine’s microphone function. This means you can monitor
sounds in the room where the answering machine is situated for up to 30
seconds.
Remotely Activate Answering Machine
If you forget to switch on your answering machine on going out, you can
switch it on remotely via another telephone.
Dial your telephone number from the remote telephone and let it ring.
After approximately 10 rings, the machine will answer and emit a long
tone
Enter the remote code, printed on the base of the unit. If the code is
accepted, you will hear two short beeps
Press 9#. You will hear two beeps. This confirms that the
answering machine is now on.
Hang up your telephone
Out of Memory
The total capacity of the answering machine’s memory is approximately 14
minutes. The memory space is shared between the outgoing message,
personal memos, and regular incoming messages. When the memory is
full the display will show FL. The answering machine will answer after
10 rings to allow remote playback and deletion of messages, no new
messages will be accepted until the existing messages have been played
and erased.
No display
•Make sure that the power adaptor is plugged in correctly and is not
damaged
CL210A does not ring
•Make sure that the telephone line cord is plugged in correctly and
is not damaged
•Connect another telephone to the telephone PTT socket or move
your telephone to another socket to track if the failure is coming
from your telephone or your PTT socket
•There may be too many communication devices connected to a
single telephone line e.g. another telephone, modem or facsimile
machine. Contact your network provider for help in calculating the
limit for your home or business line
•Check the ringer Volume setting is not switched to OFF
No dial tone
•Make sure that the telephone line cord is plugged in correctly and
is not damaged
•Connect another telephone to the telephone PTT socket or move
your telephone to another socket to track if the failure is coming
from your telephone or your PTT socket
•There may be too many communication devices connected to a
single telephone line e.g. another telephone, modem or facsimile
machine. Contact your network provider for help in calculating the
limit for your home or business line
No response on LCD display
•Check for a power cut in the area.
TROUBLESHOOTING
ANSWERING MACHINE
21
24

General
Only use the power supply included with the product.
Do not open the unit. Contact the helpline for all repairs.
Cleaning
Clean the telephone with a soft cloth. Never use polishes or cleaning
agents - they could damage the finish or the electrics inside.
Environmental
Do not expose to direct sunlight.
Always ensure there is a free flow of air over the surfaces of the
telephone.
Do not place any part of your product in water and do not use it in damp or
humid conditions e.g. bathrooms.
Do not expose your product to fire or other hazardous conditions.
Unplug your phone from the telephone socket during thunderstorms
because it could damage your telephone. Your guarantee does not cover
thunderstorm damage.
The telephone is designed for working within a temperature range of 5°C
to 45°C.
From the moment your Geemarc product is purchased, Geemarc
guarantee it for the period of one year. During this time, all repairs or
replacements (at our discretion) are free of charge. Should you experience
a problem then contact our help line or visit our website at
www.geemarc.com. The guarantee does not cover accidents, negligence
or breakages to any parts. The product must not be tampered with or
taken apart by anyone who is not an authorized Geemarc representative.
The Geemarc guarantee in no way limits your legal rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR GUARANTEE AND
MUST BE RETAINED AND PRODUCED IN THE EVENT OF A
WARRANTY CLAIM.
DECLARATION: Geemarc Telecom SA hereby declares that this product
is in compliance with the essential requirements and other relevant
provisions of the Radio and Telecommunications Terminal Equipment
Directive 1999/5/EEC and in particular article 3 section 1a, 1b and section
3. The telephone does not operate if the line current is lower than 18 mA.
Please note: The guarantee applies to
the United Kingdom only
SAFETY INFORMATION
GUARANTEE
26
23
25

Electrical connection: The apparatus is designed to operate from a 230V
50Hz supply only. (Classified as ‘hazardous voltage’ according to
EN60950 standard). The apparatus does not incorporate an integral
power on/off switch. To disconnect the power, either switch off supply at
the mains power socket or unplug the AC adaptor. When installing the
apparatus, ensure that the mains power socket is readily accessible.
Telephone connection: Voltages present on the telecommunication
network are classified TNV-3 (Telecommunication Network Voltage)
according to the EN60950 standard.
The WEEE (Waste Electrical and Electronic Equipment) has been put in
place for the products at the end of their useful life are recycled in the best
way.
When this product is finished with, please do not put it in your domestic
waste bin.
Please use one of the following disposal options:
- Remove the batteries and deposit them in an appropriate WEEE skip.
Deposit the product in an appropriate WEEE skip.
- Or, hand the old product to the retailer. If you purchase a new one, they
should accept it.
Thus if you respect these instructions you ensure human health and
environmental protection.
For product support and help visit our website at www.geemarc.com
Telephone [phone]
Or fax [phone]
UGCL210A.v01
GUARANTEE
28
RECYCLING DIRECTIVES
27
