Geemarc Clearsound CL600 User manual

Telephone
CC
CC
C
L600L600
L600L600
L600
ATTENTION:CE TELEPHONE PEUT ETRE DESTINEAUX PERSONNESAYANT DES PROBLEMES D’AUDITION. IL
POSSEDE UN ECOUTEUR A VOLUME VARIABLE. A LA PREMIERE UTILISATION, ASSUREZ VOUS QUE LE BOUTON
DE REGLAGE DU VOLUME SOIT POSITIONNE SUR LA POSITION VOLUME MINIMUM. LES PERSONNES
MALENTENDANTES POURRONT PAR LASUITE AUGMENTER LE VOLUME POUR L’ADAPTERA LEURAUDITION.
CAUTION:THIS TELEPHONE PRODUCTISSPECIFICALLYDESIGNED FOR PEOPLE WITH HEARING DIFFICULTIES
AND IS PROVIDED WITH A HANDSET EARPIECE VOLUME CONTROL FOR INDIVIDUAL REQUIREMENTS. DUE CARE
MUSTBETAKENBY ALLUSERSTHATTHEHANDSETEARPIECEVOLUMECONTROL IS SETTOTHE LOWESTLEVEL
ACCEPTABLE BYEACHRESPECTIVEUSER.CARE SHOULD THEREFORE BE EXERCISEDTOENSURE THATANYNEW
USERSARE FAMILIAR WITH THIS REQUIREMENT.
GB Noticed’utilisationp56
F
TELEPHONE MULTIFONCTIONS
Userguide:p2
MULTIFUNCTION TELEPHONE

DESCRIPTION
- General description 5
- LCD screen 7
- Screen display 8
INSTALLATION
- Connecting 9
- Wall mounting 11
SETTINGS
- Ringer settings 12
- Alarm and ringer settings 13
- Dialling mode (P/T) 13
- Choose the date / hour format 14
- Date and hour settings 15
- Set the language 16
- Screen contrast adjustment 17
- Auto-on hook 17
- DIM:X---->x 18
- Time break recall setting ”R” function 19
USING THE PHONE
- Answer a call 20
- Automatic “hands free” function 21
- Make a call 24
- Use the amplifier 26
INDEX
2

- Last number redial 26
- Recall one of the last 30 number dialled 27
- Delete one of the last 30 numbers dialled 27
- Mute button 28
- R, * and # keys 28
- Store a telephone number in memory 29
- Dialling stored numbers 30
- Use the headset (option) 30
- Use the neckloop (option) 31
- Use the shaker (option) 33
SENDING LEVEL SETTINGS 34
RECEIVING TONE AND VOLUME SETTINGS 35
SOS FUNCTION
- Set SOS number 37
- Record SOS message 38
- Play SOS message 40
- Use SOS function 40
- Remote control description 41
- Change the remote control battery 42
PHONE BOOK
- Create an entry 43
- Create an entry from the incoming call list 45
INDEX
3

- Delete a phone book entry 46
- Modify a phone book entry 46
- Make a call from a phone book entry 47
CID FEATURE
- Use the Incomming call list 48
- Recall a number from the CID list 50
- Delete a record from the CID list 51
- Delete all records from the CID list 52
- Call waiting 52
- Message waiting 54
GUARANTEE 55
For product support and help visit our website
at www.geemarc.com
telephone [phone]
or fax [phone]
INDEX
4

DESCRIPTION
1-GENERALDESCRIPTION
5
Prioritymemory
P1
Keytoactivate
toneandvolume
adjustment
function
Last numberredial
Flashingincomingcall
indicator(strobelight)
Direct memories
Handsfreedialling
andamplifier.
Mute
Headsetbutton
Timebreakrecall button
Handsfree
Microphone
Prioritymemory
P2 Prioritymemory
P3
SOSkey
Volume
reception
adjustment
On line LED
Stop SOS key
Memorystoring
key
Aerial
Stop
SOS
key
SOSkey
Tonereception
adjustment
Remotecontrol

DESCRIPTION
6
Ringerlevel
adjustment
Screentilt
Ringer/shaker/strobe
selectmode
Sendingvolume
adjustment
Cliptoturn
forwallmount
Speakervolume
adjustment
Handsetcord
Toneandvolumeadjustment
automaticallyactivated each
timeyouhang-upthephone
Speaker
Additional amplifier
button

2 - LCD SCREEN
Screenexample(Onhookposition)
- OK key is used to confirm action or a choice
on the screen.
- keysareusedtoscrollthroughthemenu.
-Ingeneral,theC keyisusedtocancelanaction/
entry, it can also be used to confirm a choice (for
exampleto cancela storednumber).
Hours
Minutes
Day
Month
Powernetworkicon
Cancelkey Up/down keys Validationkey
DESCRIPTION
7

3- SCREEN DISPLAY
Your CL600 has a screen with different icons
which help you to use the telephone.
Thetelephoneis supplied bybattery
+ battery indicator
Thetelephoneis suppliedbyadaptor
Memorystoringis required.
Screen contrast level.
“Mute” is activated.
Speaker is activated.
Precede the CID call record number.
To show new records.
8
DESCRIPTION
N

9
Line cord
socket*
Tone&volume
ON/OFFswitch
INSTALLATION
1-CONNECTING
- Connect the handset.
- Open the battery compartment ( remove the
screws ).
- Insert 4 alkaline batteries without mercury (AAA
1.5Vtype notsupplied) withgood polarityinto the
compartmentlocatedon thetelephonebase.
Note : Do not use a rechargable battery, do not
put the battery into the household rubbish. Pay
attention to the battery regulations regarding
battery disposal.
- Replace the battery cover.
Adaptor socket**
Only Geemarc
reference
(*) Classified TNV-3 according to EN60950 standard.
(**) Classified “hazardous voltage” according to EN60950 standard.
Important: Only Shaker, Neckloop, Headset and Adaptor with Geemarc
reference can be connected to the CL600 sockets.
Headsetsocket*
Only Geemarc reference
Neckloopsocket*
Only Geemarc
reference
Shakersocket*
Only Geemarc reference

-Connecttheadaptatorplugtotheadaptorsocket
locatedonthebackofthetelephonethenconnect
ittothewallsocket(**).Pleasechoose anadaptor
wall socket near your line plug to enable you to
unplugthe adaptor quicklyin case ofa problem.
If you wish to change the language see page 16.
Note:Theadaptorisrequiredforthetelephoneto
work correctly. Batteries are necessary in case of
network power failure to save stored numbers in
memory and are required for phone book use.
If the adaptor is accidentally unpluged (or in case
of power failure) and if the batteries are empty or
notinplace,minimalrestrictedphonefeaturesonly
will work on the phone (make a call or answer
incomingcall).
INSTALLATION
10

INSTALLATION
2 - WALLMOUNTING
Towall-mountyourtelephone,slideouttheclip,turn
around and slide back into the wall mounting
position.This will ensure that the handset stays
firmlyin position.
Make2holesinthewall80mmapart(usethewall
mounttemplate),insertthewallplugsandthewall
mountingscrews.
The screws should protrude from the wall by 6-7
mm. Place the phone onto the screw-heads and
slide down to secure.
INSTALLATION
80 mm
12345678
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
1
234567
8
12345678
Wallmounting
holes
7 mm
Screw
11

1-RINGERSETTINGS
A switch located on right side allows the ringer to
be switched HI,LOW,OFF:
: Off
: Low
: Hi
Your phone comes with the ringer switched to
«High».
You can choose the ringer melody as follow:
In on hook position,
- Press the key.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
- Select «SET RING»
- Press the OK key to confirm.
- Select the wanted ring.
- Press the OK key to confirm.
-Newring will beheard.
- Press the C key 3 times to exit.
SETTINGS
12

2 -ALARM AND RINGER SETTINGS
A3 positionswitchlocated onthe rightsideof the
phoneallows thesettings below:
-: Ringer and strobe flash are activated.
- : Ringer and shaker are activated.
- : Ringer, shaker and strobe flash are
activated.
3 - DIALLING MODE (T/P)
The Tone/Pulse is factory pre-set to Tone (T). In
the UK, all telephone exchanges now use Tone
dialling.Ifyourphonedoesnotdialout,itisprobably
being used from an older private switch-board
(PBX).Inthiscase,theTone/Pulsesettingmustbe
moved to Pulse (P).
In on hook position,
- Press the key.
-Usethe or keystoselect«SETPHONE».
SETTINGS
13

- Press the OK key to confirm.
- Select «TONE MODE OR PULSE MODE»
- Press the OK key to confirm.
- Press the C key 3 times to exit.
4-CHOOSETHE DATE/HOURFORMAT
Date format
You can choose between two formats:
Day - Month or Month - Day.
In on hook position,
- Press the key.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
- Select «DATE FORMAT».
- Press the OK key to confirm.
-Select«DAY-MONTH»or«MONTH-DAY».
- Press the OK key to confirm.
- Press the C key twice to exit.
Hour format
You can choose between two formats:
12 hours or 24 hours.
SETTINGS
14

In on hook position,
- Press the key.
Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
-Select«HOUR FORMAT».
- Press the OK key to confirm.
- Select «12 HOUR» or «24 HOUR».
- Press the OK key to confirm.
- Press the C key twice to exit.
Ifyouchoose«12HOUR»,hoursbeforenoonwill
be displayed with «AM» and «PM» for the hours
after noon.
5 - DATE AND HOUR SETTING
In on hook position,
- Press the key.
-Usethe or keystoselect «SET TIME».
- Press the OK key to confirm.
- Use the or keys to select the desired
digit.
-PresstheOK keytoconfirmandpasstothenext
digit.
SETTINGS
15

You will set the time like this:
HOURS- MINUTES-MONTH-DAY
- Press the C key to exit.
Note: When you receive your first call, all these
parameters will be set autoumatically if you have
the CID feature.
6 - SET THE LANGUAGE
You can choose between 16 different languages
includingEnglishandFrench.
To change the language ( ex: french to english)
follow the settings as below:
In on hook position,
- Press the key.
- Use the or keys to select «REG TEL».
- Press the OK key to confirm.
- Select « LANGAGE».
- Press the OK key to confirm.
- Select «English» (for example).
- Press the OK key to confirm.
- Press the C key twice to exit.
SETTINGS
16

7-SCREENCONTRASTADJUSTMENT
Your screen has a backlight which automatically
switches off after 15 seconds of inactivity.
Please see below to decrease or increase the
contrast:
In on hook position,
- Press the key.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
- Select «LCD CONTRAST».
- Press the OK key to confirm.
- Use the or keys to adjust the contrast
level.
- Press the C or the OK keys to exit.
8 -AUTO- ON HOOK
This function releases the line after 8 seconds if
the line is busy.
In on hook position,
SETTINGS
17

- Press the key.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
- Use the or keys to select «AUTO ON
HOOK».
- Press the OK key to confirm.
- Use the or keys to select «ON» or
« OFF» to activate or deactivate the function.
- Press the OK key to confirm.
- Press the C key twice to exit.
10 - DIM:X---->x
If the auto-screen sizing is activated, the screen
candisplay upto18 digitsof thenumberyou dial,
otherwise only 8 digits will be displayed on the
screen.
In on hook position,
- Press the key.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
SETTINGS
18

-Usethe or keystoselect«DIM:X---->x».
- Press the OK key to confirm.
- Use the or keys to select «ON» or «
OFF» to activate or deactivate the function.
- Press the OK key to confirm.
- Press the C key twice to exit.
11 - TIME BREAK RECALL SETTING “R”
FUNCTION
Yourphoneworkswitha timebreakrecallforUni-
tedKingdom(R=100ms).
If you wish to change this value, follow instruc-
tionsbelow:
In on hook position,
- Press the key.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
-Usethe or keystoselect«SETFLASH».
- Press the OK key to confirm.
- Select a new setting, 300 or 600ms and press
OK to confirm.
- Press the C key twice to exit.
SETTINGS
19

1 - ANSWER A CALL
When the phone rings, the Name/Number of the
caller will appear on the screen, if you have
subscribed to the CID service.
1st solution :
- Lift the handset and speak.
-Oncompletionofthecall,replacethehandsetin
the cradle to release the line.
2nd solution :
You can use the «hands free» function to speak
with your caller without lifting the handset.
-Press the keytospeakwithyourcallerhands
free.
- Press the key to release the line.
3rd option:
With your remote control unit, you can answer
withoutapproachingthetelephone.
- When your phone rings, press the key on
your remote control unit and the phone will be
USINGTHEPHONE
20
