Geemarc CL1400 User manual

Telephone
CL1400
ATTENTION:CE TELEPHONE PEUT ETRE DESTINEAUX PERSONNESAYANT DES PROBLEMES D’AUDITION. IL
POSSEDE UN ECOUTEUR A VOLUME VARIABLE. A LA PREMIERE UTILISATION, ASSUREZ VOUS QUE LE BOUTON
DE REGLAGE DU VOLUME SOIT POSITIONNE SUR LA POSITION VOLUME MINIMUM. LES PERSONNES
MALENTENDANTES POURRONT PAR LASUITEAUGMENTER LE VOLUME POUR L’ADAPTERALEURAUDITION.
CAUTION:THIS TELEPHONE PRODUCTIS SPECIFICALLYDESIGNED FOR PEOPLE WITH HEARING DIFFICULTIES
AND IS PROVIDED WITH A HANDSET EARPIECE VOLUME CONTROL FOR INDIVIDUAL REQUIREMENTS. DUE CARE
MUSTBETAKENBY ALLUSERSTHATTHE HANDSET EARPIECE VOLUMECONTROL IS SETTOTHE LOWESTLEVEL
ACCEPTABLE BYEACH RESPECTIVE USER.CARESHOULD THEREFORE BE EXERCISEDTOENSURE THATANYNEW
USERSARE FAMILIAR WITHTHIS REQUIREMENT.
GB
Noticed’utilisationp.47
F
TELEPHONE MULTIFONCTIONS
Userguidep.2
AMPLIFIED DESK TELEPHONE WITH
CALLER IDENTIFICATION

DESCRIPTION
- General description 4
- LCD screen 6
- Screen display 7
INSTALLATION
- Connecting 8
SETTINGS
- Ringer level adjustment 10
- Shaker option setting 11
- Date / Hour format 11
- Time & date setting 13
- Set the language 14
- Screen contrast adjustment 16
- Auto-on-hook 16
- Auto-screen sizing 17
- Area and Long distance code 18
- Time break recall - “R” 19
- Dialing types and grounding 20
USING THE PHONE
- Answering a call 21
- Making a call 22
- Last number redial 23
- Recall last 30 number dialled 24
INDEX
2

INDEX
3
- Delete last 30 numbers dialled 24
- R, * and # keys 25
- Storing a number in memory 26
- Dialling stored numbers 26
RECEIVING VOLUME AND TONE 27
PHONE BOOK
- Creating a phone book entry 29
- Create an entry from the incoming call list 31
- Delete a phone book entry 32
- Modify a phone book entry 32
- Make a call from a phone book entry 33
ADVANCED FUNCTIONS
- Use the incoming call list 34
- Recall a number from the CID list 37
- Delete a record from the CID list 38
- Delete all records from the CID list 38
- Call waiting 39
- Message waiting 41
OPTIONS
- Headset and neck loop 42
- Shaker 43
GUARANTEE 44

DESCRIPTION
4
1-DESCRIPTIFGENERAL
Extravolume&
voneactivation
Lastnumberredial
Flashing
incomingcall
indicator Message waiting /
newcall LED
Handsfreemicrophone
Direct
memories
Phonebook
Up/ Down
scroll
Delete/
Cancel Validation
Headsetor
Neck loop
LCD screen
Timebreak recall
Handsfree/
Speakerphone

DESCRIPTION
5
Speaker
Handsetcord
Reception volume
adjustment Receptiontone
adjustment
Speaker volumeadjustment

DESCRIPTION
Hours
Minutes
Day
Month
Powernetworkicon
Cancelkey Up/downkeys Validation key
Receivedcalls
record
2 - LCD SCREEN
Screenexample(Onhookposition)
- OK key is used to confirm action or a choice on
the screen.
-keys are used to scroll through the menu.
-Ingeneral,theX keyisusedtocancelanaction/
entry, it can also be used to confirm a choice (for
exampletocancel astorednumber).
6

DESCRIPTION
N
3- SCREEN DISPLAY
Your CL1400 shows on the LCD screen different
icons to help you using the telephone.
Thetelephone is supplied bybattery
+ battery indicator
Thetelephoneissuppliedbyadaptor
Screen contrast level.
Speaker is activated.
Precede the CID call record number.
To show new records.
7

INSTALLATION
CONNECTING
Important: Only Shaker, Headset and Adaptor with Geemarc reference
can be connected to the sockets.
- Connect the handset.
-Openthebatterycompartment.
- Insert 4 alcaline batteries without mercury (AAA
1.5Vtypenot supplied)with goodpolarityinto the
compartmentlocatedonthetelephonebase.
Note: Donotuserechargablebatteries,donotdo
notdisposebatteriesinhouseholdwaste.Pay at-
tention to your local battery disposal regulations.
Linecord
socket*
Adaptor socket**
Only Geemarc
reference
Headset / Neck loop
socket*
Only Geemarc reference
Shaker socket*
Only Geemarc reference
Tone / Pulse /
Groudingswitch
Ringerlevel
adjustment switch
Volume&Tone
adjustment
ON/OFF switch
ShakerON/OFF
switch
(*) Classified TNV-3 according to EN60950 standard. (**) Classified “hazardous voltage” according to EN60950 standard.
8

INSTALLATION
- Replace the battery cover.
-Connectthelinecordtothesocketlocatedatthe
rear of telephone, then connect the plug to the
wallsocket(*).
-Connecttheadaptatorplugtotheadaptorsocket
located on the back of the telephone, then con-
nect it to the wall socket (**). Please choose an
adaptor wall socket near your line plug to enable
youtounplugtheadaptorquicklyincaseofaprob-
lem.
Note: The adaptor is required to make the tele-
phone work properly. Batteries are necessary in
case of network power failure to save a stored
numberinmemoryandarerequiredforphonebook
use.
Iftheadaptorisaccidentallyunplugged(orincase
of power failure) and if the batteries are empty or
notinplace,minimalrestrictedphonefeaturesonly
will work (such as making a call or answering an
incomingcall).
9

SETTINGS
1- RINGERLEVELADJUSTMENT
You can change the ringer volume to a desired
level.Ringer level adjustmentswitch located on
the upper side allows the ringer to be switched
HI, LOW or OFF:
: Hi
: Low
: Off
Your phone comes with the ringer switched to
«High».
If you don’t like the ringer melody, you can
choose a new one by changing the settings as
follows:
In on hook position,
- Press and hold OK and keys together.
- Use the keys to select «SET PHONE».
- Press the OK key to confirm.
- Select «SET RING»
- Press the OK key to confirm.
- Select the ring you would like.
- Press the OK key to confirm.
-New ring will beheard.
- Press the X key 3 times to exit.
10

SETTINGS
2- SHAKEROPTION SETTING
A two-position switch located on the upper side
allows to activate (ON) or deactivate (OFF) the
shakerCLA2(notincluded).
Formoreinformationonthisoptionpleasereferto
p.43.
3- CHOOSINGDATE/ HOUR FORMAT
Date format
You can choose between two date formats:
Day - Month or Month - Day.
In on hook position,
- Press and hold OK and keys together.
- Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
- Select «DATE FORMAT».
- Press the OK key to confirm.
-Select«DAY-MONTH»or«MONTH-DAY».
- Press the OK key to confirm.
- Press the X key twice to exit.
11

SETTINGS
Hour format
You can choose between two hour formats:
12 hours or 24 hours.
In on hook position,
- Press and hold OK and keys together.
-Usethe or keystoselect«SETPHONE».
- Press the OK key to confirm.
-Select«HOUR FORMAT».
- Press the OK key to confirm.
- Select «12 HOUR» or «24 HOUR».
- Press the OK key to confirm.
- Press the X key twice to exit.
Ifyouchoose«12HOUR»,hoursbeforenoonwill
be displayed with «AM» and «PM» for the hours
after noon.
12

SETTINGS
4 - TIME & DATE SETTING
In on hook position,
- Press and hold OK and keys together.
- Use the or keys to select «SET TIME».
- Press the OK key to confirm.
-Select«HOUR FORMAT».
- Press the OK key to confirm.
- Use the or keys to select the correct
hour.
-Press the OK key toconfirm the Hour andmove
to Minutes setting.
- Use the or keys to select the correct
minute.
- When the time is set press OK to pass to Month
and Day setting.
- Press the X key to exit.
Note: When you receive your first call, date and
timewillbesetautoumaticallyifyouhavetheCID
feature.
13

5 - SET THE LANGUAGE
You can choose between 16 different languages
includingEnglishandFrench.
To change the language, follow the instructions
below:
In on hook position,
- Press and hold OK and keys together.
-Usethe or keystoselect«SETPHONE».
- Press OK key to confirm.
- Use the or keys to select «SET
LANGUAGE».
- Press OK key to confirm.
- Select the desirable language using keys.
- Press the OK key to confirm.
- Press X key twice to exit.
SETTINGS
14

SETTINGS
6- SCREENCONTRASTADJUSTMENT
Your screen has a backlight which automatically
switches off after 15 seconds of inactivity.
Follow the instructions below to set the screen
contrast:
In on hook position,
- Press and hold OK and keys together.
- Use the keys to select «SET PHONE».
- Press the OK key to confirm.
- Select «LCD CONTRAST».
- Press the OK key to confirm.
-Scrollwith keystoadjustthecontrastlevel.
- Press the X key to exit.
16

7 -AUTO- ON HOOK
This function automatically cancels the line after
8 seconds if the line is busy.
In on hook position,
- Press and hold OK and keys together.
- Use the keys to select «SET PHONE».
- Press the OK key to confirm.
-Usethe keystoselect«AUTOONHOOK».
- Press the OK key to confirm.
- Use the keys to select «ON» or « OFF» to
activate or deactivate the function.
- Press the OK key to confirm.
- Press the X key twice to exit.
SETTINGS
16

SETTINGS
8-AUTO-SCREENSIZING
If the auto-screen sizing is activated, the screen
candisplay upto 18digits ofthenumber youdial,
otherwise only 8 digits will be displayed on the
screen.
To activate/deactivate the auto-screen sizing
follow the instructions below:
In on hook position,
- Press and hold OK and keys together.
- Use the keys to select «SET PHONE».
- Press the OK key to confirm.
- Use the keys to select «DIM:X---->x».
- Press the OK key to confirm.
- Use the keys to select «ON» or « OFF»
to activate or deactivate the function.
- Press the OK key to confirm.
- Press the X key twice to exit.
17

9 - AREA& LONG DISTANCE CODE SETTING
Yourtelephoneneedstodistinguishbetweenlocal
and long distance calls.
First of all you have to program your area code.
In on hook position,
- Press and hold the OK and keys together.
- Use the keys to select «SET PHONE».
- Press the OK key to confirm.
- Use the keys to select «SET
AREA&LDS».
- Press the OK key to confirm.
- Use the keys to select the correct area
code.
- Press the OK key to move from digit to digit.
- When the area code is set, press the OK key
and this will lead you to LDS (long distance code)
setting.
- The LCD will show SET LDS CODE.
- Set the LDS code in the same manner as the
area code.
- Press the X key to exit.
SETTINGS
18

SETTINGS
10 - TIME BREAK RECALL SETTING - “R”
FUNCTION
Check the Time Break Recall setting of your
CL1400.FortheUKtheTimeBreakRecallshould
be set to 100 mS. Other settings - 300 mS and
600 mS are used outside the UK.
If you wish to change this value, follow instruc-
tionsbelow:
In on hook position,
- Press and hold OK and keys together.
- Use the keys to select «SET PHONE».
- Press the OK key to confirm.
- Use the keys to select «SET FLASH».
- Press the OK key to confirm.
- Select a new setting, 300 or 600ms and press
OK to confirm.
- Press the X key twice to exit.
19

11-DIALINGTYPESANDGROUNDING
A switch ETR/PR/T located on the upper side is
equiped on some models. If you wish to connect
your CL1400 to a public UK/French switch-board
(PBX), move switch ETR/PR/T to position 3 (T).
Thiswillensureoptimalcompatibilityofyourphone
with most (99%) PBX.
Positions: 1 2 3
Position 1:
Pulse dialing.The Ris grounded.This option can
be used only within the UK in very special cases.
Position 2:
Pulse dialing. The R is set according to the
determined adjustment (see «Time Break Recall
Setting for R Function» p.19).
Position 3:
Tone dialing. The R is set according to the
determined adjustment (see «Time Break Recall
Setting for R Function» p.19).
P T
ETR R
SETTINGS
20
