Genius MEDIA POINTER E540 User manual

Media Pointer E540
User’s Manual

ENGLISH
1
INDEX
1. Introduction……………………………………………...……………3
2. Features…………..…………………………………………………...4
3. Package contents………………………………………………...……5
4. System Requirements.....…………………………...…………………5
5. Mode Feature………….………….………………………………..…5
6. Installation and Operation……..…...………………………..…….….6
7. Light Signal………………………………………………….………20
8. Function Description………...……………….……………………...21
9. Functions in Microsoft® Office……….….………….……….……..24
10.Functions in OpenOffice………...........….…………..……….……..26
11.Troubleshooting………………………..…………….…..…….…….28

ENGLISH
2
!!! Attention!!!
Do not allow minors to use the laser pointer unsupervised. Laser
pointers are not toys.
Avoid direct eye exposure.
Never shine the laser pointer at anyone. The laser pointer is
designed to illustrate inanimate objects.
Do not point the laser pointer at mirror-like surfaces. A reflected
beam can act like a direct beam on the eye.

ENGLISH
3
Introduction:
This Presenter is more than an ordinary presenter. Its stylish shape
makes it more like an art piece to enhance your experience and
enjoyment.
RF wireless technology makes this Presenter transmit data up to 60 feet
(20 meters). Conveniently placed page up and page down buttons help
you page through slides effortlessly.
With its omni-directional feature, you can confidently conduct business
meetings, hold conference meetings, and give teaching lessons.
The Presentation hotkey is conveniently placed so you can open
PPT/PPS/PDF/OPD/ABW files. The Laser pointer keeps your audience’s
attention.

ENGLISH
4
Features:
1. Innovative design and omni-directional Presenter for delivering perfect
presentations
2. Simple pairing design
3. Presentation hotkey allows you to open PPT/PPS/PDF/OPD/ABW
files conveniently
4. Laser pointer helps you keep your audience’s attention.
5. Works with bundled software
6. User-friendly interface is easy to use

ENGLISH
5
Package contents: System Requirements:
Presenter
USB type RF Dongle
Value Software CD-ROM
CR2032 battery
Multi-language user’s
manual on CD
Microsoft®Windows®Win2000, XP,
Vista.
512MB RAM recommended.
CD-ROM drive or DVD-ROM drive.
USB Port; PC platform
Mode Feature:
11 button Presenter
Use Cypress wireless solution.
RX side conforms to USB Specification Version 2.0
RX side conforms to USB HID Specification Version 1.1
TX side supports one LED indicator
RX side supports one LED indicator
Supports Laser pointer function
Use DC 3V power operation: CR 2032
Receiver with USB Port is easy to connect with your computer
RX side supports one low speed USB device

ENGLISH
6
Installation and operation:
1. Separate presenter and receiver
Rotate the presenter and receiver
according to the arrow.
Pull receiver away from presenter.
Separate presenter and receiver.

ENGLISH
7
2. Installing the battery
Open the battery cover of the presenter and put in the coin type lithium
battery (CR2032).
3. Installing the receiver
Plug the receiver into the USB port of your computer with the golden
pins on top. The blue indicator on the Presenter will flash if you press a
key and the receiver is inserted in the correct direction.
4. Installing the CD-ROM
Insert the autorun CD-ROM and the “Media Pointer E540 Remote
Master” installation will start automatically.

ENGLISH
8
XP Installation

ENGLISH
9

ENGLISH
10

ENGLISH
11

ENGLISH
12
Vista Installation

ENGLISH
13

ENGLISH
14

ENGLISH
15

ENGLISH
16
After installation, “Media Pointer E540 Remote Master” icon will appear
in the system tray of Windows in the default setting. When the USB
dongle is plugged-in, it shows a green icon . Otherwise, it shows a
red icon . Always execute the Launch Manager first before you use
Presenter for a presentation.

ENGLISH
17
If you want to cancel the autorun setting of “Media Pointer E540 Remote
Master” in Windows startup, right-click on the “Media Pointer E540 -
Remote Master” icon in the system tray and switch to “Enable autorun on
startup” to “Disable autorun on startup”.
5. Other settings
5-1 Open the “Media Pointer E540 Remote Master” editor by
double-clicking on the icon of “Media Pointer E540 Remote Master”
in the system tray. Click “Browse” button to select the file that you
want to present (maximum three files), and press OK button. Or click
“Clear” button to reset the file link set previously.

ENGLISH
18
5-2 Right-click on the icon of “Media Pointer E540 Remote Master” in
the system tray, then you select these functions: “Open Editor”,
“Autorun on startup”, “Clock”, “Press Stop Button to Stop Timer”,
“Start Timer” and “Exit” operation.
6. Open your presentation file
Press to open the file(s) which you selected using the “Remote
Maser”. If you can open the file(s) successfully, the receiver and presenter
are paired.
Ps. If you select three files using “Media Pointer E540 Remote Master”,
pressing will open the three files at the same time.

ENGLISH
19
7. How to re-pair the presenter
If you cannot perform the previous step successfully, you need to
re-pair the presenter. Keep pressing and for about three
seconds and the blue indicator will flash. Then release the buttons
when you see the indicator flashing.
8. Operation without installing “Media Pointer E540 Remote
Master”
After installing the receiver, there are six buttons that work normally:
Laser Pointer
Page Up
Page Down
Start Presentation/Blank Screen (See “Function Description”
point 3)
Tap
Shut Down
