GeoVision GV-EBD Series User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual forfuture use. UBN-QG-D
Quick Start Guide
GV-IP Camera
GV-EBD Series
GV-ABL Series
GV-ADR Series
GV-AVD Series

© 2018 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part,
without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind
and assumes no responsibility for errors or omissions. No liability is assumed
for incidental or consequential damages arising from the use of the information
or products contained herein. Features and specifications are subject to
change without notice.
Note: No memory card slot or local storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the registered
trademark of Microsoft Corporation.
August 2018

i
Contents
Note for Installing Camera Outdoor ....................................................................... ii
Note for Powering the Camera ............................................................................... ii
1. GV-EBD Series .................................................................................................. 1
1.1 Packing List................................................................................................... 2
1.2 Overview ....................................................................................................... 3
1.2.1 GV-EBD2702 / 4700 .............................................................................................. 3
1.2.2 GV-EBD4711 / 8711 ............................................................................................... 4
1.3 Installation..................................................................................................... 5
1.3.1 GV-EBD2702 / 4700 Installation ............................................................................ 5
1.3.2 GV-EBD4711 / 8711 Installation............................................................................. 8
2. GV-ABL Series .................................................................................................11
2.1 Packing List................................................................................................. 12
2.2 Overview ..................................................................................................... 13
2.2.1 GV-ABL2701 Series / 4701 Series ...................................................................... 13
2.2.2 GV-ABL2702 / 4712 / 8712 .................................................................................. 14
2.3 Installation................................................................................................... 15
3. GV-ADR Series................................................................................................ 18
3.1 Packing List................................................................................................. 19
3.2 Overview ..................................................................................................... 20
3.3 Installation................................................................................................... 21
4. GV-AVD Series ................................................................................................ 24
4.1 Packing List................................................................................................. 25
4.2 Overview ..................................................................................................... 26
4.3 Installation................................................................................................... 27
5.Waterproofing the Cable ................................................................................ 29
6. Accessing the Camera ................................................................................... 31
6.1 System Requirements ................................................................................. 31
6.2 Looking Up the Dynamic IP Address ........................................................... 32
6.3 Configuring the IP Address.......................................................................... 34
7. The Web Interface........................................................................................... 35
8. Upgrading System Firmware ......................................................................... 37
9. Restoring to Factory Default.......................................................................... 38

ii
Note for Installing Camera Outdoor
When installing the camera outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from entering the
camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon
rubber or the like.
3. The screws are tightened and the cover is in place after opening the camera
cover.
Note for Powering the Camera
The Camera is powered by PoE. If you want to power the camera using the power
connector, an optional power adapter is required.

1
1. GV-EBD Series
Camera Type Model No.
GV-EBD2702 (IP67)
GV-EBD4700 (IP67)
GV-EBD4711 (IP67)
Eyeball IP Dome
GV-EBD8711 (IP67)

2
1.1 Packing List
H.265 Target Eyeball Dome
Screw x 3 Screw Anchor x 3
Drill Template Paster Waterproof Rubber Set
Download Guide Warranty Card

GV-EBD Series
3
1
1.2 Overview
1.2.1 GV-EBD2702 / 4700
No. Description
1 Bottom ring
2 Housing
3 Lens
4 Infrared indicator
5 Power connector (DC 12 V)
6 Ethernet connector / PoE

4
1.2.2 GV-EBD4711 / 8711
No. Description
1 Bottom ring
2 Housing
3 Microphone
4 Lens
5 Power connector (DC 12 V)
6 Ethernet connector / PoE
7 Micro SD card slot and default button compartment
8 Default button
9 Micro SD card slot
8

GV-EBD Series
5
1
1.3 Installation
The Target Eyeball Dome is designed for outdoors. With the standard package, you
can install the camera on the ceiling. Or you can purchase optional mounting
accessories to mount the dome on a wall.
Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount:
Concealed Installation and Open Installation. In Concealed Installation, the cables
are hidden in the ceiling. In Open Installation, the cables are led out from the open slot
on t he bottom ring.
1.3.1 GV-EBD2702 / 4700 Installation
For Concealed Installation
1. Stick the drill template paster to the ceiling and drill three holes according to the
drill template.
2. Insert the screw anchors.

6
3. Remove the bottom ring by turning it anticlockwise.
Bottom Ring
4. Connect the cables and secure the camera.
5. Adjust the monitoring direction.

GV-EBD Series
7
1
6. Mount the bottom ring.
For Open Installation
Lead the cables out from the open slot on the bottom ring before screwing the camera
to the ceiling as shown in step 4 of Conceal Installation.

8
1.3.2 GV-EBD4711 / 8711 Installation
For Concealed Installation
1. Stick the drill template paster to the ceiling and drill three holes according to the
drill template.
2. Insert the screw anchors.


GV-EBD Series
9
1
3. Loosen the fixing screw and remove the housing by turning it to the position as
shown.
4. Secure the bottom ring to the ceiling with 3 supplied screws and connect the
cable.
5. Mount the housing by adjusting to the position as shown and press and turn to
anywhere but .

10
6. Adjust the monitoring direction. Then tighten the screw.
For Open Installation
Lead the cables out from the open slot on the bottom ring before screwing the camera
to the ceiling as shown in step 5 of Concealed Installation.
Note: You can optionally purchase GV-Mount211 or GV-Mount212 for Wall Bracket
Mount. For details, see its User’s Manual.

11
Camera Type Model No.
GV-ABL2701 Series (IP66)
GV-ABL2702 (IP67 + IK10)
GV-ABL4701 Series (IP66)
GV-ABL4712 (IP67)
Bullet IP Camera
GV-ABL8712 (IP67 + IK10)
2. GV-ABL Series

12
2.1 Packing List
Bullet IP Camera Waterproof Rubber Set
Screw Kit Drill Template Paster
Download Guide Warranty Card

GV-ABL Series
13
2
2.2 Overview
2.2.1 GV-ABL2701 Series / 4701 Series
No. Description
1 Power connector (DC 12 V)
2 Ethernet connector / PoE

14
2.2.2 GV-ABL2702 / 4712 / 8712
1
2345
No. Description
1 Power connector (DC 12 V)
2 Audio input / Audio output / GND
3 Alarm input (IN, GND) / Alarm output (N,P)
4 Ethernet connector / PoE
5 Video Output (GV-ABL8712 Only)

GV-ABL Series
15
2
2.3 Installation
The Bullet IP Camera is designed for outdoors. With the standard package, you can
install the camera on the wall or ceiling. Or, you can purchase optional mounting
accessories to mount your camera on a wall.
Below are the instructions for Wall Mount. There are two kinds of Wall Mount:
Concealed Installation and Open Installation. In Concealed Installation, the cables
are hidden in the wall. In Open Installation, the cables are led out from the open slot
on the base.
For Concealed Installation
1. For GV-ABL2702 / 4712 / 8712, optionally loosen the two screws at the bottom
of the camera to insert a SD card.
2. Stick the drill template paster to the wall and align the cross center to the hole in
the wall.
3. Lead the cables across the hole on the wall.

16
4. Drill four 30-mm deep holes according to the drill template.
5. Insert the screw anchors.
6. Screw the locknut and loosen the universal joint before attaching the camera to
the wall.
