Ger Detect River G User manual

•Critical Warning
•Overview
•LONG RANGE SYSTEM
oDescription of the main unit keys
oAssembling the long-range system
oThe operating steps of the Long-Range System Device
•GEOPHYSICAL & 3D IMAGING SYSTEM
oDescription the main unit keys and inputs
oThe operating steps of the geophysical &3D system
oExplaining the search results system
•HOW TO AVOID DEVICE MISHANDLING AND MISUSE:
oFirst case
▪The solution of this case
oSecond case
▪The solution of this case
oThird case
▪The solution of this case
▪Explaining the result of the system on the 3D
program
•Printing report
•Important information and notes
•Warning
•Parts and accessories

- Please be sure that all precautions are taken against all risks.
- Do not use your device while it is raining or on extremely wet floor.
- Make sure that you are connecting properly the electric cables to the probes.
- You have to install it under the ground more than 65 CM.
- Don't install the probes into rocks or in dirty places.
- Turn on your device after you make sure that all parts are in place and connected.
- Make sure that the device battery is fully charged before starting the search.
- If the battery starts to give a beep sound, turn off the device, and recharge the
battery.
- It is recommended to read the user manual before using the device in order
to understand how it works and also to avoid mistakes during the search.
- If the device starts to make a beep sound and turns off automatically, please put the
battery on charge and do not try to start the device without charging fully the battery.
- When the green and the red light in the charger are on, while the battery is
connected to the power that means that the battery is full charged.
-Be aware of high voltage sources, and do not use any charger other than the original
one that comes with the device.

OVERVIEW
Dear customer,
“Thank you for choosing RIVER –G DEVICE”
✓This product enables you to detect the presence of underground water.
✓RIVER –G product is based on resistance principle and frequency detection system.
✓The device measures the resistance between the surface and under the ground
✓The device measures the resistance between the surface and underground
✓The device compares the measured values with the highest background values and
makes analysis and gives the results on screen.
✓The main unit of the device is under warranty against all electronic breakdowns for
two (2) years.
✓Any damages caused by user errors (opening the main unit, hits, harms, damages,
water lakes to the PCB etc.) are not within this warranty.
✓Battery and antenna are also not within this warranty.
✓You should strictly follow the instructions in this user manual to avoid errors and use
your device correctly
“NOTE”:
1- The 2500 MA Battery to be used for long range system only.
2- The 5000 MA Battery to be used for long range system only.

•Description of the main unit keys:
1- Settings Button:
to change the screen settings (light, sound).
2- Down Button:
to navigate down between the option of the
system.
3- Ok Button:
to select the options and enter the next page.
4- Up Button:
to navigate up between the system options.
5- Back Button:
to return to the language page from any page.

•Assembling the long-range system:
1-
Connect the Handle
Which holds the device.
2-
Connect Signal transmitter
Which Send signals to
Water in the ground.
3-
connect the Signal
Transmitter antennas
Which Sends signals to
The water in the ground.
4-
connect the Signal recipient
Which receives signals from
The water in the ground.
5- Connect Recipient antenna
Which Receives signals from
water in the ground

6- Extend the length of the
Recipient antenna to reach
the required front range
7- Connect the battery of the
Long range unit (2500 MAH)
through the battery entrance
8- Connect the Data transfer
cable to transfer data between
the main unit and the display
unit of the device.
9-Start the main unit of the
device by pressing on the
power button.

•The different functioning of the LONG-RANGE system
1-Inserting the long-range
Probe in the ground and
Connect its cable to the main
Unit’s upper side through the
LONG RANGE PORT.
2-After starting the device
The language menu will
Appear, select the search
Language from the screen
Which works by touch
3-Select the continent where
you are using the device in.
After selecting the continent
The countries list will Appear
Select the country where you
are using the device in.

4-After choosing the country
The systems menu will appear
Select LONG RANGE System
By using your finger on the
Touch screen.
5-The front range options will
Appear on the next screen
Select the range you want
To reach in your search
This system can reach
3000 square meters.
6-After entering all the settings
On the main unit.
The device will start
Sending signal to the
ground through the Long
range probe.
7-Start the main unit of the
Long range system by pushing
The ON / OF button on the
Battery, then the ON / OFF
Button on the back of the
Long range main unit.

8-After starting the main unit
Of the Long range system
The language menu will appear
Select the language you want
use by touching the
Screen or by using the buttons.
09-After starting the main unit
Of the Long range system
The language menu will appear
Select the language you want
use by touching the
Screen or by using the buttons.
10-After selecting the language
The soil type op tions will popup
Select the type of soil according
To the ground which you are
Working on.
11-The front range options
you can chose any range you
would like to reach in the area
NOTE : The chosen front range In
The long range system should be the
Same in the main unit of the devcie.

12-After entering all the
Settings the compass
Page will open up the
User must hold the device
Up to 90 degrees & Facing
The south direction.
After you confirm the directions press on the arrow button
To skip to the search page.
13-After connecting all parts and
Entering all the search settings
, the device will direct you to
The search page and start sending
And receiving signals, the antenna
will guide you towards the water.
1- When the water source is on the right side of the device , the antennas and the indicator will move to the
right direction and a beep sound will start Accelerates alerting the user to follow the water source.
2- When the water source is on the left side of the device , the antennas and the indicator will move to the
left direction and a beep sound will start accelerating, alerting the user to follow the water source.

3- After following the signal when you get to the water source, the antenna will turn to the back ,
the devcie will turn to the back from the right or the left side .

•Description the main unit keys:
1- DATA CABLE ENTRANCE:
to connect the main, unit to the display screen.
2- POWER BUTTON:
The power button is to start the device.
3- BATTERY ENTRANCE:
to connect the battery to the main unit
4- PROBES ENTRANCE:
to connect the 4 probes through the cables.
5- PRINTER:
To print the search report with the result details.
6- FUSE:
Do not touch (it’s to protect the main unit from
power surge).

•Assembling the GEOPHYSICAL & 3D IMAGING SYSTEMS:
1-
Connect the 5000 MAH
battery to the main unit
through the battery entrance
And start the device through
POWER button.
2-
Connect the Data transfer
Cable to transfer data between
The main unit and the display
unit of the device.
3-
Connect the 2 parts of each
Probe to each other.
Use a rubber hammer to insert
the probes into the ground
4-
Implant the 4 probes into
The ground in square shape
around the Device.

•The functioning steps of the GEOPHYSICAL & 3D system
1-After starting the device
The language menu will
Appear, select the search
Language from the screen
Which works by touch
2-Select the continent where
You are using the device
After selecting the continent
The countries list will appear
Select the country where you
are using the device in.
3-After choosing the country
The systems menu will appear
Select GEOPHSYCAL System
By using your finger on the
Touch screen.
4-The settings options will
appear on the next screen
Enter the soil type according
To the ground where you are
Using the device on.
For example (CLAY)

5- Enter the probes distance
it should beequal to the
distance on the ground.
The distance between the
4probes should be the same
Example, 10 M
6- After entering all the settings
And before we press OK.
Start the tablet of the device
To allow the device to display
The result on the 3D program.
7- Establish Bluetooth connection
From the device to the tablet,
Swipe the upper side of the
Screen to show the Bluetooth
Icon press on the Bluetooth
icon to start connection.
8- Settings page will open up
Press on (pair new devcie).
The tablet will start searching
For any bluetooth devices near
The tablet including the device
The toblet should be in 5 M
Range ner the main unit of the device

9- The RIVER G device will be
Detect it on the tablet screen
Press on the device name.
A window will pup up
Enter the Bluetooth password
The passowrd is : 1000
10- Open the 3D program
( RIVER G ) On the main
Desktop of the tablet ,
11- Press on NEW to start new
Search
12- When you press on NEW The
Device will automatically Connect
To the tablet this step will take
5 seconds and it will desplay
Device is Ready / Connected
When the connection is done the
Bluetooth light on the main unit
will stop blanking,
to proceed press on OK button
On the main unit
( soil type / probes distance page)
Then press on the start button on the tablet

13- After finishing all the steps
The device will start scanning the
Ground between the 4 probs and
Sending the data to the desplay screen
And to the 3D program
The results includes :
(Water Type –Salinity –Rate -
Rocks Persantage –Depth )
As you can get more details by
Pressing on the read more button
In the main unit Screen and more
Details button on the 3D program.
14- When press read more button on
The main unit the screen will
Desplay the type of water under
Each probe separately.
On the 3D program will apper
More details regarding the depth
& rocks rate & salinity & density .
As you can view the water shape
In 3D view by pressing (3D view).
To desplay the water from
A difreent angle use your
Finger to move the 3D
Image in all directions.

➢When the search process
ends the device will show
you the results as photo
next side
➢In the event of water
under all probes you will
see report on the device
will appear from which you
can learn the where about
of water and the type of
water as shown in the
“Note”
When the water percentage is less than 50% that means small amount
of water, and when the percentage is between 50-70% is a good
amount of water, and when the percentage is between 80-100% that
means the water amount be huge.
When the device gives, the salty water is salty and when
it gives you fresh water with simple percentage salinity,
this is the normal situation. All kinds of water containing
salinity.
About the salinity percentage:
- Fresh water: the salinity is less than 1000 ppm
- A low salinity water: between 1000 - 3000 ppm
- A medium salinity water: between 3000 - 10000 ppm
- A high salinity water: between 10000 - 35000 ppm
The shown lines (A-B-C-D-E-F) in the
final screen are the results of the search
process between the strings.

➢Dear customer,
When a "No result" message appears on the final search screen
Please read this information carefully
First case
The solution of this case
That means the
device found water
just on line “A”
1- Move the probe “3”
From its current
location
To the location of
the probe “2”
2- Move the probe “4”
From its current
location
To the location of
the probe “1”
3- Redistribute
probes “1”, “2”
Depending on
the new
location for
probes “3”,”4”
4- Re-search
again
