German pool ISF-623 User manual

P.1
Please read these instructions and warranty information carefully
before use and keep them handy for future reference.
Online Warranty Registration
Smart Auto IH Stir Fryer ISF-623
USER MANUAL

P.3P.2
Table of Contents
Warnings & Safety Precautions 03
Product Structure 05
Operation Instructions 07
Cleaning & Maintenance 10
Troubleshooting 11
Technical Specications 13
Warranty Terms & Conditions 23
Warnings & Safety Precautions
WARNING!
Be alert to risks that may result in signicant casualties and property
losses!
1. The socket must be earthed; and do not share socket with other
appliances to prevent overloading and re hazard.
2. To avoid damage to the product, do not block the air inlet or outlet
vent with towel or any other material while it is in use.
3. Do not spray water onto the product or immerse the product in water.
Otherwise it may result in electric shock or short circuit.
4. Place the product on a level and sturdy surface, keep away from
flammable materials and explosive environment to avoid danger
of re or scald.
5. When product is in use, do not let children and non-operators touch or
move the product to prevent spillage and scald.
6. Use only with the product’s dedicated power cord. To avoid danger,
do not attempt to replace cord by yourself. It must only be replaced
by the manufacturer or professional maintenance service.
7. This product should not be disassembled or repaired by non-professionals.
8. Do not touch the plug with wet hands or wet cloth. Unplug the device
when it is not in use.

P.5P.4
Handle
Inner Pot Rotation Plate
Lock – Unlock Mechanism
Support Wheel
Infrared
Temperature Sensor
Turn Knob
Outer Shell
Inner Pot Rotation Axle
Supporting Frame
Display Panel
Base
Silicone Seal Ring
Detachable Inner Cap
Lid Cover
Steam Cap
Inner Pot
Product Structure
Main Body
Warnings & Safety Precautions
ATTENTION!
Be alert to risks that may result in casualties and property losses!
1. This product is for home use only, not to be used for commercial
purposes; if used in a commercial context, manufacturer warranty
will be void, and manufacturer will not be held responsible for any
consequences.
2. Before cooking, make sure to turn inner pot anti-clockwise to
the locked position. Do not twist by brute force, otherwise it may
cause damage to the motor gear.
3. Never use any other inner pot besides the dedicated one.
4. Do not leave any dirt or water stain on the infrared temperature sensor
as it may hamper the sensor’s accuracy.
5. Do not put any metal or sharp object into the inner pot, or operate the
product with a metal tool as it may scratch the inner pot coating.
6. Before using this product, make sure surface of inner pot is completely
dry, in order to avoid causing any malfunction.
7. When product is in use and after you finish cooking, do not touch
the steam cap, inner pot or other hot areas to avoid getting burnt.
8. When pouring out the contents, make sure inner pot is securely locked
in place; after pouring out the contents, please move away the plate
before tilting the pot back into upright position.
9. Immediately stop running the product if any sign of malfunction
is detected.

P.7P.6
Product Structure
Standby Mode
When power is connected, buzzer will beep once, Display Panel will light up
for 1 second, Turn Knob LED will light up in purple, and product enters into
Standby Mode.
Turn Knob
Operating Instructions
I. Set Cooking Method
1. In Standby Mode, press Control Button, the product will announce: “Ready. Please
choose the Cooking Method.” The default Cooking Method is Stir-Fry. (Pic.1)
2. Rotate Turn Knob to choose Cooking Method. Methods cycle among Pan-Fry
, Stew , Braise , Stir-Fry respectively. Voice Prompt will announce the
associated method, and Display Panel will display the associated icon. (Pic.2)
3. Press Control Button to confirm Cooking Method selection, Voice Prompt will
announce:“Please adjust the tilt angle of the machine.” The product will then
start cooking, and the Turn Knob LED will light up in blue. (Pic.3)
4. Please select tilt angle according to the table below. (Pic.4)
5. After cooking is completed, buzzer will beep 4 times, Voice Prompt will announce:
“Finished”, and Turn Knob LED will light up in green.
Display Panel
Pic.1 Pic.2 Pic.3 Pic.4
When Power Level display is ashing, it indicates that the product has reached default
temperature.
Language Selection
1. Long-press Control Button for 3 seconds, buzzer will beep once, and product enters
into Language Selection Mode. (Pic.1)
2. Rotate Turn Knob to select Mandarin – English – Cantonese (Pic.2); long-press Control
Button for 3 seconds, buzzer will beep once to conrm that language selection is
complete. Next time you turn on the product, your previously selected language
will become the default language. (Pic.3)
3. To deactivate Voice Prompt Function, long-press Control Button for 8 seconds;
long-press Control Button for 8 seconds again to reactivate Voice Prompt. (Pic.3)
Watch the video clip
ATTENTION!
Default temperature settings as shown on the display refer to the maximum
power delivered by the product, hence the temperature monitored at the
heating element. Actual temperature inside the cook pot depends on food
quantity, water volume, ambient temperature and other environmental factors.
Control Button
Turn Knob
Turn Knob LED Light
AUTO
C
Countdown Timer
AUTO
C
Cooking MethodTemperature Power Level
~85°C ~100°C ~130°C ~170°C ~190°C ~210°C ~230°C
~
STEW PAN FRY
BRAISE
STIR FRY

P.9P.8
COOKING
METHOD
DEFAULT
TEMPERATURE
DEFAULT
TIME
MANUALLY
ADJUST
TILT ANGLE
ROTATION
MODE REMARKS
STIR FRY
Approx. 210℃4 min ANGLE
0-45°
Clockwise
continuously _
PAN FRY
Approx. 190℃10 min ANGLE
0-75°
Clockwise
intermittently
Rotates 15 sec,
then pauses
5 sec
STEW
Approx. 170℃40 min ANGLE
0°
Clockwise
intermittently
Rotates 35 sec,
then pauses
10 sec
BRAISE
Approx. 190℃25 min ANGLE
0-15°
Clockwise
continuously _
SERVING
FOOD _ _ ANGLE
0-135° _ _
Operating Instructions Operating Instructions
II. Adjusting Time And Temperature
After setting cooking method, user can adjust desired time and temperature according
to the following table:
ADJUSTMENT HOW-TO EFFECT
PAUSE/RESUME
COOKING
Press Control
Button (Pic.5)
Press once Pause cooking
Press again Resume cooking
CANCEL COOKING Press Control
Button (Pic.6)
Long-press
2 seconds
Cancel cooking and product
returns to Standby Mode
Note: When adjusting time and temperature, user must first press PAUSE.
SMALL
INCREMENT TIME
ADJUSTMENT
Rotate Turn Knob
slowly (Pic.7)
Rotate
forward
Time increases by
increments of 20 seconds
Rotate
backward
Time decreases by
increments of 20 seconds
LARGE
INCREMENT TIME
ADJUSTMENT
Rotate Turn Knob
quickly (Pic.8)
Rotate
forward
Time increases by
increments of 1 minute
Rotate
backward
Time decreases by
increments of 1 minute
TEMPERATURE
ADJUSTMENT
Long press Control
Button & rotate
Turn Knob
simultaneously
(Pic.9)
Rotate
forward
Temperature increases by
increments of 10°C
Rotate
backward
Temperature decreases by
increments of 10°C
WARNING!
DO NOT tilt cooker over 75°when cooking.
Product gets VERY HOT during cooking process. DO NOT touch steam
cap and inner pot to avoid getting burnt!
ATTENTION!
After cooking is completed, the product’s built-in fan will continue to run for
2 minutes to dissipate heat. Do not disable power source at this time. After
cooking is completed, if product does not receive any further instruction in
5 minutes, the product will automatically return to Standby Mode.
Pic.5 Pic.6 Pic.7 Pic.8 Pic.9

P.11P.10
Cleaning & Maintenance
WARNING!
Before cleaning and maintenance of this product, make sure product
is unplugged from the power source, and that the inner pot has
completely cooled down.
1. Cleaning the detachable inner cap: Remove the lid cover, push back
the slider to lift out the inner cap. Rinse it with water and wipe dry
with a soft cloth. Reinsert the inner cap properly, and lock the slider
back in place.
2. Cleaning the steam cap: Lift out the steam cap from the lid. Rinse it
with water and wipe dry with a soft cloth. Reinsert back onto the lid.
3. Cleaning the inner pot: wrap the fringe of the inner pot with a towel,
hold the pot with both hands, rotate clockwise until it reaches
the unlocked position, then take it out. Please use non-abrasive sponge
to clean inner pot, and dry with soft dry cloth. After inner pot
is completely dried, reinsert into product and rotate anti-clockwise to
locked position.
ATTENTION!
Use a light hand when removing or reinserting the inner pot. Do not use
steel scourer to clean pot.
ATTENTION!
Install the detachable inner cap, steam cap and inner pot properly after
cleaning and maintenance to safeguard product integrity for future use.
Troubleshooting
If the following problems occur, the turn knob LED will light up in red.
PROBLEM POSSIBLE CAUSE SOLUTION
Inner pot fails to rotate Motor gear box gear
collapsed Replace motor or gear
Inner pot intermittently
fails to rotate Motor gear box gear slip Replace motor or gear
Inner pot intermittently
fails to rotate, and emits
a scraping noise
Inner pot fringe is scraping
against product shell Add washer
Inner pot rotates
once then stops Support wheel won’t turn
Clean away grease
accumulated on support
wheel or replace support
wheel
Power is on
but product will not start Circuit board damaged Replace circuit board
Power is on, buzzer
beeps but product will
not start
Main control panel damaged Replace main control board
4. When cleaning the main body and inner parts: use a wrung-out wet
cloth or dry cloth. Do not rinse directly with water.

P.13P.12
Technical Specications
Model No. ISF-623
Voltage/Hertz 220V / 50Hz
Power 2400 W
Product Dimension (H) 405 (W) 360 (D) 385 mm
Inner Pot Volume 6 L
Rotating Speed 24 RPM
Tilt Angle 0-135°
Net Weight 9.8 kg
Specications are subject to change without prior notice.
If there is any inconsistency or ambiguity between the English version and the
Chinese version, the Chinese version shall prevail.
Refer to www.germanpool.com for the most up-to-date version of the Operating
Instructions.
Troubleshooting
CODE TYPE OF MALFUNCTION SOLUTION
E1 Over or under voltage AC Do not use until voltage returns to
normal value
E2
The thermistor on the circuit
board does not detect correct
measurement, or the heat sink
becomes overheated, or the
cooling fan is not properly installed
Restart the product after it cools
down. Contact Customer Service &
Repair Centre if problem persists
E3 Malfunction of NTC Resistor Contact Customer Service
& Repair Centre
E4
Infrared thermometer is not
properly installed or malfunction of
the infrared temperature sensor
Contact Customer Service
& Repair Centre
E5 Overheating of infrared
temperature sensor (＞240℃)
Restart the product after it cools
down. Contact Customer Service &
Repair Centre if problem persists
E6
Jammed motor, or the motor
wire is not connected properly,
or breakdown of relevant
components
Take out and reinstall the inner pot.
Contact Customer Service & Repair
Centre if problem persists
E7
Motor is wet; or the chipset on
the circuit board is unable to
receive signal from the main
control board, or IC5 is unable to
receive electrical signal from the IH
module
Contact Customer Service
& Repair Centre
E8 Display panel is unable to receive
signal from the control board
Contact Customer Service
& Repair Centre
E9
Is the inner pot corrected inserted?
Product is unable to heat up, the
control board IGBT driver triode
malfunctions, or the synchronizing
feedback resistor becomes
defective
Contact Customer Service
& Repair Centre

P.15P.14
目錄
警告及注意事項 15
產品結構 16
操作說明 18
清 潔 與 保 養 2 0
故障檢修 21
技術規格 22
保用條款 23
警告及注意事項
警告!
對可能導致人員危險、重傷、重大財產損失的風險要警惕
1. 必須使用接地良好的固定牆式插座，同一插座勿使用多個器具，以免
電流過大引起火災。
2. 本產品使用過程中，切勿使用毛巾等物品覆蓋本產品的風扇進出
風口，否則易引起器具損壞。
3. 不得將本產品浸入水中或淋水，否則可能會造成觸電或短路。良好
的防水意識有助於減少電源板故障。
4. 請選擇平穩地點及遠離易燃、易爆的場所，否則容易引起火災、
燙傷等事故。
5. 工作過程中，請勿讓小孩和非操作當事人盲目觸碰或移動，以免造
成鍋體傾倒燙傷事故。
6. 請使用本產品專用電源線，如果電源軟線損壞，為了避免危險，必
須由製造商、維修部或類似部門的專業人員更換。
7. 非專業維修人員不要擅自對產品進行拆卸或維修。
8. 請不要用濕手及濕抹布插拔電源插頭，使用完成後將電源插頭拔離
插座，保證用電安全。
注意!
對可能導致人員受傷或物品損害的風險要關注
1. 本產品為家用機型，不可用於商業用途；如用於商業用途，本公司
不承擔保修責任，也不承擔由此造成的後果。
2. 烹飪前請務必保證內鍋已逆時針旋轉鎖緊安裝到位。取出內鍋時必
須按說明操作，不可暴力旋轉，否則有損壞電機齒輪風險。
3. 嚴禁使用非專用內鍋。
4. 紅外探溫器處請勿殘留污物及水漬，以免影響控溫精準度。
5. 內鍋內不允許放置任何金屬、尖銳物品及使用金屬、銳利器具進行
操作，以免損傷內鍋塗層。
6. 使用前務必將內鍋表面的水分擦乾，以免造成故障。
7. 在使用中或剛使用完，請不要徒手直接觸摸蒸氣口、內鍋等高溫部位。
8. 倒菜時，請務必確認內鍋處於鎖住狀態；倒菜後請務必先拿開接菜
器皿，再將機體傾斜角度還原。
9. 若發生異常或故障時，請立即停止使用。

P.17P.16
產品結構
主機 顯示屏
7. Handle
10. Inner Pot Rotation Plate
6. Lock – Unlock Mechanism
8. Support Wheel
9. Infrared Temperature Sensor
11. Turn Knob
13. Outer Shell
12. Inner Pot Rotation Axle
14. Supporting Frame
15. Display Panel
16. Base
1. Silicone Seal Ring
2. Detachable Inner Cap
4. Lid Cover
3. Steam Cap
5. Inner Pot
主機把手
內鍋傳動盤
鎖緊-解鎖指示
支撐輪
旋鈕開關
紅外線測溫器
外殼
內鍋傳動軸承
支架
顯示屏
底板
硅膠圈
可拆內蓋
上蓋
蒸氣閥
內鍋
控制鍵
旋鈕
旋鈕LED指示燈
旋鈕
產品結構
當火力顯示閃爍時，表示已達到預設溫度。
AUTO
C
時間顯示
AUTO
C
烹飪方式溫度顯示 火力顯示
~85°C ~100°C ~130°C ~170°C ~190°C ~210°C ~230°C
1
~
燉煮 香煎
燜燒
翻炒
注意!
「預設溫度」指以最高火力加熱時發熱元件所達到的溫度。鍋內食物
或水份的溫度及加熱能力需視乎份量、食材、及環境因素有所調整。

P.19P.18
操作說明
烹飪模式 預設溫度 預設時間 手動傾斜角度 轉動方式 備註
翻炒 約210℃ 4分鐘 傾斜 0-45° 正向轉動 _
香煎 約190℃ 10分鐘 傾斜 0-75° 間歇轉動 轉15秒 停5秒
燉煮 約170℃ 40分鐘 傾斜 0° 間歇轉動 轉35秒 停10秒
燜燒 約190℃ 25分鐘 傾斜 0-15° 正向轉動 _
上菜 _ _ 傾斜 0-135° _ _
注意!
完成烹調後，風扇將繼續轉動2分鐘進行散熱。請勿在此時切斷電源。
完成烹調後5分鐘內無任何操作，將自動返回待機狀態。
II. 調整烹飪狀態
烹調狀態下，可按下表操作方式調整烹飪狀態 :
功能說明 按鍵說明 操作說明
暫停/繼續烹飪 按「控制鍵」(圖 5) 按１次 暫停烹飪
再按１次 繼續烹飪
取消烹飪 按「控制鍵」 (圖6) 長按２秒 取消烹飪並返回待機狀態
注意：調整時間及溫度前須先暫停烹調。
調整時間 旋轉旋鈕一小格 (圖 7) 向前旋轉 時間增加20秒
向後旋轉 時間減少20秒
快速調整時間 快速旋轉旋鈕 (圖 8) 向前旋轉 時間增加1分鐘
向後旋轉 時間減少1分鐘
調整溫度 按著「控制鍵」
同時旋轉旋鈕 (圖 9)
向前旋轉 溫度增加10°C
向後旋轉 溫度減少10°C
待機狀態
接通電源，蜂鳴器發出聲響1聲，顯示屏全亮１秒，
旋鈕LED指示燈以紫色常亮，進入待機狀態。
語音選擇
1. 長按「控制鍵」3秒，蜂鳴器發出聲響1聲，進入語音選擇模式。(圖 1)
2. 旋轉旋鈕切換語音，順序循環為「國語-英文-粵語」 (圖 2)；長按「控制鍵」3秒，
蜂鳴器發出聲響1聲，確認語音。下次開機時默認上次的選擇。 (圖 3)
3. 長按「控制鍵」8秒，可關閉語音提示功能；再長「控制鍵」8秒，恢復語音提示
功能。 (圖 3)
操作說明
警告!
烹飪時請勿將機身傾斜超過75° 。
烹飪時內鍋及蒸氣口非常熱，嚴禁觸摸以免燙傷！
I. 設定烹飪方式
1. 待機狀態下按「控制鍵」，產品發出語音「準備好了，請選擇烹飪方式」。 (圖 1)
2. 旋轉旋鈕切換烹飪方式，順序循環為「翻炒 - 香煎 - 燉煮 - 燜燒 」，
產品發出相應語音，顯示屏顯示相應角度圖案。 (圖 2)
3. 按「控制鍵」確認烹飪方式，產品發出語音「請調整機器傾斜角度」後，
進入烹調狀態，旋鈕LED指示燈以藍色常亮。 (圖 3)
4. 請按下表手動調整傾斜角度。 (圖 4)
5. 烹調完成後，蜂鳴器發出聲響4聲，產品發出語音「完成」，旋鈕LED指示燈
以綠色常亮。
圖 1圖 2圖3圖4
圖5圖6圖7圖8圖9
觀看操作視頻
