German pool ESB-315 User manual

Please read these instructions and warranty information
carefully before use and keep them handy for future reference.
在使用之前請詳細閱讀「使用說明書」及「保用條例」
，並妥為保存。
ESB-315
全能人體分析電子磅
All-Round Electronic Body
Analyser Scale

目錄 Table of Contents
P.2
注意事項 Notice Before Use 03
產品結構 Product Structure 04
操作說明 Operating Instructions 06
常見故障及處理 Troubleshooting 11
清潔與保養 Care & Maintenance 13
技術規格 Technical Specications 13
保用條款 Warranty Terms & Conditions 15

P.3
1.在使用本機前,請仔細閱讀本說明書以熟
悉本產品的功能和操作方法。
2.本產品不適用於體內裝置金屬儀器者，如
起搏器、節育環、金屬片及螺絲等；否則
將有可能導致儀器損壞或量度不準確。如
有疑問，請諮詢您的醫生。
3.本產品透過BIA (BIOELECTRICAL IMPEDANCE
ANALYSIS)技術來量度體重，阻抗及評估身
體脂肪及水分、肌肉及骨頭百分比。本產
品適合家庭使用於10-17歲的健康兒童，以
及生活方式活躍、一般活躍和不活躍的健
康成人。
4.本產品適用於10-85歲人士。
5.請使用規定的電池（請參照“操作說明”
部分）。
6.運動員模式適用範圍為15-85歲。
7.脂肪比率會隨著體內水分而改變，缺水狀
態或者溢水狀態都會影響人體內的脂肪
比，如喝酒、月經期、生病、劇烈運動
等。
8.本產品不適用於孕婦，否則將導致測量結
果不準確，且對胎兒的影響尚未可知。
9.使用脂肪水分度量時，請赤腳進行。
10.本產品只供家庭測量體重，不可用於商業
或其他用途。
11.請勿拆卸本機，不恰當的操作會導致損傷。
12.當您的身體或腳上帶有很多水時，特別是
剛剛沐浴後請勿稱量，謹防滑到。
13.浮腫、發燒、骨質疏鬆、接受洗腎療程等
病人不可使用本產品。
14.服用血管擴張或收縮藥物或其他心血管有
關藥物的人士不可使用本產品。
15.電池有造成窒息的危險，請勿讓兒童接觸。
1. Please read this section carefully to familiarize yourself
with features and operations before using the unit.
2. Do not use the scale on people who have body implants
such as a pacemaker, articial limbs, contraceptive
devices, or metal plates or screws. It may cause the
device to malfunction or produce an inaccurate result.
When in doubt, consult your medical ofcer.
3. This scale is intended to measure body weight and
impedance and estimate percentage of body fat and
body water, muscle mass and bone mass using BIA
(Bioelectrical Impedance Analysis). It is intended for
use by healthy children 10-17 years old and healthy
adults with active, moderately active, to inactive
lifestyles for body composition assessment in the home
environment.
4. This product is intended for adults and children (ages
10 to 85).
5. Make sure to use only the type of battery stated (see
Section “Operating Instructions”).
6. The “Athlete” mode is applicable only to people 15-85
years of age.
7. Body fat percentage estimates will vary with the amount
of water in the body, and can be affected by dehydration
or over-hydration due to such factors as alcohol
consumption, menstruation, illness, intense exercise, etc.
8. Do not use on pregnant women. The result is inaccurate
and effects on the fetus are unknown.
9. For body fat and body water estimates, always
estimate in bare feet.
10.Do not disassemble the scale as incorrect handling
may cause injury.
11.Do not step on the scale when your body or feet are
wet, especially after bathing or showering to prevent
slipping.
12.This scale is only used in household for body weight
measurement, and not for commercial or other use.
13.Edema, fever, osteoporosis and patients receiving
dialysis treatment should not use this product.
14.People taking blood vessel dilation or contraction drugs
or other cardiovascular-related drugs should not use
this product.
15.Batteries may pose a choking hazard. DO NOT let
children handle batteries.
注意事項 Notice Before Use

P.4
產品結構 Product Structure
1.功能按鍵
ON/OFF
-開/關機
-進入脂肪及水分稱重模式
SET
-確認按鍵
或
-稱重模式中調整身高及年齡數值，進行性別、
運動模式或普通模式轉換
-記憶及回憶模式選擇記憶位置
-獲取記憶中的數據
單位轉換開關
推置磅底的單位轉換開關
進行單位轉換kg/cm或ib/in
前視圖
Front View
背面視圖
Back View
電源按鍵
液晶顯示屏
磅面及電極片
設置按鍵
Set Button
& Buttons
Platform with
Electrodes
Power Button
LCD 及 按鍵
電池盒
Slide Switch
Adjust the conversion switch
located at the bottom of the
scale to change the measuring
unit between kg/cm, lb/in. User
selectable unit: kg/cm or lb/in.
Battery Compartment
1. FUNCTION KEYS
ON/OFF
- Turn the scale on or off
- Enter body fat and total body water estimation mode
SET
- Conrmation button for selection
or
- Changes value of height and age, toggle between
Male and Female, toggle between Normal and
Athlete mode in Body Fat function
- Select memory 1-12 in Memory mode & Recall mode
- Recall settings of memory locations

P.5
產品結構 Product Structure
液晶顯示屏
LCD
年齡 Age
後置按鍵
前置按鍵設置按鍵電源按鍵
肌肉% Muscle Mass%
骨重% Bone Mass %
記憶位置 User Number 卡路里 Calories
普通模式 Normal Mode
運動員模式 Athlete Mode
男性標示 Male Icon
體重讀數單位
Weight Readout in
千克（KG）或磅（LB）
Kilograms(KG), Pounds(LB)
脂肪% Body Fat%
女性標示 Female Icon
身高單位為英尺/英寸
Height Displayed in Feet/Inches
身高單位為厘米
Height Displayed in CM
水分% Body Water %
Back
Button
Forward
Button
SET
Button
POWER
Button

P.6
1. Insert the battery
This scale operates on 1 x CR2032 lithium
battery (included). Open the battery cover on
the back of the scale unit. Remove any plastic
strip before rst use or insert a new battery
for replacement. Be sure the polarity of the
battery is set correctly for the scale to function
properly. If you do not intend to use this unit
for a prolonged period of time, it is advisable to
remove the battery before storing.
1.安裝電池
本產品使用一枚CR2032電池（附贈）。
開啟磅秤背面的電池門，移除電池下面的
絕緣條或更換電池。請正確安裝電池的正
負極，以確保磅秤正常工作。如果長時間
不使用本產品，建議您取出電池後保存。
3. Some models have a static cling label on the
LCD display to prevent scratching. Remove
before use.
3.有些型號的產品液晶顯示屏上粘有靜電保護
 貼紙，使用前請撕除。
2. Set Unit
This scale is set to pounds. You can toggle the
unit of measurement switch located on the
back of the scale for kilograms or pounds.
2.設置單位
本產品預設單位為磅。您也可以通過磅秤背面
的單位轉換開關選擇千克或磅作為稱重單位。
開啟電池門Open the battery door
Kg(千克) Lb(磅)
CR2032電池方向Direction of the CR2032 battery
操作說明 Operating Instructions
- 屏幕顯示時，請更換電池。
小貼士 Tips
- Replace battery when is displayed.

P.7
操作說明 Operating Instructions
6.操作指引
 為獲取精確的測量結果，如何站在磅上是非常
 重要的。請儘量保持腳底最大面積接觸磅面上
 的金屬電極片，這樣能確保腳與金屬電極的最
 佳接觸。稱重過程中，請保持靜止直至測量完
 成顯示測量結果。乾淨且輕微潮濕的腳底可獲
 得最佳測量。
4. Set the right position
Always use the scale on a at and hard oor
surface. Do not use on carpets.
4.稱重位置
請把磅秤置於平整、牢固的地方使用，
勿用於地毯上。
5. Start-up the Scale
Press lightly on the scale platform to start-up the
scale, the display shows “0000” and then turns
off. The scale is ready to use.
6. Operating Guidelines
The accuracy of the results depends on how
you stand on the scale. Position your feet with
maximum contact on the metal electrodes on
the platform. This ensures the best contact
between your feet and metal contacts. Stay
on the scale until the body fat estimation is
completed and the result is displayed. Clean,
slightly moist feet will provide the best results.
5.初始化
輕按磅面，顯示“0000”後關機，初始化完畢。
- 請勿濕腳磅重或踩踏磅秤邊緣，謹防滑倒。
- To avoid injury, do not step with wet feet or on the edge of the platform.
Beware of slipping
注意事項 Warning！
- 在插入電池/更換電池或每次移動或磅秤被碰撞後，磅秤必須重新啟動。
- The scale must be started up after battery insertion/replacement of battery or each time it is moved or bumped.
注 意 PRECAUTION！
腳沒有居於電極中央 (X)
Feet not centered on electrodes (X)
腳居於電極中央 (√)
Feet centered on electrodes (√)

P.8
操作說明 Operating Instructions
7. Weighing-only Operation
- Step onto the scale and stand still while the
weight is being measured (Fig. 1).
- The screen displays the weight (Fig. 2).
- The scale turns off automatically after use.
ⅲ.Set Height
Press the 【】or【】key to adjust the height.
Press [SET] to conrm.
- A few steps must be followed before estimating
body fat and total body water.
PROGRAM PERSONAL DATA
- Input the user’s gender, age and height. Once
the information is memorized, it will only need
to be reentered if there is a change to the data.
ⅰ.Press the ON/OFF key to turn the scale on.
ⅱ.Set Memory
Press the 【】or【】key to select a memory
location (1-12 users). Press [SET] to conrm.
8. Body Fat and Total Body Water Estimating
Operation with User Memory
7.簡單稱重操作
- 站在磅面上，稱重過程中
請保持靜止不動（圖1）。
- 顯示您的體重（圖2）。
- 完成後，磅秤自動關機。
圖1 (Fig.1)
圖2 (Fig.2)
8.使用記憶功能進行脂肪及水分測量操作
-進行脂肪及水分稱重前，要進行以下幾個步驟。
編輯個人數據
-輸入您的性別、年齡、身高。個人信息一旦記
憶，只有進行資料更改時才需重新編輯輸入。
注 意 PRECAUTION !
ⅰ.按ON/OFF鍵開機。
ⅱ.設置記憶位置
按【】或【】鍵選擇記憶位置（1-12）。
 按【SET】鍵確認。
ⅲ.設置身高
按【】或【】鍵調整身高數值。
 按【SET】鍵確認。

P.9
操作說明 Operating Instructions
ⅶ.顯示所有個人信息，幾秒後磅秤自動關機。
 您的個人信息已存儲於記憶中。
ⅶ.All personal information stored to memory
will be displayed. The scale will automatically
shut off after a few seconds. Your personal
information is saved in memory.
ⅳ.Set Age
Press the 【】or【】key to adjust the age.
Press [SET] to conrm.
ⅳ.設置年齡
按【 】或【 】鍵調整年齡數值。
按【SET】鍵確認。
ⅴ.選擇性別
按【 】或【 】鍵進行性別轉換，男（ ），
女（ ）。按【SET】鍵確認性別。
ⅴ.Set Gender
Press the 【】or【】key to toggle
between the male ( ) & female ( ) icons.
Press [SET] to conrm.
ⅵ.選擇普通或運動員模式
按【 】或【 】鍵進行普通和運動員模式
轉換。按【SET】鍵確認所有設置。
注：運動員模式只適用於15-85歲的使用者。
14歲或以下使用者本步驟會自動省略。
ⅵ.Select Normal or Athlete Mode
Press the【】or【】key to toggle between normal
or athlete. Press [ SET ] to conrm all settings.
NOTE: Athlete mode is only available for those
15-85 years of age. For those aged 14 or
under, this step is automatically by-passed.
ⅷ.Repeat step (i)-(vii) to set other pre-programmed
user numbers.
ⅷ.重複i-vii步驟設置其他使用者的數據。

P.10
操作說明 Operating Instructions
9. The scale features 12 personal memory settings.
This allows users to store and recall their own
height, age, gender and normal/athlete mode
selection. Follow steps in the previous section
“Program Personal Data” to input your personal
information into a memory location.
A. To recall Settings from Memory for Body Fat
and Total Body Water Estimation
You must be in bare feet for body fat and total
body water estimations. Remove your shoes
and socks before proceeding. Clean, slightly
moist feet will provide the best results. Position
your feet for maximum contact with the metal
electrodes on the platform.
1. Press the ON/OFF key to turn the scale on.
2. Press the【】or【】 key to toggle between
memory location (1-12). The screen will
show the previous reading, then “0.0”.
(NOTE: The previous reading for that user
number will appear after rst use.)
3. When “0.0” appears on screen, step on the
scale with bare feet, positioning your feet
evenly on the scale platform with maximum
contact with the metal electrodes.
4. Stand still while the scale measures your
weight and estimates your body composition.
9.本產品內置12個記憶位置，可供使用者存儲及
 獲取身高、年齡、普通/運動員模式設置。根
 據上述“編輯個人數據”部分輸入個人信息並
 保存記憶。
A.獲取記憶信息進行脂肪及水分測量
  脂肪及水分測量需赤腳進行，測量前請脫掉
  鞋子及襪子。乾淨、微微濕潤的腳底可獲得
  最佳測量結果。盡可能使腳底最大面積接觸
  磅面上的電極片。
  1.按ON/OFF鍵開機。
 2.按【】或【】鍵選擇記憶位置（1-12）。
   顯示上一次的測量讀數，然後讀數歸
   零“0.0”
  （注：第一次使用後才會
   顯示上一次測量讀數。）
 3.當顯示“0.0”時，赤腳站在磅
  面上，腳底最大面積接觸電極片
  並儘量保持平穩。
 4.測量過程中請保持靜止不動。

P.11
操作說明 Operating Instructions
5. Your weight, body fat % (BF) then total body
water % (BW) are displayed. Next your Calories
(KCAL), muscle mass % (MM) and bone mass %
(BM) are displayed sequentially twice.
B. To Turn Off the Scale
To turn the scale off, press the ON/OFF key while
programming data. Or, if no key has been pressed
for a few seconds, the scale turns off automatically.
5.顯示您的體重、脂肪%（BF）及總水分%
（BW），接著顯示您的卡路里（KCAL）、
 肌肉%（MM）及骨重%(BM)，依次連續顯
 示兩次。
B.關機
 在編輯個人信息時，按ON/OFF鍵關機；
 在無操作狀態下數秒後，磅秤自動關機。
常見故障及處理 Troubleshooting
無重量顯示
No weight is displayed?
請檢查電池是否有電。如果不是，請參照“操作說明”部分。
Check if the scale is powered up and started up. If not, please refer to
the Section “Operating Instructions”.
螢幕顯示“Lo”
The display reads “Lo”
低電顯示，請更換電池。
Battery is running low. Replace the battery.
螢幕顯示“Err0”
The display reads “Err 0”
歸零異常。從磅上下來，待自動關機後，請重新輕按磅面進行初始
化，螢幕顯示“0000”後自動關機，初始化完成。
Initialization error. Step off the scale and wait until the scale is
automatically switches off. Start the scale again by pressing lightly on
the scale platform to re-initialize the scale. The scale is ready for use
again.
螢幕顯示“Err1”
The display reads “Err 1”
不穩定異常。從磅上下來，待自動關機後，重新站在磅上進行稱重，
並注意在稱重過程中保持靜止不動。
Instability error. Step off the scale and wait until the scale automatically
switches off. Step on the scale to repeat the measurement again,
standing still while computation is in progress.
稱重過程中，螢幕顯
示“Err2”
The display reads “Err 2”
when measuring
超重預警。立即從磅上下來，否則將對磅秤造成永久性傷害。
Overload warning. Remove the weight immediately; otherwise,
permanent damage to the scale will occur.

P.1 2
脂肪及水分測量過程中，
螢幕顯示“Err3”
The display reads “Err 3”
when estimating body fat
and body water values
測量異常。電阻無法測量到。請確保稱重過程中保持靜止並使腳底最
大面積接觸電極片。如若仍然不能測量到，請參考“操作說明”部
分。您也可以通過微微濕潤你的腳底，促進電極接觸。
Measurement error. Impedance cannot be measured. Please make
sure that you are standing still on the scale and maintaining maximum
contact between your feet and the metal contacts. If not, please refer to
“Operating Instructions” section. You may need to moisten your feet to
improve the electrical contact.
Err1至Err3都試過了，
可仍不能解決問題
After I tried the corrective
actions for Err 1 to Err
3, I still can’t solve the
problem
解決方案都試過了，可問題仍然存在，請移除電池一分鐘後重新安裝。
If Err 1 to Err 3 persists after following the corrective actions, remove
and reinsert battery after 1 minute.
我已經試過所有的解決方
案了，仍然不能解決問題
I have tried all corrective
actions, but still can’t solve
the problem
請聯繫德國寶維修中心或授權經銷商。
Please contact German Pool Repair Centre or an authorized dealer.
為什麼我使用不同品牌的
磅秤，測量的脂肪結果
不同？
Why do I get a different
body fat reading when I
use a different brand of
body fat scale?
不同的脂肪磅秤運用不同的數學原理測量身體不同部分獲得脂肪百分
比。我們建議您無需進行不同產品的比較，只需每次都使用同一款產
品進行測量跟蹤。
Different body fat scales take estimations around different parts of
the body and use different mathematic algorithm to estimate the
percentage of the body fat. The best advice is not to make comparison
from one device to another, but to use the same device each time to
monitor any change.
常見故障及處理 Troubleshooting

P.13
1. Do not disassemble the scale other than for replacing
the battery; it contains no user serviceable parts.
Damage to the scale may occur as a result of
improper handling.
2. Remove the battery when the scale is not used for a
prolonged period of time.
3. Clean the scale after use with a dampened cloth.
Do not use solvents or immerse the unit in water.
4. Avoid excessive impact or vibration to the scale,
such as dropping it onto the oor.
5. Do not dispose of batteries in re. Batteries may
explode or leak. When replacing batteries at the same
time; do not mix old and new batteries. Do not mix
alkaline, standard or rechargeable batteries. Remove
the batteries if the scale will not be used for a long
period of time.
清潔與保養 Care & Maintenance
1.除拆裝電池外，請勿私自拆卸本產品，本產品
內部未置用家使用部分。不恰當的操作可能會
導致產品損害。
2.如長期不使用本產品，請將電池取出後保存。
3.請使用潮濕的抹布擦拭磅秤，禁止使用具有腐
蝕性的溶劑或將磅秤浸入水中。
4.請避免劇烈撞擊或震動本產品，如拋落磅秤。
5.請勿將電池丟入火中，可能會引起電池爆炸或
洩漏。如產品需要兩枚或以上電池，請同時更
換電池，勿混合使用新舊電池，勿混合使用鋰
電池、標準電池或充電電池。
型號 Model ESB-315
生物電阻分析技術用於測量人體脂肪、水分、
肌肉、骨重百分比及卡路里預測
Bioelectrical Impedance Analysis (BIA) technology for
body fat and body water percentage, muscle and bone
estimations and calories predictor.
有/YES
高精密的STRAINGAUGE稱重技術
High-precision STRAIN GAUGE weighing technology 有/YES
運動員（15-85歲）或普通模式選擇
Athlete (for ages 15-85) or Normal Mode selection 有/YES
12個記憶位置
12-user memories 有/YES
技術規格 Technical Specications

P.14
型號 Model ESB-315
4個按鍵操作4-button operation 有/YES
自動開關機功能
Auto on/off function 有/YES
節能液晶顯示屏幕
Power-saving LCD display 有/YES
低電量顯示 Low power indicator 有/YES
最大稱重量 Maximum weighing capacity 150kg/ 330lb
年齡範圍Age range 10-85歲/ 10-85 years
身高量程 Height range 2’5’’ – 7’4’’ (75-225cm)
人體脂肪量程Body fat range 4-60%
人體總水分量程
Total body water range 29-70%
電源
Battery
一枚CR2032電池（附贈）
1 x CR2032 lithium battery (included)
產品規格及設計如有變更，恕不另行通知。
Specications are subject to change without prior notice.
中英文版本如有出入，一概以中文版為準。
If there is any inconsistency or ambiguity between the English version and the Chinese version,
the Chinese version shall prevail.
本產品使用說明書以 www.germanpool.com 網上版為最新版本。
Refer to www.germanpool.com for the most up-to-date version of the Operating Instructions.
技術規格 Technical Specications

P.15
保用條款
此保用提供德國寶產品之機件在正常使用下壹年
保用(自購買日起計算)。
Warranty Terms & Conditions
Under normal operations, the product will receive a 1-year full
warranty provided by German Pool (effective starting from the
date of purchase).
1. Customer who fails to present original purchase invoice
will be disqualified for free warranty.
2. Customer should always follow the operating
instructions. This warranty does not apply to:
- labour costs for on-site installation, check-up, repair,
replacement of parts and other transportation costs;
- damages caused by accidents of any kind (including
transport and others);
- plastic parts and accessories;
- operating failures resulted from incorrect voltage,
improper operations and unauthorized installations
or repairs.
3. This warranty is invalid if:
- purchase invoice is modified by unauthorized party;
- product is used for any commercial or industrial applications;
- product is repaired or modified by unauthorized
personnel, or unauthorized parts are installed;
- serial number is modified, damaged or removed from
the product.
4. German Pool will, in its discretion, repair or replace any
defective part.
5. This warranty will be void if there is any transfer of
ownership from the original purchaser.
1. 未能出示購買發票正本者，將不獲免費維修服務。
2. 用戶應依照說明書的指示操作。本保用並不包括﹕
- 上門安裝、檢驗、維修或更換零件之人工以及一
切運輸費用﹔
- 因天然與人為意外造成的損壞(包括運輸及其他)﹔
- 任何塑膠附件及輔助裝置﹔
- 電源接合不當、不依說明書而錯誤或疏忽使用本
機所引致之損壞。
3. 於下列情況下，用戶之保用資格將被取消﹕
- 購買發票有任何非認可之刪改；
- 產品被用作商業或工業用途；
- 產品經非認可之技術人員改裝或加裝任何配件；
- 機身編號被擅自塗改、破壞或刪除。
4. 總代理有權選擇維修或更換配件或其損壞部份。
5. 產品一經被轉讓，其保用即被視作無效。
機身號碼 Serial No. :
購買商號 Purchased From :
發票號碼 Invoice No. :
購買日期 Purchase Date :
型號 Model No. :
請填妥以下空格並與發票一併保存¸以便維修時核對資料。用戶提供本公司之所有資料必須正確無誤¸否則免費保用將會無效。
Please fill out the form below. This information and the purchase invoice will be required for any repairs. Warranty will be invalid
if information provided is found to be inaccurate.
ESB-315
P.19
* 貴戶須在購機十天內，以下列其中一種方
式向本公司登記資料，保用手續方正式生效﹕
1)填妥本公司網頁內之保用登記表格
www.germanpool.com/warranty。
2)填妥保用登記卡，並連同購機發票之副本一
併郵寄到客戶服務部 (本公司將不發還發票
副本或登記卡)。
* This warranty is not valid until Customer’s registration
information is returned to and received by our Service
Centre within 10 days of purchase via one of the
following methods:
1) Visit our website and register online:
www.germanpool.com/warranty.
2) Completeall fields on the attached Warranty Card and
mail itback to our Customer Service Centre along with
a photocopy of the purchase invoice (Warranty Card
and invoice copy will not be returned to Customer).
[phone] [phone]

P.16
ESB-315-M-13(1)
德國寶(香港)有限公司
German Pool (Hong Kong) Limited
© 版權所有。未獲德國寶授權，不得翻印、複製或使用本說明書作任何商業用途，違者必究。
© All rights reserved. Copying, reproducing or using the contents of this manual is not allowed without prior authorization from German Pool, violators will be prosecuted.
香港總代理Hong Kong Sole Agent中國總代理China Sole Agent
九龍土瓜灣馬頭角道116號新寶工商中心高層地下2-4號室
Room 2-4, Upper G/F, Newport Centre, 116 Ma Tau Kok Road,
Tokwawan, Kowloon
電話 Tel: [phone] 傳真 Fax: [phone]
廣東省佛山市順德區大良南國東路德順廣場三層
3/F, Takshun Plaza, Nanguo East Road, Shunde,
Foshan, Guangdong
電話 Tel: [phone] 傳真 Fax: [phone]
