GFW MORGAN 3FT BEDSTEAD User manual

Thank you for purchasing the Morgan 3ft Bedstead.Please read the
instructions carefully to ensure safe operation of this product.
Batch No. 231602
Page 1of 7
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking.
Tools Required
Number of people
x2
1 Hour
Set Up
MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
Size : 200 x 92 x 88 - 41 cm (LWH)
Colours: Sliver / Black / White / Blue / Pink
Finish: Painted steel

MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
Batch No. 231602
Page 2of 7
INFORMATION
CARE INFORMATION
Never use scourers, abrasives or chemical cleaners.
To clean, wipe with a damp sponge and warm soapy water. Do not use solvent based
cleaners or detergents as they can bleach or damage the product.
WARNINGS
This product is designed to support a maximum load of 100Kg spread evenly over the
length of the bed. Do not exceed this weight.
We recommend that this unit is assembled in the room intended for use.
When you are ready to start, make sure that you have the right tools, plenty of space and
a clean, dry area for assembly.
Unwrap all packaging materials and place each component on top of the carton box or on
a clean floor to prevent it from scratching.
Check the pack and make sure you have all the parts listed.
Ensure that this product is fully assembled as illustrated before use.
When finished, check all screws or bolts are tightened and inspect regularly.
Tools are not included unless specified in the parts list.
This product should only be used on a firm and level floor.
Keep small parts out of reach of children.
Make sure the legs/base remain in contact with the floor.
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
use power tools to construct this product.
tighten screws until parts are assembled or as advised in this guide..
over tighten screws or bolts.
use this product if parts are missing, damaged or worn.
climb or stand on the product.
sit on the product unless a mattress is in place.

MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
Parts and Fittings Checklist
Please check the pack contents before assembling the product. If any components are missing,
please contact your retailer. The fittings pack contains small items that should be kept away from
small children.
123
Description: Headboard Leg
Qty: 2 Qty: 2 Qty: 1
Carton No: 1/1 Carton No: 1/1 Carton No: 1/1
456
Description: LH Side Rail
Qty: 2 Qty: 2
Description: Footboard Panel
Qty: 1
Carton No: 1/1 Carton No: 1/1 Carton No: 1/1
7 8
11
9
Description: Middle support Rail
Qty: 1 Qty: 14 Qty: 2
Carton No: 1/1 Carton No: 1/1 Carton No: 1/1
10
Description: End Rail
Qty: 2
Carton No: 1/1
Parts are packed in one carton
Description: Footboard Leg Description: Headboard Panel
Description: RH Side Rail
Description: Slat Description: Side Support Leg
Batch No. 231602
Page 3of 7
Qty: 28
Carton No: 1/1
Description: Single Plastic Cap

MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
Batch No. 231602
Page 4of 7
8A
8D
Item QuantityCode
Fittings (to scale)
Nut for Bolt M8
8E
10 20 30 40 50 60 70 80
Fittings (not to scale)
QuantityCode
2
G
1
H
Item
Spanner
Allen Key
Bolt M6x35 mm
Sleeve Nuts
(For Blot M6)
8F Curve Washer
(For Blot M6)
4B Bolt M6x40 mm
20C Bolt M6x50 mm

MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
Batch No. 231602
Page 5of 7
C x12
Fittings required
For this step:
Tools required
G
C x8
Fittings required
For this step:
Tools required
G
D x8
H

Batch No. 231602
Page 6of 7
MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
STEP 3
STEP 4
A x8
B x4
E x8
F x8
G
Fittings required
For this step:
Tools required

MORGAN 3FT BEDSTEAD ASSEMBLY INSTRUCTIONS
Assembly Completed
Your Morgan 3ft bedstead .delbmessayletelpmocwonsi
Periodically check to ensure that the components are in their proper position, free from damage.
Also, make sure the connectors are tight and secure.
Keep instructions for future reference
Batch No. 231602
Page 7of 7
