GFW Jakarta Coffee Table With Shelf User manual

Size: 105 x 55 x 40 cm (WDH)
Colour: Mango
Finish: Melamine Veneer
JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Thank you for purchasing the Jakarta Coffee Table With Shelf.
Please read the instructions carefully to ensure safe operation of this product.
Version 1 - 180520
Page 1of 6
PLEASE READ this sheet prior to assembly to familiarise yourself with the various stages of construction.
Carefully open the pack supplied and check the contents against the parts and fittings check list. Do not
destroy any of the packaging until you are certain that you have all the necessary parts for the assembly.
CAUTION: There are small components used in the construction of this unit. These loose items should be
kept away from young children whilst assembling your unit to avoid the danger of choking.
Tools Required
Number of people
x1
0.5 Hour
Set Up

JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Version 1 - 180520
Page 2of 6
IMPORTANT - READ CAREFULLY - RETAIN THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
INFORMATION
CARE INFORMATION
Never use scourers, abrasives or chemical cleaners.
To clean, wipe with a damp sponge. Do not use solvent based cleaners or detergents
as they can bleach or damage the product.
DO NOT place hot items or liquids directly on the surace, use a coaster or mat...
When you are ready to start, make sure that you have the right tools, plenty of space
and a clean, dry area for assembly.
Unwrap all packaging materials and place the components on top of the carton box or
on a clean floor to prevent them from scratching.
Check the pack and make sure you have all the parts listed.
Ensure that this product is fully assembled as illustrated before use.
Check all screws or bolts are tightened and inspect regularly
Tools not included unless specified in parts list.
WARNINGS
This product is designed to hold 15Kg distributed evenly throughout the product.
Do not exceed this weight.
We recommend that this unit is assembled in the room intended for use.
This product should only be used on a firm and level floor.
Keep small parts out of reach of children.
Make sure the legs/base remain in contact with the floor.
DO NOT
DO NOT
DO NOT
DO NOT
DO NOT
use power tools to construct this product.
tighten screws until parts are assembled or as advised in this guide. over
tighten screws or bolts.
use this product if parts are missing, damaged or worn.
sit or stand on the product.

JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Version 1 - 180520
Page 3of 6
Parts and Fittings Checklist
Please check the pack contents before assembling the product. If any components are missing,
please contact your retailer. The fittings pack contains small items that should be kept away from
small children.
1
2
3
General Hints & Tips
A26mm
A
A
B
Tighten
Stop when
level
All parts are packed in one carton
Carton No: 1/1
Carton No: 1/1
Qty: 1
Qty: 2
Size: 1050 x 550 x 50 mm
Size: 550 x 350 x 50 mm
1 2
Description: Top Panel Description: Side Panels
2
3
Description: Base Shelf
Qty: 1
Size: 948 x 550 x 50 mm
Carton No: 1/1

JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Version 1 - 180520
Page 4of 6
8A
8B
8C
Item QuantityCode
Fittings (to scale)
Cam Lock
Dowel (8x30mm)
Cam Bolt
10 20 30 40 50 60 70 80
(35mm overall)
Fittings (not to scale)
QuantityCode Item
4K Sticker Cover
STEP 1
Fittings required
For this step:
Tools required
A x8
1
x2
2
A
A
A
A
A
A

JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Version 1 - 180520
Page 5of 6
STEP 2
STEP 3
Fittings required
For this step:
Tools required
B x4
For this step:
Tools required
C x4
3
2
2
Fittings required
B x4
C x4
K x4
1
C
C
C
C
B
B
B
B
Tighten
B
C
C
C
C
C
BK
BK
KB
KB

JAKARTA COFFEE TABLE WITH SHELF ASSEMBLY INSTRUCTIONS
Version 1 - 180520
Page 6of 6
Assembly Completed
Your Jakarta Coffee Table With Shelf is now completely assembled.
Periodically check to ensure that the components are in their proper position, free from damage.
Also, make sure the connectors are tight and secure.
Keep instructions for future reference
