GFW POLAR HIGH GLOSS LED TV UNIT User manual

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
Thank you for purchasing the POLAR HIGH GLOSS LED TV UNIT. Please read the instructions
carefully to ensure safe operation of the product.
COLOUR：WHITE
Size: W1000 x D45 x H48cm
Batch No.WMI16800 (PO#2898)
Page 1 of 12

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
40
Batch No.WMI16800 (PO#2898)
Page 2 of 12

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
Batch No.WMI16800 (PO#2898)
Page 3 of 12
Please check the pack contents before assembling this product. If any components are missing,
please contact your retailer.The fittings pack contains small items that should be kept away from
small children.
1
2
3
45
6
7
8
9
10
11
9
10

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
Batch No.WMI16800 (PO#2898)
Page 4 of 12
TOP PANEL BOTTOM PANEL LEFT SIDE PANEL
RIGHT SIDE PANEL CENTRE PANEL TOP FRONT RAIL
DOOR BACK PANEL BOTTOM FRONT RAIL
BOTTOM SIDE RAIL SHELVE

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
G
H
A
B
C
D
I
J
E
2
1
24
24
6
16
2
4
12
Ref
Fixings ( to scale)
(Not to scale)
QtyDimensions
F 3
CAM BOLT
(40mm)
CAM LOCK
(15mm)
WOODEN SCREW
(7 x 38mm)
SHORT SCREW
(3.5 x 14mm)
DOWEL
(8 x 30mm)
LONG SCREW
(3.5 x 40mm)
HINGE
LED LIGHT
WIRE CLIP
GLASS HOLDER
Batch No.WMI16800 (PO#2898)
Page 5 of 12
If you keep the fittings in a bowl during assembly you will be less likely to lose them!
CAUTION: There are many small components used in the construction of this product.
Please keep these components away from young children whilst assembling this product.

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
Batch No.WMI16800 (PO#2898)
Page 6 of 12

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
LED lights require
2 x AA 1.5v Batteries (NOT SUPPLIED)
D
I
D
x2
A
E
H
AE
A
E
AE
A
E
I
I
1: TOP PANEL x1
A: CAM BOLT x 6
E: DOWEL x 6
H: LED LIGHT x 1
D: SHORT SCREW X 4
I: WIRE CLIP X 2
Batch No.WMI16800 (PO#2898)
Page 7 of 12
OFF
ON
i )
ii )
H
H
H
Secure battery box in desired position using
double sided tape.

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
A
B
J
3
4
6
B
A
3: LEFT SIDE PANEL x 1
4: RIGHT SIDE PANEL x 1
5: CENTRE PANEL x 1
6: TOP FRONT RAIL x 1
A: CAM BOLT x 2
B: CAM LOCK x 2
J: GLASS HOLDER X 4
A
3: LEFT SIDE PANEL x 1
4: RIGHT SIDE PANEL x 1
5: CENTRE PANEL x 1
6: TOP FRONT RAIL x 1
B: CAM LOCK x 6
E: DOWEL x 6
A
B
E
3
4
5
6
x6
STEP 2
STEP 3
Batch No.WMI16800 (PO#2898)
Page 8 of 12
5
A
B
E
AE
B
B
B
E
A
E
A
A
A
J
x2

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
C
E
F
2
8
C
C
C
C
C
C
E
E
F
F
F
2: BOTTOM PANEL X 1
8: BACK PANEL x 1
C: WOODEN SCREW x 6
E: DOWEL x 6
F: LONG SCREW X 3
STEP 4
STEP 5
A
B
9
10
10
9
B
B
B
B
A
A
A
A
9: BOTTOM FRONT
RAIL x 2
10: BOTTOM SIDE
RAIL x 2
A: CAM BOLT x 8
B: CAM LOCK x 8
Batch No.WMI16800 (PO#2898)
Page 9 of 12
3
4
5

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
180
STEP 6
STEP 7
9: BOTTOM FRONT
RAIL x 2
10: BOTTOM SIDE
RAIL x 2
A: CAM BOLT x 8
B: CAM LOCK x 8
9
10
B
A
A
9
10
A
Batch No.WMI16800 (PO#2898)
Page 10 of 12

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
STEP 8
D
G
7
11
D
7
7: DOOR x 1
11: SHELVE x 1
D: SHORT SCREW x 12
G: HINGE x 2
Batch No.WMI16800 (PO#2898)
Page 11 of 12
x2
G
G

POLAR HIGH GLOSS LED TV UNIT
ASSEMBLY INSTRUCTIONS
Batch No.WMI16800 (PO#2898)
Page 12 of 12
