Gigabyte GV-R7032T User manual

GV-R7032T/GV-R7064T
RADEONTM7000 Graphics Accelerator
USER'SMANUAL
中文使用手冊
Upgrade your Life
REV.1.02
12MD-R7064T-102

GV-R7032T/GV-R7064TGraphics Accelerator - 2-
English
Copyright
CopyrightbyGIGA-BYTETECHNOLOGYCO., LTD.(“GBT”)Nopartofthismanual
maybe reproduced ortransmitted inanyfromwithoutthe expressed,written permission of
GBT.
Trademarks
Third-partybrandsand namesarethe propertyoftheirrespectiveowners.
Notice
Due torapidchange intechnology,someofthe specificationsmightbe outofdatebefore
pwblicution ofthisbooklet.
The authorassumesno responsibilityforanyerrorsoromissionswhichmayappearinthis
documentnordoesitmakeacommitmenttoupdatethe information contained herein.
Pleasedo notremoveanylabelson VGAcard,thismayvoidthe warrantyofthisVGA
card.
Jul.03,2003 Taipei,Taiwan
User'sManual
Thisproductincorporatescopyrightprotection technologythatisprotected by
method claimsofcertainU.S.patentsand otherintellectualpropertyrights
owned byMacrovision Corporation and otherrightsowners.Useofthis
copyrightprotection technologymustbe authorized byMacrovision
Corporation,and isintended forhomeand otherlimited viewing usesonly
unless otherwiseauthorized byMacrovision Corporation.Reverseengineer-
ing ordisassemblyisprohibited.

TableofContent-3-
English
TableofContents
1.INTRODUCTION
1.1.PREFACE................................................................................... 4
1.2.KeyFeature................................................................................ 4
2.HARDWAREINSTALLATION
2.1.UNPACKING............................................................................... 5
2.2.BOARD LAYOUT......................................................................... 6
2.3.HARDWAREINSTALLATION....................................................... 7
3.SOFTWAREINSTALLATION
3.1Win98 /WinME/WinXP DriverAnd UtilitiesInstallation ....................... 9
3.1.1Operating systemrequirement .................................................. 9
3.1.2DirectXinstallation ................................................................... 10
3.1.3Driverinstallation .................................................................... 12
3.1.4Utilitieson driverCD ............................................................... 15
3.1.5TaskbarIcon ......................................................................... 16
3.1.6Propertypages..................................................................... 20
3.3.WINDOWS2000 DRIVERINSTALLATION................................... 28
3.4BIOSFLASHUTILITY................................................................ 28
4.Troubleshooting Tips................................................................................. 29
5.Appendix.................................................................................................. 30
5.1Howtoreflashthe BIOS................................................................ 30
5.2Resolutionsand ColorDepthTable............................................... 31

GV-R7032T/GV-R7064TGraphics Accelerator - 4-
English
1.INTRODUCTION
1.1.PREFACE
GV-R7032T/GV-R7064Tdeliversenhanced 3Dand2Dgraphicsperformancefortoday’sdemanding
applications.Powered bythe ATiRADEON™7000 graphics processorand 32 /64 MBDDR memory;
GV-R7032T/GV-R7064TfeaturesHYPERZ™technologytoincreaseeffectivememorybandwidthand
PIXELTAPESTRY™forfastimage rendering.GV-R7032T/GV-R7064Thasindustryleading,built-in
DVDplayback capability.
1.2.KEY FEATURES
nPoweredbytheRADEON™7000 graphics processor
nATIHYPERZ™ technologyreduces memorybandwidthconsumption
resulting inimproved3Dperformance
nIncredible3Dgraphics performance withATIPIXELTAPESTRY™3D
rendering engine
n32MBDDR,64MBDDR
nSilverHeatSinkOnboard
nSupportsDirectX®and OpenGL®
nDVDplayback withintegratedmotion compensation and iDCT
nSupports3Dresolutions(32-bitcolor)up to2048x1536
nAGPuniversalbus(forAGP2X/4Xsystems)
nSupportTV-OUT(Sand AVconnector)Function

HardwareInstallation-5-
English
2.HARDWAREINSTALLATION
2.1.UNPACKING
The GV-R7032T/GV-R7064Tpackage containsthe following:
lThe GV-R7032T/GV-R7064Tgraphics accelerator
lThisUSER'SMANUAL
l DVDPlayersoftwareincluded
lCD fordriver&Utilities
WARNING!
Expansion cardscontainverydelicateIntegrated Circuit(IC)chips.Toprotectthemagainst
damage fromstaticelectricity,you shouldfollowsomeprecautionswheneveryou workon your
computer.
1.Turnoffyourcomputerand unplug powersupply.
2.Useagrounded wriststrap beforehandling computercomponents.Ifyou do nothaveone,touch
bothofyourhandstoasafelygrounded objectortoametalobject, suchasthe powersupply
case.
3.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe components
wheneverthe componentsareseparated fromthe system.
The cardcontainssensitiveelectriccomponents,whichcan be easilydamaged bystatic
electricity,sothe cardshouldbe leftinitsoriginalpacking until itisinstalled.
Unpacking and installation shouldbe done on agrounded anti-staticmat. The operatorshouldbe
wearing an anti-staticwristband,grounded atthe samepointasthe anti-staticmat.
Inspectthe cardcarton forobviousdamage.Shipping and handling maycausedamage toyour
card.Besurethereareno shipping and handling damageson the cardbeforeproceeding.
M DONOTAPPLYPOWERTOYOUR SYSTEMIFITHASBEENDAMAGEDONTHE
CARD.
M Inordertoensureyourgraphics cardworking correctly,please use officialGigabyte
BIOSonlyUse noneofficialgigabyteBIOSmightcause problemon thegraphics
card.

GV-R7032T/GV-R7064TGraphics Accelerator - 6-
English
2.2.BOARD LAYOUT
GV-R7032T(32MBDDR)
GV-R7064T(64MBDDR)
TV-Out
VGAMonitor
Connector
(15pin)
TV-OUT
VGAMonitor
Connector
(15pin)
Analog LCD MonitorAnalog Monitor
ORVGAOutput
AV Output
NTSC/PALTV
Projector
S-VideoOutput

HardwareInstallation-7-
English
2.3.HARDWAREINSTALLATION
Installing YourGraphics card.
Nowthatyou haveprepared yourcomputer,you arereadytoinstall yourgraphics acceleratorcard.
To install yourgraphics acceleratorcard:
1.Poweroff the computerand monitor,then
disconnectthedisplaycablefromthe backofyour
computer.
2.Removethecomputercover.Ifnecessary,consult
yourcomputer'smanualforhelpinremoving the
cover.
3.Removeanyexisting graphics cardfromyour
computer.
Or,ifyourcomputerhasanyon-boardgraphics
capability,you mayneed todisableiton the
motherboard.Formoreinformation,see you
computerdocumentation.

GV-R7032T/GV-R7064TGraphics Accelerator - 8-
English
4.Locatethe AGPslot. If necessary,remove
the metalcoverfromthisslot; then align your
graphics cardwiththeAGPslot, and press it
infirmlyuntil the cardisfullyeated.
AGPSlot
Graphics card
5.Replacethescrewtofasten thecardinplace,
and replacethe computercover.
6.Plug the displaycableintoyourcard;then
turnon the computerand monitor.If your
Graphics cardcamewithaDVIconnector,
you can connectaflatpaneldisplaytothe
appropriateconnector,asshownbelow...
You arenowreadytoproceed withthe installation ofthe Graphics carddriver.Fordetailed
instructions,selectyouroperating systemfromthe listbelow.
ToTVorVCR
ToVGAMonitor

SoftwareInstallation-9-
English
3.SOFTWAREINSTALLATION
Inthismanual, weassumethatyourCD-ROMDrive lettertobeDrive D:
PicturebelowareshowninWindowsXP
3.1.WINDOWS®98 /98SE orWINDOWSME/WINDOWS2000 or
WINDOWSXP DRIVERAND UTILITIES INSTALLATION
The installation ofWin98/98SE /WinME/WinXP driversisverysimple.
When you insertthe driverCD intoyourCD-ROMdrive,you can see the AUTORUN
window(ifitdoesnotshowup,run "D:\setup.exe").Then you can followguidestosetup
yourGV-R7032T/GV-R7064Tdriver(Pleasefollowthe subsection 3.1.3"Step ByStep
Installation"toinstall the driverforyourGV-R7032T/GV-R7064Tgraphics accelerator.
3.1.1.Operating systemrequirement
lIf yourOSisMicrosoft Windows,when loading the GV-R7032T/GV-R7064Tdriversfor
the system,pleasemakesureyoursystem(Win98/98SE orWinME/Win2000 /Win
XP)hasinstalled DirectXorlater.
lIf you install the GV-R7032T/GV-R7064Tdriversforthe mainboard,which
consistofSIS,ALIorVIAchipsets,pleaseinstall the appropriateDriverprogramfor
thatmainboard.OrpleasecontactyourmotherboardnearestdealerforM/BDiver.

GV-R7032T/GV-R7064TGraphics Accelerator - 10 -
English
2.Click "Iacceptthe agreement",
than click"Next"icon.
1.Installation DirectXDriver
Click "Intall Direct9"Item.
3.1.2.DirectXInstallation
Install Microsoft DirectX(orlaterversion)toenable3Dhardwareacceleration supportfor
Windows®98 /98SE /Windows®2000 /Windows®MEorWindows®XP toachievebetter3D
performence.
MNote:ForsoftwareMPEGsupportinWindows®98/98SE/Windows®2000 /
Windows®MEorWindows®XP,you mustinstall DirectX(orlaterversion)first.
DirectX9.0isthe up-to-dateruntimelibraryforall Windowsoperating system.Thisversion is
capableofupdating yourDirectXofyouroperating systemtowhatisrequired foryourgraphics
acceleratorhardwaretorun toitsbestperformance.
Forexample,ifyourgraphics acceleratorcan supportDirectX8.1,updating withDirectX9.0can
upgrade youroperating systemtothe fullsetofDirectX8.1.

SoftwareInstallation-11 -
English
4.Click "Finish"icon torestart
computer.
3.Click "Next"icon.

GV-R7032T/GV-R7064TGraphics Accelerator - 12 -
English
3.1.3.DriverInstallation
The following isthe step-by-step installation guide.
Step1:NewHardwareFound
AfterGV-R7032T/GV-R7064Tisinserted intoyourcomputeratthe firsttime,the windows
will automaticallydetectanewhardwareinthe systemand pop outa"NewHardware
Found"message.Pleaseselect"Donotinstall adriver"and press OK.
Step2:UpdateDevice DriverWizard:StandardPCIGraphics Adapter(VGA)
Step3:UpdateDevice DriverWizard:Finish
Atthistime,systemwill ask foryourWindowsCD inordertocompletethe VGAdriver
installation.
If you don'thavethe CD,you can press C:\Windows\Systemdirectory.
Step4:SystemSetting Change
1.Click "Next"icon.
2.Click "Finish"icon.
MDon'tclick "Cancel",because
the systemwill hang ifyou press it.

SoftwareInstallation-13 -
English
Afterthe systemhasfinished loading,insertthe GV-R7032T/GV-R7064TdriverCD disk
intoyourCD-ROM,and then you can see the AUTORUN window.If itdoesnotshowup,
pleaserun "D:\setup.exe".
3.Click "NO"icon.
Step5:DriverSetup
1.Click "WindowsXP Driver(Radeon
VE Series)"item.
2.Click "Next"icon.

GV-R7032T/GV-R7064TGraphics Accelerator - 14 -
English
2.Click "Yes"icon.
3.Click "Express"than click
"Next"icon.
4.Click "Finish"icon torestart
computer.

SoftwareInstallation-15 -
English
3.1.4.Utilities on driverCD
The utilitiesinclude DisplayDriverand V-Tunerutilities.Pleasebrowsethe driverCD fordetail.
OtherUtility(V-Tunerand Hydravision)
A.Installing V-TunerUtility
2.Click "Next".
3.Enteryournameand company.
4.Click "Finish"torestartcomputer.
Click "V-Tuner"Item.

GV-R7032T/GV-R7064TGraphics Accelerator - 16 -
English
3.1.5TaskbarIcon
Afterinstallation ofthe displaydrivers,you will find an GBTicon on the taskbar'sstatusarea.Right-
clicking thisicon opensthe GBTcontrolpanel,showing amenu composed ofshortcuteofthe graphics
card'senhanced and otherfunctions.
You mayclick the "DisplayProperties"item,and then click Settings.Click "Advanced"afterclickng
Settings.Click the appropriatetab tochange yourdisplaysettings.
You can linktoGBTwebsitefor
updated information aboutthe
graphicscard,latestdrivers,and
otherinformation.
Rightclick the icon.

SoftwareInstallation-17 -
English
V-Tuner(Overclock Utility)
V-Tunerletsyou adjustthe working frequency ofthe graphicengine and video
memory(CoreClock and MemoryClock)
DisplayMemoryClock
CloseV-Tuner
MinV-Tuner
DisplayCoreClock
Display&Adjust
CoreClock
ThisPage CloseV-TunerTo
systemTray
Display&Adjust
MemoryClock

GV-R7032T/GV-R7064TGraphics Accelerator - 18 -
English
VGAInfo
VGAInfoliststhe relevantinformation aboutyourcard.
ColorAdjust
ColorAdjustallowsyou tomakecoloradjustments,suchasbrightness,
contrast, and gammavaluesforeachorall ofRGBcolors.

SoftwareInstallation-19 -
English
Afterinstallation ofthe displaydrivers,you will find anATiicon on the taskbar'sstatusarea.
Clicking thisicon open the ATicontrolpanel.
HYDRAVISION™isprimarilysoftwaredesigned formultiplemonitorsettings.RADEON7000
graphiccardsthathavemorethan one displayoutputcan benefitfullyfromthissoftware.A
RADEON7000 withonlyone displayoutputcan still takeadvantage ofthe manyfeaturesof
HYDRAVISION™.
HYDRAVISION™installation enablesthe Desktop Managerand createsaWindows®program
group forHYDRAVISION™displaymanagementsoftware.
HYDRAVISION™
HYDRAVISION™and theDesktop ManagerareactivatedwheneverWindows®starts.Installing
HYDRAVISION™addsmenu optionstotheATIIcon.
Click on the ATIicon toaccess the application'sfeaturesand help,ortounload the
HYDRAVISION™Desktop Manager.
1.Using SingleDisplay
2.Hydravision

GV-R7032T/GV-R7064TGraphics Accelerator - 20 -
English
3.1.6.Display Propertypages
The screen showsthe information ofdisplayadapter,color,the range ofdisplayarea .
and the refreshrate.
Setting (Resolutionsand Colordepthforwindows)
The Setting propertiespage allowsyou toadjustthe Direct3Dsettings
OptionsProperties
Click"Advanced"icon foradapter
and setting.
You can movethe sliderto
thechange resolution.
You can click the itemtochange the
colordepth.
nVersion Information providesthe Catalyst
versionnumber,2Dversionnumberandthedriver
buildinformation.
nDetailsbutton access tothe Detailstab which
liststhe card'shardwaredetailsand driver
information.
nRe-activateall warning messages allowsyou
toreactivateanydisabled graphics warning
messages.
nEnableATItaskbaricon application enables
ordisablesthe ATItaskbaricon.However,this
featuremustbe enabled forATIhotkeysupport.
nShowATIicon on taskbaraddsorremovesthe ATIicon fromthe taskbar.
nDisablequick resolution featureisaccessiblebyleft-clicking the ATIicon inthe taskbar.
nReduce DVIfrequency on high-resolution displays enablesordisablestoreducethe DVI
frequency when using high-resolution.
