GIGAIPC QBiX-Pro Series User manual

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
1www.gigaipc.com
QBiX-Pro-GLKB5040HD-A1
(QP-5040B-SI)
Industrial Embedded System
Quick Start Guide

2
www.gigaipc.com
Copyright Notice
This document is copyrighted, 2022. All rights are reserved. The
original manufacturer reserves the right to make improvements to the
products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for any
infringements upon the rights of third parties that may result from its
use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its accuracy,
Beijer assumes no liabilities resulting from errors or omissions in this
document, or from the use of the information contained herein.
GIGAIPC reserves the right to make changes in the product design
without notice to its users.

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
3www.gigaipc.com
Acknowledgement
All other products’ name or trademarks are properties of their
respective owners.
• AMD is trademark of Advanced Micro Devices.
• Microsoft Windows is a registered trademark of Microsoft Corp.
• Intel, Pentium, Celeron, and Xeon are registered trademarks of Intel
Corporation
• Core, Atom are trademarks of Intel Corporation
• ITE is a trademark of Integrated Technology Express, Inc.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
All other product names or trademarks are properties of their
respective owners.

4
www.gigaipc.com
Packing List
Before setting up your product, please make sure the following items
have been shipped:
Item Quantity
System 1
Screw HDD M3x3L (P/N: 25984G-1C014-S00) 4
Terminal Blocks 1 x 3P (P/N: 25IO0-5ESDV0-D2R ) 1
Terminal Blocks 1 x 2P (P/N: 25IO0-EC3500-D2R) 1
Terminal Blocks 1 x 10P (P/N: 25IO0-EC3810-D2R) 1
If any of these items are missing or damaged, please contact your
distributor or sales representative immediately.

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
5www.gigaipc.com
About this Document
This User’s Manual contains all the essential information, such as
detailed descriptions and explanations on the product’s hardware
and software features (if any), its specifications, dimensions, jumper/
connector settings/definitions, and driver installation instructions (if
any), to facilitate users in setting up their product.

6
www.gigaipc.com
Safety Precautions
Please read the following safety instructions carefully. It is advised that
you keep this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the
device.
3. Position the power cord so that people cannot step on it. Do
not place anything over the power cord.
4. Always completely disconnect the power before working on the
system’s hardware.
5. No connections should be made when the system is powered
as a sudden rush of power may damage sensitive electronic
components.
6. If the device is not to be used for a long time, disconnect it from
the power supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before
cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray
detergents.
9. Make sure the device is installed near a power outlet and is
easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent
falls
12. Do not cover the openings on the device to ensure optimal heat
dissipation.

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
7www.gigaipc.com
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is
running
15. Never pour any liquid into the openings. This could cause fire or
electric shock.
16. As most electronic components are sensitive to static electrical
charge, be sure to ground yourself to prevent static charge
when installing the internal components. Use a grounding
wrist strap and contain all electronic components in any static-
shielded containers.
17. If any of the following situations arises, please the contact our
service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described
in this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED
ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S
PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO
PREVENT DAMAGE.

8
www.gigaipc.com
FCC Statement
This device complies with Part 15 FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received including
interference that may cause undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions and your local government’s
recycling or disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du fabricant
et les directives gouvernementales de recyclage.

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
9www.gigaipc.com
Table Contents
Industrial Embedded System 1
Quick Start Guide
Copyright Notice .......................................................................... 2
Acknowledgement ....................................................................... 3
Packing List................................................................................... 4
About this Document ................................................................... 5
Safety Precautions ....................................................................... 6
FCC Statement.............................................................................. 8
Chapter 1 - Product Specifications 11
1.1 Specifications ............................................................... 13
Chapter 2 – QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI) 15
2.1 Dimension .................................................................... 16
2.2 Getting Familiar with Your Unit..................................... 17
2.3 A) Wireless Module : How to safely install the Module
(Wireless Module inclusion may vary based on local
distribution) .................................................................. 19
2.4 B) Memory Installation: DDR4 SO-DIMM .................... 20
2.5 Antenna Installation (Antenna inclusion may vary based
on local distribution) .................................................... 21
2.6 Din Rail Bracket Installation .......................................... 22
2.7 HDD Installation ........................................................... 23
2.8 Cable Pin-define ........................................................... 24
2.9 Safety and Regulatory Information............................... 25

10
www.gigaipc.com
Chapter 3 – 3.5” SBC Board/ QBiP-5040B Define 26
3.1 Jumpers and Connectors ............................................. 27
3.2.1 CPU FAN (CPU FAN connector) .................................... 30
3.2.2 USB2 (Vertical USB2.0 connector) ............................... 31
3.2.3 BATTERY (Battery cable connector).............................. 32
3.2.4 JCOM1, JCOM2 (RI# pin RI#/5V/12V Select jumper for
COM1 & COM2 Port) .................................................... 33
3.2.5 SATAPW (SATA power connector) ................................. 34
3.2.6 SATA (SATA 6Gb/s Connector) ....................................... 35
3.2.7 M2M (M.2 Slot, M-Key, NGFF2280).............................. 36
3.2.8 M2E (M.2 Slot, E-key, NGFF2230) ................................. 37
3.2.9 SIM-CARD (SIM Card slot) ............................................. 38
3.2.10 MPCIE (Mini PCIe full size, support 3G/4G module) .... 39
3.2.11 GPIO_CNT (General Purpose input/output header ).... 40
3.2.12 COM3, COM4 (Serial port header, RS-232/422/485).....41
3.2.13 LPC_CN (LPC Connector) .............................................. 42
3.2.14 SYS_PANEL (Front panel header) .................................. 43
3.2.15 SODIMM1 (DDR4 SO-DIMM Slot) ................................. 44
3.2.16 COM1, COM2 (Serial Port connector (RS-232/422/485 &
RI/5V/12V)) .................................................................... 45
3.2.17 LAN1, LAN2 (LAN Connector) ....................................... 46
3.2.18 Headphone Jack(Headphone Jack) ............................... 47
3.2.19 HDMI (HDMI Connector)............................................... 48
3.2.20 VGA (DB-15 VGA Connector) ........................................ 49
3.2.21 USB3 (USB 3.2 Gen 1 Connector).................................. 50
3.2.22 Power Switch (Remote Control connector ) ................. 51

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
11 www.gigaipc.com
3.2.23 Power Button ................................................................ 51
3.2.24 DC_IN (DC IN 1x3pin power connector )...................... 52
Chapter 4 – BIOS 53
4.1 Introduction .................................................................. 54
4.2 The Main Menu............................................................. 55
4.3 Advanced ...................................................................... 56
4.3.1 TPM Configuration........................................................ 57
4.3.2 IT8786 Super IO Configuration ..................................... 59
4.3.3 Hardware Monitor ........................................................ 60
4.3.4 S5 RTC Wake Settings ................................................... 61
4.3.5 CPU Configuration ........................................................ 62
4.3.6 SATA Configuration ....................................................... 63
4.3.7 CSM Configuration........................................................ 64
4.3.8 Digital IO Port Configuration ........................................ 65
4.4 Chipset .......................................................................... 66
4.5 Security ......................................................................... 68
4.6 Boot............................................................................... 70
4.7 Save & Exit .................................................................... 71

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
12 www.gigaipc.com
Chapter 1
Chapter 1 - Product Specifications

13
www.gigaipc.com

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
14 www.gigaipc.com
1.1 Specifications
System QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
Dimension System Size : 160W x 118D x 62.6H(mm)
CPU
Intel® Pentium® Silver J5040 Processor
14nm, 4 cores, 4 threads, up to 3.2 GHz
TDP 10W
Chipset SoC
Memory 1 x DDR4 SO-DIMM sockets, Max. Capacity 8 GB
Support Single Channel DDR4 2400 MHz memory modules
Ethernet 2 x GbE LAN Ports (Intel® I211AT)
Graphic
support
Integrated Graphics Processor -
Intel® UHD Graphics 605:
1 x HDMI port, supporting a maximum resolution of 4096x2160
@60Hz
1 x VGA port, supporting a maximum resolution of 2048×1536
@60Hz
(2 independent display outputs)
Audio Realtek® Audio Codec
Storage 1 x 2.5” HDD/SSD (SATA 6Gb/s)
Expansion
Slots
1 x 2280 M.2 M-Key (SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support
3G/4G module
1 x Vertical USB 2.0
Front I/O
2 x RJ45 LAN Ports
4 x USB 3.2 Gen 1
1 x HDMI
1 x VGA
2 x COM Ports (RS-232/422/485 & RI/5V/12V)
1 x Power button with LED
1 x WiFi/HDD LED
1 x Remote control connector
1 x Headphone Jack
1 x External Antenna Hole (Optional)
Rear I/O 1 x Din Rail Mounting Support

15
www.gigaipc.com
System QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
Side I/O
1 x GPIO (8 bit)
1 x 3-pin Terminal Block
2 x COM Ports (RS-232/422/485)
2 x External Antenna Holes (Optional)
TPM —
Power +9V~36VDC (Full Range)
Operation
temperature
Operating temperature: 0°C to 50°C
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-condensing)
Use wide temperature range memory and storage
Vibration
During
Operation
Operation: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr / Per
Axis, with SSD/M.2 2280
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1
hr / Per Axis
Shock During
Operation
Operation: IEC 60068-2-27, 50 G, half sine, 11 ms duration, With
SSD
Packaging
Content
Carton size: 416 x 409 x 347 (mm)
Packing Capacity: 6pcs
Including:
Screw HDD M3x3L x 4 (P/N: 25984G-1C014-S00)
Terminal Blocks 1*3P x 1 (P/N: 25IO0-5ESDV0-D2R)
Terminal Blocks 1*2P x 1 (P/N: 25IO0-EC3500-D2R)
Terminal Blocks 1*10P x 1 (P/N: 25IO0-EC3810-D2R)
Order
Information System: 6BQP5040BMR-SI (Box packing)

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
16 www.gigaipc.com
Chapter 2
Chapter 2 – QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)

17
www.gigaipc.com
2.1 Dimension

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
18 www.gigaipc.com
2.2 Getting Familiar with Your Unit
[Rear I/O Port on Board]
[Side IO Top Side]
WiFi Antenna x 1 (Optional)COM Ports x 2
(RS-232/422/485)
3G/4G Antenna (Optional)
Headphone
Jack
HDMI VGA USB 3.2
Gen 1
Remote control
Power Butto
n
COM Ports
(RS-232/422/485 & RI/5V/12V)
RJ-45
HDD LED
WiFi LED
[Side IO Down side ]
[Front Side]
DC IN
DIO

19
www.gigaipc.com
[Side IO Top Side]
[Installation]
[Bottom PCB Side]
* Before opening the case, make
sure to unplug the power cord.
* 打 開 機 殼 前，請 確 實 移 除 電 源。
* Before Connecting the power,
make sure to fasten the case
securely.
* 接上電源前，請確實將機殼完整鎖附。
Information
A M.2 2230 WiFi module connector
B Mini PCIe (PCIe + USB2.0) connector
C M.2 2280 SSD connector
D DDR4 2400 MHz SO-DIMM Slot
E USB 2.0 Vertical connector
A
D
B
C
E

System - QBiX-Pro Series QBiX-Pro-GLKB5040HD-A1 (QP-5040B-SI)
20 www.gigaipc.com
2.3 A) Wireless Module : How to safely install the
Module (Wireless Module inclusion may vary based on
local distribution)
3
向下安裝連結於無線模組左側頂端天線。
青山依舊在，幾度夕陽紅。慣看秋月春風。一
壺濁酒喜相逢，浪花淘盡英雄。是非成敗轉頭
Install the antenna on the left side of the connection
wireless module down.
2
Lock the screw in the middle.
鎖入固定於無線模組中央頂端的螺
絲。
1
Carefully insert the wireless module into
the M.2 slot
小心地將無線模組安裝於M.2插槽中。
