GIGAIPC QBiX-JMB-CMLA47EH-A1 Installation and operation manual

Before you begin installing your card, please make
sure that the following items have been shipped:
1. Screw HDD x 20 pcs (25984G-1C014-S00)
2. 4-pin Terminal Blocks Male Plug x 1 pcs
(25IO0-2ESDV0-D2R)
Dimension System Size: 224W x 256.1D x 77.7H(mm)
CPU Support for 10th Generation Intel® Core™
i7/i5/i3, Pentium® and Celeron® processors in
the LGA1200 package, TDP under 65W
Chipset Intel® Q470E Express Chipset
Memory 2 x DDR4 SO-DIMM sockets supporting up to
64 GB,
Dual channel DDR4 3200 MHz
Ethernet 1 x GbE LAN Port (Intel® I219V)
3 x GbE LAN Ports (Intel® I211AT)
Graphic
support
Integrated Graphics Processor - Intel® HD
Graphics support:
1 x DVI-D port, supporting a maximum
resolution of 1920x1080 @60Hz
1 x D-Sub port, supporting a maximum
resolution of 1920x1200 @60Hz
1 x DP port, supporting a maximum resolution
of 4096x2160 @60Hz
3 independent displays output
Audio Realtek® Audio Codec
Storage 4 x 2.5" HDD/SSD (SATA 6Gb/s)
Expansion
Slots
1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot
Caution: DANGER OF EXPLOSION
IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE
SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS.

Front I/O 1 x DC IN (4-pin Terminal Block +12V~48V)
1 x VGA / 1 x DVI-D /1 x DP
2 x COM Ports (RS-232/422/485 & RI/5V/12V)
2 x COM Ports (RS-232)
4 x RJ45 LAN Ports
4 x USB 3.2 Gen 1
6 x USB 2.0
3 x Audio Jacks (Line in, Line out & Mic in)
2 x External Antenna Holes (Optional)
Rear I/O —
Power DC in +12V~48Vdc (Full Range)
Operation
Temperature
Operating temperature: -20°C to 50°C (CPU
65W TDP)
Operating temperature: -20°C to 60°C (CPU
35W TDP)
Operating humidity: 0-90% (non-condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-
condensing)
Use wide temperature range memory and
storage
Vibration
During
Operation
Operation: IEC 60068-2-64, 3 Grms, random,
5 ~ 500 Hz, 1 hr / Per Axis, with SSD/M.2 2280
Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~
500 Hz, 1 Oct/min, 1 hr / Per Axis
Shock During
Operation
Operation: IEC 60068-2-27, 50 G, half sine, 11
ms duration, With SSD
Packaging
Content
Carton size: 300 x 315 x 166 (mm)
Packing Capacity : 1
Including:
Terminal Blocks Male Plug x 1pc
(25IO0-2ESDV0-D2R)
Screw M3x4L x 20pcs (25984G-1C014-S00)
Order
Information
System : 6BQJQ47EAMR-SI (Box packing) No. Code Scription
1 VGA VGA Connector
2 DVI-D DVI-D Connector
3 DP Digital Display Port
4 COM 1/2 RS-232/422/485
5 COM 3/4 RS-232
6 USB 1 4 x USB 3.2 Gen 1
7 USB 2 4 x USB 2.0
8 USB C1 2 x USB 2.0
9 LAN 1 Intel® I219V
10 LAN 2 Intel® I211AT
11 LAN A Intel® I211AT
12 LAN B Intel® I211AT
13 LED Power and Storage Device Status LED
14 DC-12-48V Power connector
15 Audio Audio Jacks (Line in, Line out & Mic
in)

COM3
2 x DDR4 SO-DIMM
sockets
SATA Power Connector
4 x SATA 6 Gb/s
Connector
TPM Connector
M2E Slot
M2M Slot
MINI-PCIe Slot Supports SIM
SIM Card Slot
PCIE X8 Slot PCIE X16 Slot
COM4

QBiX-JMB-CMLA47EH-A1 supports DDR4 SO-DIMM type memory module.
1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove memory thermal cover.
3. Remove the release paper, and assemble memory.
4. Install 4 screws and memory thermal cover.
Note : Thermal pad and memory thermal cover must be fully mated and compacted.
5. Replace the bottom cover and secure with screws.

1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove M2E thermal cover.
3. Install the module in the M2E (Support NGFF-2230 Wifi/BT) slot and secure with screws.
4. Remove the release paper on the thermal pad.
5. Install 4 screws and M2E thermal cover.
6. Replace the bottom cover and secure with screws.

1. Loosen 7 screws and remove the bottom cover
2. Loosen 4 screws to remove storage tray.
3. Secure storage with 4 x screws.
4. Assemble SATA cable/power cable and replace storage tray securely with 4 x screws.
5. Replace the bottom cover and secure with screws.

1. Loosen 7 screws, and then remove the bottom cover
2. Loosen 4 screws to remove the hard disk storage aluminum sheet
3. Loosen the 2 screws to remove the aluminum heat sink.
4. Assemble the M2M (NGFF-2280 SATA) storage hard drive, and remove the release paper which is
on the aluminum heat sink.
5. Install the 2 screws to securely replace the aluminum heat sink and heat sink paste.
6. Install 4 screws to firmly install the hard disk storage aluminum sheet
7. Replace the bottom cover and secure with screws.

QBiX-JMB-CMLA47EH-A1 supports one full size Mini-PCIe.
1. Loosen 7 screws, and then remove the bottom cover
2. Loosen 4 screws to remove the hard disk storage aluminum sheet
3. Assemble the Mini-PCIe expansion Card (Mini-PCIex1 + USB2.0) or 3G/4G SIM Card in SIM Slot.
4. Install 4 screws to firmly install the hard disk storage aluminum sheet
5. Replace the bottom cover and secure with screws.

1. Read these safety instructions carefully.
2. Keep this Startup Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or
spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be
easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause
damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO
NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the power
outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by
transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it to work according to the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE
MAY GO BELOW -40°C (-40°F) OR ABOVE 85°C (185°F). THIS COULD DAMAGE THE EQUIPMENT. THE
EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
17. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area.
18. DISCLAIMER: This set of instructions is given according to IEC 704-1. GIGAIPC disclaims all
responsibility for the accuracy of any statements contained here in.

BIOS (Basic input/output system) provides hardware detailed information and boot-
up options, which include firmware to control, set-up and test all hardware settings.
Therefore, BIOS is the communication bridge between OS/application software and
hardware.
Once the system is power on, press the <DEL> key as soon as possible to access into BIOS
Setup program.
Function keys Description
→← Select Screen
↑↓ Select Item
Enter Execute command or enter the submenu
Increase the numeric value or make changes
Decrease the numeric value or make changes
F1 General Help
F2 Previous Values
F3 Load Optimized Defaults Settings
F4 Save changes & Exit the BIOS Setup program
ESC Exit the BIOS Setup program

The main menu shows the basic system information.
Use arrow keys to move among the items.
Items Description
Project Name Shows Project name information
BIOS Version Shows the BIOS version of the system
Build Date and Time Shows the Build Date and Time when the BIOS was created.
LAN1 MAC Address Shows LAN1 MAC Address information
LAN2 MAC Address Shows LAN2 MAC Address information
LANA MAC Address Shows LANA MAC Address information
LANB MAC Address Shows LANB MAC Address information
Total Memory Shows the total memory size of the installed memory
ME FW version Shows ME firmware version
System Date Set the Date for the system
(Format : Week - Month - Day - Year)
System Time Set the time for the system
(Format : Hour - Minute - Second)

The Advanced menu is to configure the functions of hardware settings through submenu.
Use arrow keys to move among the items, and press <Enter> to access into the related
submenu.

Use TPM Configuration submenu to choose TPM interface.
Item Description
TPM Device
Selection
PTT : Internal TPM (Default setting)
dTPM : External TPM (When using External TPM module or having TPM
chip on MB)

Trusted Computing : Shows TPM information, and TPM module configuration setting.
Item Description
Security Device Support Enabled : Enables TPM feature (Default setting)
Disabled : Disables TPM feature
Pending operation None : No execution will be conducted (Default setting)
TPM clear : Set to clear data on TPM

Item Description
Super IO Chip Shows Super I/O chip model
Serial Port 1 Configuration
Serial Port 2 Configuration
Press [Enter] to configure advanced items :
Serial Port :
Enabled : Enables allows you to configure the serial port settings
Disabled : if Disabled, displays no configuration for the serial port
Device settings :
Display the specified Serial Port base I/O address and IRQ
COM Port Mode :
Choose RS-232, RS-422, or RS-485 feature
Serial Port 3 Configuration
Serial Port 4 Configuration
Press [Enter] to configure advanced items :
Serial Port :
Enabled : Enables allows you to configure the serial port settings
Disabled : if Disabled, displays no configuration for the serial port
Device settings :
Display the specified Serial Port base I/O address and IRQ

Item Description
System Fan 1
Fail Warning
Enabled : Enables System FAN 1 Fail warning alert function
Disabled : Disables System FAN 1 Fail warning alert function (Default setting)
(This setting will effect only if you add the extend kit on the system)
System Fan 2
Fail Warning
Enabled : Enables System FAN 2 Fail warning alert function
Disabled : Disables System FAN 2 Fail warning alert function (Default setting)
(This setting will effect only if you add the extend kit on the system)
System Fan 1
Speed Control
Normal : Fan speed set by BIOS default (Default setting)
Full Speed : Set Fan operates at full speed
(This setting will effect only if you add the extend kit on the system)
System Fan 2
Speed Control
Normal : Fan speed set by BIOS default (Default setting)
Full Speed : Set Fan operates at full speed
(This setting will effect only if you add the extend kit on the system)
CPU Temperature Shows current CPU temperature
System Temperature 1 Shows current System temperature
System Temperature 2 Shows current System temperature for the extend kit of the system
(This numerical value will shows only if you add the extend kit on the system)
System Fan 1
Speed
Shows current System fan 1 Speed for the extend kit of the system
(This numerical value will shows only if you add the extend kit on the system)
System Fan 2
Speed
Shows current System fan 2 Speed for the extend kit of the system
(This numerical value will shows only if you add the extend kit on the system)

Item Description
Wake system
from S5
Enable or Disable System to wake on a specific time.
Disabled : Disables system to wake on a specific time (Default setting)
Fixed Time : Enables system to wake on a specific time
(Format : hr : min : sec)

Item Description
Software Guard
Extensions (SGX)
Disabled : Disables Software Guard Extensions (SGX) (Default seeting)
Enabled : Enables Software Guard Extensions (SGX)
Software Controlled : If this item is selected, SGX will be controlled by SGX
application for UEFI boot OS
Intel Virtualization
Technology
Virtualization enhanced by Intel® Virtualization Technology will allow a platform to
run multiple operating systems and applications in independent partitions. With
virtualization, one computer system can function as multiple virtual systems.
Enabled : Enables Intel Virtualization Technology (Default setting)
Disabled : Disables Intel Virtualization Technology
EIST
According to System loading, Enhanced Intel SpeedStep Technology (EIST)will
automatically adjust the CPU voltage and core frequency to decrease heat and power
consumption for power saving.
Enabled : Enables EIST Technology (Default setting)
Disabled : Disables EIST Technology
CPU C states
Command CPU to enter into low power consumption mode when CPU is under idle
mode.
Enabled : Enables CPU C states function (Default setting)
Disabled : Disables CPU C states function
CPU P states CPU will adjust frequency depends on it's loading. Enabled : Enables CPU P states function
Disabled : Disables CPU P states function (Default setting)
Optimize Performance To optimize CPU performance. Enabled : Enables optimize performance function
Disabled : Disables optimize performance function (Default setting)

Item Description
SATA Mode Selection Set SATA controller to AHCI mode
M.2 SATA Port shows M.2 SSD information
Serial ATA Port 0
shows 2.5" SATA HDD/SSD information
Serial ATA Port 1
Serial ATA Port 3
Serial ATA Port 4

Item Description
Network Stack
When system is power on, install LAN driver under UEFI mode
Disabled : Disables UEFI Network Stack (Default setting)
Enabled : Enables UEFI Network Stack
Ipv4 PXE Support
When Network stack is enabled :
Disabled : Disables Ipv4 PXE Support
Enabled : Enables Ipv4 PXE Support
Ipv6 PXE Support
When Network stack is enabled :
Disabled : Disables Ipv6 PXE Support
Enabled : Enables Ipv6 PXE Support
