GIGAIPC QBiX-JMB-CMLA47EHG-A1 Installation and operation manual

1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
QBiX-JMB-CMLA47EHG-A1
Industrial System with Intel® Q470E Chipset, Support for Intel®
10th Gen. Core™ i Processor and Discrete GFX card support
Startup Manual
Packing List
Before you begin installing your card, please make
sure that the following items have been shipped:
For Main system : 9BQJQ47EAMR-SI
1. Terminal Blocks Male Plug x 1 (P/
N: 25IO0-2ESDV0-D2R)
2. Screw M3x4L x 16 (P/N : 25984G-1C014-S00)
*Quantity of the HDD screws in the accessory kit may decreased based on
actual HDD assemble quantity.
For Expansion slot kit : 6BQJH310APR-SI
1. Screw #6-32x4L x11 (P/N: 25KS2-13004F-S0R)
Dimension
Specifications
Dimension System Size : 224W x 343D x 146H(mm) -
Discrete GFX max 250W support.(Optional)
CPU Support for 10th Generation
Intel® Core™ i9/i7/i5/i3, Pentium® and
Celeron® processors in the LGA1200
package, TDP under 65W
Chipset Intel® Q470E Express Chipset
Memory 2 x DDR4 SO-DIMM sockets, Max. Capacity
64 GB
Support Dual channel DDR4 2933/2666 MHz
memory modules
Ethernet 1 x GbE LAN Port (Intel® I219V)
3 x GbE LAN Ports (Intel® I211AT)
Graphic
Support
Integrated Graphics Processor - Intel® HD
Graphics support:
1 x DVI-D port, supporting a maximum
resolution of 1920x1080 @60Hz
1 x D-Sub port, supporting a maximum
resolution of 1920x1080 @60Hz
1 x DP port, supporting a maximum
resolution of 4096x2160 @60Hz
(3 independent display outputs)
Audio Realtek® Audio Codec
Storage 4 x 2.5" HDD/SSD (SATA 6Gb/s)
Expansion
Slots
1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot (PCIe
x1 + USB2.0) -- support 3G/4G module
1 x PCIe slot -- Discrete riser card support
Caution: DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER, DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS.

2www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Front I/O 1 x Power Switch/Power/HDD LED
3 x Audio Jacks (Line in, Line out, Mic in)
1 x Display port
1 x DVI-D
1 x VGA
2 x COM Ports (RS-232/422/485 &
RI/5V/12V)
2 x COM Ports (RS-232)
4 x RJ45 LAN Ports
4 x USB 3.2 Gen 1
6 x USB 2.0
1 x 4-pin Terminal Block
2 x External Antenna Holes (Optional)
Riser Card
(Optional)
1 x PCIe x4 (Gen3 x4)
1 x PCIe x16 (Gen3 x16)
Power +24V~48VDC (full Range)
-- Support discrete GFX card
Operation
Temperature
For Main system :
Operating temperature: -20°C to 50°C (CPU
TDP 65W)
Operating temperature: -20°C to 60°C (CPU
TDP 35W)
For Full system :
Depends on the Graphic cards installed in
the system
Operating humidity: 0-90% (non-
condensing)
Non-operating temperature: -40°C to 85°C
Non-operating humidity: 0%-95% (non-
condensing)
Use wide temperature range memory and
storage
Vibration
During
Operation
Operation: IEC 60068-2-64, 1 Grms,
random, 5 ~ 500 Hz, 1 hr / Per Axis, With
SSD/M.2 2280 & Without Graphics Cards
Non-operation: IEC 60068-2-6, 2 G, Sine, 10
~ 500 Hz, 1 Oct/min, 1 hr / Per Axis
Shock During
Operation
Operation: IEC 60068-2-27, 50 G, half sine,
11 ms duration, with SSD
Packaging
Content
For Main system : 9BQJQ47EAMR-SI
Carton size: 351 x 300 x 166 (mm)
Packing Capacity: 1pc
Including:
Terminal Blocks Male Plug x 1 (P/N: 25IO0-
2ESDV0-D2R)
Screw M3x4L x 16 (P/N :
25984G-1C014-S00)
*Quantity of the HDD screws in the
accessory kit may decreased based on
actual HDD assemble quantity.
For Expansion slot kit : 6BQJH310APR-SI
Carton size: 460 x 315 x 279 (mm)
Packing Capacity: 1pc
Including:
Screw #6-32x4L x11 (P/N: 25KS2-13004F-
S0R)
System I/O Interface
LAN 1
LAN BLAN ACOM 4
DVI-D
COM 3
External Antenna (optional) External Antenna (optional)
3 x I/O Bracket
VGA
HDD LED
Power switch
COM 1/2
Digital Display
USB2 (USB2.0)
USB1 (USB3.0)
USBC1 (USB2.0)
Audio Jacks
LAN 2
DC IN (4-pin terminal block 24V~48V)
Oeder
Information
System: 9BQJQ47EAMR-SI &
6BQJH310APR-SI
(Built in Components: Please contact
with your sales representative for more
information
or e-mailed to : s[email protected])

3
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Jumpers and Connectors
The board has a number of jumpers that allow you to configure your system to suit your
application. The table below lists the function of each of the jumpers and connectors.
Front I/O Connectors
No. Code Scription
1VGA VGA Connector
2DVI-D DVI-D Connector
3DP Digital Display Port
4COM 1/2 RS-232/422/485
5COM 3/4 RS-232
6USB 1 4 x USB 3.0
7USB 2 4 x USB 2.0
Internal I/O Connectors
COM3
2 x DDR4 SO-DIMM sockets
SATA Power Connector
4 x SATA 6Gb/s Connector
TPM Connector
M2E Slot
M2M Slot
MINI-PCIe Slot Supports SIM
SIM Card Slot
PCIE X8 Slot PCIE X16 Slot
COM4
Front I/O Connectors
8USB C1 2 x USB 2.0
9 LAN 1 Intel® i219V
10 LAN 2 Intel® i211AT
11 LAN A Intel® i211AT
12 LAN B Intel® i211AT
13 LED Power and Storage Device Status LED
14 DC-12-48V Power connector
15 Audio Audio Jacks (Line in, Line out & Mic in)

4www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Expansion I/O Connectors
No. Code Scription
1DC_OUT GPU Power Supply Connector DC Output
2SYS_FAN1 Fan1 Power Connector
3SYS_FAN2 Fan2 Power Connector
4PCIEX4 PCIE X4 Slot
5PCIEX8 PCIE X8 Slot
6PCIEX16 PCIE X16 Slot
DC_OUT SYS_Fan 1 PCIE X4 Slot
PCIE X8 SlotPCIE X16 Slot
SYS_Fan 2
Expansion Front View Expansion Rear View
3 x I/O Bracket System FAN2
System FAN1

5
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
System Dimensions

6www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Simple Installation Process
Memory Installation
QBiX-JMB-CMLA47EH-A1 supports DDR4 SO-DIMM type memory module.
1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove memory thermal cover.
3. Remove the release paper, and assemble memory.
4. Install 4 screws and memory thermal cover.
Note : Thermal pad and memory thermal cover must be fully mated and compacted.
5. Replace the bottom cover and secure with screws.
1
2
3
4

7
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
M2E (Support NGFF-2230 Wifi/BT) Installation
1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove M2E thermal cover.
3. Install the module in the M2E (Support NGFF-2230 Wifi/BT) slot and secure with screws.
4. Remove the release paper on the thermal pad.
5. Install 4 screws and M2E thermal cover.
6. Replace the bottom cover and secure with screws.
1
2
3
4

8www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Storage Installation 1 (2.5” HDD/SSD)
1. Loosen 7 screws and remove the bottom cover.
2. Loosen 4 screws to remove storage tray.
3. Secure storage with 4 x screws.
4. Assemble SATA cable/power cable and replace storage tray securely with 4 x screws.
5. Replace the bottom cover and secure with screws.
1
2
3
4

9
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Storage Installation 2 (M2M Storeage)
1. Loosen 7 screws, and then remove the bottom cover.
2. Loosen 4 screws to remove storage tray.
3. Loosen the 2 screws to remove the aluminum heat sink.
4. Assemble the M2M (NGFF-2280 SATA) storage hard drive.and remove the release paper which is
on the aluminum heat sink.
5. Install the 2 screws to securely replace the aluminum heat sink and heat sink paste.
6. Install 4 screws to firmly install storage tray.
7. Replace the bottom cover and secure with screws.
1
2
3
4

10 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Mini-PCIe Slot (PCIex1 + USB2.0) and SIM Card Slot Installation
QBiX-JMB-CMLA47EH-A1 supports one full size Mini-PCIe.
1. Loosen 7 screws, and then remove the bottom cover.
2. Loosen 4 screws to remove storage tray.
3. Assemble the Mini-PCIe expansion Card (Mini-PCIex1 + USB2.0) or 3G/4G SIM Card in SIM Slot.
4. Install 4 screws to firmly install storage tray.
5. Replace the bottom cover and secure with screws.
1
2
3

11
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
How to combine the QBiX-JMB-CMLA47EH-A1 system & PCI-E extension chassis
QBiX-JMB-CMLA47EHG-A1 is combined with QBiX-JMB-CMLA47EH-A1 and Expansion PCIE Slot Chassis.
1. Loosen 7 screws and remove the bottom cover of QBiX-JMB-CMLA47EH-A1. (refer Figure 1 and 2)
2. Loosen 6 screws and remove the cover of Expansion PCIE Slot Chassis. (refer Figure 3 and 4)
3. Loosen 2 screws on the system fan side of Expansion PCIE Slot Chassis to seperate into 2 parts
as below A & B parts. (refer Figure 5 and 6)
3
4
2
5
6
A
B
1

12 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
How to combine the QBiX-JMB-CMLA47EH-A1 system & PCI-E extension chassis
(Cont.)
4. Assemble 4 screws (Torsion : 4 - 5 kgf.cm) to fix A parts on the QBiX-JMB-CMLA47EH-A1 system
(refer Figure 7)
※Recommend to use at least 15cm length screwdriver.
5. Insert the PCIe riser card into PCI-E slot of QBiX-JMB-CMLA47EH-A1 system from Top to Bottom.
(refer Figure 8)
6. Assemble 5 screws (Torsion : 4 - 5 kgf.cm) to fix B parts on the QBiX-JMB-CMLA47EH-A1 system.
(refer Figure 9)
7. Remove the screws on the IO Bracket, and then insert the graphic card into the PCI-E slot
of PCI-E extension chassis from top to bottom. Connect the power cord in the extension card to
the power connector of the graphics card (refer Figure 10 to 15)
7
A
8
9
B
10
11

13
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
16
17
13
12
14
15
How to combine the QBiX-JMB-CMLA47EH-A1 system & PCI-E extension chassis
(Cont.)
8. Align the three grooves at the bottom of the case with the three iron posts in the fuselage (refer Figure
16 and 17), and place them from top to bottom. (refer Figure 18)

14 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
How to combine the QBiX-JMB-CMLA47EH-A1 system & PCI-E extension chassis
(Cont.)
9. Place the upper edge of the iron shell against the upper edge of the fuselage iron sheet, align the
screw holes, and lock 8 screws (refer Figure 20 and 21) to complete the installation.
20
21
19
18

15
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this Startup Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or
spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may cause
damage.
7. The openings on the enclosure are for air convection. Protect the equipment from overheating. DO
NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the power
outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by
transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened only by qualified
service personnel.
14. If one of the following situations arises, get the equipment checked by service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it to work according to the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE
MAY GO BELOW -40°C (-40°F) OR ABOVE 85°C (185°F). THIS COULD DAMAGE THE EQUIPMENT. THE
EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED
BATTERIES ACCORDING TO THE MANUFACTURER’S INSTRUCTIONS.
17. RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area.
18. DISCLAIMER: This set of instructions is given according to IEC 704-1. GIGAIPC disclaims all
responsibility for the accuracy of any statements contained here in.

16 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
QBiX-JMB-CMLA47EHG-A1
Industrial System with Intel® Q470E Chipset, Support for Intel® 10th
Gen. Core™ i Processor and Discrete GFX card support
BIOS Manual
Introduction
How to Entering into BIOS menu
Function Keys to setup in BIOS Setup program
BIOS (Basic input/output system) provides hardware detailed information and boot-
up options, which include firmware to control, set-up and test all hardware settings.
Therefore, BIOS is the communication bridge between OS/application software and
hardware.
Once the system is power on, press the <DEL> key as soon as possible to access into BIOS
Setup program.
Function keys Description
→← Select Screen
↑↓ Select Item
Enter Execute command or enter the submenu
＋Increase the numeric value or make changes
–Decrease the numeric value or make changes
F1 General Help
F2 Previous Values
F3 Load Optimized Defaults Settings
F4 Save changes & Exit the BIOS Setup program
ESC Exit the BIOS Setup program

17
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Function keys Description
→← Select Screen
↑↓ Select Item
Enter Execute command or enter the submenu
＋Increase the numeric value or make changes
–Decrease the numeric value or make changes
F1 General Help
F2 Previous Values
F3 Load Optimized Defaults Settings
F4 Save changes & Exit the BIOS Setup program
ESC Exit the BIOS Setup program
1. The Main Menu
The main menu shows the basic system information.
Use arrow keys to move among the items.
Items Description
Project Name Shows Project name information
BIOS Version Shows the BIOS version of the system
Build Date and Time Shows the Build Date and Time when the BIOS was created.
LAN1 MAC Address Shows LAN1 MAC Address information
LAN2 MAC Address Shows LAN2 MAC Address information
LANA MAC Address Shows LANA MAC Address information
LANB MAC Address Shows LANB MAC Address information
Total Memory Shows the total memory size of the installed memory
ME FW version Shows ME firmware version
System Date Set the Date for the system
(Format : Week - Month - Day - Year)
System Time Set the time for the system
(Format : Hour - Minute - Second)

18 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
2. Advanced
The Advanced menu is to configure the functions of hardware settings through submenu.
Use arrow keys to move among the items, and press <Enter> to access into the related
submenu.

19
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
2.1 TPM configuration
Use TPM Configuration submenu to choose TPM interface.
Item Description
TPM Device
Selection
PTT : Internal TPM (Default setting)
dTPM : External TPM (When using External TPM module or having TPM
chip on MB)

20 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Trusted Computing : Shows TPM information, and TPM module configuration setting.
Item Description
Security Device Support Enabled : Enables TPM feature (Default setting)
Disabled : Disables TPM feature
Pending operation None : No execution will be conducted (Default setting)
TPM clear : Set to clear data on TPM
