GILBARCO VEEDER-ROOT FlexPay IV CRIND User manual
MDE-5361A
October 2020
FlexPay™ IV CRIND® (with Omnia) Retrofit Kit
Installation Instructions for The Advantage® Series
This page is intentionally left blank
MDE-5361A
i
Table of Contents
SECTION 1 - INTRODUCTION PAGES 1-2
Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Intended Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Required Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Configured Kits - Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Configured Kit Optional Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
S E C T I O N 2 - I M P O R T A N T S A F E T Y I N F O R M A T I O N PAGES 3-4
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
S E C T I O N 3 - R E M O V I N G C O M P O N E N T S PAGES 5-10
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Left Option Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CRIND Electronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
AFP/HIP 2/DCM2/DCM2.x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
S E C T I O N 4 - I N S T A L L A T I O N PAGES 11-22
FlexPay IV CRIND Retrofit Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Left Option Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Omnia Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
AC Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The Advantage Series Units Built Prior to 1999 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
AC Power Distribution Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
The Advantage Series Units Built After 1999 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Completing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Registering Kits with Gilbarco Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
S E C T I O N 5 - R E F E R E N C E I N F O R M A T I O N PAGES 23-24
Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Abbreviations and Acronyms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
S E C T I O N 6 - A P P E N D I X PAGES 25-40
ii
MDE-5361A
Appendix A: PCB, Connections, and LED Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Omnia PIP Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Omnia Assembly Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Omnia PIP LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Omnia LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
UPM Board Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Appendix B: System Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix C: Verifying Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Cable Connections on Display Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Appendix D: DCM3 Assembly (M15724A001) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
FCC Supplier’s Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
1
SECTION 1 - INTRODUCTION
1
MDE-5361A
Purpose
This manual provides instructions to install a 5.7-inch Color Screen FlexPay™ IV CRIND® (with Omnia)
Retrofit Kit into The Advantage® Series. The Advantage Series includes configurations with or without
CRIND. The FlexPay IV CRIND provides a secure payment platform that is EMV®-certified and Payment Card
Industry PIN Entry Device (PCI-PED)-certified.
This manual also includes instructions for installing the Omnia board, which replaces the Dispenser
Communication Module (DCM)2.X [including Gilbarco Systems on Module (GSoM) Printed Circuit Board
(PCBs)] in the FlexPay IV units.
Intended Users
This manual is intended for Gilbarco®-trained and certified Authorized Service Contractors (ASCs).
Required Tools
• Phillips® and Flat-blade Screwdrivers
• 1/4-inch Socket Set (Nut Driver)
• 7- and 8-mm Socket (Nut Driver or Socket Set)
• Diagonal Cutters
• Needle Nose Pliers
• T15 or T20 Torx Driver, depending on the Universal Payment Module (UPM)
• Universal Joint Socket Adapter
• Putty Knife or Scraping Tool (if required)
Configured Kits - Parts List
FlexPay IV CRIND Retrofit Kits are configured based on the serial number of the pump/dispenser unit for
which they are intended. Therefore, the parts list will vary for each configured kit and unit/option type.
For additional part details, refer to the Bill of Materials (BOM) in the kit, contact your distributor, or contact
Gilbarco Customer Service.
A common FlexPay IV CRIND (with Omnia) Retrofit Kit will include the following parts:
• CIM™ insert with UPM assembly (keypad), UX300, display card reader, Omnia Peripheral Interface PCB
(PIP) Assembly
• T-rail assembly with Omnia assembly
• Universal Serial Bus (USB) Printer assembly
• Applause™ Media System, Omnia assembly
MDE-5361A
2
SECTION 1 - INTRODUCTION
1
Configured Kit Optional Components
The following parts are potential configured kit optional components:
• UX400 Contactless Card Reader
• Cabinet Heater (optional for 5.7-inch display)
For a complete parts list of the configured kit, refer to the build ticket that is provided with the kit.
Note: Printers will be needed for all units.
Components
For a complete parts list, see the packing list. The following parts are critical components for
FlexPay IV with Omnia:
Location Description Part # Notes
Located on Left Door Assembly, Advantage Door M14500 Variants are color
5.7” Softkeys M01254A003
5.7” Color Display M10369B001
M10369B003
Ampire
AM320240SNTN-QW16H
PCA, Omnia PIP M15649A001
Card Reader, VeriFone® UX300 M14330A001
Contactless Card Reader, VeriFone,
UX400
M14331A001
Printer Assembly M12479A001 Print head: M13832A001
Cable, Wire and Speaker M09259A001
Located on CRIND Tray Assembly, UPM M13888AXXX “XXX” varies based on
customer requirement
Omnia Assembly Omnia M16181A002
DCM3 M15724A001
Phoenix Supply M04161B001
Fuse Board M05748A001
MDE-5361A
3
SECTION 2 - IMPORTANT SAFETY INFORMATION
2
Important Safety Information
Notes: 1) Save this Important Safety Information section in a
readily accessible location.
2) Although DEF is non-flammable, Diesel is flammable.
Therefore, for DEF cabinets that are attached to
Diesel dispensers, follow all the notes in this section
that pertain to flammable fuels.
This section introduces the hazards and safety precautions
associated with installing, inspecting, maintaining or servicing this
product. Before performing any task on this product, read this safety
information and the applicable sections in this manual, where
additional hazards and safety precautions for your task will be found.
Fire, explosion, electrical shock or pressure release could occur and
cause death or serious injury, if these safe service procedures are
not followed.
Preliminary Precautions
You are working in a potentially dangerous environment of
flammable fuels, vapors, and high voltage or pressures. Only trained
or authorized individuals knowledgeable in the related procedures
should install, inspect, maintain or service this equipment.
Emergency Total Electrical Shut-Off
The first and most important information you must know is how to
stop all fuel flow to the pump/dispenser and island. Locate the switch
or circuit breakers that shut off all power to all fueling equipment,
dispensing devices, and Submerged Turbine Pumps (STPs).
The EMERGENCY STOP, ALL STOP, and PUMP
STOP buttons at the cashier’s station WILL NOT
shut off electrical power to the
pump/dispenser. This means that even if you activate
these stops, fuel may continue to flow uncontrolled.
You must use the TOTAL ELECTRICAL
SHUT-OFF in the case of an emergency and not the
console’s ALL STOP and PUMP STOP or similar
keys.
!
WARNING
!
Total Electrical Shut-Off Before Access
Any procedure that requires access to electrical components or the
electronics of the dispenser requires total electrical shut off of that
unit. Understand the function and location of this switch or circuit
breaker before inspecting, installing, maintaining, or servicing
Gilbarco equipment.
Evacuating, Barricading and Shutting Off
Any procedure that requires access to the pump/dispenser or STPs
requires the following actions:
• An evacuation of all unauthorized persons and vehicles from the
work area
• Use of safety tape, cones or barricades at the affected unit(s)
• A total electrical shut-off of the affected unit(s)
Gilbarco Veeder-Root encourages the recycling of
our products. Some products contain electronics,
batteries, or other materials that may require special
management practices depending on your location.
Please refer to your local, state, or country
regulations for these requirements.
Read the Manual
Read, understand and follow this manual and any other labels or
related materials supplied with this equipment. If you do not
understand a procedure, call a the Gilbarco Technical Assistance
Center (TAC) at 1-800-743-7501. It is imperative to your safety and
the safety of others to understand the procedures before beginning
work.
Follow the Regulations
Applicable information is available in National Fire Protection
Association (NFPA) 30A; Code for Motor Fuel Dispensing Facilities
and Repair Garages, NFPA 70; National Electrical Code (NEC),
Occupational Safety and Health Administration (OSHA) regulations
and federal, state, and local codes. All these regulations must be
followed. Failure to install, inspect, maintain or service this
equipment in accordance with these codes, regulations and
standards may lead to legal citations with penalties or affect the safe
use and operation of the equipment.
Replacement Parts
Use only genuine Gilbarco replacement parts and retrofit kits on your
pump/dispenser. Using parts other than genuine Gilbarco
replacement parts could create a safety hazard and violate local
regulations.
Federal Communications Commission (FCC) Warning
This equipment has been tested and found to comply with the
limits for a Class A digital device pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used
in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense. Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate this
equipment.
Safety Symbols and Warning Words
This section provides important information about warning symbols
and boxes.
Alert Symbol
This safety alert symbol is used in this manual and on
warning labels to alert you to a precaution which must be
followed to prevent potential personal safety hazards. Obey
safety directives that follow this symbol to avoid possible
injury or death.
Signal Words
These signal words used in this manual and on warning labels tell
you the seriousness of particular safety hazards. The precautions
below must be followed to prevent death, injury or damage to the
equipment:
DANGER: Alerts you to a hazard or unsafe practice which
will result in death or serious injury.
WARNING: Alerts you to a hazard or unsafe practice that
could result in death or serious injury.
CAUTION with Alert symbol: Designates a hazard or unsafe
practice which may result in minor injury.
CAUTION without Alert symbol: Designates a hazard or
unsafe practice which may result in property or equipment
damage.
!
!
!
MDE-5361A
4
SECTION 2 - IMPORTANT SAFETY INFORMATION
2
Working With Fuels and Electrical Energy
Prevent Explosions and Fires
Fuels and their vapors will explode or burn, if ignited. Spilled or
leaking fuels cause vapors. Even filling customer tanks will cause
potentially dangerous vapors in the vicinity of the dispenser or
island.
DEF is non-flammable. Therefore, explosion and fire safety
warnings do not apply to DEF fluid lines.
No Open Fire
Open flames from matches, lighters, welding torches or
other sources can ignite fuels and their vapors.
No Sparks - No Smoking
Sparks from starting vehicles, starting or using power tools,
burning cigarettes, cigars or pipes can also ignite fuels and their
vapors. Static electricity, including an electrostatic charge on your
body, can cause a spark sufficient to ignite fuel vapors. Every time
you get out of a vehicle, touch the metal of your vehicle, to
discharge any electrostatic charge before you approach the
dispenser island.
Working Alone
It is highly recommended that someone who is capable of rendering
first aid be present during servicing. Familiarize yourself with
Cardiopulmonary Resuscitation (CPR) methods, if you work with or
around high voltages. This information is available from the
American Red Cross. Always advise the station personnel about
where you will be working, and caution them not to activate power
while you are working on the equipment. Use the OSHA Lockout/
Tagout procedures. If you are not familiar with this requirement,
refer to this information in the service manual and OSHA
documentation.
Working With Electricity Safely
Ensure that you use safe and established practices in working with
electrical devices. Poorly wired devices may cause a fire, explosion
or electrical shock. Ensure that grounding connections are properly
made. Take care that sealing devices and compounds are in place.
Ensure that you do not pinch wires when replacing covers. Follow
OSHA Lockout/Tagout requirements. Station employees and service
contractors need to understand and comply with this program
completely to ensure safety while the equipment is down.
Hazardous Materials
Some materials present inside electronic enclosures may present a
health hazard if not handled correctly. Ensure that you clean hands
after handling equipment. Do not place any equipment in the mouth.
The pump/dispenser contains a chemical known to the State
of California to cause cancer.
WARNING
!
The pump/dispenser contains a chemical known to the State
of California to cause birth defects or other reproductive
harm.
WARNING
!
In an Emergency
Inform Emergency Personnel
Compile the following information and inform emergency
personnel:
• Location of accident (for example, address, front/back of
building, and so on)
• Nature of accident (for example, possible heart attack, run over
by car, burns, and so on)
• Age of victim(for example, baby, teenager, middle-age, elderly)
• Whether or not victim has received first aid (for example,
stopped bleeding by pressure, and so on)
• Whether or not a victim has vomited (for example, if swallowed
or inhaled something, and so on).
Gasoline/DEF ingested may cause unconsciousness
and burns to internal organs. Do not induce vomiting.
Keep airway open.
Oxygen may be needed at scene. Seek medical
advice immediately.
DEF generates ammonia gas at higher temperatures. When
opening enclosed panels, allow the unit to air out to avoid
breathing vapors.
If respiratory difficulties develop, move victim away from source
of exposure and into fresh air. If symptoms persist, seek medical
attention.
WARNING
!
WARNING
!
Gasoline inhaled may cause unconsciousness and
burns to lips, mouth and lungs.
Keep airway open.
Seek medical advice immediately.
WARNING
!
Gasoline/DEF spilled in eyes may cause burns to eye
tissue.
Irrigate eyes with water for approximately
15 minutes.
Seek medical advice immediately.
WARNING
!
Gasoline/DEF spilled on skin may cause burns.
Wash area thoroughly with clear water.
Seek medical advice immediately.
WARNING
!
DEF is mildly corrosive. Avoid contact with eyes, skin, and
clothing. Ensure that eyewash stations and safety showers are
close to the work location. Seek medical advice/recommended
treatment if DEF spills into eyes.
WARNING
!
IMPORTANT: Oxygen may be needed at scene if gasoline has been
ingested or inhaled. Seek medical advice immediately.
Lockout/Tagout
Lockout/Tagout covers servicing and maintenance of machines and
equipment in which the unexpected energization or start-up of the
machine(s) or equipment or release of stored energy could cause
injury to employees or personnel. Lockout/Tagout applies to all
mechanical, hydraulic, chemical, or other energy, but does not cover
electrical hazards. Subpart S of 29 CFR Part 1910 - Electrical
Hazards, 29 CFR Part 1910.333 contains specific Lockout/Tagout
provision for electrical hazards.
5
SECTION 3 - REMOVING COMPONENTS
3
MDE-5361A
Before You Begin
Ensure that the unit is functional. Check with the manager for any existing
operational issues. If the unit has any special features, such as TRIND®,
barcode scanner, and so on, verify proper operation before removal. Print a
system health report to verify printer and CRIND functions.
IMPORTANT INFORMATION
CAUTION
A properly grounded Electrostatic Discharge (ESD) wrist strap must be worn
while servicing any electronic devices or components. Failure to use
electrostatic precautions may damage electronic components and void
warranty.
To prepare the site and unit for the installation:
1 Perform an inventory of the parts list provided. Ensure that there is no damage to the parts and that all
the parts are accounted for based on the BOM shipped with the kit. Ensure that you carry the
recommended spare parts to the installation site.
Note: Retain all parts (including cables, nuts, bolts, screws, and so on) that are removed. These are
required in case the unit must be reverted to the original as a fallback mitigation.
2 Read all the safety information found in “Important Safety Information” on page 3. Perform a Job
Safety Analysis (JSA) before beginning the installation.
3 Inform the manager.
4 Barricade the unit to be worked on.
5 Check the current state of the unit.
a Verify that the printer firmware is version 3.00 or later by removing and refeeding paper to the
printer while it is still powered.
Note: If the software is not V3.00 or later, be prepared to update the printer software.
b Verify site and dispenser operation.
c Perform a fueling transaction, including printing a receipt.
d Check Applause for idle and busy media (if applicable). Verify video and audio.
e Verify all unit options are functional (for example, intercom).
f Check the pump software version and update to the latest version, if necessary.
MDE-5361A
6
SECTION 3 - REMOVING COMPONENTS
3
6 Remove power to the unit at the breaker panel. Follow OSHA lockout/tagout procedures.
7 Isolate the two-wire, any Ethernet® cabling, and any network connections from the unit.
Failure to turn off the power to the unit during kit installation may cause injury or bodily
harm from electrical shock. Ensure that all power to the unit is turned off before
opening the door to the unit and during installation.
WARNING
Left Option Door
To remove the left option door:
1 Open the main door by loosening the lower screws that secure the lower portion of the main door and
then open the left and right option doors. Release the four main door latches.
2 Disconnect all the cables from the left option door, CRIND display, card reader, and Contactless Smart
Card (CSC) antenna (if applicable).
Note: Discard the CSC antenna cables as they cannot be reused.
Figure 1: Opening Left Option Door
3 Remove the left option door by pulling the hinge pin up through the hole.
Note: The left option and the main door must be open to gain access to the hinge pin.
4 Remove any existing old gaskets on the option door opening using a putty knife or scraping tool.
5 Remove any customer supplied locks and add to the new option door.
7
SECTION 3 - REMOVING COMPONENTS
3
MDE-5361A
CRIND Electronics
Note: If the unit is not equipped with CRIND, proceed to the installation instructions beginning with
“FlexPay IV CRIND Retrofit Kit” on page 11.
To remove the existing CRIND electronics from the cabinet:
1 Disconnect all the cables connected to the CRIND tray.
2 Disconnect the cables that are connected to the printer. Then remove all the CRIND cables and place
with the CRIND tray, when removed.
3 Remove the CRIND tray by pulling it out toward you and lifting it out of the support bracket
(see Figure 2 (i) and (ii)).
Figure 2: Removing CRIND Tray
(ii)
(i)
MDE-5361A
8
SECTION 3 - REMOVING COMPONENTS
3
4 Remove the tray and carefully place it in a safe location.
5 Remove the tray support slide rails.
Figure 3: Removing Tray Support Slide Rails
Tray Support
Slide Rail
Printer
To remove the printer, disconnect all printer cables and remove the existing printer(s) by removing the three
or four nuts underneath.
Note: The printer cables can be discarded.
Figure 4: The Advantage Series Printer
(i) (ii)
Printer Front View Printer Rear View
MDE-5361A
10
SECTION 3 - REMOVING COMPONENTS
3
2 Remove the two M00414B005 M4 Nuts to detach the AFP, HIP 2, or DCM2/DCM2.x bracket.
Figure 6: Mounting Bracket
(i) (ii)
M4 Nuts
11
SECTION 4 - INSTALLATION
4
MDE-5361A
FlexPay IV CRIND Retrofit Kit
Left Option Door
To install the new left option door:
1 Place the new left option door in the opening.
2 Re-insert the hinge pin to secure the new left option door.
Figure 1: Installing Left Option Door
(i) (ii)
Rear View of Left Option Door Front View of Left Option Door
New Left Option
Door Installed
MDE-5361A
12
SECTION 4 - INSTALLATION
4
Omnia Assembly
To install the Omnia assembly, proceed as follows:
1 Attach the Omnia bracket to Advantage Adapter Bracket (M15122A001) using three M00414B005 M4
Nuts supplied in the kit.
Figure 2: Attaching Omnia Bracket
(i) (ii)
2 Attach this assembly underneath the Advantage printer shelf, opposite of the main power supply,
using the two holes vacated by the right side CRIND tray rail. Secure with two M00414B005 M4 Nuts.
Figure 3: Mounting Omnia Assembly
Printer Shelf
Adapter Bracket
3 Continue with instructions to connect cables.
13
SECTION 4 - INSTALLATION
4
MDE-5361A
Connecting Cables
To connect the cables:
Note: Ensure that the AC cables are not bundled with any non-AC cables.
1 Connect J104 of the M12777A004 Cable to the M04406A001 AC Distribution Cable in the U-channel.
2 Connect P301A/B of the M14340 Cable side A to J301A of the M12777A004 Cable.
3 Connect P301A/B of the M14340 Cable side B to J301B of the M12777A004 Cable.
4 Connect the Ethernet cable to the card reader. The yellow Category 5 (CAT5) cable in the kit matches
the yellow connector on the Omnia PCB (for dedicated side).
Figure 4: Connecting Ethernet Cable to the UX300 Card Reader
Figure 5: M12777A004 Cable Connection
Omnia PWR Input-J6001
DCM3-J511
AC Input -P104
Side A J301A
MDE-5361A
14
SECTION 4 - INSTALLATION
4
5 Connect the USB cable from the printer to Omnia PIP, using the port on the left side.
Note: Ensure that the USB printer cable is seated.
Figure 6: Omnia PIP (M15649A001) Connections
Display Power
P219 - Audio
Input from
Omnia
P212 - Audio
Output from
Speaker
P214D - USB
P214F - USB
Uplink from
UPM
JP1 - Beeper
Input from
UPM
P213 - Beeper
Input from
UPM
P204 - TRIND
Serial
connection
P214A - USB
P214C - USB
P213 - Video
Input from
UPM
P214B -
USB to
Printer
JP2 - Side
Select
Jumper
P220 - 24
VDC Input
15
SECTION 4 - INSTALLATION
4
MDE-5361A
6 Connect P212 to speaker.
Figure 7: Omnia Speaker Connection
Notes: 1) If Applause Media System is installed, there will also be a new audio cable from Omnia PIP and a
video cable from Omnia to UPM. Audio Cable (M14425A002) goes from P419L to Omnia PIP P219.
Video Cable (M14338A00X) goes from Omnia P1 for Side A UPM and Omnia P2 for Side B UPM to
UPM P6.
2) On the Omnia PIP, the J202 connection (RS-232 Serial Cable) will not be used. The cable can be
removed or tucked away neatly on the door.
MDE-5361A
16
SECTION 4 - INSTALLATION
4
7 Connect all the applicable cables to the Omnia assembly as shown in Figure 8. For additional details
regarding direct CAT5 connections, refer to MDE-5369F FlexPay IV (with Omnia) Programming and
Service Manual Insite360™ Forecourt with Applause Media System.
Figure 8: Omnia Board Connections
Other manuals for FlexPay IV CRIND
1
Table of contents
Other GILBARCO VEEDER-ROOT Payment Terminal manuals
