GILES GGF Series Installation and operating instructions

Model
GGF-400
GGF-720
Printed in USA, Form No. 65474 (Rel. Jan.2009; Rev. Mar.2020; Rev. G)
Operations & Service Manual GGF Series Fryer
ISO 9001 Registered • Committed to Quality
2750 G nter Park Drive West • Montgomery, AL 36109 USA
Toll Free: 800.554.4537 (USA & Canada Only) Other: 334.272.1457
Fax: [phone] • Website: www.gfse.com • Email: [email protected]

IN A PROMINENT LOCATION, post instruction for actions to be taken in the event users smells gas. This
information can be obtained by contacting the local gas utility company.
•DO NOT install and/or use gas fired appliances in areas without sufficient ventilation
to provide an ade uate room air exchange rate to prevent accummulation of
combustion flue gases (carbon monoxide & CO2). Improper installation and use can
cause personal injury, even death.
•Read the installation, operating, and maintenance instructions thoroughly before
installing and attempting to operate or service this appliance.
FOR YOUR SAFETY
DO NOT store or use flammable liquids or materials, or those which may produce
flammable vapors, in the vicinity of this or any other appliance.

LIMITED WARRANTY
• Subjec o he erms and condi ions of his Limi ed Warran y as herein s a ed, all Giles En erprises Inc.
(hereaf er referred o as “Giles”) food service equipmen and par s purchased new from an au horized Giles
represen a ive are warran ed as o defec s in ma erial or workmanship for a period of wen y-four (24)
mon hs from he da e of ins alla ion, provided, however, ha wi h regard o labor cos s in connec ion wi h
his warran y, see below. All ins alla ions mus be made by a qualified ins alling agency in accordance wi h
all applicable codes and/or regula ions in he jurisdic ion in which ins alled. Limi ed warran y coverage is
ex ended only o he original owner and is void if he uni is resold.
• During he Limi ed Warran y period, Giles will replace or recondi ion, a i s fac ory, any par or par s of his
uni which Giles inspec ors judge defec ive, provided he uni has been properly ins alled, subjec ed o
normal usage, and opera ed and main ained in accordance wi h specified procedures. This Limi ed Warran y
does no cover cosme ic damage, and damage due o ac s of God, acciden , misuse, al era ion, negligence,
abuse, or use of unor hodox repair me hods. All par s replaced under his Limi ed Warran y carry only he
unexpired erm of his Limi ed Warran y. Limi ed Warran y service may be furnished only by an au horized
Giles service represen a ive.
• If Limi ed Warran y service is reques ed, Giles will dispa ch fac ory-au horized service represen a ives o
inspec , repair, recondi ion, or replace uni s of i s manufac ure wi h such labor being rendered wi hou cos
o owner for wen y-four (24) mon hs from he da e of ins alla ion. O herwise, service, including labor and
ranspor a ion charges or o her expenses, in connec ion wi h he removal or ins alla ion of any par or par s
supplied under his Limi ed Warran y, are specified on he original sales con rac be ween he purchaser and
he au horized Giles represen a ive.
•Failure to use Giles OEM replacement parts and Giles OEM filters may void this Warranty.
• Giles reserves he righ o change or improve i s equipmen and/or par s in any way wi hou obliga ion o
al er such equipmen or par s previously manufac ured.
• Giles makes no fur her warran ies, express or implied, including implied warran ies of merchan abili y or
fi ness for a par icular purpose, and has no o her obliga ion or liabili y no specifically s a ed herein.
• Repair or replacemen as provided under his limi ed warran y is he exclusive remedy. Giles shall no be
liable for any inciden al or consequen ial damages for breach of any express or implied warran y on his
produc , excep o he ex en prohibi ed by applicable law. Any implied warran y of merchan abili y or
fi ness for a par icular purpose on his produc is limi ed in dura ion o he dura ion of his limi ed warran y.
• Used Giles food service equipmen or par s, or Giles food service equipmen or par s no purchased from an
au horized Giles represen a ive, carry no warran ies, express or implied.

Model: GGF-400, GGF-720
Table Of Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Safety Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
Specific Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vi
. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1. Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2. Standard Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Optional Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.4. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4.1. Overall Dimensions: GGF-400 & GGF-720. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.4.2. Agency Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4.3. Bas et Sizes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4.4. Coo ing Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.1. Appliance Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2. Upac ing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3. Clearances, Gas Supply, and Electrical Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4. Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5. Utility Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5.1 Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.5.2 Fuel Gas Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.6. Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.7. Gas Line Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.7.1 Typical Gas Supply Line Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.8 Gas Orifices: Informations & Replacement Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.9. Gas Pressure Setting and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.10 Blower Vacuum Switch Setting and Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2-11 Restraint Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1. Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.2. Lower Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3. Filter Pan Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.4. Bas et and Elevator Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.5. Accessories (Included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.6. Accessories (Not Included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4. Pre-Operation Checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4.1. Set-up Before Performing Each Chec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2. Power Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.3. Burner System Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.4. Filter Pump Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.5. Perform Boil Out Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.6. Clean Filter Pan and Fryer Acessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
iii

iv
Model: GGF-400, GGF-720 Table Of Contents
5. Fryer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.1. Computer Coo ing Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.1.1. Keys and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.1.2. General Operation - Fryer Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.1.3. Manually Setting a Coo Time & Coo ing Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.1.4. Wor ing with Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.1.4.1. Editing a Menu Item Preset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.1.4.2. Selecting a Menu Preset for Coo ing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.1.5. Coo ing Cycle - General Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.1.6. Other Controller Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.1.6.1. Manually Operating the Bas et Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.1.6.2. COOL Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.6.3. AUTO-COOL Feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.6.4. Boil-Out Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.1.7. User Settings - Access & Edit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.8. PASSWORD Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.1.9 Start-up Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.1.10 Controller Errors and Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.1.10.1 Resolving Controller Errors and Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.2. Coo ing Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.3. Filtering Coo ing Oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.4. Removing Waste Oil from Fryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
5.5. Normal Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.6. Emergency Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.1. Boil-Out Procedure (Cleaning the Fry Pot). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
6.2. Cleaning the Filter Pan and Replacing Filter Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.1. Temperature Control System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.2. Oil Filtration System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7.3. Bas et Lift System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8. Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8.1. Parts Ordering and Service Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8.2. Front Header & Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8.3. Front Lower Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.4. Rear Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
8.5. Plumbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
8.6. Bas et & Bas et Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
8.7. Filter Pan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

v
Safety Model: GGF-400, GGF-720
Safety
Safety Overview:
Indicate an imminently hazardou ituation which, if not avoided, will re ult in eriou per onal injury, even
death.
Indicate a potentially hazardou ituation which, if not avoided, could re ult in eriou injury, even death.
Indicate a potentially hazardou ituation which, if not avoided, may re ult in minor to moderate injury. Thi
notification i al o u ed a an alert to un afe practice .
If u ed without the afety alert ymbol, indicate a potentially hazardou ituation which, if not avoided, may
re ult in equipment and/or property damage, and may void the factory warranty.
NOTE or IMPORTANT!
Identifie ugge ted, recommended, or other important information.
The in truction contained in thi manual have been prepared to aid in learning the proper procedure for in talling,
operating and ervicing Giles Model GGF Series Gas Fryer.
Throughout the manual, afety precaution are identified by a hazard alert ymbol and key word uch a DANGER,
WARNING or CAUTION. Alert information precede the ta k to which it applie . Sugge ted, recommended, or
other noteworthy information i identified a NOTES, or will be noted a IMPORTANT!. Additionally, certain word
are u ed to indicate a pecific meaning, or to add empha i a follow :
Shall: under tood to be mandatory.
Should: under tood to be advi ory.
May: under tood to be permi ive.
Will: indicate a future event or condition to occur.
Hazard Alert Symbols are u ed in conjunction with key word , uch a DANGER, WARNING, or
CAUTION, to alert u er of potential per onal injury hazard and/or poor operating practice . The e will
immediately precede precautionary mea ure pertaining to avoiding uch hazard or practice . Adhere to all
information following the e ymbol to avoid po ible injury, or even death. Failure to do o may al o void the
factory warranty.
This product can expose Users to chemicals including lead, nickel, cobalt, aluminum, cadmium, brass,
carbon, copper or BPA which are known in the state of California to cause cancer, birth defects and other
reproducti e harm. For more information go to: www.p65warnings.ca.go .

vi
Safety
Model: GGF-400, GGF-720
• Before cleaning or performing maintenance, place power witch in the [OFF] po ition. Unplug power cord or
turn OFF power at the electrical panel upplying power to remove all power from the appliance. Clo e ga
upply valve and place the fryer ga valve in the [OFF] po ition.
• DO NOT wa h down the fryer with water from a pray ho e.
• Failure to comply with DANGER notice will re ult in eriou injury, even death; or damage to equipment and/or
property and may void the factory warranty.
Specific Safety Precautions:
For your afety, plea e ob erve the following precaution when operating or ervicing the GGF Series Gas Fryer.
Adhering to the following important afety precaution will help U er to avoid per onal injury and/or damage to
the equipment.
•Fryer must be installed and used in locations that have ventilation to the outside and be sufficient to provide
an adequate fresh air exchange rate necessary to prevent accummulation of hazardous combustion gases
(carbon monoxide & CO2). Combustion gases produced by this appliance must be vented to the outside in
accordance with the prevailing National Fuel Gas Code, ANSI Z223.1. Failure to comply can result in personal
injury, even death.
• Prior to in tallation, con ult a qualified electrician to en ure that in tallation complie with all electrical
requirement and code .
• Appliance must be installed and electrically grounded in accordance with local code, or in the absence of local
code, in accordance with the National Electrical Code, NFPA 70. Improper grounding may result in electrical
shoc to users. Always refer to local electrical code to ensure proper grounding of this or any other electrical
equipment.
• Chec the rating label on the unit to determine the proper power supply required. Always consult with an
electrician, or other qualified service technician, to ensure that circuit brea ers and wiring are of sufficient rating
and gauge to power this equipment. A wiring diagram is provided.
• Improper in tallation, adju tment, alteration, ervice, or maintenance could re ult in eriou injury, even death;
equipment and/or property damage; and will potentially void the factory warranty.
•DO NOT u e or tore flammable liquid , or material that produce flammable vapor , in the vicinity of thi or
any other appliance!
•DO NOT (or ALLOW OTHERS) for any reason, stand or step onto the top of the appliance. Cooking
oil in Fryer can be EXTREMELY HOT (excess of 330°F [166°C]). Bodily contact will cau e extremely
eriou injury. Lid u ed to ometime cover cooking vat /pot are not de igned to, and WILL NOT,
upport the weight of a per on.
• Failure to comply with WARNING notice could re ult in eriou injury, even death; damage to equipment
and/or property; and will potentially void the factory warranty.

vii
Safety Model: GGF-400, GGF-720
• Component expo ed on the control panel urface are impact- en itive. To avoid damage and maintain proper
operation, exerci e care when working around, or u ing rolling cart or table , near the appliance.
• The control panel contain a high-tech electronic microproce or controller. While the front panel is liquid-
resistant, it is not completely wash-down safe. When cleaning, avoid praying directly with high pre ure pray.
• DO NOT in tall the unit near combu tible wall and material . Failure to maintain afe di tance may re ult in
fire.
• When cleaning the appliance:
- DO NOT team clean.
- DO NOT u e product containing chlorine, or other corro ive chemical .
- DO NOT u e abra ive product , teel wool or couring pad .
- DO NOT u e oven cleaner .
• DO NOT alter, add attachment , or otherwi e modify thi equipment!
• Failure to comply with CAUTION notice may re ult in damage to equipment or property, and void the factory
warranty.
• The appliance mu t remain in an upright po ition.
• Exerci e care when removing the unit from hipping pallet.
• DO NOT operate the appliance, unle it component and their intended function are fully under tood ( ee
Section 3). After reading and fully under tanding Section 3, clo ely follow the pre ented procedure and
in truction in order to avoid equipment damage or malfunction.
• To avoid personal injury, it is recommended that thermal hand protection (gloves or mitts) be worn while
tended the appliance. Certain part of the Fryer will become very HOT during operation; temperature in ide
cabinet may exceed 150°F (65.5°C)! Exerci e caution when operating and cleaning.
• Placing food containing exce ive moi ture into hot oil, or attempting to load larger than recommended batch
ize can cau e “surge boiling” and re ult in an overflow of HOT cooking oil. Proceed lowly and exerci e due
care when loading food to ob erve how hot oil react before continuing.
• Be ure the appliance i po itioned in a table, afe location with the ca ter in the locked po ition. DO NOT
operate appliance if not ecured. Some juri diction may require pecial anchoring for thi type appliance;
check local code.
• Allow the appliance to cool for 15-20 minute before cleaning or ervicing.
• Thi appliance i not intended for u e by per on (including children) with reduced phy ical, en ory, or mental
capabilitie , or lack of experience and knowledge, unle they have been given adequate in truction and/or
upervi ion concerning it u e by a per on re pon ible for their afety. Children hould not be allowed to play
with, or around, thi appliance.
• Prior to ale, cooked food product mu t be maintained at a minimum temperature of 150°F (65.5°C), or in
accordance with governing health regulation .

viii
Safety
Model: GGF-400, GGF-720
NOTE:
• If upon receipt, the palletized unit howed any ign of damage, you hould immediately in pect the appliance
and a ociated acce orie , and notify the freight carrier of any and all damage .
• Comply with all appropriate tate and/or local heath regulation regarding cleaning and anitization of
food ervice equipment.

1
Model: GGF-400, GGF-720
Introduction
THANK YOU for purchasing the Giles Model GGF Series Gas Fryer, manufactured by GILES Food Service Equipment;
Montgomery, Alabama (USA), hereafter referred to as "Giles". Every unit is thoroughly inspected and tested prior
to shipment in efforts to ensure that it will operate flawlessly when installed. With proper care and maintenance
the appliance will provide years of trouble-free service.
To help protect your investment in this state-of-the-art cooking e uipment, we recommend that you take a few
moments to become familiar with the procedures for installation, operation, cleaning, and maintenance contained
in this Manual. Adherence to the recommended procedures will minimize the potential for costly “downtime” and
future repair expense. Please retain this manual for future reference.
NOTE: Due to cont nu ng mprovements and product enhancements, some of the llustrat ons shown n th s manual m ght
not exactly dep ct current models.
1. Introduction
1.1 Construction
Constructed of 18 and 20 Ga. 430 Stainless Steel.
Computer Controller - Accurately controls cooking oil temperature and cooking time. Provides for up to fifty (50)
programmable menu item cooking presets. Monitors fryer status; displays operational instructions, warnings and
errors (DRAIN OPEN, LOW OIL LEVEL,MAX. ELEMENT TEMP, etc). Features BOIL-OUT program, COOL MODE,
FORCE FILTER control, available password protection, multiple languages, and enhanced safety.
Dual Burner system (Model GGF-720 only) - Uni ue dual burner system delivers maximum BTU’s when needed,
while saving energy during light load cooking and idle periods.
Automat c Basket L ft - Automatically lowers product when cook cycle is started ... lifts cooked product from hot oil
at the conclusion of the cook cycle.
Bu lt- n O l F ltrat on System - Completely self-contained system helps to extend the life of cooking oil. Features
1/2 HP pump; designed to perform a filter cycle within approximately five (5) minutes.
Push-To-Start Feature -After any power interruption, the User must press a [START] key to power-up the
appliance. This feature will comply with code re uirements in some jurisdictions.
1.2 Standard Features
1.3 O tional Features
F lter Screen Med a [purchased separately] - Stainless steel micro-mesh, cleanable, filter screen used as a direct
replacement for Filter Paper. Reusable and durable; with proper care can last for many months. Helps to reduce
cost of operation and minimize the waste stream. Order Item Number: 41014

2
Model: GGF-400, GGF-720 Introduction
1.4. S ecifications
1.4.1. Overall Dimensions: GGF-400 & GGF-720
= ±.010
. = ±.031 T
-ECO: ECO1116 - REV: -FILE: 71380 REF 3 VIEW.asm!DOOR CLOSED
R
44 7/16 1129mm
36 5/8 931mm
5 1/4 133.99mm
115°
21 7/8
556mm
DOOR SWING REVERSIBLE
42 11/32
= ±.010
. = ±.031 T
- REV: -FILE: 71380 REF 3 VIEW.asm!DOOR CLOSED
R
24 3/8
619mm

3
Model: GGF-400, GGF-720
Introduction
1.4.2. Agency Certifications
Exceeding the product load capacity or over-filling fry pot with oil may result personal injury and/or damage to
e uipment or property.
1.4.3 Basket Sizes
Model
Basket S ze Volume
D ameter: n [mm] He ght: n [mm] Cub c nch [Cu m]
GGF-400 12-3/8 [314.2] 10-1/4 [260.4] 1,231.8 [.020]
GGF-720 14-3/4 [374.7] 12-3/4 [323.9] 2,178.6 [.036]
** Never exceed [MAX] oil level * 8-way cut, bone- n
1.4.4 Cooking Ca acity
Model
Cook ng O l Capac ty** Product Capac ty (*Ch cken)
Lbs [kg] Gal [l] Lbs [kg]
GGF-400 45 [21] 5.8 [21.9] 14 [6.3]
GGF-720 75 [34] 9.7 [36.7] 24 [10.8]

4
Model: GGF-400, GGF-720 Introduction

5
Installation GGF-400, GGF-720
This section summarizes procedures necessary for proper installation of the GGF Series Gas Fryer. To prevent personal
in ury or damage to the equipment, please ensure the following steps are taken and the following check sheet is
initialed and dated.
INSTALLATION CHECK SHEET
Check Date Initial Section Description
X 8/18/05 CSY 0.0 Completely read Manual (EXAMPLE)
2-01. Inspect crate for damage
2-01. Uncrate
2-02. Proper clearances
2-04. Proper ventilation
2-05. Proper circuit breaker installed (Licensed Electrician Only)
2-06. Proper electrical connections (Licensed Electrician Only)
2-07. Unit has power (Licensed Electrician Only)
2-08. Gas line connected (Qualified Gas Technician Only)
2-09. Correct gas orifice installed (Qualified Gas Technician Only)
2-10. Correct gas pressure setting (Qualified Gas Technician Only)
2-11. Correct blower vacuum switch setting (Qualified Gas Technician Only)
2-12. Filter Pump operating
2-13. Restraint device installed
2-14. Performed Boil-Out procedure
2-15. Cleaned Filter Pan
Various installation tasks described in this Manual MUST be performed only by a Licensed Electrician and a
Qualified Gas Appliance Technician.
NOTE:
This appliance must be electrically grounded in accordance with the local codes, or in the absence of local codes,
with the Nationa E ectrica Code, ANSI/NFPA 70, or Canadian E ectrica code, CSA C22.2, as applicable.
2. Inst ll tion
2.1. Appli nce Loc tion
DO NOT MODIFY, ADD ATTACHMENTS OR OTHERWISE ALTER THIS EQUIPMENT.
DO NOT install or use the appliance in a location or kitchen space that does not have ventilation to
the outside. Ventilation must be sufficient to provide a adequate fresh air exchan e rate to prevent accummulation of
hazardous combustion ases (carbon monoxide & CO2). Failure to comply can result in personal injury, even death.
Continued on Next Pa e

• The fryer must remain in an upright (vertical) position.
• Exercise care when lifting or moving the unit.
• Exercise care when removing the wooden crate and shipping materials from around the unit.
• Failure to comply with CAUTION notices may result in minor to moderate in ury, damage to equipment or
property, and voiding of the factory warranty.
6
Installation
GGF-400, GGF-720
1. The appliance is palletized on a wooden pallet, secured with high-tensile plastic strapping and protected by a
wooden framework. The entire unit load is wrapped with machine applied stretch wrap.
2. Carefully cut and remove the plastic shipping wrap.
3. Carefully remove the wooden crate framework and cut plastic strapping. Secure and remove all accessory
items (basket & cover, brushes & tools, filter pan & cover, etc.). Set aside in a safe place and properly dispose
of shipping materials.
4. Carefully remove the fryer from the shipping pallet. The appliance is very heavy [approximately 280 lbs (127
kg) uncrated]. Extreme care should be taken when lifting or moving the unit to prevent personal in ury and/or
damage to the equipment. Use sufficient manpower and appropriate handling equipment.
2.2. Unp cking
1. Installation location must comply with clearances to combustibles described in Section 2.3.
2. Allow adequate space for easy access when operating or servicing.
3. Verify that electrical power available in the intended location is the proper voltage and amp rating adequate
to power the appliance.
4. A stable fuel gas supply must be available at the intended location. 1/2” supply line, fitted with “service”
shutoff valve is required.
5. Be sure unit is installed in a stable position and will not unintentionally move. Unit has locking brakes on
front casters ... be sure they are locked. Some urisdictions may require special anchoring of the appliance;
check local codes. See Section 2.13, Restraining Device.
6. This appliance is to be installed, used and maintained in accordance with the Standard for Ventilation
Control, and Fire Protection of Commercial Cookin Operations, NFPA 96.
The above will help to ensure proper installation. If there are questions concerning installation procedures, contact
Gi es Technica Support at 800.554.4537 or email [e-mail].
2.1. Appli nce Loc tion - continued
IMPORTANT!
If crate exhibited evidence of damage or mishandling, immediately inspect the unit and all accessory items and
notify the freight carrier of any damages. Typically it is the purchaser’s responsibility to file and negotiate
freight damage claims.
Giles is not liable for dama es to the unit caused by use of improper material handlin equipment or poor
work practices, or for personal injuries or property dama e which may be incurred durin installation of this
equipment. Installation is the sole responsibility of the purchaser, unless previous arran ements have been
made in writin .

7
Installation
2.3. Cle r nces, G s Supply nd Electric l Loc tions
INCHES [mm]
GGF-400, GGF-720
= ±.010
.= ±.031 T
REF. FILE INFO: -ECO: ECO1116 - REV: -FILE: 92096.asm!DOOR CLOSED
R
24 3/8
619mm
= ±.010
.= ±.031 T
REF. FILE INFO: -ECO: ECO1116 - REV: -FILE: 92096.asm!DOOR CLOSED
R
44 7/16 1129mm
36 5/8 931mm
5 1/4 133.99mm
42 25/32
1086.51
REGULATOR W/1/2” NPT
GAS LINE CONNECTION
COMBUSTIBLES
NON-COMBUSTIBLES
18”[457.2]
4”[101.6]
4”[101.6]
18”[457.2]
18”[457.2]
4”[101.6]
NON-COMBUSTIBLES
COMBUSTIBLES
6’ POWER CORD INCLUDED

8
Installation
GGF-400, GGF-720
2.5. Utility Requirements
• Fryers must be adequately and properly rounded. Improper roundin may result in electrical shock. Always
refer to local electrical code to ensure proper roundin of this or any other electrical equipment. Always
consult with a qualified electrician or service technician to ensure breakers and wirin are of sufficient ratin
and au e to supply power for the equipment.
2.4. Ventil tion
•The combustion ases produced by this appliance must be vented to the outside in accordance with the
prevailin National Fuel Gas Code, ANSI Z223.1 and terminate with a UL listed outside vent terminal. For
Canadian installations reference CSA-B149.1 or .2, Installation Codes for Gas Burnin Appliances and Equipment.
• This appliance is to be installed, used and maintained in accordance with the Standard for Ventilation Control &
Fire Protection of Commercial Cookin Operations, NFPA 96.
• Consult a professional, certified, HVAC company for assistance in designing and specifying a ventilation hood
system for this unit.
NOTE:
Guidelines for ventilation system requirements may differ by locale. Always consult with local authorities to
ensure compliance for this appliance.
T ble 2.5.1 Electric l Specific tions
Model Volta e Hz Ph Amps Breaker
Required
GGF-400, 720 120 60 1 7.0 15
T ble 2.5.2 Fuel G s Specific tions
Fuel Type Max. Incomin Supply
Pressure
Re ulated Pressure to
Fryer Gas Valve Supply Line Size
Nat. Gas 13.85” w.c. [3.45 kPa] 5” w.c. [1.23 kPa] 1/2”
LP Gas 13.85” w.c. [3.45 kPa] 11” w.c. [2.74 kPa] 1/2”

9
Installation GGF-400, GGF-720
2.6. Electric l Connections
1. Connect Fryer power cord to an appropriate receptacle ... the circuit must have properly sized circuit breaker
and wiring of sufficient gauge to power the appliance, See Tab e 2.5.1.
2. Fryer is equipped with power cord with molded plug.
IMPORTANT!
When installed, appliance must be electrically grounded in accordance with local code, or in the absence of local
code, with the National Electrical Code, ANSI/NFPA 70, or Canadian Electrical Code, CSA C22.2, as applicable.
2.7. G s Line Connection
Verify that a proper facility gas supply line (1/2” min.) is install and equipped with a “service” Shut-Off Valve (not
provided). See Section 2.8.1, Typica Gas Supp y Line Connections.
• Combustion ases produced by this appliance must be vented to the outside in accordance with the prevailin
National Fuel Gas Code, ANSI Z223.1 and terminate with a UL listed outside vent terminal. For Canadian
installations reference CSA-B149.1 or .2, Installation Codes for Gas Burnin Appliances and Equipment
.
•
Quick-disconnect devices must comply with the Standard for Quick-Disconnect Devices for Use with Gas Fuel,
ANSI Z21.41 [in Canada CSA 6.9-2014].
• Gas Connectors and Lines must comply with Standard for Movable Gas Appliance, ANSI-69, and Addenda Z21.69
[in Canada CSA 6.10-2015].
• This unit MAY require installation of a secondary in-line as pressure Re ulator (customer supplied), see Section
2.5, Uti ity Requirements & Tab e 2.5.2, Fue Gas Specifications.
• This unit MUST only be installed by a Qualified Gas Technician.
• Ensure both the Facility Shut-Off Valve and the Fryer Shut-Off Valve are in the [OFF] position.
Continued on Next Pa e

10
Installation
GGF-400, GGF-720
2.7.1 Typic l G s Supply Line Connection
*1/2” Flexible
Gas Line
* Secondary In-
Line Regulator
[May not be
required, see
below]
To Fryer
Re ulator
*Customer supplied
*Gas Supply Shut-
Off Valve
IMPORTANT!
• Installation must comply with local code, or in the absence of local code, with the National Fuel Gas Code,
ANSI Z223.1/NFPA 54 [in Canada, Natural Gas and Propane Installation Code, CSA B149.1] includin :
• The appliance must be disconnected from the incoming gas supply line at the main shut-off valve, during any
testing of the piping at test pressures in excess of 1/2 psi (3.5kPa).
• The appliance must be isolated from the incoming gas supply line by closing the fryer Gas Shutoff Valve, during
any testing of the piping at test pressures equal to or less than 1/2 psi (3.5kPa).
1. Check pressure of the incoming gas supply and compare to Tab e 2.5.2. If necessary install a secondary pressure
regulator on the supply line to regulate supply pressure to a maximum of 13.85” W.C. [3.45 kPa].
2. Install an appropriate Quick-Disconnect fitting on the gas line.
3. Connect an approved 1/2” flexible gas line (not provided) between the supply line disconnect and the Fryer gas
regulator located on the rear of the unit.
Note: The flexible gas line should be long enough to allow for the Fryer to be moved away from wall for any
servicing and cleaning.
4. WHEN TIGHTENED, CHECK ALL CONECTIONS FOR LEAKS USING A SUITABLE METHOD!
Continued on Next Pa e
*Quick Disconnect

11
Installation GGF-400, GGF-720
IMPORTANT!
The factory-installed regulator on the fryer controls gas pressure supplied to the gas valve as shown in Table 5-
2.2. This regulator is rated for max. input pressure of 13.85” W.C. [ 3.45 kPa]. If supply line pressure exceeds
this maximum, a secondary re ulator must be installed in the supply line, upstream of the installed re ulator,
to maintain pressure at or below the maximum ratin .
2.7.1 Typic l G s Supply Line Connection - continued
