Glamox TL14-W58 Series User manual

ignition of fire or other hazards. Read therefore the following safety and operating instructions carefully and
2.Technical Information and dimensions
1.General information
With the use of electrical devices general safety precautions must be taken to reduce the risk of an electrical shock,
attentively. Keep this document for later rereading carefully. If you pass the equipment on to other persons, you must
also this document to ensure a safe use of the equipment.
TL14-W58
LED
S : Switch
U : Universal razor socket with transformer and selector
230/110-230V
SC : Schuco type socket
SSC: Switch and schuco type socket
SU : Switch, universal razor socket
with transformer and selector
230/110-230V
OP : Opal diffuser
5530700004
5530700004-A2

Do not touch the surface
of the LED module.
Remove diffuser
4
321
Max:3X2.5mm²
Min:3X0.75mm²
5
Loose screws.
Remove gear tray
Max cable
diameter
Ø19mm
6
10
9
8
3.Installation
Fix plate with 2 screws
2X St 4.2*6
Mounting to wall
Disconnect
install diffuser
Install Connector
Electrostatic sensitive device
7
11
Wear anti-static gloves
5530700004-A2

4. Caution /Warning:
When the power cable is damaged it must in order to avoid dangers only be replaced from the
manufacturer, his service agency or a similar qualified company.
1.The product must be installed by professional technicians and power supply must be cut off before
installation.
2. Power cable should be not less than 0.75mm² .
3. Ensure this manual is provided to the installers and users.
4. Improper wiring may signifificantly reduce luminaries life expectancy and void the driver or lamp warranty.
5. Cleaning instruction
1.Disconnect the control gear or luminaries or LED module from the mains and from the LED
module before starting cleaning.
2.Never use abrasive or corrosive cleaning materials. These materials can damage the surfaces
and electric insulation layers.
3.It should be not use flammable liquids for cleaning.
4.It should be not immerse the control gear or the cable into water. This can cause a life-threatening situation.
Disposal information
This product contains recyclable materials. Do not dispose this product as unsorted municipal waste.
Please contact your local municipality for the nearest collection point. In the interest of the technical
advancement construction changes or modifications of the appliance and the associated documents
are reserved without prior notice.
Note: Regular cleaning of light luminaries is essential for optimal lighting. Light luminaries are cleaned in a
de-energized state. Electrical components and connections should not be exposed to water or moisture.
Cleaning intervals are normally consistent with those planned during the project planning.
Light luminaries can be cleaned with a neutral detergent (pH 7). The detergent is mixed in lukewarm water.
The mixture is then applied with a micro fiber cloth, sponge or the like. Afterwards, soap residues should be
removed using a soft clean micro fiber cloth dampened with water. Do not spray cleaning solutions directly
onto the fitting as residual detergent may collect in the cover, reflector or optical components, and be difficult
to remove later. Organic solvent-based and strongly alkaline detergents should be avoided, as they can
damage components in the short and long term. This applies particularly to components made from various
plastics. Glossy reflective surfaces should be dusted regularly to ensure optimum lighting. A brand new,
clean and dry micro fiber cloth is recommended for dusting. For removal of grease and fingerprints, reflector
material can be sprayed with a detergent for cleaning windows, glass, computer screens etc. and dried with
a brand new, clean and dry micro fiber cloth. Any remaining detergent can be removed by applying clean
water and then be wiped clean with a brand new, clean and dry micro fiber cloth. Reflectors should be
cleaned with care in order to prevent damage to reflector materials.
Do not connect to a temporary electricity supply. This may damage the electronics.
If the luminary is delivered with connecting leads, the chosen terminal block and
connection to the mains must be according to the installation instructions.
5530700004-A2
