GLOBAL ASSISTIVE DEVICES Access 4 User manual

Multi-purpose Alerting Device:
Alarm Clock, LED Lamp with flashing feature,
Telephone Ring Signaler, Vibrator Jack.

12/24 HOUR DISPLAY MODE:
Select the desired 12 or 24 Hour mode by using
the HOUR switch located on the back of the unit.
POWER SOURCE:
AC Operation
A plug in 9VAC 750 mA power supply (included)
powers the clock. Check to ensure that the
voltage indicated on your power supply
corresponds to the correct voltage of your area.
Connect the barrel plug of the power supply into
the jack on the back of the unit marked AC-9V.
Connect the AC plug into a wall AC outlet near
your bedside. 12:00 (12-hour display mode) or
0:00 (24-hour display mode) will flash on the clock
display. When you set the time, the display will
stop flashing.

Battery Back up for Clock Memory
Keeps the clock time running in the event of a
short term AC power failure. The LED Lamp can
also be powered by the Battery back up.
The correct time will show when AC power returns
if battery is not dead.
Note: The clock display will not show the time
during power outage.
Remove Cover from Battery Compartment
(located on back of unit) by sliding the tab and
lifting up.
Install 9 Volt Alkaline Battery (not included) into
the battery compartment matching positive (+) and
negative (–) markings and replace cover.
Replace battery as required. Do not leave battery
in compartment when unit not in use.

SETTING THE CLOCK TIME:
To set the Hour: Press and hold the TIME button
(located on the front). While you hold down the
TIME button, press the HOUR button until it
advances to the correct hour. Note: For 12-Hour
Display mode, check that you have set correctly in
AM or PM. PM Indicator light (green dot located at
the top left of the clock display) will illuminate
when in PM time.
To set the Minutes: Press and hold the TIME
button (located on the front). While you hold down
the TIME button, press the MIN button until it
advances to the correct minutes.
SETTING THE ALARM TIME:
To set the Hour: Press and hold the ALARM
button (located on the front). While you hold down
the ALARM button, press the HOUR button until it
advances to the correct hour. Note: For 12-Hour
Display mode, check that you have set correctly in
AM or PM. PM Indicator light (green dot located at

the top left of the clock display) will illuminate
when in PM time.
To set the Minutes: Press and hold the ALARM
button (located on the front). While you hold down
the ALARM button, press the MIN button until it
advances to the correct minutes.
To check the Alarm Set Time, push and hold the
ALARM button.
TO ACTIVATE OR DEACTIVATE ALARM(S):
Slide the ALARM SELECTOR (located on the
back) to the desired position of OFF, AUDIBLE,
VIBRATE, or ALL.
When you do not want the Alarm(s) to be activated
(example: weekends), slide the ALARM selector to
the OFF position. Alarm indicator light will not be
illuminated. The Alarm Time will remain set for
future use.
AUDIBLE position will activate the sound alarm.

VIBRATE position will activate the VIBRATOR
jack and cause the connected “Vibes” Bedshaker
to vibrate.
ALL position will activate the audible, vibrate and
flashing lamp. If you do not want the lamp to
flash, slide the lamp switch (located on the back
top right of the clock) to OFF.
Alarm indicator light marked AL (located on the left
of the clock display) will illuminate when any mode
of alarm is set.
ALARM/ALERTING OPTIONS:
Audible: You can select the Volume and Tone that
you require or want by rotating the dials on each
side of the unit. VOLUME can be set from 0 dB
(no sound) to 90 dB (very loud). Indicator dial on
face of unit confirms setting. TONE is adjustable
from Low to High to provide you with the optimum
results.
Vibration: Connect a 12 Volt Bedshaker
(purchased separately) to the back of the unit

marked VIBRATOR. Place the Bedshaker
between your box spring and mattress or under
your pillow. When the alarm is activated, the
vibrations will alert you.
Flashing: The LED lights will flash when the alarm
is activated. If you do not want it to flash, slide the
lamp switch (located on the back top right of the
clock) to OFF.
SNOOZE ALARM:
To activate the snooze feature, press the
SNOOZE button (located on the front of the unit).
The alarm(s) will stop and re-activate again in
approximately 8 minutes. This may be repeated.
TO STOP THE CLOCK ALARM:
Press the AL. OFF (Alarm Off) button, located on
the front.
The Alarm Clock will remain set on standby to be
activated again for the preset time the next day.

LED LAMP:
To turn on the LED Lamp, press the LIGHT
BUTTON located on the front. Press again to turn
off.
TELEPHONE RING SIGNALER:
Connect your telephone to the RJ11 jack at the
back of the unit marked OUT. With the telephone
line cord provided, plug one end into the second
RJ11 jack marked IN and the other end of the cord
into the wall phone jack. ACCESS 4 will respond
to the Telephone Ring with the functions that are
set. Select Light, Audible and/or Vibrate. A green
indicator light (located on the front of the unit at
the right of the time display) will flash with each
ring of the phone.

LIMITED WARRANTY:
ACCESS 4 is warranted to be free from defects in
material or workmanship for One Year from the
date of purchase. This is a limited warranty and
does not apply to the telephone line cord. This
warranty does not cover any unit which has been
subject to misuse, negligence or accident. This
warranty is void if the unit has been tampered
with, altered or repaired by other than a qualified
service center. At its option GLOBAL ASSISTIVE
DEVICES, INC may select to replace the unit,
rather than repair it. During the warranty period,
return the unit, with dated proof of purchase, in a
secure package, insured and with shipping
charges prepaid. No C.O.D. packages will be
accepted. Include a note describing the service
required and include $9.95 (check, money order,
Visa, Master Card, American Express, or
Discover) for shipping and handling within the
U.S.A. Other countries contact us for shipping
and handling charges.

Disclaimer: In no event shall Global Assistive
Devices, Inc. be held liable for any special,
incidental, indirect or consequential damages
whatsoever including, but not limited to, damages
for loss of property, personal injury, loss of
privacy, failure to meet any duty, negligence, and
any other loss whatsoever, however caused, even
if Global has been advised of the possibility of
such damages. This disclaimer of liability applies
to any damages or injury, including but not limited
to those caused by any failure of performance of
the product. Responsibility for selection, safety
and suitability of any product rests with the
consumer. Circumstances or consequences
arising out of or in any way related to the use of or
inability to use our products is the responsibility of
the consumer. Global Assistive Devices, Inc.
cannot be held liable in any way.
GLOBAL ASSISTIVE DEVICES, INC.
1121 East Commercial Boulevard, Fort Lauderdale Florida USA 33334
