APR 2017 GFS-520b ( Formerluy A-93)
EXTENDED
STANDARD RESPONSE
AUTOMATIC SPRINKLERS
GL SERIES DRY TYPE
HORIZONTAL SIDEWALL
DESCRIPTION AND OPERATION
RECESSED
SPRINKLER TEMPERATURE RATING/CLASSIFICATION and COLOR CODING
• Water Working Pressure Rating - 175 psi (12 Bars)
• Factory tested hydrostatically to 500 psi (34 Bars)
• Maximum low temperature glass bulb rating is -67°F (-55°C)
• Frame - bronze •Deflector - brass •Screw - brass
•Bulb Seat - brass •Spring - nickel alloy •Seal - teflon
•Retainer - brass •Pin - stainless steel
•Torsion Spring - stainless steel •Orifice Insert - brass
• Bulb - glass with glycerin solution, 5mm size
•3/4”NPT or 1”NPT •Outer Tube - galvanized steel pipe •Inner Tube - stainless steel
TECHNICAL DATA
• See reverse side for Approvals and Specifications.
• Temperature Ratings -
135°F (57°C), 155°F (68°C), 175°F (79°C)
200°F (93°C), 286°F (141°C)
SLEEVE & SKIRT
SURFACE MOUNT
CLASSIFICATION AVAILABLE SPRINKLER
TEMPERATURES BULB COLOR N.F.P.A. MAXIMUM CEILING TEMPERATURE
ORDINARY
INTERMEDIATE
HIGH
135°F/155°F
175°F/200°F
286°F
57°C/68°C
79°C/93°C
141°C
ORANGE/RED
YELLOW/GREEN
BLUE
100°F
150°F
225°F
38°C
66°C
107°C
The Globe GL Series Dry Type Horizontal Sidewall Sprinkler is
designedforuseinspecialapplicationssuchasfreezingenvironments
and conditions where sediment or foreign materials might accumulate
in ordinary horizontal pipe nipples.
The Globe GLSeries Dry Type Horizontal Sidewall Sprinkler utilizes
a frangible glass ampule sprinkler. At the ampule’s rated temperature,
the sprinkler opens releasing the bulb seat, causing the inner tube
assembly to move, allowing the spring assembly to pivot alongside
the inner tube. At this time, water flows through the sprinkler and is
distributed by the deflector, in an approved discharge pattern.
The heart of Globe’s GLSeries sprinkler proven actuating assembly
isahermeticallysealedfrangibleglassampulethatcontainsaprecisely
measured amount of fluid. When heat is absorbed, the liquid within
the bulb expands increasing the internal pressure. At the prescribed
temperature the internal pressure within the ampule exceeds the
strength of the glass causing the glass to shatter. This results in water
discharge which is distributed in an approved pattern.

APR 2017 GFS-520b ( Formerluy A-93)
NOTE: METRIC CONVERSIONS ARE APPROXIMATE.
1FINISHES AVAILABLE ON SPECIAL ORDER.
2cULus LISTED CORROSION RESISTANT WHEN SPECIFIED ON ORDER.
SPECIFICATIONS
APPROVALS
PRINTED U.S.A.
4077 AIRPARK DRIVE, STANDISH, MICHIGAN 48658
FAX [phone]
www.globesprinkler.com
989-846-4583
1-800-248-0278
GLOBE®PRODUCT WARRANTY
Globe agrees to repair or replace any of its own manufactured
products found to be defective in material or workmanship for a
period of one year from date of shipment.
For specific details of our warranty please refer to Price List
Terms and Conditions of Sale (Our Price List).
STANDARD RESPONSE
AUTOMATIC SPRINKLERS
GL SERIES DRY TYPE HORIZONTAL SIDEWALL
1SPRINKLERS SHALL BE LIMITED AS PER THE REQUIREMENTS OF NFPA13 ANDANY OTHER RELATED DOCUMENTS.
*HORIZONTAL SIDEWALL STYLE - FMAPPROVED 155°F (68°C), 200°F (93°C), AND 286°F (141°C)
*RECESSED HORIZONTAL SIDEWALL STYLE - FMAPPROVED 155°F (68°C)AND 200°F (93°C)
LH: LIGHT HAZARD; OH: ORDINARY HAZARD
SIN MODEL NOMINAL
“K” FACTOR THREAD SIZE LENGTH FINISHES
GL5685 5.6 (80 metric) 1”NPT cULus Variable to 48”
FM Variable to 36”
Factory Bronze
Chrome
White Polyester2
Black Polyester1,2
GL5686 5.6 (80 metric) 3/4”NPT
GL8185 8.0 (115 metric) 1”NPT
STYLE SIN
MODEL HAZARD1135°F (57°C) 155°F (68°C) 175°F (79°C) 200°F (93°C) 286°F (141°C) *FM cULus
DEFLECTOR
TO CEILING
DISTANCE
Inches (mm)
MIN.
DISTANCE
BETWEEN
SPRINKLERS
Feet (Meters)
Horizontal
Sidewall
Recessed
Horizontal
Sidewall
GL5685 LH X X X X X X X 4 (102)
to
12 (305) 6 (1.8)GL5686 LH X X X X X --- X
GL8185 LH/OH X X X X X --- X
"A"
1" MIN. 3/4"NPT
3/4" MIN. 1"NPT
2 1/2" DIA. MIN.
HOLE IN WALL
TEE FITTING
ANSI B16.3 CLASS 155 OR
ANSI 16.4 CLASS 125
FACE OF
MOUNTING
SURFACE
CEILING 4" TO 12"
3 1/2"
DIA.
3 3/4" MIN.
4 3/4" MAX.
FACE OF
TEE
FITTING
TWO PIECE
ESCUTCHEON
"A"
2 1/2" MIN. 3/4"NPT
2 1/4" MIN. 1"NPT
4" TO 12"
CEILING
FACE OF
MOUNTING
SURFACE
3" DIA.
1 1/2" DIA. MIN.
HOLE IN WALL
TEE FITTING
ANSI B16.3 CLASS 155 OR
ANSI 16.4 CLASS 125
1/4"
FACE OF
TEE
FITTING
TEE FITTING
ANSI B16.3 CLASS 155 OR
ANSI 16.4 CLASS 125
FACE OF
MOUNTING
SURFACE
"A"
3 1/4" MIN. 3/4"NPT
2 3/4" MIN. 1"NPT
1 1/4" MIN.
2" MAX.
2" DIA. MIN.
HOLE IN WALL
2 15/16" DIA. 4" TO 12"
CEILING
FACE OF
TEE
FITTING
CUP
RETAINER
"A"
1 3/4" MIN. 3/4"NPT
1 1/2" MIN. 1"NPT
1 3/4" DIA. MIN.
HOLE IN WALL
3 7/32" DIA.
2 1/2" MIN.
4" MAX.
TWO PIECE
ESCUTCHEON
FACE OF
MOUNTING
SURFACE
FACE OF
TEE
FITTING
TEE FITTING
ANSI B16.3 CLASS 155 OR
ANSI 16.4 CLASS 125
CEILING 4" TO 12" ESCUTCHEON
1/8"
CROSS SECTIONS
EXTENDED
SLEEVE & SKIRT
RECESSED
SURFACE MOUNT
IMPORTANT INSTALLATION DATA
Globe GL Series Dry Pendent Sprinklers should be
installed in accordance with the requirements set
forth in NFPA 13. These sprinklers are to be installed
using a pipe wrench applied to the outer tube. When
this is not possible, the proper sprinkler head wrench
may be used with extreme care for lengths up to
approximately 18”. Excessive force may distort the
frame thus destroying the unit.
The GL Series Dry Sprinkler must not be installed
in a short radius 90° elbow. When installing in other
than an iron tee, the clearances between the end of the
sprinkler and fitting should be checked.
When installed in a wet system extending into a
freezing area see chart on Dry Caution Sheet for
minimum exposed barrel length to prevent ice
plugs. Please refer to our Dry Caution Sheet for further
important installation data.
ORDERING INFORMATION
• Quantity •Model No. •Style •Orifice •Temperature •Finishes
•Quantity - Wrenches - P/N 333010
•Quantity Recessed Wrenches - P/N 337014
• Quantity - Protective Caps - P/N 327109-cap ( Friction Fit Recessed )
• Escutcheons Desired
“A” Dimension - Distance from face of fitting to the finished ceil-
ing line regardless of escutcheon used.
SPECIFY
