4077AIRPARKDRIVE,STANDISH,MICHIGAN 48658 FAX[phone]
RA-8 BULLETINGL4247,REV.#3
OCTOBER2003
REPLACEMENTRESIDENTIAL
AUTOMATICSPRINKLERS
MODEL GL4247
ADJUSTABLECONCEALEDPENDENT
DESCRIPTION AND OPERATION
The Globe Model GL4247 Residential Adjustable Concealed Pendent Sprinkler is a low profile
yetdurabledesignwhichutilizesa3mmfrangibleglassampuleasthethermosensitiveelement. It
features economy,aestheticsand1/2"ofadjustment. Thecombinationofthe3mmfrangibleglass
ampule and specially designed deflector make the Model GL4247 Residential Adjustable Con-
cealedPendentSprinklertheultimateinlifesafetyandfirecontrol. Thisresidentialsprinklerhasmet
thestrictrequirementsofUnderwritersLaboratoriesInc.asdescribedintheULStandard,UL1626,
for Residential Sprinklers for Fire Protection Service, and should be used accordingly. These
sprinklersshouldalsobeinstalledinaccordancewiththeappropriateNFPAStandard13Ror13D.
Allthatisseenattheceilingisa35/16"diameterceilingplatecolorfinishedtomatchthespecifier's
exact requirements. Globe's Residential Adjustable Concealed Pendent Sprinkler utilizes its
pendentresidentialtypesprinklerwhichisconcealedfromviewbyadomeshapedceilingplatethat
concealsthesprinklerjustbelowtheceilinglineforfasterresponseoncetheceilingplatehasfallen
away. Theceilingplateissolderedtothesprinkler'sspecialuppersupportassemblyinthreeplaces.
Upontheapplicationofsufficientheat,theplatefallstothefloorexposingtheresidentialpendentspray
sprinkler. Attheampule'sratedtemperature,thesprinkleropensdischargingwaterontothefloorin
itsrequiredandapproveddistributionpattern.
TheheartofGlobe'sModelGL4247sprinklerprovenactuatingassemblyisahermeticallysealed
frangibleglassampulethatcontainsapreciselymeasuredamountoffluid. Whenheatisabsorbed,
theliquidwithinthebulbexpandsincreasingtheinternalpressure. Attheprescribedtemperaturethe
internalpressurewithintheampuleexceedsthestrengthoftheglasscausingtheglasstoshatter. This
resultsinwaterdischargewhichisdistributedinanapprovedpattern.
RESIDENTIAL
CONCEALED PENDENT
TECHNICAL DATA
See reverse side for Approvals and Specifications.
TemperatureRating-155°F(68°C).
Water Working Pressure Rating - 175 psi (12 Bars).
Factorytestedhydrostaticallyto 500psi(34Bars).
Maximumlowtemperatureglassbulbratingis-67°F(-55°C).
Frame - bronze Deflector - brass Screw - brass
Bulb seat - copper Spring - nickel alloy Seal - teflon
Bulb-glasswithalcoholsolution,3mmsize.
Cover Plate - brass
UpperEscutcheonAssembly-steel
SPRINKLER TEMPERATURE RATING/CLASSIFICATION and COLOR CODING
CLASSIFICATION AVAILABLE SPRINKLER
TEMPERATURES BULB COLOR N.F.P.A.MAXIMUM CEILING TEMPERATURE
ORDINARY 155°F 68°C RED 100°F 38°C

FAX[phone]
www.globesprinkler.com
PRINTEDU.S.A.
4077AIRPARKDRIVE,STANDISH,MICHIGAN 48658
989-846-4583
1-800-248-0278
OCTOBER2003 BULLETINGL4247,REV.#3
REPLACEMENTRESIDENTIAL
AUTOMATICSPRINKLERS
MODEL GL4247 BULB SPRAY SERIES
ADJUSTABLECONCEALEDPENDENT
NOTE: METRIC CONVERSIONS ARE APPROXIMATE.
GLOBE®PRODUCT WARRANTY
Globe agrees to repair or replace any of its own
manufactured products found to be defective in mate-
rial or workmanship for a period of one year from date
of shipment.
For specific details of our warranty please refer to
PriceList TermsandConditionsofSale(OurPriceList).
ORDERING INFORMATION
SPECIFY
Quantity Model Number Style
Orifice Temperature Finishes desired
Quantity - Wrenches - P/N 325390
Quantity - Recessed Wrenches - P/N 325391
Quantity - Protective Caps - P/N 327119
CROSS SECTION
*FINISHES AVAILABLE ON SPECIAL ORDER.
INSTALLATION DATA
SIN
MODEL K FACTOR THREAD SIZE LENGTH FINISHES 155°F (68°C)
WITH PLATE
135°F (57°C) cULus
GL4247 4.2 (59 metric) 1/2" NPT 2 1/2"
(6.4 cm)
Bright Chrome
White Painted
*Satin Chrome
*Bright Brass
*Other Painted Finishes
XX
CONCEALED PENDENT SPRINKLER
MAXIMUM AREA
OFCOVERAGE MIN IMUM W AT ER DISCHARGE & PRESSURES NEEDED
SIN GLE SPRINKLER TW O SPRINKLERS
12' x 12' 13 G.P.M. - 9.6 P.S.I. 11 G.P.M.- 7 P.S.I. (EACH)
14' x 14' 17 G.P.M. - 16.4 P.S.I. 13 G.P.M. - 9.6 P.S.I. (EACH)
16' x 16' 22 G.P.M.- 27.4 P.S.I. 16 G.P.M. - 14.5 P.S.I. (EACH)
1/2" ADJUSTMENT
SPECIFICATIONS AND APPROVALS
