GMG 1030-PA User manual

Operator’s Manual
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . inside cover
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
California Proposition 65 Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Alert Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Electrocution Hazard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Tip-over Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Fall Hazards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Collision Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Additional Safety Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Battery Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Controls & Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Component Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Platform Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Lower Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Workplace Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Operating Instructions & Function Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Prestart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Functions Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Shutdown Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Battery Charging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintenance . . . . . . . . . . . . ......... . . . . . . . . . . . . . . . . . ......... . . . . . . . 18
Routine Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Frequent and Annual Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Pre-Start Inspection Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Frequent Inspection Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Annual Inspection Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Troubleshooting . . . . . . . . ......... . . . . . . . . . . . . . . . . . ......... . . . . . . . 24
Transport and Lifting Instructions . . . . . . . . . . . . . . . . . . ......... . . . . . . . 25
Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Lifting Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1030-PA
1030-PA Serial # 210301000 - Up
1OP1030EN
February 2018

—Specifications—
Meets applicable requirements of ANSI A92.6-2006. *Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
C
H
B
G
A
I
D
E
F
Power
Power source 12v, 100Ah
Weight
ANSI 1,025 lbs 465 kg
CE 1,025 lbs 465 kg
MODEL 1030-PA Micro
Measurements US Metric
Working height maximum 15.9’ 5 m
A
Platform height maximum 9.9’ 3 m
B
Platform height - stowed 29.5” .75 m
Platform length outside - stowed
C
45.3” 1.15 m
Platform width - outside
D
29.3” .74 m
Toeboard height 6.7” 0.17 m
E
Height - stowed 72.8” 1.85 m
F
Length stowed
w/o ladder
48.4”
45.3”
1.23 m
1.15 m
G
Width 29.9” .76 m
Wheelbase
H
42” 1.07 m
Ground clearance - center 2.3” 6 cm
Productivity
Maximum platform occupancy 2
Lifting capacity 530 lbs 240 kg
Extension deck capacity 220 lbs 100 kg
Raise speed
Lower speed
28 seconds
24 seconds
Tires 6” 15 cm
I
A
B
C
D
E
F
G
H

1OP1030 – February 2018 Page 1
1030-PA Introduction
Introduction
This Operator’s Manual has been designed to provide you, the owner, user or operator, with the instructions and operating procedures
essential to properly and safely operate your GMG Aerial Work Platform for positioning personnel, along with their necessary tools
and materials, to overhead work locations.
The Operator’s Manual must be read and understood prior to operating your GMG Aerial Work
Platform. The user/operator should not accept operating responsibility until he/she has read and
understands the operator’s manual as well as having operated the GMG Aerial Work Platform under
supervision of an authorized, trained and qualified operator.
It is essential that the operator of the aerial work platform is not alone on the workplace during
operation.
Modifications of this machine from the original design and specifications without written permission
from GMG are strictly forbidden. A modification may compromise the safety of the machine, subjecting
operator(s) to serious injury or death.
Your GMG Aerial Work Platform has been designed, built, and tested to provide safe,
dependable service. Only authorized, trained and qualified personnel shall be allowed to
operate or service the machine.
GMG, as manufacturer, has no direct control over machine application and operation. Proper
safety practices are the responsibility of the owner, user and operator.
If there is a question on application and/or operation contact:
Global Machinery Group
Global Machinery Group, Inc.
3428 Bullock Lane
San Luis Obispo, CA 93401 USA
Phone: [phone]
Toll Free (USA/Canada): 800.303.0499
www.goGMG.com

Page 2 1OP1030 – February 2018
Safety
Safety
DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection,
Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating
Instructions section.
Failure to read, understand and follow all safety rules, warnings, and instructions could result in serious injury or death. For your
safety and the safety of those around you, you must operate your machine as instructed in this manual.
GMG designs aerial work platforms to safely and reliably position personnel, along with their necessary tools and materials, at
overhead work locations. The owner/user/operator of the machine should not accept responsibility for the operation of the machine
unless properly trained.
ANSI and other applicable standards identify requirements of all parties who may be involved with self-propelled elevating work
platforms. The ANSI/SIA A92.5-2006 Manual of Responsibilities is considered a part of this machine and can be found in the manual
compartment, located at the platform control station. To ensure safe use of machine, inspections and training specified in ANSI/SIA
A92.5-2006 must be performed at designated intervals as prescribed.
California Proposition 65 Warning
This product contains chemicals known to the State of California to cause cancer and/or birth
defects or other reproductive harm.
Safety Alert Symbols
GMG manuals and decals use symbols and colors to help you recognize important safety, operation and maintenance information.
RED – Indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
ORANGE – Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
YELLOW with alert symbol – Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
YELLOW without alert symbol – Indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
GREEN – Indicates operation or maintenance information.
1030-PA

1OP1030 – February 2018 Page 3
Safety
Fall Protection
Operators must comply with employer, job site and governmental rules regarding the use of
personal protective equipment.
If required by your employer or job site, use personal fall protection equipment (PFPE) when
operating this machine.
All PFPE must comply with applicable governmental regulations, and must be inspected and
used in accordance with the PFPE manufacturer’s instructions.
Fall restraint must be properly attached to a designated anchorage point when driving or
operating the machine. Attach only one fall restraint to each anchorage point.
Electrocution Hazard
ELECTROCUTION HAZARD! THIS MACHINE IS NOT INSULATED!
DEATH OR SERIOUS INJURY will result from contact with or inadequate clearance from any electrically
charged conductor.
You must maintain a CLEARANCE OF AT LEAST 10 FEET (3.05 m) between any part of the machine, or its
load, and any electrical line or apparatus carrying over 300 Volts up to 50,000 Volts. One foot (30.5 cm)
additional clearance is required for every additional 30,000 Volts.
Observe Minimum Safe Approach Distance.
This machine is not electrically insulated and will not provide protection from contact with or
proximity to electrical current.
Maintain safe distances from electrical power lines and apparatus in accordance with
applicable government regulations and the following chart:
Allow for platform movement, electrical line sway or sag and beware of strong or gusty winds.
Keep away from the machine if it contacts energized power lines. Personnel on the ground or
in the platform must not touch or operate the machine until energized power lines are shut off.
Do not use the machine as a ground for welding.
13301
13302
13303
Minimum Save Approach Distance
Voltage Minimum Safe Approach Distance
Phase to Phase Feet Meters
0 to 300 Volts Avoid Contact
Over 300V to 50kv 10 3.1
Over 50KV to 200KV 15 4.6
Over 200KV to 350KV 20 6.1
Over 350KV to 500KV 25 7.6
Over 500KV to 750KV 35 10.7
Over 750KV to 1000KV 45 13.7
1030-PA

Page 4 1OP1030 – February 2018
Safety
Tip-over Hazards
DO NOT exceed the maximum platform capacity. The weight of options and accessories will
reduce the rated platform capacity and must be factored into the total platform load. Refer to
the decals on the options.
The machine must be positioned on a firm, level surface before operating.
DO NOT elevate the platform when the machine is on a surface that is soft and / or on a
slope.
Use extreme caution to lower the platform.
DO NOT push o or pull toward any object outside the platform. DO NOT push the machine
or other objects with the platform. DONOT contact adjacent structures with the platform.
DO NOT tie the platform toadjacent structures.
DO NOT usethe platform controls to free a platform that is caught, snagged or otherwise
prevented from normal motion byanadjacent structure.
For outdoor rated machines, DO NOT elevate the platform when wind speeds are in excess of
28 m.p.h. (12.5 m/s). If wind speeds exceed 28 m.p.h. (12.5 m/s) when the platform is elevated,
carefully lower the platform and discontinue operation.
DO NOT increase thesurface area oftheplatform (i.e. cover the rails with tarp or plywood).
Increased surface area exposed to the wind will decrease machine stability.
DO NOT attach overhanging loads or use the machine as a crane. DO NOT place loads outside
the platform perimeter.
NEVER transport tools and materials unless they are firmly secured. Secure all tools and loose
materials.
NEVER alter or disable any machine components.
NEVER replace any part of the machine with items of different weight or specification.
NEVER modify or alter the work platform without written permission from GMG. NEVER
place ladders or scaffolds inthe platform or against anypart of the machine.
NEVER use the machine on a moving ormobile surface or vehicle.
Ensure that all wheels are in good condition and nuts are properly torqued.
DO NOT operate the machine with the chassis tray open.
DO NOT alter or disable the limit switches or machine components that in any way affect
safety and stability.
DO NOT replace items critical to machine stability with items of different weight or
specification. DO NOT modify or alter this machine without prior written permission from
the manufacturer.
DO NOT usebatteries that weigh less than the original equipment.
DO NOT OVERLOAD
DO NOT PUSH OR PULL OBJECTS
OUTSIDE PLATFORM
DO NOT ELEVATE IN WINDY
CONDITIONS
DO NOT USE AS CRANE
13304
13308
13307
13306
Maximum Allowable Side Force
50 lbs (222 N) per person
1030-PA

1OP1030 – February 2018 Page 5
Safety
Fall Hazards
DO NOT sit, stand or climb on the platform guard rails. Maintain a firm footing on the
platform floor at all times.
DO NOT exit the platform when elevated
Keep the platform floor clear of debris.
DO NOT fasten a fall restraint lanyard to an adjacent structure.
Ensure that all gates are properly closed and secured before operating the machine.
Operators must comply with employer and job site rules and governmental regulations
regarding the use of personal protective equipment.
Collision Hazards
Check for equipment, materials or other obstructions before moving.
Check for overhead obstructions before operating.
Check for crushing hazards when holding the platform rail before operating.
Be aware of limited sight distance and blind spots when operating.
DO NOT operate in the path ofany crane unless the controls of the crane have been locked
out and/or precautions have been taken to prevent any possible collision.
Horseplay is PROHIBITTED.
Watch forpersonnel and obstructions below the platform when lowering the platform.
Keep hands and limbs out of scissors.
Use common sense and planning when operating the machine with the controller from the
ground. Maintain safe distances between the operator, the machine and fixed objects.
DO NOT CLIMB ON RAILS
13309
13313
13312
13311
1030-PA

Page 6 1OP1030 – February 2018
Safety
Additional Safety Hazards
Explosion and Fire Hazards
DO NOT operate the machine in hazardous locations or locations where potentially
flammable or explosive gases or particles may be present.
Damaged Machine Hazards
Conduct a thorough prestart inspection of the machine and test all functions before each work
shift to check for damage, malfunction and unauthorized modification. Tag and remove a
damaged, malfunctioning or modified machine from service. DO NOT use a damaged,
malfunctioning or modified machine.
Routine maintenance must be performed by the operator before each work shift. Scheduled
maintenance must be performed by a qualified service technician at scheduled intervals. Tag
and remove from service any machine that has not had scheduled preventative maintenance
performed.
Check that all safety and instructional decals are in place and undamaged.
Check that the operator’s, safety and responsibilities manuals are present in the storage
container located in the platform. All manuals must be complete, undamaged and readable.
Bodily Injury Hazards
DO NOT operate the machine when there is a hydraulic fluid or air leak. Hydraulic fluid or air
under pressure can penetrate and/or burn skin.
All compartments must remain closed and secure during machine operation. Improper
contact with components under any cover will cause serious injury. Only trained maintenance
personnel should access compartments. The operator should only access a compartment when
performing prestart inspection.
Weld Line to Platform Safety (if equipped)
Read, understand and follow all warnings and instructions provided with the welding power
unit.
Do not connect weld leads or cables unless the welding power unit is turned off at the platform
controls.
DO NOT operate unless the weld cables are properly connected.
DO NOT connect the ground lead to the platform.
Battery Safety
Burn Hazards
Batteries contain acid. Always wear protective clothing and eye wear when working with
batteries.
Avoid spilling or contacting battery acid. Neutralize battery acid spills with baking soda and
water.
Explosion Hazard
Keep sparks, flame and lighted tobacco away from batteries. Batteries emit explosive gas.
Leave the battery tray open while charging to avoid gas buildup.
Electrocution Hazard
Avoid contact with electrical terminals.
1030-PA

1OP1030 – February 2018 Page 7
Controls & Components
Controls & Components
Component Locations
Manuals
Case
Platform
Controls
Platform
Guardrails
Entry Gate
Lift
Cylinder
Chassis
Lower
Control
Station
Power /
Emergency
Stop Switch
Battery
Charger
Battery
Charge
Location
Forklift
Pockets
Forklift
Pockets
Entry Ladder
Emergency Lower
Handle
Maintenance
Lock
1030-PA

Page 8 1OP1030 – February 2018
Controls & Components
Platform Controls
ALWAYS be aware of the machine’s position and of your surroundings
before activating any control function.
CONTROL DESCRIPTION
1 Lift Button Push and hold button to LIFT platform
2 Lower Button Push and hold button to LOWER platform
3 Emergency Stop Switch Press the EMERGENCY STOP switch at any time to stop all machine functions. Pull the
switch out to reset.
UP
DOWN
1
2
3
1030-PA

1OP1030 – February 2018 Page 9
Controls & Components
Lower Controls
ALWAYS be aware of the machine’s position and of your surroundings
before activating any control function.
CONTROL DESCRIPTION
1 Platform Lift/Lower Switch With the Key Switch in the BASE position, move this switch up to lift the platform or down
to lower the platform
2 Key Switch PLATFORM Select to operate from the platform control panel
BASE Select to operate from the lower control panel
OFF Select to stop operation from either control panel
3 Emergency Stop Switch Press the EMERGENCY STOP switch at any time to stop all machine functions. Pull the
switch out to reset.
4 Hour Meter Indicates total elapsed time of machine operation.
5 Circuit Breaker Trips when there is excessive electrical load. Push to reset.
15 A
15
3
4
2
1030-PA

Page 10 1OP1030 – February 2018
Workplace Inspection
Workplace Inspection
DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection,
Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating
Instructions section.
Inspect the workplace and determine whether the workplace is suitable for safe machine operation. Do this before moving the
machine to the workplace.
Be sure the lift is the correct machine for the job.
Be aware of workplace conditions, and continue to watch for hazards while operating the machine.
Workplace Inspection
Before operating the machine, check the workplace for all possible hazards, including but not
limited to:
• drop-offs or holes, including those concealed by water, ice, mud, etc.
• sloped, unstable or slippery surfaces
• bumps, surface obstructions and debris
• overhead obstructions and electrical conductors
• other objects or equipment
• hazardous locations and atmospheres
• inadequate surface and support to withstand all load forces imposed by the machine
• wind and weather conditions
• the presence of unauthorized personnel
• other possible unsafe conditions
1030-PA

1OP1030 – February 2018 Page 11
Operating Instructions & Function Tests
Operating Instructions & Function Tests
DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection,
Prestart Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating Instructions
section.
This section provides instructions and tests for each function of machine operation. Follow all safety rules and instructions. The
operator must conduct inspections and a Functions Test of the machine before each work shift to check that all machine systems are
working properly.
Test the machine on a firm level surface with no debris, drop-offs, potholes or overhead obstructions. Perform each step outlined in
this section.
This machine shall only be operated by trained and authorized personnel. If multiple operators use this machine, all must be trained,
qualified and authorized to use it. New operators must perform a Pre-Start Inspection and Functions Test prior to operating the
machine.
Operators must comply with all employer and job site rules and governmental regulations regarding the use of personal protective
equipment.
DO NOT use a machine that is malfunctioning. If any function does not perform as described, tag the machine and remove for repair
by a qualified service technician. After repairs are completed, a Pre-Start Inspection and Functions Test must be performed before
using the machine.
Prestart
•PerformPrestart Inspection (seepage 21).
•Check Emergency Stop Switch at the platform controls – pull out to reset.
•Check Main Power/Lower Emergency Stop Switch atthe lower controls – pull
out to reset.
Functions Test
1 Select a test area that is firm, level and free of obstruction.
2 Be sure the battery pack is connected.
At the Ground Controls
Test Emergency Stop
3 Set the red Emergency Stop button tothe on position atboth the ground and
platform controls
4 Turn the Key Switch to ground control.
5 Push inthe ground red Emergency Stop button tothe off position.
• Result: Nofunctions should operate.
6 Pull out the red Emergency Stop button to the ON position.
Emergency Stop Switch
1030-PA

Page 12 1OP1030 – February 2018
Operating Instructions & Function Tests
Test Up/Down Functions
Check the area above and around the machine for obstructions and electrical power lines before
operating the machine.
The descent alarm sounds at a continuous beep until the lower button or switch is released.
7 At the Lower Controls station, turn the Key Switch to off or platform position.
8 At the Lower Controls station, push up and hold the platform up / down switch.
• Result: No function should operate.
9 Turn the Key Switch to ground control position.
10 At the Lower Controls station, push up and hold the Platform Up switch.
• Result: The platform should raise.
11 Push down and hold the Platform Down switch.
• Result: The platform should lower toend. The descent alarm should sound.
Test the Emergency Lowering
12 Activate the up function and raise the platform approximately 2 ft / 60 cm.
13 Pull the Emergency Lowering Knob.
• Result: The platform should lower. The descent alarm will not sound.
At the Platform Controls
14 Turn the Key Switch to platform control.
Test Emergency Stop
15 Push in the platform red Emergency Stop button to the off position.
• Result: No functions should operate.
16 Pull out the red Emergency Stop button to the on position and push the lower button
on the platform controls
• Result: The descent alarm should sound.
Emergency Lowering Handle
1030-PA

1OP1030 – February 2018 Page 13
Operating Instructions & Function Tests
Test Function Enable and Up/Down Functions
Check the area above and around the machine for obstructions and electrical power lines before
operating the machine.
17 Press and hold the Lift button on the upper control box.
18 Release the Lift button.
Test Anti Surf Braking
20 Press and hold the Lift button on the upper control box for 2 seconds.
• Result: The Anti Surf brakes should apply to the rear wheels and prevent any
rolling of the machine.
• Result: The platform should rise.
• Result: The platform should stop rising.
19 Press and hold the Lower button on the upper control box.
• Result: The platform should lower. The descent alarm should sound while the
button is pressed.
21 Press and hold the Lower button on the upper control box until the machine is in
the stowed position.
• Result: The Anti Surf brakes should release and allow the machine to roll.
Test Foot Applied Brakes
22 At the front wheels, push down on the foot applied brake so that ON is positioned
closest to the ground.
• Result: The wheel should not be able to easily move while pushing on the
machine.
23 At the front wheels, push down on the foot applied brake so that OFF is positioned
closest to the ground.
• Result: The wheel should be able to easily move while pushing on the machine
1030-PA

Page 14 1OP1030 – February 2018
Operating Instructions & Function Tests
Operating Instructions
Check the area above and around the machine for obstructions and electrical power lines before
operating the machine.
Emergency Stop
• Push in the red Emergency Stop button to
the off position atthe ground controls or
the platform controlsto stop all machine
functions.
•Ifanyfunctionoperates when either red
Emergency Stop button is pushed in, repair
the Emergency Stop function before using
the machine.
Emergency Lowering
If the control system fails while the platform is elevated, use the emergency lowering procedure to
safely lower the platform.
DO NOT climb down the scissor assembly or exit the platform.
The Emergency Lowering System is used to lower the platform in case of power failure.
• Pull the Emergency Lowering Handle to lower the platform.
Emergency
Stop Switch
15 A
Emergency
Stop Switch
1030-PA

1OP1030 – February 2018 Page 15
Operating Instructions & Function Tests
Operation from Ground
Check the area above and around the machine for obstructions and electrical power lines before
operating the machine.
1 Turn the Key Switch to ground control.
2 Set the red Emergency Stop button to the on position at both the ground and platform
controls.
3 Be sure the battery pack is connected before operating the machine.
To Position Platform from Ground
Move the up/down toggle switch according to the markings on the control panel.
Operation from Platform
Check the area above and around the machine for obstructions and electrical power lines before
operating the machine.
1 Turn the Key Switch to platform control.
2 Set the red Emergency Stop button to the on position at both the ground and
platform controls.
3 Be sure the battery pack isconnected before operating the machine.
ToPosition Platform
1 Push the Lift button to raise the platform.
2 Push the Lower button to lower the platform.
UP
DOWN
1030-PA

Page 161OP1030 – February 2018
Operating Instructions & Function Tests
Operation from Ground with Controller
Use extreme caution when operating the machine with the controller from the ground
Maintain safe distances between operator, machine and fixed objects.
Be aware of the direction the machine will travel when using the controller.
Maintenance Lock
DEATH OR SERIOUS INJURY HAZARD!
NEVER perform work or inspection on the machine with the platform elevated without first blocking
the scissor assembly with the Maintenance Lock.
DO NOT engage the Maintenance Locks unless the platform in empty of tools and material.
1 Raise the platform approximately 7.2 ft/2.2m from the ground
2 Rotate the Maintenance Lock and allow it to hang straight down.
3 Lower the platform until the Maintenance Lock(s) rests securely on the link.
Keep clear of the Maintenance Lock when lowering the platform.
Stow the Maintenance locks by raising the platform slightly and rotating them to the stowed
position.
Maintenance Lock
1030-PA

1OP1030 – February 2018 Page 17
Operating Instructions & Function Tests
Shutdown Procedure
• When finished with the machine, place the platform in the stowed position.
• Park the machine on a level surface.
• Turn the Key Switch to the OFF position and remove the key to prevent
unauthorized use.
• Carefully exit the platform using a constant three (3) point dismount/grip.
• Push in the red Main Power/Lower Emergency Stop Switch button to the OFF
position when leaving the machine at the end of the work day.
• Charge the batteries.
Battery Charging
The charger surface can get hot while operating. Contact with the skin or surrounding materials should
be avoided.
To reduce the risk of an electric shock, connect only to a properly grounded single-phase (3 wire) outlet.
Do not use an external charger or booster battery.
Charge the battery in a well-ventilated area.
Use proper AC input voltage for charging as indicated on the machine.
Use only GMG authorized batteries and chargers.
IMPORTANT— Be sure to disconnect the charger from the outlet before attempting to
operate the unit.
The charger will indicate the status of the charge cycle.
Battery Charger
Battery Charge
Location
1030-PA

Page 18 1OP1030 – February 2018
Maintenance
Maintenance
DO NOT operate this machine until you have read and understood this manual, have performed the Workplace Inspection,
Pre-Start Inspection and Routine Maintenance, and have completed all the test operations detailed in the Operating
Instructions section.
The operator must conduct a Pre-Start Inspection of the machine and test all functions before each work shift to check for damage,
malfunction and unauthorized modification. The inspection is designed to discover if anything is apparently wrong with a machine
before the operator performs the function tests.
Tag and remove a damaged, malfunctioning or modified machine from service. DO NOT use a damaged, malfunctioning or modified
machine.
Use the Pre-Start Inspection to determine what Routine Maintenance is required. The operator may perform only the routine
maintenance items specified in this manual.
IMPORTANT—Scheduled maintenance inspection checklists are included in this manual for use only by qualified service
technicians. Only qualified service technicians may perform repairs to the machine. After repairs are completed,
the operator must perform a Pre-Start Inspection before proceeding to the Functions Test.
Hydraulic fluid under pressure can penetrate and burn skin, damage eyes, and may cause serious
injury, blindness, and death. Repair leaks immediately. Fluid leaks under pressure may not always be
visible. Check for pin hole leaks with a piece of cardboard, not your hand.
NEVER perform work or inspection on the machine with the platform elevated without first blocking
the scissor assembly with the Maintenance Lock (see page 16).
Perform scheduled maintenance at recommended intervals. Failure to perform scheduled
maintenance at recommended intervals may result in a defective or malfunctioning machine and may
result in injury or death of the operator. Keep maintenance records current and accurate.
Immediately report any damage, defect, unauthorized modification or malfunction to your supervisor.
Any defect must be repaired prior to continued use. DO NOT use a damaged, modified or
malfunctioning machine.
Never leave hydraulic components or hoses open. Plug all hoses and fitting immediately after
disassembly to protect the system from outside contamination (including rain).
Never open a hydraulic system when there are contaminants in the air.
Always clean the surrounding area before opening hydraulic systems.
Use only recommended lubricants. Improper lubricants or incompatible lubricants may cause as much
damage as no lubrication.
Watch for makeshift “fixes” which can jeopardize safety as well as lead to more costly repair.
Inspection and maintenance should be performed by qualified personnel familiar with the equipment.
1030-PA
