GO RHINO! PRODUCTS 3000 SERIES INSTALLATION INSTRUCTIONS
03-06 FORD EXPEDITION2/4WDPARTNO. 3285 B-C
QTY PARTS DESCRIPTION
1P200 PLUG KIT
6¼”X¾”BUTTONHEADBOLTS
6 ¼” LOCK WASHERS
6 ¼” FLAT WASHERS
6 ¼” HEX NUTS
4 5/16” X 1” HEX BOLTS
4 5/16” LOCK WASHERS
4 5/16” HEX NUTS
6 3/8” X 1” BUTTON HEAD BOLTS
63/8”X1”HEXBOLTS
6 3/8” LOCK WASHERS
6 3/8” HEX NUTS
QTY PARTS DESCRIPTION
4 ½” X 1 ½” HEX BOLTS
4 ½” FLAT WASHERS
4 ½” LOCK WASHERS
4 ½” HEX NUTS
2 1122LP LICENSE PLATE BRACKETS
1 1122AD DRIVER SIDE UPPER BRACKET
1 1122AP PASSENGER SIDE UPPER BRACKET
1 1122BD DRIVER SIDE LOWER BRACKET
1 1122BP PASSENGER SIDE LOWER BRACKET
51/4" PLASTIC PIN GRIPS
ASSEMBLY INSTRUCTIONS
STEP 1. BEGIN THE ASSEMBLY BY LOOSELY
ATTACHING THE BOTTOM STEP TUBE TO THE GRILLE
GUARD SIDE PLATES USING THE 3/8” X 1” BUTTON
HEAD BOLTS.
STEP 2.INSTALL THE TUBE CONNECTORS FROM
THE P200 PLUG KIT INTO THE TOP TUBE.
STEP 3. POSITION THE CENTER PLATE BETWEEN THE
GRILLE GUARD SIDE PLATES. ATTACH USING THE 3/8"
HEX HEAD BOLTS SUPPLIED.
STEP 4.ALIGNTHEGRILLEAND TIGHTEN ALL NUTS
AND BOLTS.
INSTALLATION INSTRUCTIONS
STEP 1. REMOVE THE LICENSE PLATE AND MOUNTING BRACKET FROM THE FRONT BUMPER.
STEP 2. BEGINNING WITH THE DRIVER SIDE, LOCATE
AND REMOVE THE TWO HEX NUTS FROM THE BOLT
ASSEMBLY THAT SECURE THE BUMPER TO THE
FRAME FLANGE.
NOTE: REMOVE THE (3) PLASTIC RIVETS AND PULL BACK THE RUBBER SPLASH GUARD TO EASE THE INSTALLATION.

2
2
STEP 3. POSITION 1122BD LOWER BRACKET OVER
THE BOLTS, AND ATTACH IT TO THE FRAME FLANGE
USING THE FACTORY NUTS. (FINGER TIGHTEN ONLY).
STEP 4. INSERT 1122AD UPPER BRACKET THROUGH
THE OPENING IN THE GRILLE, AND ATTACH IT TO
1122BDLOWERBRACKETUSINGTHE5/16” HEX HEAD
BOLTS. (FINGERTIGHTENONLY).
STEP 5. REPEAT THE ABOVE STEPS FOR THE PASSENGER SIDE BRACKETS.
STEP 6. ATTACH THE GRILLE GUARD ASSEMBLY TO
THE LOWER BRACKETS USING THE ½” FASTENERS.

3
STEP 7. ATTACH THE GRILLE GUARD ASSEMBLY TO
THE UPPER BRACKETS USING THE 3/8” FASTENERS.
STEP 8. ALIGN THE GRILLE GUARD ASSEMBLY WITH THE FRONT OF THE VEHICLE AND TIGHTEN ALL MOUNTING
NUTS AND BOLTS.
STEP 9. ATTACH 1122LP LICENSE PLATE BRACKETS
AND THE LICENSE PLATE TO THE BOTTOM SIDE OF
THE GRILLE GUARD CENTER PLATE, USING THE ¼”
FASTENERS.
STEP 10. RE-ATTACH THE RUBBER SPLASH GUARD USING THE PLASTIC RIVETS SUPPLIED.
