gofanco PRO-QuadView User manual

PRO-QuadView
4x1 HDMI Quad-Viewer & Seamless Switcher
®
Made in Taiwan
User‘s Guide

®
PRO-QuadView
Congratulaons for owning a gofanco product. Our products
aim to meet all your connecvity needs wherever you go.
Have fun with our products!
Please read this manual carefully before rst use.
If you need more informaon about our products, please visit
www.gofanco.com.
For technical support, please email us at
[e-mail].
For drivers/manuals download, please go to
hp://www.gofanco.com/download.

®
PRO-QuadView
1. Introduction
3
The PRO-QuadView 4x1 HDMI Quad-Viewer & Seamless
Switcher provides the most exible and cost eective so-
lution in the market to route high denition video source
from any of the four HDMI sources to the remote display
at the same time. Besides, this device supports a variety of
video layout (5 default modes) and seamless switching in
One-View Mode . This solution is well suited for use in digi-
tal signage, conference room presentation systems or other
similar settings or applications.
With up to FHD output resolution, users can display the re-
sulted mixed video with improved presentation quality. In
the meantime, the unit can be controlled thru the IR remote,
software and push button control to provide the most exi-
ble control way to t into any applications.
• 4 x HDMI inputs and 1 x HDMI output
• Input resolution supports 480i/480p/576i/576p/720p/
1080i/1080p
• Output resolution supports 720p@60 & 1080p@60
• Supports HDCP 1.4
• Supports 5 Display Modes: One-View Mode , Dual-View
Mode(left & right), Quad-View Mode, Quad-View Cycled
Mode, Quad-View H mode
• Supports seamless switching in One-View Mode
2. Features

®
PRO-QuadView
4
• Supports audio extraction via stereo audio from selected
HDMI input
• Supports audio switch function
• Firmware upgradable for support of new features and
technology enhancements
• Software control through micro-USB
• Supports IR remote, software and push button control
• 1x PRO-QuadView
• 1x DC 5V 2A
• 1x IR Remote control (15 keys)
• 1x User Manual
4. Package Contents

®
PRO-QuadView
3. Specications
5
Item Description
Technical
Role of usage Multi-viewer/ video processor
HDCP compliance HDCP 1.4
Video bandwidth HDMI [6.75Gbps]
Output Video Support 720p60/ 1080p60
Input Video Support 480i/480p/576i/576p/720p/1080i/1080p
Video Format Support DVI/HDMI
Audio support Bypass
Control IR remote, software and push button control
Embedded video mixer Yes
Input TMDS signal 1.2 Volts [peak to peak]
ESD protection Human body model — ±15kV [air-gap discharge] &
±8kV [contact discharge]
Input 4x DVI/HDMI + 1x micro-USB
Output 1x HDMI + 1x 3.5mm phone jack
HDMI connector Type A [19-pin female]
USB connector Micro-USB
Mechanical
Housing Metal enclosure
Dimensi-
ons
[L x D x H]
Model 150 x 93 x 24mm [5.9“ x 3.7“ x 0.9“]
Package 198 x 137 x 74mm [7.8" x 5.4" x 2.9"]
Carton 420 x 400 x 300mm [1'4"x 1'3" x 11.8"]
Weight Model 273g [9.6 oz]
Package 553g[1.2 lbs]
Power supply 5V 2A DC
Power consumption 5 Watts [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]

®
PRO-QuadView
5. Connection Diagram
6

®
PRO-QuadView
1. Stereo output (3.5mm)
2. IR SENSOR: IR sensor for receiving the IR commands from IR re-
mote
3. Dip Switch: [UP] Normal mode; [DOWN] Firmware Update mode
4. Micro-USB: for software control or rmware update
5. Source Status LED: Input source detection LED (from the right to
the left is input 1-4)
6. One-View Mode : Switch source in One-View (full screen) mode
7. Audio Switch: Switch stereo audio out from source 1-4 or mute
8. Quad-View Cycled Mode: Switch source in Quad-View Cycled
Mode
9. Default layout Modes: Switch 3 default layout modes
Dual-View Mode(left & right), Quad-View Mode, Quad-View H mode
6. Panel Description
7
23 4 6 7 8 9 10
5
1
Front Panel
10.1080p/ 720p: Switch output resolution in 1080p/ 720p

®
PRO-QuadView
11 12 13
Real Panel
11. SOURCE 1-4: HDMI inputs (from the left to the right is input 1-4)
12. HDMI OUT: HDMI output
13. +5V DC: 5V DC power jack
8

®
PRO-QuadView
7. Operation Approach
9
Method A: IR Remote Control
Button Function
POWER Power ON/OFF the device
F1 Reserved
F2 Reserved
CH 1 Input 1 in One-View Mode
CH 2 Input 2 in One-View Mode
CH 3 Input 3 in One-View Mode
CH 4 Input 4 in One-View Mode
Quad-View mode
Quad-View H mode
Dual-View mode (left & right) 1
Dual-View mode (left & right) 2
Switch stereo audio from source 1-4
Audio Mute
Switch channel in One-View mode
Switch channel in Quad-View cycled mode

®
PRO-QuadView
10
Method B: Software Control through Micro-USB port
1. System Requirement
(1) OS information: MS Win XP/7/8/10
(2) Baud rates: 115200
(3) Software size: 3KB
(4) Minimum RAM requirement: 256MB
2. Control Interface
Before clicking on the icon of the software, make sure
you have secured the connection between your computer
COM port and the 4K EDID Emulator.
When clicking on the software control program, the fol-
lowing window will pop-up (under Microsoft Windows 7,
please run as administrator.)
After you clicking the OK button, it will enter directly to the con-
trol interface (Please click DISCONNECTED button to connect the
software),

®
PRO-QuadView
11
1
2
3
6
5
47
8
9 10
1Refresh
2COM Port Selection & Connection Status
3Factory Reset
4Video Switch – One-View Mode (Full Screen)
5Video Switch – Quad-View Mode
6Video Switch – Dual-View Mode
7Audio Switch
8Input Information
9Output Resolution
10 System Update

®
PRO-QuadView
Dual-View Mode
(1) Refresh
This button can get all information of the device and update this soft-
ware state.
(2) COM Port Selection & Connection Status
Please ensure you have secured the connection between your com-
puter COM port and the device. Select correct COM port and click the
connection/disconnect button to connect software.
(3) Factory Reset
The process of default reset will take about 10~15 seconds.
(4) Video Switch – One-View Mode (Full Screen)
Select input source in One-View Mode (full screen).
(5) Video Switch – Quad-View Mode
We provides 3 default Quad-View Mode for user to select dierent
layout modes.
(6) Video Switch – Dual-View Mode
It has 2 Dual-View layout modes for user to select.
12
One-View Mode
Quad-View Mode
Quad-View cycled Mode
Quad-View H Mode

®
PRO-QuadView
(7) Audio Switch
To set up the audio source of the output (stereo and HDMI).
(8) Input Information
Show the input source resolution. You also can click button
to refresh input resolution information.
(9) Output Resolution
We provide 2 most common output resolution (1080p & 720p) for
user select.
(10) System Update
Before you start to update, please make sure you have secured the
connection between your computer COM port and the device.
• Please move the dip switch on F/W mode, and then power cycle the device.
• Click button to do rmware update.
• The rmware update window shows up as below.
• Click button to load rmware le.
• Click button to start rmware update process.
• After updating, please move the dip switch on normal mode and power cycle
the device.
13

®
PRO-QuadView
14
8. Limited Warranty
The SELLER warrants the PRO-QuadView 4x1 HDMI Quad-Viewer & Se-
amless Switcher free from defects in the material and workmanship for
1 year from the date of purchase from the SELLER or an authorized de-
aler. Should this product fail to be in good working order within 1 year
warranty period, The SELLER, at its option, repair or replace the unit,
provided that the unit has not been subjected to accident, disaster, ab-
use or any unauthorized modications including static discharge and
power surge. This warranty is oered by the SELLER for its BUYER with
direct transaction only. This warranty is void if the warranty seal on the
metal housing is broken.
Unit that fails under conditions other than those covered will be repai-
red at the current price of parts and labor in eect at the time of repair.
Such repairs are warranted for 90 days from the day of reshipment to
the BUYER. If the unit is delivered by mail, customers agree to insure the
unit or assume the risk of loss or damage in transit. Under no circum-
stances will a unit be accepted without a return authorization number.
The warranty is in lieu of all other warranties expressed or implied, in-
cluding without limitations, any other implied warranty or tness or
merchantability for any particular purpose, all of which are expressly
disclaimed.
Proof of sale may be required in order to claim warranty. Customers
outside Taiwan are responsible for shipping charges to and from the
SELLER. Cables and power adapters are limited to a 30 day warranty
and must be free from any markings, scratches, and neatly coiled.
The content of this manual has been carefully checked and is belie-
ved to be accurate. However, The SELLER assumes no responsibility for
any inaccuracies that may be contained in this manual. The SELLER will
NOT be liable for direct, indirect, incidental, special, or consequential
damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. Also, the technical infor-
mation contained herein regarding the 4K EDID Emulator features and
specications is subject to change without further notice.

®
PRO-QuadView
15
The product name and brand name may be registered trademarks of related manufacturers. TM and ®
may be omied on the user‘s guide. The pictures on the user‘s guide are just for reference, and there
may be some slight dierences with the actual products.
We reserve the rights to make changes without prior noce to a product or system described herein to
improve reliability, funcon, or design.
