Goldmedal 1027HDX User manual

Part No.12644
Instruction Manual
10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA
Hawaii’s Finest
Model No. 1027HD, 1027HDX

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 2
gmpopcorn.com
SAFETY PRECUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment will
void the warranty and may cause a dangerous condition. NEVER make
alterations to this equipment. Read the Installation, Operating, and
Maintenance Instructions thoroughly before installing, servicing, or operating
this equipment.
014_051514
WARNING
This machinery contains sharp blades. Keep hands and body parts clear
at all times.
037_103114
WARNING
NEVER put your fingers into the shaver body (the goose-neck, ice chute, or
hopper). Serious injury may occur.
017_103114
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 3
gmpopcorn.com
SAFETY PRECAUTIONS (continued)
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_010914
WARNING
DO NOT allow direct contact of this equipment by the public when used in
food service locations. Only personnel trained and experienced in the
equipment operation may operate this equipment.
Carefully read all instructions before operation.
012_010914
WARNING
This machine is NOT to be operated by minors.
007_010914
Note: Improvements are always being made to Gold Medal’s equipment. This
information may not be the latest available for your purposes. It is critical that
you call Gold Medal’s Technical Service Department at -800-543-0862 for any
questions about your machine operations, replacement parts, or any service
questions. (Gold Medal Products Co. does not assume any liability for injury due
to careless handling and/or reckless operation of this equipment.)

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 4
gmpopcorn.com
General Operating Safety
when using a Foot Switch
WARNING
Always use a grounded plug or cable. DO NOT cut off the ground prong and
be sure to ground the foot switch with the ground screw provided.
CAUTION
Failure to use foot switch safely could result in personal injury. Foot switch
should only be used where adequate guards or other safety devices are in
place for those applications where the use of a foot switch could cause
personal injury.
•Follow the appropriate wiring and safety requirements as set forth in the American
National Standards Institute (ANSI) and National Electrical Code (NEC) or other
appropriate standards.
•Use proper electrical circuits and circuit protection when wiring foot switch.
•Disconnect power before servicing.
•Do not allow cord to rest on floor or in areas where it can be a tripping hazard or can be
abused by heavy traffic.
•Do not leave foot switch accessible to inadvertent operation when left unattended or
when not being used.
•Do not bypass any machine or equipment safety features with this foot switch.
•Replace damaged cord immediately.
•It is the responsibility of the user to determine the suitability of a foot control for the
intended use.
•It is the responsibility of the user to comply with federal, state and local safety and health
regulations.

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 5
gmpopcorn.com
INSTALLATION INSTRUCTIONS
Inspection of Shipment
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims
should be filed immediately with the transportation company. The warranty does not cover
damage that occurs in transit, or damage caused by abuse, or consequential damage due to the
operation of this machine, since it is beyond our control (reference warranty in back of manual).
Manual
Read and understand the operator’s manual and all other safety instructions before using this
equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold
Medal Products Co., 0700 Medallion Drive, Cincinnati, OH 4524 USA -(800)-543-0862.
Items Included with this Unit
Drain Hose
Optional Accessory: Foot Switch (sold separately, Item No. 008 or 008EX)
Setup
This unit has been tested at the factory.
. Remove all packaging and tape prior to operation.
2. Place unit on a sturdy, level base which can withstand accidental dripping of water
and ice.
3. Connect the drain hose to funnel excess water to floor drain or basin tub. Drained
water is not intended for human consumption.
4. After setup, the unit should be cleaned prior to use (see Care and Cleaning section of
this manual).

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 6
gmpopcorn.com
Electrical Requirements
The following power supply must be provided:
1027HD: 20 V~, 536 W, 60 Hz
1027HDX: 230 V~, 536 W, 50 Hz
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
A certified electrician must furnish sufficient power for proper machine operation and install any
supplied receptacle. We recommend this equipment be on a dedicated and protected circuit.
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold
Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The
use of extension cords is not recommended due to safety concerns, and may cause sacrificed
and/or reduced performance. Make sure cord is located to prevent a trip hazard or unit upset.
Before You Plug In Machine
. Make sure all machine switches are in the OFF position before plugging the equipment
into the receptacle.
2. Make sure the wall outlet can accept the grounded plugs (where applicable) on the
power supply cord.
3. The wall outlet must have the proper polarity. If in doubt, have a competent
electrician inspect the outlet and correct if necessary.
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable).
5. Install the unit in a level position.
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 7
gmpopcorn.com
OPERATING INSTRUCTIONS
Controls and Their Functions
MAIN SWITCH
Turns shaver motor “ON” or “OFF”.
RESET SWITCH
Motor overload switch.
BLADE ADJUSTMENT KNOB
Adjusts the blade height to change the ice texture.
Ice Requirements
The Hawaii’s Finest can take ice cubes or block ice, if you break the block into pieces
approximately 2 to 3 inches in size.
NOTE: The ice will not enter the shaving chute if the pieces are too large.
Operation of Hawaii’s Finest
. Allow ice to soften at least hour in an ice cooler before use. Using ice straight from
the freezer affects the quality of the shaved ice as well as damage the shaver blade.
2. Lift cover lid and load ice cubes about ½ full then close the lid. Be sure ice is loaded
evenly in each cavity. Place cup directly below the ice chute and turn power “ON”.
Failure to close the lid will cause machine not to operate!
3. Adjust the blade height with the adjustment knob to achieve the preferred ice texture.
4. To stop, turn power switch to the “OFF” position. Should the motor thermal protector
trip, reset it by pushing the red button. It is recommended the cause of over load be
found and eliminated before continuing. The machine may need to cool a bit before
the reset button may take effect.
NOTE: Never allow any foreign or metallic objects around the shaver area of the Hawaii’s
Finest. Ice picks, scoops, and debris that may be in the ice often damage blades.
Main S itch
Reset S itch
Blade Adjustment
Knob

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 8
gmpopcorn.com
Care and Cleaning
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
DO NOT immerse in water.
Always unplug the equipment before cleaning or servicing.
025_020314
WARNING
This machinery contains sharp blades. Keep hands and body parts clear
at all times.
037_103114
Good sanitation practice demands that all food preparation equipment be cleaned regularly (only
use non-toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of
advertising your product.
Follow the directions below to clean and sanitize the unit after each day of use.
. With the machine OFF, unplug the unit before attempting to clean.
2. Empty water from pans and clean using appropriate cleaners for the type of machine;
review all manufacturer’s instructions and warnings on cleaning product prior to use.
DO NOT use oven cleaners or abrasive materials as they will damage parts of the
machine.
DO NOT use Ammonia cleaners, they will damage plastic panels.

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 9
gmpopcorn.com
MAINTENANCE INSTRUCTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment will
void the warranty and may cause a dangerous condition. NEVER make
alterations to this equipment. Read the Installation, Operating, and
Maintenance Instructions thoroughly before installing, servicing, or operating
this equipment.
014_051514
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
CAUTION
THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY
FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH
ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE
OPERATOR.
027_010914

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 10
gmpopcorn.com
Blade Replacement
WARNING
This machinery contains sharp blades. Keep hands and body parts clear
at all times.
037_103114
This section describes the steps to replace the shaver blade and to disassemble the impeller.
ALWAYS turn the machine OFF and unplug unit from the power supply prior to disassembly or
replacement.
Pivot Pin
Ice Chute
(Screws to remove
are located on side.)
Blade Adjustment
Knob and Shaft
Steps for Blade Removal and Replacement
Spring
(located between
Blade Assembly and Unit)
Shaver Blade
Blade Assembly
Step
1:
Turn
machine OFF,
and
unplug the
unit from the power supply.
Step 2: Remove the (2) screws fastening the
ice chute, and remove ice chute.
Step 3: Unscrew the blade adjustment knob,
and remove shaft.
Step 4: Pull pivot pin out completely to free
blade assembly and spring for removal.
Step 5: Unfasten the (2) blade retaining
screws, then remove blade from assembly.
Step 6:
Position new blade on
assembly and fasten with the
(2) blade retaining screws.
(Blade may be sharpened for
reuse.)
Step 7: Reassemble in reverse
order (make sure spring
properly sets between blade
assembly and unit).
Blade Retaining
Scre s
Ice Chute

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 11
gmpopcorn.com
To Disassemble the Impeller
. Turn machine OFF, and unplug the unit from the power supply.
2. Remove lid by removing the wing nut and hinge pin.
3. Remove the four plastic button screws that hold the top hopper cover, then lift and
roll over.
3. Disconnect wire harness at plug.
4. Remove three thumb screws and remove impeller cover.
5. Remove impeller knob, and lift impeller off.
Note: For removal of Impeller Knob a screwdriver slot is supplied on bottom end of
motor.

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 12
gmpopcorn.com
ORDERING SPARE PARTS
. Identify the needed part by checking it against the photos, illustrations, and/or
parts list.
2. When ordering, please include part number, part name, and quantity needed.
3. Please include your model number, serial number, and date of manufacture (located
on the machine nameplate) with your order.
4. Address all parts orders to:
Parts Department
Gold Medal Products Co.
0700 Medallion Drive
Cincinnati, Ohio 4524 -4807
Or, place orders by phone or online:
Phone: [phone]
(5 3) 769-7676
Fax: [phone]
(5 3) 769-8500
E-mail: inf[email protected]
Web Page: www.gmpopcorn.com

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 13
gmpopcorn.com
Cabinet Exterior Assembly
1027HD
1027HDX
TOP COVER DOOR 2 9W 2 9W
2 TOP COVER 2557W 2557W
3 WING NUT 6-32 STL ST 2 52 2 52
4 ICE SHAVER DECAL 2 2 55 2 55
5
ICE CHUTE WELD ASSEMBLY
2683
2683
6
PEDISTAL MAIN WRAPPER
2639
2639
7
BACK COVER
2638
2638
8
/2 ID SILCON TUBING
.3'
2 56
2 56
9 BASE 2088 2088
0 RUBBER BUMPER 2 2487 2487
SUCTION CUP, /4-20 STUD 2 2642 2642
2
TOP COVER KNOB
4
2 2
2 2
3
HINGE PIN DOOR
2 45
2 45
Qty.Part DescriptionItem Part Number
1 2
3
4
5
6
7
8
9
10 11
13
12

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 14
gmpopcorn.com
Cabinet Exterior Assembly
1027HD
1027HDX
SWITCH MOUNTING BRACKET 2 36 2 36
2 DOOR SAFTEY SWITCH 2 6 2 6
3 /2 OD X /2 T MAGNET 2078 2078
4 MOUNTING BLOCK MAGNET 2 35 2 35
5
SPACER (Not Shown)
2 5 2 5
6
WATER SHIELD
2097 2097
7
IMPELLER
2090 2090
8
IMPELLER NUT
2 06 2 06
9 SPINNING HOPPER 2 09 2 09
0 DOOR SAFTEY SWITCH HARNESS 2 3 2 3
WIRING HARNESS BRACKET 2 46 2 46
2 UPPER BASIN 2556 2556
3 PUSHER IMPELLER (Not Shown) 2098 2098
4 PUSHER STUD (Not Shown) 2 04 2 04
5 BALL BEARING F. 5/8" SHFT (Not Shown) 209 209
6 WATER SHIELD HARNESS 2 60 2 60
Qty.Part DescriptionItem Part Number
1, 2, 3, 4, 5
7
8
9
11
4
3
2
10
12
13, 14, 15
6
16

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 15
gmpopcorn.com
Shaver Assembly
1027HD
1027HDX
BLADE ADJUSTMENT KNOB 2 2
2 SET SCREW 8-32 X /8 S.S. 2 65 2 65
3 BLADE ADJUSTMENT SCREW ASSEMBLY 2 25 2 25
4 ICE CHUTE WELD ASSY 2683 2683
5*
0-32 x /2 HOLLOW SET*
2 29 2 29
6
BLADE HOLDER PIN
2 0 2 0
7
BLADE HOLDER
2 95 2 95
8
THUMB SCREW 0-32 X 3/8
2 2 58 2 58
9 SHAVER BLADE 2094 2094
0
COMPRESSION SPRING
2 7
2 7
STUD SPRING RETAINER
2 43
2 43
Qty.Part DescriptionItem Part Number
*NOTE: Factory pre-set, DO NOT tamper with
1
2
3
4
7
5*
8
6
9
10
11

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 16
gmpopcorn.com
Cabinet Internal Assembly
1027HD
1027HDX
STRAIN RELIEF-WATER TIGHT 2 49 2 49
SPST ROCKER SWITCH 2 5
SPST ROCKER SWITCH 2 5EX
3 RESET SWITCH 23 6 23 6
4
MOTOR SUPPORT PLATE
25 4 25 4
5
DIRVE MOTOR
226 226
6
DRAIN TRAY UPPER BASIN
2643 2643
7
MOUNT BRACKET-SWITCH
2 8 2 8
Qty.Part DescriptionItem Part Number
2
1
2
3
5
4
6
7

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 17
gmpopcorn.com
Cabinet Bottom Assembly
1027HD 1027HDX
/4-20 X HX HD C S 8-8 4 2 85 2 85
2 5/ 6 FLAT WASHER, 8-8 4 2 84 2 84
3
BOTTOM COVER STAINLESS
2294
2294
4
/2 ID SILCON TUBING
.3'
2 56
2 56
5 STRAIN RELIEF #SR-6P3-4 76026 76026
LEAD-IN CORD 5 AMP PLUG 2 54
EXPORT POWER SUPPLY CORD 42369
7
HOSE CLAMP WITH SCREW
4 63 4 63
8
DRAIN HOSE 3/4 ID 7/8 OD
4'
2 59
2 59
Qty.Part DescriptionItem Part Number
6
1, 2
3
4
5
6
7 8

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 18
gmpopcorn.com
Wiring Diagram 1027HD

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 19
gmpopcorn.com
Wiring Diagram 1027HDX

Hawaii’s Finest Model No. 1027HD, 1027HDX
Page 20
gmpopcorn.com
© 2015 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of
Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website
display, without its express written consent.
WARRANTY
Gold Medal Products Co. warrants to the original purchaser each item of its manufacture to
be free of defects in workmanship and material under normal use and service. Gold Medal
Products Co.’s obligation under this warranty is limited solely to repairing or replacing parts,
f.o.b. Cincinnati, Ohio, which in its judgment are defective in workmanship or material and
which are returned, freight prepaid, to its Cincinnati, Ohio factory or other designated point.
Except for “Perishable Parts” on specific machines, the above warranty applies for a period
of two (2) years from the date of original sale to the original purchaser of equipment when
recommended operating instructions and maintenance procedures have been followed. These
are packed with the machine. Parts warranty is two (2) years, labor is six (6) months.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR
IMPLIED, AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON OUR PART,
INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY. THERE ARE
NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE
HEREOF. In no event shall Gold Medal Products Co. be liable for special, incidental or
consequential damages. No claim under this warranty will be honored if the equipment covered
has been misused, neglected, damaged in transit, or has been tampered with or changed in any
way. No claim under this warranty shall be honored in the event that components in the unit at
the time of the claim were not supplied or approved by Gold Medal Products Co. This warranty
is effective only when electrical items have been properly attached to city utility lines only at
proper voltages. This warranty is not transferable without the written consent of Gold Medal
Products Co.
The term “Original Purchaser” as used in this warranty shall be deemed to mean that person,
firm, association, or corporation who was billed by the GOLD MEDAL PRODUCTS CO.,
or their authorized distributor for the equipment.
THIS WARRANTY HAS NO EFFECT AND IS VOID UNLESS THE ORIGINAL
PURCHASER FIRST CALLS GOLD MEDAL PRODUCTS CO. AT 1-800-543-0862 TO
DISCUSS WITH OUR SERVICE REPRESENTATIVE THE EQUIPMENT PROBLEM,
AND, IF NECESSARY, FOR INSTRUCTIONS CONCERNING THE REPAIR OR
REPLACEMENT OF PARTS.
NOTE: This equipment is manufactured and sold for commercial use only.
10700 Medallion Drive, Cincinnati, Ohio 45241
-
4807 USA
gmpopcorn.com
Phone: [phone] Fax: [phone]
[phone] [phone]
