Goldmedal Shavette 1006 User manual

Part No. 29014
Revised May 2002
Shavette
Ice Shaver Instruction Manual
Model #1006, #1006EX
Cincinnati, OH 45241-4807 USA

Shavette Little Shaver
All Models #1006 and 1006EX
2
Safety Precautions

Shavette Little Shaver
All Models #1006 and 1006EX
3
INSTALLATION
The Shavette Little Shaver is the finest value in ice shaving on the market today. With only the slightest
amount of care, this unit will give years of trouble free service. The shaver is a simple little machine to
operate, but in order to get the best results, please read these instructions before you attempt to operate the
machine.
Plug in the lead-in cord and flip the motor switch to be sure the motor runs. On the end of the motor is the
shaver head, which is inside the shaver body (hopper). The pusher handle is packed in a small separate
box and must be connected to the shaver body. The pusher handle goes down the shaver body to press the
ice against the revolving shaver head. The revolving shaver head shaves the ice.
ELECTRICAL REQUIREMENTS
The Shavette Little Shaver operates on 120 Volt, 15 Amp, single phase, 60 cycle AC current. The Shavette
Little Shaver Export operates on 230 Volt, 50 cycle. Models are available in a 12 volt DC version. Be sure
that your electrical supply meets this requirement.
ICE REQUIREMENTS
The Shavette Little Shaver can take ice cubes or block ice, if you break the block into pieces approximately
3 to 4 inches in size.
NOTE: The ice will not enter the shaving chute if the pieces are too large.
MACHINE OPERATION
After unpacking the Shavette Little Shaver you should locate the pusher handle (packed in a separate box).
Connect the pusher handle to the shaver body. Plug the power cord into the appropriate electrical outlet.
TO OPERATE THE SHAVETTE LITTLE SHAVER
1. Fill the hopper to within an inch of the top with ice cubes or block ice (no larger than 3" to 4"). The larger
the pieces, the better the snow.
2. Switch the motor on. Wait for the motor to come to full speed (a minute or so).
3. Push the pusher handle down against the ice in the hopper. Apply firm and even pressure to make the
best snow. Practice will allow you to gauge when to stop pressing. This allows the ice to resettle against
the shaver head. You may find that you need to relieve the pressure two or three times in a cycle. Too
much pressure will result in snow that is coarse; too little pressure will make the snow mushy.
NOTE: Never allow any foreign or metallic objects around the shaver area of the Shavette Little Shaver. Ice
picks, scoops, and debris that may be in the ice often damage blades.

Shavette Little Shaver
All Models #1006 and 1006EX
4
MAINTENANCE INSTRUCTIONS

Shavette Little Shaver
All Models #1006 and 1006EX
5
ORDERING SPARE PARTS
1. Identify the needed part by checking it against the photos, illustrations, and/or the parts list.
2. When ordering, please include part number, part name, and quantity needed.
3. Please include your model name and machine serial number (located on the machine nameplate) with
your order.
4. Address all parts orders to:
Parts Department
Gold Medal Products Co.
10700 Medallion Drive
Cincinnati, Ohio 45241-4807
or place orders at:
[phone]
Fax: [phone]
E-mail: [email protected]et

Shavette Little Shaver
All Models #1006 and 1006EX
6
INSTALLING NEW SHAVER BLADES
Inspect your equipment before replacing the blades. Use a flashlight to examine the blades in the shaver
body. If the blades appear to be nicked or bent, then the blades should be replaced.
Follow this procedure:
1. Unplug the main power supply cord from the electrical outlet.
2. Remove the shaver head from the motor shaft by loosening the Allen head set screw between the motor
and the hopper.
3. Remove the shaver head. Pull the shaver head off of the motor shaft and through the hopper. If the
shaver head is frozen onto the shaft, remove the hold down bolts on the motor. Pull the motor back,
trapping the shaver head against the inside of the hopper, until the shaver head disengages.
4. After removing the shaver head, check the motor shaft for burrs and corrosion. Use a fine tooth file to
remove the burrs and corrosion.
5. Remove the blades from the shaver head. These blades may be resharpened, but it is far better to
replace the old blades with a new set.
6. Position the new blades and insert screws until they are finger tight.
7. Set the blade thickness equal to a dime. (See illustration below.) Make sure that the height is even
across the shaver head.
8. Tighten the blade screws completely. Check the blades again with a dime to ensure the blades did not
move while tightening the screws.
9. Replace the motor and shaver head. Mount the motor using the hold down bolts. Insert the shaver head
through the hopper and onto the motor shaft. Press the shaver head onto the motor shaft with the
pusher handle, then move the shaver head in another 1/8". Check that the shaver head is not rubbing
against the back of the hopper and the blades are not touching the pusher handle.
10. Replace the set screw between the hopper and the motor.
NOTE: Replace the shims that were between the motor base and the mounting surface.
HEIGHT GAGE
(USE A DIME)
SET TOP OF BLADE
FLUSH WITH HEIGHT
GAGE, AS SHOWN
SHAVER BLADE
BLADE MOUNTING SCREW
SHAVER HEAD

Shavette Little Shaver
All Models #1006 and 1006EX
7
#1006 ASSEMBLY
23 22
13
9
7
8
21
26
6
25

Shavette Little Shaver
All Models #1006 and 1006EX
8
SHAVER HEAD
28
19
27
11

Shavette Little Shaver
All Models #1006 and 1006EX
9
PARTS LIST
Model # Model #
1006 1006EX
Item No. Part No. Part No. Description
1 12071 12071 Label, "Do Not Apply Pressure" *
2 47010 47010 Label, "Safe Operating Instructions" *
3 74119 74119 Label, "Warning Disconnect Power" *
4 76097 76097 Label, "Unplug to Clean" *
5 12062 12062 Warning, Sharp Blades *
6 12480 12480 Decal, Front Glass
7 22068 22068 Pusher Handle
8 22009 22009 Hopper Casting
9 22012 39022EX Drive Motor
10 42798 42798 Motor Switch *
11 22015NM 22015NM Sno-Konette Shave Head
12 22021 22021 Pusher Handle Gasket
13 22038 42369 Lead-In Cord
14 76135 76135 Power Cord Tag
15 1088 1088 6 oz Sno Dipper
16 49132 49132 Grip Nut (5/16-8; Motor Mounting)
17 74125 74125 Set Screw (1/4-20 x 3/8)
18 12018 12018 Blade Mounting Screw
19 22018 22018 Two-Hole Blade Set with Screws
20 12423 12463 Control Box *
21 29004 29004 Ice Pan *
22 29012 29012 Leg, Shavette Includes Plastic Foot
23 29013 29013 Front Skirt
24 39068 39068 Ice Scoop *
25 22062 22062 5/ 16 x 2 Bolt
26 49132 49132 Grip Nut 5/16 x 18
27 12018 12018 Brass Mounting Screw (4)
28 74125 74125 Set Screw 1/4-20 x 3/8
* Not Shown

Shavette Little Shaver
All Models #1006 and 1006EX
10
WIRING DIAGRAM
MODEL #1006

Shavette Little Shaver
All Models #1006 and 1006EX
11
WIRING DIAGRAM
MODEL #1006EX

Shavette Little Shaver
All Models #1006 and 1006EX
12
WARRANTY
WE WARRANT to the original purchaser the Gold Medal equipment sold by us to
be free from defects in material or workmanship under normal use and service. Our
obligation under this warranty shall be limited to the repair or replacement of any
defective part for a period of six (6) months from the date of sale to the Original
Purchaser with regard to labor and one (1) year with regard to parts and does not
cover damage to the equipment caused by accident, alteration, improper use, voltage,
abuse, or failure to follow instructions.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESSED
OR IMPLIED, AND OF ALL OTHER OBLIGATIONS OR LIABILITIES ON OUR
PART, INCLUDING THE IMPLIED WARRANTY OF MERCHANTIBILITY.
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION
ON THE FACE HEREOF. We neither assume, nor authorize any other person
to assume for us, any other obligation or liability in connection with the sale of said
GOLD MEDAL equipment or any part thereof.
The term “Original Purchaser” as used in this warranty shall be deemed to mean that
person, firm, association, or corporation who was billed by the GOLD MEDAL
PRODUCTS COMPANY, or their authorized distributor for the equipment.
THIS WARRANTY HAS NO EFFECT AND IS VOID UNLESS THE ORIGINAL
PURCHASER FIRST CALLS GOLD MEDAL PRODUCTS COMPANY AT 1-800-
543-0862 TO DISCUSS WITH OUR SERVICE REPRESENTATIVE THE
EQUIPMENT
PROBLEM, AND, IF NECESSARY, FOR INSTRUCTIONS CONCERNING
THE REPAIR OR REPLACEMENT OF PARTS.
NOTE: This equipment is manufactured and sold for commercial use only.
GOLD MEDAL PRODUCTS COMPANY
10700 Medallion Drive
Cincinnati, Ohio 45241-4807 USA
