Goldmedal Sno-Konette 1002S User manual

Part No 67933
Sno–Konette
Instruction Manual
Deluxe – Model #1002S, 1002-01-100
Standard – Model #1003S, 1003SX
DC Model #1009S
Cincinnati, OH 45241-4807 USA

Sno-Konette
2
Models #1002S Series, 1003S Series, 1009S
SAFETY PRECAUTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any alterations to this equipment will
void the warranty and may cause a dangerous condition. NEVER make
alterations to this equipment. Read the Installation, Operating, and
Maintenance Instructions thoroughly before installing, servicing, or operating
this equipment.
014_051514
WARNING
This machinery contains sharp blades. Keep hands and body parts clear
at all times.
037_103114
WARNING
NEVER put your fingers into the shaver body (the goose-neck, ice chute, or
hopper). Serious injury may occur.
017_103114
WARNING
ALWAYS wear safety glasses when servicing this equipment.
010_010914
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514

Sno-Konette
3
Models #1002S Series, 1003S Series, 1009S
SAFETY PRECAUTIONS (continued)
WARNING
Read and understand operator’s manual and all other safety instructions
before using this equipment. To order copies of the operator’s manual go to
gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive,
Cincinnati, OH 45241 USA 1-(800)-543-0862
022_060215
WARNING
DO NOT allow direct contact of this equipment by the public when used in
food service locations. Only personnel trained and experienced in the
equipment operation may operate this equipment.
Carefully read all instructions before operation.
012_010914
WARNING
This machine is NOT to be operated by minors.
007_010914
Note: Improvements are always being made to Gold Medal’s equipment. This information may
not be the latest available for your purposes. It is critical that
you call Gold Medal’s Technical Service Department at -800-543-0862 for any
questions about your machine operations, replacement parts, or any service questions.
(Gold Medal Products Co. does not assume any liability for injury due
to careless handling and/or reckless operation of this equipment.)

Sno-Konette
4
Models #1002S Series, 1003S Series, 1009S
Installation Instructions
Inspection of Shipment
After unpacking, check thoroughly for any damage which may have occurred in transit. Claims
should be filed immediately with the transportation company. The warranty does not cover
damage that occurs in transit, or damage caused by abuse, or consequential damage due to the
operation of this machine, since it is beyond our control (reference warranty in back of manual).
Manual
Read and understand the operator’s manual and all other safety instructions before using this
equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal
Products Co., 0700 Medallion Drive, Cincinnati, OH 4524 USA -(800)-543-0862.
Items Included with this Unit
•Drain Hose
Setup
This unit has been tested at the factory.
. Remove all packaging and tape prior to operation.
2. Place unit on a sturdy, level base which can withstand accidental dripping of water and ice.
3. Locate the pusher handle (packed in a separate box). Connect the pusher handle to the
shaver body using the bolt and nut provided.
4. Connect the drain hose to funnel excess water to floor drain or basin tub. Drained water is
not intended for human consumption.
5. After setup, the unit should be cleaned prior to use (see Care and Cleaning section of this
manual).

Sno-Konette
5
Models #1002S Series, 1003S Series, 1009S
Electrical Requirements
The following power supply must be provided for:
1009S: 2 Volts DC - Customer must supply 2 volt battery for proper machine operation.
Make sure to follow all safety precautions provided by the battery manufacturer.
Cables must be attached to the proper polarity.
The following power supply must be provided for:
1002S, 1003S: 20 V~, 972 W, 60 Hz
1002-01-100, 1003SX: 230 V~, 972 W, 50 Hz
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
A certified electrician must furnish sufficient power for proper machine operation and install any
supplied receptacle. We recommend this equipment be on a dedicated and protected circuit.
Failure to wire properly will void the warranty and may result in damage to the machine. It is Gold
Medal Products Co.’s recommendation that this machine be plugged directly into a wall outlet. The
use of extension cords is not recommended due to safety concerns, and may cause sacrificed
and/or reduced performance. Make sure cord is located to prevent a trip hazard or unit upset.
Before You Plug In Machine
. Make sure all machine switches are in the OFF position before plugging the equipment into
the receptacle.
2. Make sure the wall outlet can accept the grounded plugs (where applicable) on the power
supply cord.
3. The wall outlet must have the proper polarity. If in doubt, have a competent electrician
inspect the outlet and correct if necessary.
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable).
5. Install the unit in a level position.
CAUTION
If the supply cord is damaged, it must be replaced by Gold Medal Products Co.,
its service agent or similarly qualified persons in order to avoid a hazard.
039_080614

Sno-Konette
6
Models #1002S Series, 1003S Series, 1009S
Operating Instructions
To Operate the Sno-Konette:
. Fill the hopper to within an inch from the top with ice cubes or block ice (no larger than 3 to 4
inches). The larger the pieces, the better the snow.
2. Switch the motor on, and wait for it to reach full speed (this will take a minute or so).
3. Press the pusher handle down against the ice in the hopper. Apply firm and even pressure to
make the best snow. Practice will enable you to gauge when to stop. This allows the ice to
resettle against the shaver head. You may find that you need to relieve the pressure two or
three times during a cycle. Too much pressure will result in snow that is coarse; too little
pressure will make the snow mushy.
NOTE: Never allow any foreign or metallic objects around the shaver area of the Sno-Konette.
Ice picks, scoops, and debris that may be in the ice often damage blades.
Ice Requirements:
The Sno-Konette can take ice cubes or block ice, if you break the block into pieces
approximately 3 to 4 inches in size.
NOTE: The ice will not enter the shaving chute if the pieces are too large.

Sno-Konette
7
Models #1002S Series, 1003S Series, 1009S
Care and Cleaning
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
DO NOT immerse in water.
Always unplug the equipment before cleaning or servicing.
025_020314
WARNING
This machinery contains sharp blades. Keep hands and body parts clear
at all times.
037_103114
Good sanitation practice demands that all food preparation equipment be cleaned regularly (only
use non-toxic, food grade cleaners). A clean looking, well-kept machine is one of the best ways of
advertising your product.
Follow the directions below to clean and sanitize the unit after each day of use.
. With the machine OFF, unplug the unit before attempting to clean.
2. Empty water from pans and clean using appropriate cleaners for the type of machine;
review all manufacturer’s instructions and warnings on cleaning product prior to use.
DO NOT use oven cleaners or abrasive materials as they will damage parts of the
machine.
DO NOT use Ammonia cleaners, they will damage plastic panels.

Sno-Konette
8
Models #1002S Series, 1003S Series, 1009S
MAINTENANCE INSTRUCTIONS
DANGER
Machine must be properly grounded to prevent electrical shock to personnel.
Failure to do so could result in serious injury, or death.
DO NOT immerse any part of this equipment in water.
DO NOT use excessive water when cleaning.
Keep cord and plug off the ground and away from moisture.
Always unplug the equipment before cleaning or servicing.
Make sure all machine switches are in the OFF position before plugging the
equipment into the receptacle.
008_051514
DANGER
Improper installation, adjustment, alteration, service, or maintenance can
cause property damage, injury, or death. Any altera
tions to this equipment will
void the warranty and may cause a dangerous condition. NEVER make
alterations to this equipment. Read the Installation, Operating, and
Maintenance Instructions thoroughly before installing, servicing, or operating
this equipment.
014_051514
WARNING
No user serviceable parts inside. Refer servicing to qualified service
personnel.
011_051514
CAUTION
THE FOLLOWING SECTIONS OF THIS MANUAL ARE INTENDED ONLY
FOR QUALIFIED SERVICE PERSONNEL WHO ARE FAMILIAR WITH
ELECTRICAL EQUIPMENT. THESE ARE NOT INTENDED FOR THE
OPERATOR.
027_010914

Sno-Konette
9
Models #1002S Series, 1003S Series, 1009S
Installing New Shaver Blades
WARNING
This machinery contains sharp blades. Keep hands and body parts clear
at all times.
037_103114
The section describes the procedure to replace the shaver blades. ALWAYS turn the machine OFF
and unplug unit from the power supply prior to blade inspection or replacement. Use a flashlight to
examine the blades in the shaver body. If the blades appear to be nicked or bent, then the blades
should be replaced.
Blade Replacement
. With the machine OFF, unplug the unit from the power supply.
2. Remove motor cover (keep all fasteners as they will be used to reinstall the cover).
3. Use a permanent marker and put a guide mark on the motor shaft where the shaver head
stops; also place a small guide mark on the cabinet where the motor sets (reference shaver
cut away view on next page).
4. To remove the shaver head from the motor shaft, loosen the motor mounting bolts. (If unit
has a hopper support and guide, it must also be removed).
5. Pull motor back until the (2) Allen head set screws on the shaver head are visible. Loosen
the (2) set screws (do not remove set screws).
6. Carefully guide the shaver head off of the motor shaft and through the hopper. If the shaver
head is frozen to the shaft, pull the motor back trapping the shaver head against the inside
of the hopper, until the shaver head disengages.
7. After removing the shaver head, check the motor shaft for burrs and corrosion (use a fine
tooth file to remove any burrs or corrosion).
8. Remove blades from shaver head. Replace old blades with a new set (blades may be re-
sharpened).
9. Position new blades on shaver head and insert blade mounting screws until finger tight.
0. Set the blade thickness to /32” using a height gauge (thickness of a dime), reference Set
Blade Height illustration shown on next page. Make sure the blade height is even across the
shaver head.
. Tighten the blade mounting screws completely. Check the blade height again to ensure the
blades did not move while tightening the screws.
2. Carefully guide the shaver head through the hopper and back onto the motor shaft; realign
head with guide mark made on the shaft in Step 3 above. (The pusher handle may be used to
help press the shaver head onto the shaft.)

Sno-Konette
10
Models #1002S Series, 1003S Series, 1009S
3. The shaver head set screws must be on the flat side of the motor shaft. Once aligned, fasten set
screws securely.
4. Adjust the motor to realign with guide mark made on the cabinet in Step 3, then refasten motor
mounting bolts (if unit has a hopper support and guide, it must also be reinstalled). Check the
shaver head to make sure it is not rubbing against the back of the hopper and the blades are not
touching the pusher handle or sides of hopper; adjust as needed.
Note: Replace any shims that were between the motor base and the mounting surface.
5. Reinstall motor cover.
Height Gauge 1/32”
(thick ess of a dime)
Set top of blade flush with
height gauge, as show .
Blade Mou ti g Screw
Shaver Blade
Shaver Head
With a perma e t marker, mark
shaft where shaver head stops. Shaver Head
(2) Set Screws (faste o
flat side of motor shaft)
With a perma e t marker, mark
cabi et where motor sets.
Motor
Mou ti g
Bolts
Cut Away View of Shaver Head o Motor Shaft
General shaver image shown for reference only (models may vary).
Set Blade Height
