golmar EL4503/NFC User manual

4
ESQUEMAS DE INSTALACIÓN
*
( )
*
( )
Portero y videoportero de
Golmar se reserva el derecho a cualquier modificación sin previo aviso.
Golmar se réserve le droit de toute modification sans préavis .
Golmar reserves the right to make any modifications without prior notice.
GUÍA RÁPIDA
Sistemas de comunicación S.A.
pulsadores Nexa combinado
5012 9208
Cód. 5012 8Web 208 T 3450 /NFC ES GR REV.0 192
golmar@golmar.es www.golmar.es
Para más información ver manual de usuario “ (cód. 5012208 )”.T4503/NFC 8
https://doc.golmar.es/search/manual/50122088
Placas con módulo de sonido
EL63 PLUS P/T - EL64 PLUS2 2
Módulo de control de accesos
3EL450 /NFC Alimentador FA-Plus,
ó FA-Plus/C
NC1
CN1
~ ~
SEC
+
-
PRI
~~
Red
CN1
+
- -
+CV1CV2
Equipos de portero electrónico o videoportero con instalación digital.
El conexionado del módulo de control de accesos en placas 'Nexa Modular/ Nexa Inox' variará en
función del tipo de instalación. Utilizar el mismo alimentador que se emplea para las placas.
10
1
9
2
8
3
7
4
6
5
CN3
C1NA1 PL1
-
Placas con módulo de sonido
EL63 R5 P/T - EL64 /R52 2
Módulo de control de accesos
3EL450 /NFC Alimentador
FA-Plus/C
SEC
+
-
PRI
~~
Red
CN1
+
-
+CV1CV2
-
+12
-
NC1
CN1
~ ~ C1NA1 PL1
-
con control de acceso NFC
Combinado en placas Nexa Modular / Nexa Inox:
Módulo EL-4503/NFC
PORTERO Y VIDEOPORTERO NEXA - MÓDULO C. ACCESO NFC
CONFIGURACIONES DE MONTAJE
*
( )
Activar/ desactivar los tonos de confirmación y error por acceso de
tarjeta/ llavero: (Valor "activado" por defecto).
Para desactivar los tonos: El lector de proximidad debe estar en reposo y los microinterruptores
1 a 5 en OFF. A continuación presione y mantenga presionado el pulsador P1 mientras mueve
consecutivamente (de ON a OFF) una vez el microinterruptor 5 verde, el led del frontal parpadeará (color )
durante 2 segundos y no se escuchará ningún tono de confirmación.
Para activar los tonos: El lector de proximidad debe estar en reposo y los microinterruptores 1 a 5 en OFF. A
continuación presione y mantenga presionado el pulsador P1 mientras mueve consecutivamente (de ON a
OFF) una vez el microinterruptor 5 verde durante 2 segundos y se, el led del frontal parpadeará (color )
escucharán 2 tonos cortos de confirmación.
Viene de la página anterior
P1
SW1

2 3
CONFIGURACIONES DE MONTAJE
*
( )
*
( ) Para más información ver manual de usuario “(cód. 5012208 )”.T4503/NFC 8
https://doc.golmar.es/search/manual/50122088
PRECAUCIONES DE SEGURIDAD
- Cuando se instale o modifique los equipos, hacerlo sin alimentación.
- La instalación y manipulación de estos equipos deben ser realizado por personal autorizado.
- Toda la instalación debe viajar al menos a 40 cm. de cualquier otra instalación.
- En el alimentador:
wNo apretar excesivamente los tornillos de la regleta.
wInstale el alimentador en un lugar seco y protegido sin riesgo de goteo o proyecciones de agua.
wEvite emplazamientos cercanos a fuentes de calor, húmedos o polvorientos.
wNo bloquee las ranuras de ventilación para que pueda circular el aire libremente.
wPara evitar daños, el alimentador tiene que estar firmemente anclado.
wPara evitar choque eléctrico, no quite la tapa ni manipule los cables conectados a los terminales.
- Módulo control de accesos .NFC (tarjetas de proximidad Golmar)
- Combinable en placas “Nexa Modular”e“Inox Modular”.
- onfiguración .Configuración básica por microinterruptor de c SW1 ó mediante tarjeta Master
- Configuración avanzada y gestion del control de accesos NFC. Necesario móvil con NFC y aplicación
"AC Manager" (sólo versiónAndroid), ver manual "TAC Manager (cód.50124945).
- Permite gestionar la tarjeta residente para activar el abrepuertas del control de accesos/ llavero
NFC en el móvil. Necesario móvil con NFC y aplicación "OpenGo" (sólo versión Android), ver
manual ."TOPENGO" (cód. 50124946)"
-Led y tonos indicadores de estado.
CARACTERÍSTICAS
*
( )
DESCRIPCIÓN DEL MÓDULO
*
( )
a
b
c
a. Lado frontal.
b. Lector tarjetas de proximidad.
c. Led (bicolor rojo/ verde)de estado .
d. Lado posterior.
e. Regleta de conexión.
f .. Microinterruptor de programación SW1
g Pulsador de programación .. P1
: Entrada de alimentación.
: Salida normalmente abierta relé 1.
Común relé 1.
: Salida normalmente cerrada relé 1.
: Negativo.
: Entrada para pulsador exterior relé 1.
~ ~
NA1
C1
NC1
-
PL1
Control de accesos combinado con placas Nexa :NFC de pulsadores
E la con NFCquipa a placa un control de accesos , permitiendo a los usuarios realizar llamadas a
los pisos mediante los pulsadores de llamada acceder al recinto, igualmente se podrá al
aproximar una tarjeta "residente" EL450 /NFC./ llavero (Golmar) en el módulo 3
Dar de alta tarjetas residentes/llaveros : coloque el microinterruptor 3 a
ON, el led del frontal parpadeará (color rojo). A continuación aproxime de
una a una todas las tarjetas residentes "NFC/US" / llaveros "TAGNFC/US"
nuevas (Golmar) que desee dar de alta al lector de proximidad
EL450 /NFC, el módulo emitirá 2 tonos y el led se iluminará (color verde) durante 13
seg cada vez que memorice una tarjeta de proximidad residente o el led. /llavero
parpadeará (color rojo) si la tarjeta ya estaba memorizada. Se puede memorizar/llavero
hasta 2000 tarjetas . Para salir del modo "dar de alta tarjetas/llaveros / llaveros
residentes" coloque el microinterruptor 3 a OFF, el led del frontal (color rojo) se apagará.
Dar de baja todas las tarjetas residentes/llaveros : coloque el
microinterruptor 1 y 3 a ON, el led del frontal parpadeará (color rojo). A
continuación presione el pulsador P1 de programación durante 5
segundos, el led parpadeará rápido (color rojo); transcurridos los 5
segundos el led se iluminará (color verde) durante 1 segundo y el módulo
emitirá 2 tonos cortos indicándonos que el proceso se ha realizado con exito.
Para salir del modo "dar de baja todas las tarjetas residentes" coloque el/llaveros
microinterruptor 1 y 3 a OFF, el led del frontal (color rojo) se apagará.
PORTERO Y VIDEOPORTERO NEXA - MÓDULO C. ACCESO NFC PORTERO Y VIDEOPORTERO NEXA - MÓDULO C. ACCESO NFC
Programación del tiempo de activación relé 1 por acceso con tarjeta/
llavero: coloque el microinterruptor 5 a ON, el led del frontal parpadeará
(color rojo). Presione el pulsador P1, mientras mantenemos pulsado el led
rojo se apagará y el led verde parpadeará; cada parpadeo incrementará 1
segundo al tiempo mínimo de activación ya configurado de fábrica de 3
segundos. Una vez seleccionado el tiempo de activación deseado dejar de presionar el
pulsador P1, a continuación el módulo emitirá 2 tonos cortos y el led se iluminará fijo
(color verde) durante 1 segundo confirmando el nuevo tiempo de activación.
Si se desea reestablecer el tiempo por defecto de 3 segundos, realizar una pulsación
corta sobre el pulsador P1.
Para salir del modo "tiempo de activación relé 1 con tarjeta " coloque el micro/llavero -
interruptor 5 a OFF, el led del frontal (color rojo) se apagará. Continua.
*
( ) Para más información ver manual de usuario “(cód. 5012208 )”.T4503/NFC 8
https://doc.golmar.es/search/manual/50122088
d
e
g
f
Descripción de la regleta de conexión:
P1
SW1
P1
SW1
P1
SW1
DESCRIPCIÓN DE LA PLACA
*
( )
Detalle general de las partes, para el montaje de la placa.
Placa aluminio
Módulos
Electrónicos
Módulos bastidorCajas de empotrar
*
( )

4
WIRING DIAGRAMS
*
( )
*
( )
Audio and video door entry system
with Nexa button panels
combined with NFC access control
Golmar se reserva el derecho a cualquier modificación sin previo aviso.
Golmar se réserve le droit de toute modification sans préavis .
Golmar reserves the right to make any modifications without prior notice.
QUICK GUIDE
Sistemas de comunicación S.A.
5012 9208
Code 5012 8Web 208 T 3 N450 /NFC E GR REV.0 192
golmar@golmar.es www.golmar.es
For more information, see the T4503/NFC user manual (code 50122088).
https://doc.golmar.es/search/manual/50122088
Door panels with
EL632 PLUS P/T / EL642 PLUS sound module
EL4503/NFC access
control module FA-Plus or FA-Plus/C
power supply unit
NC1
CN1
~ ~
SEC
+
-
PRI
~~
Mains
CN1
+
- -
+CV1CV2
Electronic or video access control systems with digital installation.
The wiring of the access control module with 'Nexa Modular/Nexa Stainless Steel' panels will vary
depending on the type of installation. Use the same power supply unit as the panels.
10
1
9
2
8
3
7
4
6
5
CN3
C1NA1 PL1
-
SEC
+
-
PRI
~~
Mains
CN1
+
-
+CV1CV2
-
+12
-
NC1
CN1
~ ~ C1NA1 PL1
-
Combined with Nexa Modular / Nexa Stainless Steel panels:
EL-4503/NFC module
NEXA AUDIO AND VIDEO DOOR ENTRY SYSTEM - NFC ACCESS CONTROL MODULE
MOUNTING CONFIGURATIONS
*
( )
Activating/deactivating confirmation and error tones by access with
card/key tag: (Value 'activated' by default).
To deactivate the tones: The proximity reader must be in standby mode and DIP switches 1 to 5
must be set to OFF. Then, while pressing and holding the P1 button, set DIP switch 5 from ON to
OFF once, the LED on the front will blink (green) for 2 seconds and no confirmation tone will be heard.
To activate the tones: The proximity reader must be in standby mode and DIP switches 1 to 5 must be set to OFF.
Then, while pressing and holding the P1 button, set DIP switch 5 from ON to OFF once, the LED on the front will
blink (green) for 2 seconds and 2 confirmation tone will be heard.
Continued from previous page
P1
SW1
Door panels with
R5 - /R5EL632 P/T EL642 sound module
EL4503/NFC access
control module FA-Plus/C
power supply unit

2 3
MOUNTING CONFIGURATIONS
*
( )
*
( ) For more information, see the T4503/NFC user manual (code 50122088).
https://doc.golmar.es/search/manual/50122088
SAFETY PRECAUTIONS
-Always disconnect the power supply before installing or making modifications to the devices.
-The fitting and handling of these devices must be carried out by authorised personnel.
-The wiring must run at least 40cm. away from any other wiring.
-On the power supply unit:
wDo not overtighten the screws on the connector.
wInstall the power supply unit in a dry protected location free from the risk of dripping or splashing
water.
wAvoid locations that are humid, dusty or near heat sources.
wEnsure that the air vents are free from obstruction so that air can circulate freely.
wTo avoid damage, the power supply unit must be firmly secured in place.
wTo prevent electric shock, do not remove the cover or handle the wires connected to the
terminals.
-NFC access control module (Golmar proximity cards).
- Can be combined with 'Nexa Modular' and 'Inox Modular' door panels.
-Basic configuration using the SW1 configuration DIP switch or Master card.
-Advanced configuration and management of the NFC access control. Mobile with NFC and AC
Manager app required (Android only), see the TAC Manager manual (code 50124945).
-Enables management of the residents' card/key tag to activate the lock release of the NFC
access control via mobile. Mobile with NFC and OpenGo app required (Android only), see the
TOPENGO manual (code 50124946).
-Status LED and tones.
CHARACTERISTICS
*
( )
DESCRIPTION OF THE MODULE
*
( )
a
b
c
a. Front.
b. Proximity card reader.
c. Status LED (two-colour red/green).
d. Back.
e. Monitor connector.
f. SW1 programming DIP switch.
g. P1 programming button.
:Power input.
:Normally open output relay 1.
Common relay 1.
:Normally closed output relay 1.
: Negative.
:Input for exterior button relay 1.
~ ~
NA1
C1
NC1
-
PL1
NFC access control combined with Nexa button panels:
This equips the door panel with NFC access control, allowing users to make calls to apartments
using the call buttons. The site can also be accessed by waving a residents' card/key tag
(Golmar) over the EL4503/NFC module.
Add residents' cards/key tags: set DIP switch 3 to ON, the LED on the
front will blink (red). Then wave the new residents' NFC/US cards /
TAGNFC/US key tags (Golmar) that you wish to add over the
EL4503/NFC proximity reader one by one, the module will emit 2 tones
and the LED will light up (green) for one second every time a residents' proximity
card/key tag is memorised or the LED will blink rapidly (red) if the card/key tag has
already been memorised. Up to 2,000 cards/key tags can be memorised. To exit
'Add residents' cards/key tags' mode, set DIP switch 3 to OFF, the LED on the front
(red) will turn off.
Remove all residents' cards/key tags: set DIP switches 1 and 3 to ON,
the LED on the front will blink (red). Then press the P1 programming
button for 5 seconds, the LED will blink rapidly (red); after 5 seconds,
the LED will light up (green) for 1 second and the module will emit 2 short
tones indicating that the process has been carried out successfully.
To exit 'Remove all residents' cards/key tags' mode, set DIP switches 1 and 3 to
OFF, the LED on the front (red) will turn off.
NEXA AUDIO AND VIDEO DOOR ENTRY SYSTEM - NFC ACCESS CONTROL MODULE
Programming relay 1 activation time by access with card/key tag: set
DIP switch 5 to ON, the LED on the front will blink (red). Press and hold
down the P1 button, the red LED will turn off and the green LED will
blink; each blink will increase the minimum activation time of 3 seconds
already set at the factory by 1 second. Once the desired activation time
has been selected, stop pressing the P1 button, the module will then emit 2 short
tones and the LED will light up (green) for 1 second confirming the new activation
time.
If you wish to reset the default time of 3 seconds, press the P1 button.
To exit 'Relay 1 activation time with card/key tag' mode, set DIP switch 5 to OFF, the
LED on the front (red) will turn off. Continued overleaf.
*
( ) For more information, see the T4503/NFC user manual (code 50122088).
https://doc.golmar.es/search/manual/50122088
d
e
g
f
Description of the monitor connector:
P1
SW1
P1
SW1
P1
SW1
DESCRIPTION OF THE DOOR PANEL
*
( )
Exploded view of the parts of the panel.
Aluminium panel
Electronic
modules
Frame modulesEmbedding boxes
*
( )
NEXA AUDIO AND VIDEO DOOR ENTRY SYSTEM - NFC ACCESS CONTROL MODULE
Table of contents
Languages:
Other golmar IP Access Controllers manuals
Popular IP Access Controllers manuals by other brands

H3C
H3C WX Series Registration and activation guide

digicon
digicon catrax automatic master product manual

nvent
nvent SPECTRACOOL instruction manual

Vanderbilt
Vanderbilt BLUE-EX Installation and operation manual

Nidac
Nidac Presco PEL1 installation manual

Austin Hughes
Austin Hughes InfraSolution X Series user manual

Schlage
Schlage Panel Interface Module RS485 Installation & operating instructions

Soyal
Soyal AR-888-PBI-S manual

Identiv
Identiv MobilisID Installation guide and user's manual

Essex Electronics
Essex Electronics K1 ERM Series Installation instructions manual

Nortech
Nortech CRC22 Series Wiring

TECOM
TECOM TS1066 Programming manual
