Goodwe Lynx C Series User manual

V1.0-2022-10-12
(LX C 101-10 | LX C120-10 | LX C138-10 | LX C156-10)
Rechargeable Li-ion Battery System
Lynx C Series
Quick Installation Guide

01
01 Safety Precaution
• The information in this user manual is subject to change due to product updates or other
reasons. This guide cannot replace the product labels or the safety precautions in the user
• Read through the quick installation guide before installations. For additional information,
please see the user manual.
•
familiar with local standards and safety regulations.
• Check the deliverables for correct model, complete contents, and intact appearance. Contact
• Use insulating tools and wear personal protective equipment (PPE) when operating the
equipment to ensure personal safety.
•
relative user manual. The manufacturer shall not be liable for equipment damage or personal
injury if you do not follow the instructions. For more warranty details, please visit https://
en.goodwe.com/warranty.
•
precautions outlined in this manual and safety labels on the equipment.
• The Lynx C Series Rechargeable Li-ion Battery System for Commercials and Industries
(hereinafter referred to as the Lynx C BMS in short) is a high voltage system. Do not touch or
operate it. Keep away from it. Only professionals are allowed!
• Please use appropriate tools and take protective measures when installing and maintaining
heavy equipment. Improper operations will cause personal injuries.
• Do not use the battery module or Power Control Unit (PCU in short) if it is defective, broken,
or damaged.
•
authorization from the manufacturer.
• Pay attention to the negative and positive during installation to avoid reverse polarity
connection. Otherwise the short circuit may cause personal injuries and equipment damage.
Damaged battery modules may leak electrolyte. Do not contact with the liquid leakage or
• Inhalation: Evacuate from the contaminated area, and seek immediate medical assistance.
• Eye contact: Rinse your eyes for at least 15 minutes with clean water and seek immediate
medical assistance.
• Skin contact: Thoroughly wash the touch area with soap and clean water, and seek
immediate medical assistance.
• Ingestion: Induce vomiting, and seek immediate medical assistance.
General Disclaimer
Safety Disclaimer
Instructions during Installation
Emergency Measures

02
Label Description
Symbol Description Symbol Description
Potential risks exist. Wear proper
PPE before any operations.
Keep the equipment away from
voltage exists during the
equipment's running.
before any operations.
Keep the equipment away from
children.
Operate the equipment properly to
avoid explosion. No extinguishing with water.
The equipment contains corrosive
electrolytes. In case of a leak in
the equipment, avoid contact the
leaked liquid or gas.
Do not dispose of the equipment
with household garbage at its end
of life. Dispose it according to local
laws and regulations. Or send it to
the manufacturer.
Put the battery in the right place
and recycle it in compliance with
local environmental regulations.
Read through the user manual
before any operations.
Pay attention to safety protection
during installation, operation and
maintenance.
No stepping. Grounding. To indicate PE cable
connection position.
CE Marking. TUV Marking.
RCM Marking. --

03
Check before Power ON
EU Declaration of Conformity
The Lynx C BMS sold in the European market meets the following directives and requirements:
• Electromagnetic compatibility Directive 2014/30/EU (EMC)
•
• Restrictions of Hazardous Substances Directive 2011/65/EU and (EU) 2015/863 (RoHS)
• Waste Electrical and Electronic Equipment 2012/19/EU
•
https://en.goodwe.
com.
No. Check Item
1operate.
2Ensure that PE, the battery high voltage copper bus, the inverter power cable, the
3 Cable ties are intact, routed properly and evenly.

04
Battery Cabinet
02 Product Introduction
Model Length (mm) Width (mm) Height (mm)
LX C101-10 1155 1650
LX C120-10
LX C138-10 1155 2065
LX C156-10
Power Control Unit (PCU)
Length Width
Height
Front View Right View Left View
Handle
BMS Routing HoleSlot

05
1. Battery Terminal
(Positive) 2. DC Circuit Breaker 3.
4. Main Circuit Breaker 5. Indicator 6. Battery Terminal
(Negative)
Power Input/Output
Port (Negative) 8. 9. Power Input/Output Port (Positive)
10. External COM Port 11. Internal COM Port
Battery Module
525mm
202mm
1. Connector for Battery
Communication 2. Battery Positive Polarity 3. Battery Negative Polarity
4. Battery Hoisting Hole 5. Battery Fixing Hole

06
03 Installation
Deliverables
Battery Module
x N
Battery Cabinet and Accessories
x 1 x 1 x 1 x 1
x 1 x 1 x N x 1
x 1 x N x N x N
x 4 x N

Space Requirements
Angle Requirements
300mm
600mm 600mm
600mm

08
BMS Installation
30-100mm

09
M6
4.5-6N·m
15
1
2
3
4
5
6
8
9
10
11
12
13
14
16
1
2
10
3
11
4
12
5
13
6
14
15
8
9

10
04 Electrical Connection
No. Cable Type Requirement
1 PE Cable Single-core copper cable Cross-sectional area of conductor SPE: 8mm2.
2
Power cable to
connect with
the inverter
The power cable shall be
normal 1000V PV cables.
• Outer diameter of the cable:
11mm~13mm
• Cross-sectional area of conductor S:
35mm2
3 Others Use the delivered cable or connecting bar.
Connecting PE Cable
LL
M5
3.5-4.5N·m
Connecting Inverter Communication Cable
No.
3
4
8 RS485B
Others

11
Connecting Battery Communication Cable
16
1
2
10
3
11
4
12
513
6
14
15
8
9

12
Connecting Power Connecting Bar
M8
10-12N·m
16
1
2
10
3
11
4
12
513
6
14
15
8
9
18

13
(Optional) Connecting Single Phase AC Power Cable
Connecting Inverter Power Cable
4
1 2 3
Click Click
20± 1mm

14
05 Power ON and OFF
Power ON Power OFF
31
Self-powered:
External single 1 2
31
Self-powered:
External single 1 2
32
1

15
Commissioning via PV Master APP
06 Commissioning
Commissioning via SEMS Portal
Lynx C Series
User Manual
For more information, please scan the following QR for User Manual.

GoodWe Technologies Co., Ltd.
www.goodwe.com
[e-mail] Local Contacts
