Graco PD346910A User manual

FAST ACTION FOLD™ JOGGER
PD346910A 8/15

1 WARNING
3-A To Open Stroller
3-B Canopy
3-C Front Wheel
3-D Rear Wheels
3-E Kickstand
3-F Basket Assembly
3-G Parent’s Tray
3-H Child’s Tray
3 Assembly
2 Features
2-A Parts List
5-A Care & Maintenance
5 Care
4-A To Secure Child
4-B To Recline Seat
4-C Brakes
4-D Swivel Wheel
4-E Parent’s Tray with Smart Device Holder
4-F Removing Wheels
4-G To Use Tether
4-H To Attach Graco® Infant Car Seat
4-I To Fold Stroller
4 Use

Failure to follow these warnings and the
assembly instructions could result in serious injury or death.
PLEASE SAVE OWNER’S
MANUAL FOR FUTURE USE.
ADULT ASSEMBLY REQUIRED.
NEVER LEAVE child unattended.
Always keep child in view while
in stroller.
AVOID SERIOUS INJURY from
falling or sliding out. Always use
seat belt. After fastening buckles,
adjust belts to get a snug fit
around your child.
AVOID FINGER ENTRAPMENT.
Use care when folding and
unfolding the stroller. Be certain
the stroller is fully erected and
latched before allowing your child
near the stroller.
AVOID STRANGULATION.
DO NOT place items with a string
around your child’s neck,
suspend strings from this
product, or attach strings to toys.
NEVER USE STROLLER ON
STAIRS or escalators. You may
suddenly lose control of the
stroller or your child may fall out.
Also, use extra care when going
up or down a step or curb.
USE OF THE STROLLER with a
child weighing more than 50 lb
(22.7 kg) or taller than 45 in.
(114.3 cm) will cause excessive
wear and stress on the stroller.
Use the stroller with only one
child at a time.
TO PREVENT TIPPING, do not
place more than 3 lb (1.4 kg) on
the parent’s tray.
TO AVOID BURNS, never put hot
liquids in the parent’s tray.
TO PREVENT A HAZARDOUS,
UNSTABLE CONDITION, never
place purses, shopping bags,
parcels or accessory items (other
than approved Graco stroller
bags) on the handle. Never place
anything on the canopy.
TO PREVENT A HAZARDOUS,
UNSTABLE CONDITION, do not
place more than 10 lb (4.5 kg) in
the storage basket.
DO NOT ALLOW child to stand on
basket. It may collapse and cause
injury.
DO NOT use storage basket as a
child carrier.
NEVER PLACE child in the stroller
with head toward front of stroller.
NEVER ALLOW YOUR STROLLER
to be used as a toy.
DISCONTINUE USING YOUR
STROLLER should it become
damaged or broken.
PRODUCT NOT INTENDED for
use with roller skates or in-line
skates.

10
IF YOU ARE JOGGING WITH
THIS STROLLER:
DO NOT INFLATE above the
maximum recommended inflation
pressure that is written on the side
of the tire. Over-inflation may
cause wheel and/or tire to blowout
and could result in serious injury.
DO NOT use stroller for jogging
while carrier is in stroller.
BE AWARE of the increased speed
and greater possibility of losing
control of the stroller.
ALWAYS USE and snugly
adjust the seat belt provided.
ALWAYS ATTACH the
tether strap to your wrist while
jogging with this stroller.
BE AWARE of traffic and other
hazardous conditions that may be
present.
FALL HAZARD from tip over:
Before running, jogging, or walking
fast, LOCK the front wheel from
swiveling.
USING GRACO® INFANT CAR
SEAT WITH STROLLER:
TO AVOID
INJURY TO
YOUR
CHILD: THIS
STROLLER IS ONLY
COMPATIBLE WITH GRACO®
SNUGRIDE® INFANT CAR
SEATS WITH CLICK CONNECT™.
Only use with Graco® infant car
seats that have the Click
Connect™ logo.
Improper use of this stroller with
other manufacturers’ car seats
may result in serious injury or
death.
READ THE MANUAL provided
with your Graco car seat before
using it with your stroller.
ALWAYS SECURE your child with
the car seat harness when using
the car seat in the stroller.
If your child is already in the car
seat, check that the child is
secured with the harness.
Improper use of this stroller with a
car seat may result in serious
injury or death.
See Graco infant car seat owners
manual for maximum size of child.

2-A Parts List
Check that you have all the parts for this model BEFORE assembling
your product. If any parts are missing, call Customer Service.
NO TOOLS REQUIRED.
All models
2X

3-A To Open Stroller
Before assembly, be sure to place stroller on top of a piece of cardboard
or other protective cover to prevent damage to floor surface.
1. Open storage latch.
2. Lift handle of stroller up.

3. CHECK that the stroller is
completely latched open every
time you open the stroller and
before continuing with the rest
of the assembly steps.
SNAP!

3-B Canopy
WARNING
1. Choking Hazard: Remove and
immediately discard foam on
the canopy wire.
2. Insert canopy wire into the
canopy mounts on each side of
the stroller as shown.
3. Push backwards to close canopy.
Pull forward to open canopy.
SNAP!

3-C Front Wheel
CHECK the tire pressure before
using the stroller.
DO NOT INFLATE above the
maximum recommended inflation
pressure that is written on the side
of the tire. Over-inflation may
cause wheel and/or tire to blowout
and could result in serious injury.
DO NOT use air compressor to
inflate tire. ONLY use hand-pump.

2. CHECK that wheel is securely
attached by pulling on wheel
assembly.
1. Attach front wheel to stroller as
shown.
SNAP!

3-D Rear Wheels
WARNING
Choking Hazard: Remove and immediately discard protective end cap from
each wheel. DO NOT remove rear wheels unless replacing them. Child
could fall on exposed rear axle and be injured.
2X
SNAP!
1. Remove and immediately discard
protective end cap from each
wheel.
2. Attach rear wheels to stroller
as shown.

3-E Kickstand
SNAP!
Snap kickstand onto basket
as shown.
3. CHECK that wheels are securely
attached by pulling on wheel
assemblies.

SNAP!
Fasten basket to tube with snaps
as shown.
3-F Basket Assembly

3-G Parent’s Tray
1. CHECK that canopy wire is
attached.
SNAP!
2. Parent tray needs to snap over
the top of the canopy wire.

3-H Child’s Tray
WARNING
Always secure your child with the seat belt. The tray is not a restraint
device. DO NOT lift the stroller by the child’s tray. Use care when
snapping the tray on the stroller with a child in the stroller.
SNAP!
1. Insert armrests into slots on each
side of the stroller until they click
into place.
Pull on armrests to make sure
they are attached.

SNAP!
3. To open the tray.
2. Attach child tray to armrests.

4. To remove child’s tray, press
buttons on bottom of tray.
5. To remove armrest, push
button as shown and remove.

4-A To Secure Child
WARNING Falling Hazard: Always use the seat belt.
5 Point Harness
1. To open, press button on
buckle to release the waist
straps.
2. To close, slide shoulder strap
connectors onto waist straps
and insert into buckle.

3. Use slide adjuster at shoulder
and waist for tighter
adjustment. To change
shoulder harness slots.
Use slide adjuster at shoulder and
waist for further adjustment.
Repeat on other side.
Utilisez le régulateur coulissant
à l'épaule et à la taille pour un
ajustement plus précis. Répétez
de l'autre côté.
Use el ajuste deslizable en el
hombro y la cintura para hacer
ajustes adicionales. Repita el
proceso del otro lado.

3 Point Buckle
1. To open, press button on
buckle to release the waist
straps.
2. Slide shoulder strap
connectors off of waist straps.
3. Remove shoulder straps from
stroller.
