Graco TURBOBOOSTER GROW RightGuide User manual

Read This Instruction Manual
featuring RightGuide™Seat Belt Trainer
FAILURE TO PROPERLY USE THIS
CHILD RESTRAINT INCREASES THE
RISK OF SERIOUS INJURY OR DEATH
IN A SUDDEN STOP OR CRASH.
Do not install or use this child restraint
until you read and understand the
instructions in this manual.
NWL0000792167A 7/18 www.gracobaby.com
TURBOBOOSTER®GROW™

2
1-A Quick Guide to Your Manual
1-B Welcome to the Graco Family
1-C Before You Begin
Register This Car Seat
If You Need Help
Certification
Car Seat’s Useful Life
Vehicle Seat Protection
Warm Weather Use
1-D Safety Warnings
1 Important Pages 5-17
2 Features Pages 18-23
2-A Car Seat Features

3
3 Booster Pages 24-34
4-A Securing Child in Highback Booster
4-B Securing Child in Backless Booster
4-C Securing Child in RightGuide™ Seat Belt Trainer
4 Securing Child Pages 35-50
6 Accessories Page 53
3-A Booster Use
3-B Install Highback Booster
3-C Install Backless Booster
3-D Install RightGuide™ Seat Belt Trainer
5 Reinstall RightGuide™ Seat Belt Trainer to Booster Pages 51-52

4
7-A How to Remove Lower Anchor Connectors
7-B Choosing Vehicle Seat Location
7-C Unsafe Vehicle Seat Location
7-D Vehicle Seat Belts
8-A Cleaning Seat Pad
8-B Cleaning Lower Anchor Straps
7 Vehicle Information Pages 54-58
8 Care & Cleaning Pages 59-67

5
1-A Quick Guide to Your Manual
Car Seat Assembly (On Select Models)
Adult Assembly Required
1. Attach Headrest to Seat Back
Squeeze the adjustment button and slide the headrest into the
seat back.
CHECK to make sure the two pieces are securely snapped
together by pulling on them.
This car seat is for children:
Highback Booster:
40-100 lb (18.1-45 kg) 43-57 in. (110.1-145 cm) at least 4 years old
Backless Booster:
40-110 lb (18.1-50 kg) 43-57 in. (110.1-145 cm) at least 4 years old
RightGuide™ Seat Belt Trainer:
50-120 lb (22.5-54 kg) 43-60 in. (110.1-152 cm) at least 5 years old

6
2. Headrest Seat Pad
With the headrest all the way up, insert the pad from the
headrest underneath the seat back pad.
3. Attach Seat Back to Base
The “U”-shaped hooks on bottom
of the seat back will interlock with
bars on the base. Make sure that no
part of the seat pad interferes when
attaching the backrest to the base.
4. Raise Seat Back
Once the seat back is securely attached to the base, push
backrest up.
CLICK!

7
5. Attach Cup Holder and Storage
Compartment
Align locking tabs with the holes in the base.
Push down to lock them in.
Circular cup holder goes on the left and the
oval storage compartment goes on the right
as shown.
Assembly Complete
Your Graco booster seat is now ready to use.
CLICK!CLICK!

8
Get to Know Your Car Seat
What Seating Location Should I Use?
Review section 2-A to see all of the features of this booster seat.
The best seating location for this booster seat is one that:
• Is recommended by your vehicle owner’s manual, and
• Results in a secure installation of this booster seat.
Some vehicles have specific requirements for where the booster seat can be installed, so be sure to
check your vehicle owner’s manual for available seating positions, if any. For example, sometimes the
center rear seat has a lap belt only vehicle seat belt, which cannot be used with this booster seat.
Review section 7-B, 7-C, 7-D of this manual AND your vehicle owner’s manual.
According to accident statistics, the safest place for your
child in any vehicle is the back seat. The center of the back
seat can be the safest during a possible side impact.

9
When Installing As a Booster
Vehicle Seat Belt
There is one type of vehicle seat belt that can be used: Lap/
Shoulder Seat Belt.
Review section 3 of this manual AND your vehicle owner’s
manual.
Lower Anchor System
The lower anchor system consists of lower anchor bars, which are built-in
to your vehicle, and connectors that are built-in your car seat.
Review section 3 of this manual AND your vehicle owner’s manual.
Using The Car Seat Correctly
To make sure your child is secured properly, review section 3 and 4 to fit your child.

10
Use Lap/Shoulder Belt Only
Review section 3
Booster Installation
Highback Backless
Position Lap Belt
Be sure the lap portion of the vehicle seat belt goes in front of
both armrests and the shoulder belt goes under the armrest
on the buckle side.
Review section 3
Position Lap Belt on RightGuide™ Seat Belt Trainer
Be sure the lap portion of the vehicle seat belt goes through
both seat belt guides and the shoulder belt goes through the
seat belt guide on the buckle side.
Review section 3 RightGuide™
Seat Belt Trainer

11
Booster Installation
1-B Welcome to the Graco Family!
Your child’s safety depends on you. No car seat can guarantee protection from injury in every
situation, but proper use helps reduce the risk of serious injury or death.
Even if this car seat seems easy to figure out on your own, you must follow the detailed instructions
in this instruction manual to ensure the steps below are performed correctly.
Position Shoulder Belt
Shoulder belt lies across shoulder
between neck and edge of shoulder.
Review section 3

12
1-C Before You Begin
Please fill out the prepaid registration postcard attached to the seat and mail it in today or register
online at www.gracobaby.com/carseatregistration.
Child restraints could be recalled for safety reasons. You must register this restraint to be reached in a
recall. Send your name, address, and the restraint’s model number and manufacturing date to:
Graco Children’s Products, Inc.
Attn: Customer Service
P.O. Box 169, Elverson, PA 19520-9901
or call 1-800-345-4109
or register online at www.gracobaby.com/carseatregistration
For recall information, call the U.S. Government’s Vehicle Safety Hotline at
1-888-327-4236 (TTY: 1–800–424–9153), or go to http://www.NHTSA.gov.
Register This Child Restraint

13
Model Name_________________________
Model Number _______________________
Date of Manufacture __________________
Date of Purchase _____________________
For future reference or if you change addresses, record the model name, model number, date of
manufacture and purchase date of this car seat on the below. These numbers can be found on a
sticker on the bottom of your car seat.
In the U.S.A, please contact our Customer Service Department with any questions you may have
concerning parts, use, or maintenance. When you contact us, please have your product’s model
number and date of manufacture ready so that we may help you efficiently. These numbers can be
found on a sticker on the bottom of your car seat.
For additional resources or to get your car seat checked by a child passenger safety technician, please
visit the following web sites:
www.nhtsa.gov • www.seatcheck.org • www.safekids.org
If You Need Help

14
This child restraint meets or exceeds all applicable requirements of Federal Motor Vehicle Safety
Standard 213 for use in motor vehicles.
This child restraint is NOT certified for aircraft use because aircrafts do not have shoulder
belts.
STOP using this car seat and throw it away 10 years after the date of manufacture. Look for date of
manufacture label on the bottom of the car seat.
Graco Children’s Products Inc. advises against loaning or passing along a car seat unless you know
the complete history of the product. We also advise against purchasing a car seat second hand.
Certification
Car Seat’s Useful Life
Protect vehicle seat. Use a car seat mat, towel, or thin blanket under and behind car seat.
Vehicle Seat Protection

15
Car seat parts can get very hot in the sun or warm weather. To avoid burns, always check before
putting child in car seat.
Warm Weather Use
Failure to follow these instructions and child restraint’s labels can result
in child striking the vehicle’s interior during a sudden stop or crash.
1-D Safety Warnings
No car seat can guarantee protection from injury in every
situation, but proper use helps reduce the risk of serious
injury or death. READ THIS MANUAL CAREFULLY.

16
! Review your vehicle owner’s manual for more information about air bags and car
seat use.
! If your vehicle does not have a back seat, review your vehicle owner’s manual.
! Select a suitable location for the car seat in your vehicle.
! Always secure car seat with the lower anchor connectors or a vehicle seat belt,
even when unoccupied. In a crash, an unsecured car seat can injure passengers.
! If car seat is in a crash, it must be replaced. DO NOT use it again! A crash can
cause unseen damage and using it again could result in serious injury or death.
! The American Academy of Pediatrics (AAP) recommends that children should use
a built-in harness system car seat for as long as possible until they reach the
maximum forward-facing weight or height for their car seat. After reaching the
maximum forward-facing weight or height, they also recommend that children 4
feet 9 inches (145cm) tall or under should ride in a belt-positioning booster seat.

17
! DO NOT use car seat if it is damaged or missing parts.
! DO NOT use accessories or parts other than those provided by Graco. Their use
could alter the performance of the car seat.
! Never leave child unattended, even when sleeping. Child may become tangled in
vehicle belt straps and suffocate or strangle.
! Never attach two lower anchor connectors to one
vehicle lower anchor bar unless specifically allowed by
the vehicle manufacturer.

2 Features
18
2-A Car Seat Features
F
A
C
B
D
E I
H
J
GK

2 Features
19
A Headrest
B Shoulder Belt Guide
C Backrest
D Body Support
E Cup Holder
F Lower Anchor Adjuster Button
G Lower Anchor Adjustment Straps
H Storage Compartment
I RightGuide™ Seat Belt Trainer
J RightGuide™ Seat Belt Trainer Release Lever
K Instruction Manual Storage

2 Features
20
A
B
C
B
D
