Graco Fluid Automation 633 Instruction Manual

332078C
EN
Operation
633 Meter-Mix
Dispense Systems
For metering, mixing, and dispensing of silicone material.
For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
See page 3 for model information, including maximum
working pressure and approvals.
If the visuals in the printed copy are unclear, refer to the
electronic version available on www.graco.com.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.

Contents
2332078C
Contents
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Component Identification . . . . . . . . . . . . . . . . . . . . 7
Model 633 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Model 633-SR657-1M-LR . . . . . . . . . . . . . . . . . . 8
General Information . . . . . . . . . . . . . . . . . . . . . . . . 9
Pressure Settings . . . . . . . . . . . . . . . . . . . . . . . . 9
Solvents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Screen Navigation . . . . . . . . . . . . . . . . . . . . . . . . . 10
Screen Identification . . . . . . . . . . . . . . . . . . . . . . . 18
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Pressure Relief Procedure . . . . . . . . . . . . . . . . . . 42
Manual Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Dispense Head Solenoid . . . . . . . . . . . . . . . . . . 42
Bleed Valves . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Testing Procedures . . . . . . . . . . . . . . . . . . . . . . . . 44
Pump Testing . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Calibrate Pressure Transducers . . . . . . . . . . . . 45
Schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Model 633 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Model 633-SR657-1M-LR . . . . . . . . . . . . . . . . . 50
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 52
Graco Information. . . . . . . . . . . . . . . . . . . . . . . . . 52
Related Manuals
Manual Description
332354 633 Meter-Mix Dispense Systems,
Repair-Parts
332079 SR657-1M-LR Meter-Mix Dispense Systems,
Operation

Models
332078C 3
Models
Part No.
Maximum Working
Pressures
psi (MPa, bar) Description
633
3000 (21, 207)
PLC, Potentiometer Controlled, Fixed Ratio Meter Mix Dispense Sys-
tem. Dispense System has proportional pneumatic control to provide
automatic adjustment during material dispense.
633-SR657-1M-LR
PLC, Potentiometer Controlled, Fixed Ratio Meter Mix Dispense System
mounted to a Pneumatic Controlled 1:1 to 2:1 Variable Ratio 55-Gallon
Feed Machine. Dispense System has proportional pneumatic control to
provide automatic adjustment during material dispense. Machine uses
B442M Base Pumps. Machine has 6 in. (15 cm) ram air cylinders, Paral-
lel Low-Rider frame with Shrouded Casters.

Warnings
4332078C
Warnings
The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-
tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When
these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific
hazard symbols and warnings not covered in this section may appear throughout the body of this manual where
applicable.
WARNING
ELECTRIC SHOCK HAZARD
This equipment must be grounded.Improper grounding, setup, or usage of the system can cause electric
shock.
• Turn off and disconnect power cord before servicing equipment.
• Connect only to grounded electrical outlets.
• Use only 3-wire extension cords.
• Ensure ground prongs are intact on power and extension cords.
• Do not expose to rain. Store indoors
TOXIC FLUID OR FUMES HAZARD
Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or
swallowed.
• Read MSDSs to know the specific hazards of the fluids you are using.
• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.
• Always wear chemically impermeable gloves when spraying, dispensing, or cleaning equipment.
PERSONAL PROTECTIVE EQUIPMENT
Wear appropriate protective equipment when in the work area to help prevent serious injury, including
eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective equipment includes but is
not limited to:
• Protective eyewear, and hearing protection.
• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer
SKIN INJECTION HAZARD
High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This
may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical
treatment.
• Engage trigger lock when not dispensing.
• Do not point dispensing device at anyone or at any part of the body.
• Do not put your hand over the fluid outlet.
• Do not stop or deflect leaks with your hand, body, glove, or rag.
• Follow the Pressure Relief Procedure when you stop dispensing and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the equipment.
• Check hoses and couplings daily. Replace worn or damaged parts immediately

Warnings
332078C 5
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent
fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop
cloths (potential static arc).
• Keep work area free of debris, including solvent, rags and gasoline.
• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes
are present.
• Ground all equipment in the work area. See Grounding instructions.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering into pail. Do not use pail liners unless they
are antistatic or conductive.
•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment
until you identify and correct the problem.
• Keep a working fire extinguisher in the work area.
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
• Do not operate the unit when fatigued or under the influence of drugs or alcohol.
• Do not exceed the maximum working pressure or temperature rating of the lowest rated system com-
ponent. See Technical Data in all equipment manuals.
• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all
equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information
about your material, request MSDS from distributor or retailer.
• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-
facturer’s replacement parts only.
• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create
safety hazards.
• Make sure all equipment is rated and approved for the environment in which you are using it.
• Use equipment only for its intended purpose. Call your distributor for information.
• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
WARNING

Warnings
6332078C
MOVING PARTS HAZARD
Moving parts can pinch, cut or amputate fingers and other body parts.
• Keep clear of moving parts.
• Do not operate equipment with protective guards or covers removed.
• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment,
follow the Pressure Relief Procedure and disconnect all power sources.
SPLATTER HAZARD
Hot or toxic fluid can cause serious injury if splashed in the eyes or on skin. During blow off of platen,
splatter may occur.
• Use minimum air pressure when removing platen from drum.
WARNING

Component Identification
332078C 7
Component Identification
Model 633
A Stack Light Indicator
(Red = Fault, Amber = Pump Started)
BAirInlet
C Operator Interface Panel
D Main Air Solenoid
E Automatic Pressure Regulator and Air Motor Solenoids
F Cylinder Pressure Transducer
G Refill Solenoid
J Bleed Ball Valve
K Refill Valve
L Feed Pressure Gauge
M Pump Linear Position
N Stop Button
FIG. 1: 633
A
C
B
D
E
G
F
J
K
M
L
N

Component Identification
8332078C
Model 633-SR657-1M-LR
A Stack Light Indicator
(Red = Fault, Amber = Pump Started)
BAirInlet
C Operator Interface Panel
D Main Air Solenoid
E Automatic Pressure Regulator and Air Motor Solenoids
F Cylinder Pressure Transducer
G Refill Solenoid
J Bleed Ball Valve
K Refill Valve
L Feed Pressure Gauge
M Pump Linear Position
N Stop Button
FIG. 2: 633-SR657-1M-LR
A
B
D
E
G
F
J
K
M
L
C
N
Refer to the SR657-1M-LR Meter-Mix
Dispense Systems, Operation manual for
additional component callouts.

General Information
332078C 9
General Information
Pressure Settings
All pressure settings are controlled through the Operator
Interface Panel. Refer to Screen 2, page 27, to set the
feed station pressure.
Fluid Pressure Gauges
All A and B material pressure gauges should read
the same as each other during normal operation of
the machine.
Solvents
These are rarely used with modern 1:1 silicones. For
cleaning, methylene chloride or white spirits solvent are
used. Methylene chloride is recommended because it is
non-flammable.
NOTICE
To avoid machine damage, do not exceed 120 psi
(0.8 MPa, 8.3 bar) air pressure at the machine inlet.
To avoid serious injury, do not use flammable
solvents for cleaning.

Screen Navigation
10 332078C
Screen Navigation

Screen Navigation
332078C 11

Screen Navigation
12 332078C
Refer to Screen 1, page 25, for mor details.

Screen Navigation
332078C 13
Refer to Screen 2, page 26, for mor details.

Screen Navigation
14 332078C
Refer to Screen 3, page 26, for mor details.

Screen Navigation
332078C 15
Refer to Screen 4, page 27, for mor details.

Screen Navigation
16 332078C

Screen Navigation
332078C 17

Screen Identification
18 332078C
Screen Identification
Main Screen
This is the default screen that shows up when the machine is powered on. It shows the current state of the machine
and navigates to all screens related to setup and running.
Icon Description
Shows the current mode of the machine.
Navigates to the screen where the user can select the mode to run the machine.
Navigates to a screen showing:
• All pressures being monitored on the machine
• Grams remaining in the Cylinder
• The color injector spacing
• The next color injection point
Navigates to screens that allow configuration of the machine.
• Pressure Setpoints
• Refill Setpoints
• Pressure Thresholds for Alarms
• Color Injection Parameters

Screen Identification
332078C 19
Navigates to a screen allowing calibration of:
• Pressure Transducers
• Cylinder Linear Position Sensor
Navigates to a screen allowing the user to select if a condition is either a Warning (keeps
the machine running) or a Fault (stops dispensing).
Navigates to a screen showing the history of alarms that have occurred.
Navigates to a screen showing what IO is currently active.
Navigates to a screen showing the software part number and version installed on the
machine.
Icon Description

Screen Identification
20 332078C
Mode Select Screen
The Mode Select Screen is used for the following:
• Select the mode to operate the machine in.
• Turn color injectors on or off.
• Enable/Disable Frequency Fault Alarms.
Icon Description
This mode allows the machine to operate in a fully automatic mode. It waits for a signal from the
press to begin dispensing material. It will dispense as long as the “Screw Rotate Signal” is present
and there is material left in the cylinders. Once the cylinder reaches a pre-determined refill point, it
will begin refilling. The screw rotate signal must turn off first before the machine will check if it
requires refilling.
This Purges A-Material through the system by applying air to the feed cylinders, opening the refill
valve, and the “A” outlet valve. The purge process continues as long as the “Screw Rotate Signal” is
active.
NOTE: Before resuming normal operation using a mold, be sure to run enough material through the
unit in Auto Mode that it begins to cure.
This purges B-Material through the system by applying air to the feed cylinders, opening the refill
valve, and the “B” outlet valve. The purge process continues as long as the “Screw Rotate Signal” is
active.
NOTE: Before resuming normal operation using a mold, be sure to run enough material through the
unit in Auto Mode that it begins to cure.
Allows the operator to fully control the unit through the use of buttons on the operator interface.
