Graco Fast-Flo A Series User manual

Instructions - Parts List
FastFast
Fast-- -Flo®Flo® Flo® AirAir Air MotorMotor Motor 307456W
EN
ModelModel
Model 215963,215963, 215963, SeriesSeries Series A,A, A, 101.6101.6 101.6 mmmm mm (4(4 (4 in.)in.) in.) strokestroke stroke
ImportantImportant
Important SafetySafety Safety InstructionsInstructions Instructions
Read all warnings and instructions in this manual. SaveSave
Save thesethese these
instructions.instructions.
instructions.
12.5 bar (1.25 MPa, 180 psi) Maximum
Air Working Pressure
NOTE: To replace Air Motor 215963,
order Motor Replacement Kit 223099.
See manual 307977 for parts.
PROVEN QUALITY. LEADING TECHNOLOGY.

ContentsContents
Contents
Warnings ........................................................... 3
Installation.......................................................... 5
Grounding ................................................... 5
To ground the pump..................................... 5
Operation........................................................... 6
Pressure Relief Procedure............................ 6
Troubleshooting.................................................. 7
Service .............................................................. 8
Air Piston and Lower Spring Service ............. 8
Packing Replacement .................................. 8
Upper Spring Replacement........................... 8
Cleaning the Muf󰘱er..................................... 8
Parts.................................................................. 10
Dimensions ........................................................ 12
Technical Data ................................................... 13
Graco Standard Warranty.................................... 14
2307456W

Warnings
WarningsWarnings
Warnings
The following warnings are for this equipment. The exclamation point symbol alerts you to a general warning
and the hazard symbol refers to procedure-speci󰘰c risks. When these symbols appear in the body of this
manual or on labels refer back to these Warnings. Product-speci󰘰c hazard symbols and warnings not covered
in this section may appear throughout the body of this manual where applicable.
WARNINGWARNING
WARNING
EQUIPMENTEQUIPMENT
EQUIPMENT MISUSEMISUSE MISUSE HAZARDHAZARD HAZARD
Equipment misuse can cause the equipment to rupture or malfunction and result in serious
injury.
• This equipment is for professional use only.
• Read all instruction manuals, tags, and labels before operating the equipment.
• Use the equipment only for its intended purpose. If you are not sure, call your Graco
distributor.
• Do not alter or modify this equipment. Use only genuine Graco parts and accessories.
• Check equipment daily. Repair or replace worn or damaged parts immediately.
• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine
manufacturer’s replacement parts only.
• Do not exceed the maximum working pressure stated on the equipment or in the TechnicalTechnical
Technical
DataData
Data section for your equipment. Do not exceed the maximum working pressure of the lowest
rated component in your system.
• Handle hoses carefully. Do not use hoses to pull equipment.
• Route hoses away from traf󰘰c areas, sharp edges, moving parts, and hot surfaces. Do not
expose Graco hoses to temperatures above 66°C (150°F) or below –40°C (–40°F).
• Wear hearing protection when operating this equipment.
• Comply with all applicable local, state, and national 󰘰re, electrical, and safety regulations.
TOXICTOXIC
TOXIC FLUIDFLUID FLUID HAZARDHAZARD HAZARD
Hazardous 󰘱uid or toxic fumes can cause serious injury or death if splashed in the eyes or
on the skin, inhaled, or swallowed.
• Know the speci󰘰c hazards of the 󰘱uid you are using.
• Store hazardous 󰘱uid in approved container. Dispose of hazardous 󰘱uid according to all
local, state, and national guidelines.
• Always wear protective eyewear, gloves, clothing, and respirator as recommended by the
󰘱uid and solvent manufacturer.
307456W 3

Warnings
WARNINGWARNING
WARNING
SKINSKIN
SKIN INJECTIONINJECTION INJECTION HAZARDHAZARD HAZARD
Spray from the gun, leaks, or ruptured components can inject 󰘱uid into your body and cause
extremely serious injury, including the need for amputation. Fluid splashed in the eyes or on the
skin can also cause serious injury.
• Fluid injected into the skin might look like just a cut, but it is a serious injury. GetGet
Get immediateimmediate immediate
surgicalsurgical
surgical treatment.treatment. treatment.
• Do not point the gun at anyone or at any part of the body.
• Do not put your hand or 󰘰ngers over the spray tip/nozzle.
• Do not stop or de󰘱ect leaks with your hand, body, glove, or rag.
• Always have the tip guard and the trigger guard on the gun when spraying.
• Be sure the gun trigger safety operates before spraying.
• Close the gun ball valves when you stop spraying.
• Lock the gun trigger safety when you stop spraying.
• Follow the PressurePressure
Pressure ReliefRelief Relief ProcedureProcedure Procedure on page 6 if the spray tip/nozzle clogs and before
cleaning, checking, or servicing the equipment.
• Tighten all 󰘱uid connections before operating the equipment.
• Check the hoses, tubes, and couplings daily. Replace worn or damaged parts immediately.
Do not repair high pressure couplings; you must replace the entire hose.
FIREFIRE
FIRE ANDAND AND EXPLOSIONEXPLOSION EXPLOSION HAZARDHAZARD HAZARD
Improper grounding, poor ventilation, open 󰘱ames, or sparks can cause a hazardous condition
and result in a 󰘰re or explosion and serious injury.
• Ground the equipment and the object being sprayed/dispensed. Refer to GroundingGrounding
Grounding on
page 5.
• If there is any static sparking or you feel an electric shock while using this equipment, stopstop
stop
sprayingspraying
spraying immediately.immediately. immediately. Do not use the equipment until you identify and correct the problem.
• Provide fresh air ventilation to avoid the buildup of 󰘱ammable fumes from solvents or the 󰘱uid
being sprayed/dispensed.
• Keep the spray/dispensing area free of debris, including solvent, rags, and gasoline.
• Before operating this equipment, extinguish all open 󰘱ames or pilot lights in the
spray/dispensing area.
• Do not smoke in the spray/dispensing area.
• Do not turn on or off any light switch in the spray/dispensing area while operating or if
fumes are present.
• Do not operate a gasoline engine in the spray/dispensing area.
4307456W

Installation
InstallationInstallation
Installation
GroundingGrounding
Grounding
Proper grounding is an essential part of maintaining
a safe system.
To reduce the risk of static sparking, ground the
pump. Check your local electrical code for detailed
grounding instructions for your area and type of
equipment. Be sure to ground all of this equipment:
Pump: Use a ground wire and clamp as shown in
Fig. 1.
Air compressors: Follow manufacturer’s
recommendations.
Object being sprayed: Follow your local code.
All solvent pails used when 󰘱ushing or relieving
pressure:
Always hold a metal part of the gun 󰘰rmly
to the side of a grounded metal pail, then trigger the
spray gun.
To maintain grounding continuity when 󰘱ushing or
relieving pressure:
Always hold a metal part of the
spray gun 󰘰rmly to the side of a grounded metal pail,
then trigger the spray gun.
ToTo
To groundground ground thethe the pumppump pump
1. UL–Listed Pumps: Use a ground wire, connector,
and clamp. See Fig. 1. Loosen screw (X). Insert
one exposed end of a 12 ga (1.5 mm2) minimum
ground wire (Y) through the eye of the ground
terminal connector (W) and tighten screw (X)
securely. Connect the other end of the wire to
a true earth ground. Order Part No. 237569
Ground Wire and Clamp.
2. Non UL–Listed Pumps: See Fig. 1. Remove the
ground screw (Z). Fasten the ground connector
(W) onto the pump with the ground screw (Z)
and tighten securely. Loosen screw (X). Insert
one exposed end of a 12 ga (1.5 mm2) minimum
ground wire (Y) through the eye of the ground
terminal connector (W) and tighten screw (X)
securely. Connect the other end of the wire to
a true earth ground. Order Part No. 222011
Ground Connector/Wire and Clamp.
Figure 1
307456W 5

Operation
OperationOperation
Operation
PressurePressure
Pressure ReliefRelief Relief ProcedureProcedure Procedure
INJECTIONINJECTION
INJECTION HAZARDHAZARD HAZARD
The system pressure must be manually relieved
to prevent the system from starting or spraying
accidentally. Fluid under high pressure can be
injected through the skin and cause serious injury.
To reduce the risk of an injury from injection,
splashing 󰘱uid, or moving parts, follow the Pressure
Relief Procedure whenever you:
• are instructed to relieve the pressure,
• stop spraying/dispensing,
• check or service any of the system equipment,
• or install or clean the spray tips or nozzles.
1. Shut off the air to the pump.
2. Close the bleed-type master air valve (required
in your system).
3. Hold a metal part of the gun to the side of a
grounded metal pail and trigger the gun to relieve
pressure.
4. Open the 󰘱uid drain valve (required in your
system), having a container ready to catch the
drainage.
5. Leave the drain valve open until you are ready to
spray/dispense again.
If you suspect that the spray tip/nozzle or hose is
clogged or that 󰘱uid pressure is not fully relieved after
following the steps above
, veryvery
very slowlyslowly slowly loosen the tip
guard retaining nut or hose end coupling and relieve
pressure gradually. Clear the tip or hose obstruction.
6 307456W

Troubleshooting
TroubleshootingTroubleshooting
Troubleshooting
Follow Pressure Relief Procedure, page 6 before
you check or service any system equipment.
NOTENOTE
NOTE: Check all other possible problems and
solutions before disassembling the pump.
ProblemProblem
Problem SolutionSolution
Solution
Air motor stalls Turn off and relieve air pressure to the motor. Turn
on the air supply . If the motor does not start, service
the air piston (11) or springs (5 and 20).
Air leaks down along the piston shaft (23) Replace the v-block packing (9).
Air leaks from the piston shaft relief holes (23a) Clean and service the piston (11).
Icing; allow the air motor to thaw.
Slow operation
Muf󰘱er (26) clogged. Clean the muf󰘱er with mineral
spirits. See Cleaning the Muf󰘱er, page 8 .
307456W 7

Service
ServiceService
Service
NOTENOTE
NOTE: Repair Kit 214584 is available. For best
results, use all the new parts in the kit, even if the
old parts look good. Parts included in the kit are
marked with a dagger, for example (6†), in the text
and illustrations.
AirAir
Air PistonPiston Piston andand and LowerLower Lower SpringSpring Spring ServiceService Service
To reduce the risk of injury from trapped air
pressure when servicing the air motor, always
remove air cap (7) from air cylinder (8) before
removing air cylinder from base (22).
1. Unscrew the cylinder cap (7) from the cylinder
(8). To remove the spring (5), pry gently under
the coils in the direction of the helix.
2. Unscrew the cylinder (8) from the base (22) and
lift the cylinder off the air piston (11). Using a
pliers (B) on the air exhaust plate (16) and a
wrench (C) on the piston shaft (23), unscrew the
piston from the shaft. See Fig. 2.
NOTICENOTICE
NOTICE
Ketone fumes may damage the piston o-rings.
When pumping ketones (such as acetone,
MEK, etc.), use Conversion Kit 221038. This
kit replaces the standard 󰘱uoroelastomer
o-rings with EPDM o-rings which are resistant
to ketones.
3. Disassemble the piston and wash all parts in
compatible solvent. Refer to the parts list on
page 9. Blow parts dry and inspect for wear
or damage. If any of the valve plate spacers
(13) are damaged, replace all three to maintain
proper clearance between the valve plates and
the seats.
4. Remove and inspect the lower spring (20).
Replace if necessary, and reinstall.
5. A decrease in performance accompanied by
a slower than normal cycle rate is commonly
caused by icing. It is recommended that the
pump is shut down, and the ice is allowed to
thaw.
6. Reassemble the air piston (11), using new parts
as needed. Apply a good grade of thread sealant
to the threads of the screws (12). and torque
evenly to 1.1–1.6 N•m (10–14 in-lb). With the
washer (4) in place, apply thread sealant to the
threads of the piston. Carefully screw the piston
(11) onto the shaft (23) by hand so it is securely
fastened. Do not use pliers on the air exhaust
plate while tightening. When installed, there
should be 0.8 mm (0.032 in.) minimum clearance
between the washer (4) and the piston shaft
shoulder. See Fig. 2.
PackingPacking
Packing ReplacementReplacement Replacement
1. Unscrew the cylinder cap (7) from the cylinder
(8). To remove the spring (5), pry gently under
the coils in the direction of the helix.
2. Unscrew the cylinder (8) from the base (22) and
lift the cylinder off the air piston (11). Disconnect
the piston shaft (23) from the pump connecting
rod and pull the shaft up out of the air motor
base. Remove and inspect the packing (9†),
being careful not to mar the inner lip. See Fig. 2.
NOTENOTE
NOTE: Fluoroelastomer packing 111383 is
available as an accessory, for use with solvents
not compatible with the standard nitrile rubber
packing.
3. Replace the packing and reassemble the air
motor in the reverse order of disassembly.
UpperUpper
Upper SpringSpring Spring ReplacementReplacement Replacement
Unscrew the cylinder cap (7) from the cylinder (8).
To remove the spring (5), pry gently under the coils
in the direction of the helix.
CleaningCleaning
Cleaning thethe the Muf󰘱erMuf󰘱er Muf󰘱er
To clean the muf󰘱er (26), remove it from the unit and
soak it in mineral spirits, then blow dry with air to
remove excess solvent.
8 307456W

Service
220168 Air Valve and Piston Assembly (11) Motor Cap and Cylinder
Piston Rod and Base Piston Detail
Figure 2.
307456W 9

Parts
PartsParts
Parts
1
Apply Sealant
2
Torque to 1.3–1.6 N•m (10-14 in-lb)
10 307456W

Parts
RefRef
Ref PartPart
Part DescriptionDescription
Description QtyQty
Qty
1 116343 SCREW, grounding, for
non-listed pumps
1
2 104029 LUG, grounding, for
UL-listed pumps
1
3 104582 WASHER, tab, for UL-listed
pumps
1
4 157872 HOUSING, piston 1
5178866 SPRING, compression 1
6†172404 GASKET,neoprene 2
7172406 GAP, cylinder 1
8 172407 CYLINDER 1
9†172585 PACKING, v-block; nitrile
rubber
1
10†172595 WASHER, backup 1
11 220168 AIR VALVE & PISTON
ASSEMBLY Includes items
12–16, 27 & 28
1
12* 220884 SCREW, socket hd cap;
No. 6–32 25 mm (1 in.) lg;
with copper gasket
3
RefRef
Ref PartPart
Part DescriptionDescription
Description QtyQty
Qty
13* 181485 SPACER, valve plate 3
14* 189210 PISTON, air, aluminum 1
15 181487 PLATE, air intake valve 1
16*†162729 PLATE, air exhaust valve 1
20 178780 SPRING, compression 1
22 215946 BASE, air motor (include
item 9)
1
23 215947 SHAFT, piston (Includes
item 26)
1
26 178490 MUFFLER 1
27†108357 O-RING, 󰘱uoroelastomer 1
28†108358 O-RING, 󰘱uoroelastomer 3
* Recommended tool box spare parts. Keep these
spare parts on hand to reduce downtime.
†Supplied in Repair Kit 214584.
307456W 11

Dimensions
DimensionsDimensions
Dimensions
12 307456W

Technical Data
TechnicalTechnical
Technical DataData Data
FastFast
Fast-- -FloFlo Flo AirAir Air MotorMotor Motor
U.S.U.S.
U.S. MetricMetric
Metric
Maximum inbound Air Pressure 180 psi 12.5 bar, 1.25 MPa
Air Inlet 1/4 npt (f)
Effective piston area 1.6 in210 cm2
Effective piston diameter 1.4 in. 35.2 mm
Stroke length 4 in. 101.6 mm
Weight 4 lb. 1.8 kg
307456W 13

GracoGraco
Graco StandardStandard Standard WarrantyWarranty Warranty
Graco warrants all equipment referenced in this document which is manufactured by Graco and bearing its name to be
free from defects in material and workmanship on the date of sale to the original purchaser for use. With the exception
of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the
date of sale, repair or replace any part of the equipment determined by Graco to be defective. This warranty applies
only when the equipment is installed, operated and maintained in accordance with Graco’s written recommendations.
This warranty does not cover, and Graco shall not be liable for general wear and tear, or any malfunction, damage
or wear caused by faulty installation, misapplication, abrasion, corrosion, inadequate or improper maintenance,
negligence, accident, tampering, or substitution of non-Graco component parts. Nor shall Graco be liable for
malfunction, damage or wear caused by the incompatibility of Graco equipment with structures, accessories,
equipment or materials not supplied by Graco, or the improper design, manufacture, installation, operation or
maintenance of structures, accessories, equipment or materials not supplied by Graco.
This warranty is conditioned upon the prepaid return of the equipment claimed to be defective to an authorized
Graco distributor for veri󰘰cation of the claimed defect. If the claimed defect is veri󰘰ed, Graco will repair or replace
free of charge any defective parts. The equipment will be returned to the original purchaser transportation prepaid.
If inspection of the equipment does not disclose any defect in material or workmanship, repairs will be made at a
reasonable charge, which charges may include the costs of parts, labor, and transportation.
THISTHIS
THIS WARRANTYWARRANTY WARRANTY ISIS IS EXCLUSIVE,EXCLUSIVE, EXCLUSIVE, ANDAND AND ISIS IS ININ IN LIEULIEU LIEU OFOF OF ANYANY ANY OTHEROTHER OTHER WARRANTIES,WARRANTIES, WARRANTIES, EXPRESSEXPRESS EXPRESS OROR OR IMPLIED,IMPLIED, IMPLIED,
INCLUDINGINCLUDING
INCLUDING BUTBUT BUT NOTNOT NOT LIMITEDLIMITED LIMITED TOTO TO WARRANTYWARRANTY WARRANTY OFOF OF MERCHANTABILITYMERCHANTABILITY MERCHANTABILITY OROR OR WARRANTYWARRANTY WARRANTY OFOF OF FITNESSFITNESS FITNESS FORFOR FOR AA A
PARTICULARPARTICULAR
PARTICULAR PURPOSE.PURPOSE. PURPOSE.
Graco’s sole obligation and buyer’s sole remedy for any breach of warranty shall be as set forth above. The buyer
agrees that no other remedy (including, but not limited to, incidental or consequential damages for lost pro󰘰ts, lost
sales, injury to person or property, or any other incidental or consequential loss) shall be available. Any action for
breach of warranty must be brought within two (2) years of the date of sale.
GRACOGRACO
GRACO MAKESMAKES MAKES NONO NO WARRANTY,WARRANTY, WARRANTY, ANDAND AND DISCLAIMSDISCLAIMS DISCLAIMS ALLALL ALL IMPLIEDIMPLIED IMPLIED WARRANTIESWARRANTIES WARRANTIES OFOF OF MERCHANTABILITYMERCHANTABILITY MERCHANTABILITY ANDAND AND
FITNESSFITNESS
FITNESS FORFOR FOR AA APARTICULARPARTICULAR PARTICULAR PURPOSE,PURPOSE, PURPOSE, ININ IN CONNECTIONCONNECTION CONNECTION WITHWITH WITH ACCESSORIES,ACCESSORIES, ACCESSORIES, EQUIPMENT,EQUIPMENT, EQUIPMENT, MATERIALSMATERIALS MATERIALS
OROR
OR COMPONENTSCOMPONENTS COMPONENTS SOLDSOLD SOLD BUTBUT BUT NOTNOT NOT MANUFACTUREDMANUFACTURED MANUFACTURED BYBY BY GRACO.GRACO. GRACO. These items sold, but not manufactured by
Graco (such as electric motors, switches, hose, etc.), are subject to the warranty, if any, of their manufacturer. Graco
will provide purchaser with reasonable assistance in making any claim for breach of these warranties.
In no event will Graco be liable for indirect, incidental, special or consequential damages resulting from Graco
supplying equipment hereunder, or the furnishing, performance, or use of any products or other goods sold hereto,
whether due to a breach of contract, breach of warranty, the negligence of Graco, or otherwise.
FOR GRACO CANADA CUSTOMERS
The Parties acknowledge that they have required that the present document, as well as all documents, notices and
legal proceedings entered into, given or instituted pursuant hereto or relating directly or indirectly hereto, be drawn
up in English. Les parties reconnaissent avoir convenu que la rédaction du présente document sera en Anglais,
ainsi que tous documents, avis et procédures judiciaires exécutés, donnés ou intentés, à la suite de ou en rapport,
directement ou indirectement, avec les procédures concernées.
GracoGraco
Graco InformationInformation Information
For the latest information about Graco products, visit www.graco.com.
For patent information, see www.graco.com/patents.
ToTo
To placeplace place anan an order,order, order, contact your Graco Distributor or call to identify the nearest distributor.
Phone:Phone:
Phone: [phone] oror or TollToll Toll Free:Free: Free: 1-800-328-0211 Fax:Fax: Fax: [phone]
All written and visual data contained in this document re󰘱ects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Original Instructions. This manual contains English. MM 307456
GracoGraco
Graco Headquarters:Headquarters: Headquarters: Minneapolis
InternationalInternational
International Of󰘰ces:Of󰘰ces: Of󰘰ces: Belgium, China, Japan, Korea
GRACOGRACO
GRACO INC.INC. INC. ANDAND AND SUBSIDIARIESSUBSIDIARIES SUBSIDIARIES •• •P.O.P.O. P.O. BOXBOX BOX 14411441 1441 •• •MINNEAPOLISMINNEAPOLIS MINNEAPOLIS MNMN MN 55440-144155440-1441 55440-1441 •• •USAUSA USA
CopyrightCopyright
Copyright 1980,1980, 1980, GracoGraco Graco Inc.Inc. Inc. AllAll All GracoGraco Graco manufacturingmanufacturing manufacturing locationslocations locations areare are registeredregistered registered toto to ISOISO ISO 9001.9001. 9001.
www.graco.com
Revision W, July 2016
