Graco 223627 Operation manual

Instructions–Parts List
307016S
Important Safety Instructions
Read all warnings and
instructions in this manual. See
page 2 for Table of Contents.
Save these instructions.
Fluid Controls and Fittings
Part No.s 223627, 208085, 223621, 208082, 223622, 223623, 223624,
208250, 214019, 223626 and 210097
200 psi (1.4 MPa, 14 bar) Maximum Inbound Fluid Pressure
Part No.s 223625 and 223628
300 psi (2.1 MPa, 21 bar) Maximum Inbound Fluid Pressure
TWIST LOCK SLIP RING UNION
ADAPTER
TWIST LOCK
223627*
1.0 oz 208085*
1.5 oz 223628*
1.3 oz
223621*
7.0 oz 208082* 7.5 oz 223623* 7.3 oz
223622*{
7.0 oz
COUPLER
STEMS
3/8 npsm
Models
Models
Models
Models
GUN
MOUNTED
FLUID
REGULATORS
1/4 npsm inlet &
return ports
5 to 35 psi
(0.5 to 2.5 bar)
Regulated
Pressure
STRAIGHT
ADAPTERS
3/8 npsm inlet
223624* 208250 223625*
CIRCULATING
ADAPTERS
1/4 npsm inlet &
return ports
214019
223626* 210097
* Stainless Steel Models
02286

2 307016
Table of Contents
Warnings 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Accessories 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Graco Standard Warranty 10. . . . . . . . . . . . . . . . . . . . . .
Graco Information 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols
Warning Symbol
WARNING
This symbol alerts you to the possibility of serious
injury or death if you do not follow the instructions.
Caution Symbol
CAUTION
This symbol alerts you to the possibility of damage to
or destruction of equipment if you do not follow the
corresponding instructions.
NOTE: The following warning applies only to Models 214018, 208250, 214019, & 210097, which contain aluminum
housings.
WARNING
Hazard of Using Fluids Containing Halogenated Hydrocarbons
Never use 1,1,1–trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or fluids contain-
ing such solvents in the models listed in the not above. Such use could result in a serious chemical reaction,
with the possibility of explosion, which could cause death, serious injury and/or substantial property damage.
Consult you fluid suppliers to ensure that the fluids being used are compatible with aluminum parts.
Installation
Connect the Fluid Hose
Regulators or Circulating Adapters:
Connect the fluid hoses to the 1/4 npsm(m) inlet and
return fittings.
Straight Adapter:
Connect a hose to the 3/8 npsm(m) inlet fitting.
Connect the Regulator or Adapter to the Gun
Model 223622:
Screw the regulator union adapter onto the gun fluid
inlet.
Models with Twist-lock Couplers:
Screw the coupler stem onto the gun inlet. Connect the
twist-lock couplers by lining up the coupler slots with
the pins on the stem, pushing the coupler onto the
stem, then twisting the coupler clockwise to lock it.
Models with Slip-ring Couplers:
Pull the slip ring back as you push the coupler onto the
stem.

307016 3
Operation
CAUTION
To avoid damaging the regulator diaphragm, never
exceed 200 psi (1.4 MPa, 14 bar) Maximum Inbound
Fluid Pressure to the regulator.
To Adjust the Fluid Pressure
Trigger the gun. Turn the fluid regulator setscrew (2)
clockwise to the desired setting. Release the gun
trigger, tighten the locknut (1), and install the acorn nut
(16).
Service
WARNING
To reduce the risk of serious injury, including
splashing in the eyes or on the skin, always shut off
the air and fluid pressure to the gun and trigger the
gun to relieve fluid pressure in the hoses before
disconnecting hoses from the regulator or adapter.
To Clean or Service the Regulator
1. Relieve the air and fluid pressures.
2. Disconnect the regulator from the gun and the
hoses from the regulator.
3. Disassemble the regulator. Refer to the Parts
Drawing.
4. Clean and inspect the parts carefully.
5. Replace worn or damaged parts and reassemble
the regulator. Be sure the nylon side of the dia-
phragm (12) faces the fluid.
Torque Notes:
Diaphragm Nut (3) onto Valve Stem (8):
6 to 10 in-lb (0.7 to 1.1 NSm)
Screws (5) into the Housing (18):
20 to 30 in-lb (2.3 to 3.4 NSm)
Cap (14 )into the Housing (18):
10 to 15 ft-lb (13.5 to 20.0 NSm)

18
4 307016
Parts
Ref.
No. Part No. Description Qty.
1 100166 NUT, hex mach; No. 10–32 1
2 102433 SCREW, set, hex socket;
No. 10–32 x 3/4” 1
3 102980 NUT, hex; stainless steel; 1
No. 4–40
4* 102982 O-RING; PTFE 1
5 103229 SCREW, cap, socket head; 5
No. 8–32 x 3/8”
6 167244 RETAINER, spring 1
7 167245 SPRING, compression 1
8 168872 VALVE STEM 1
9 168877 HOUSING, upper 1
10* 178320 GASKET; cellulose fibre 1
11 168879 WASHER, back-up 1
12*{178321 DIAPHRAGM; nylon & buna-n 1
13* 168881 WASHER; acetal 1
14 168884 CAP 1
15* 169597 VALVE SEAT 1
16 170303 ACORN NUT; No. 10–32 1
17* 178322 GASKET; cellulose fibre 1
208086 HOUSING, lower; 1
Models 223621, 208082, &
223622 only
208180 HOUSING, lower; 1
Model 223623 only
19{101947 BALL; stainless steel;
0.375” (9.5 mm) dia. 1
Ref.
No. Part No. Description Qty.
20 186203 COUPLING NUT; stainless steel 1
21{104338 SEAL, spring loaded; PTFE 1
22{171887 BALL SEAT; PTFE 1
23{171888 HOUSING, seal; acetal 1
24 186202 HOUSING, coupler; stainless steel 1
25 168890 SPRING, compression 1
26 168888 VALVE SEAT; acetal 1
27 168889 RETAINER, seat 1
28 168891 SPRING, compression 1
29 208088 SLIP RING COUPLER ASSY.
Includes items 30–34 1
30 100172 SBALL; chrome alloy,
0.188” (4.76 mm) dia. 3
31n157230 SRING, retaining 1
32 168874 SRING, coupler 1
33 168875 SSPRING, compression 1
34 168876 SHOUSING, coupler 1
35n168882 GASKET; acetal 1
36 223892 UNION, adapter; 3/8” npsm(f)
swivel 1
37** 178846 SEAL; nylon 1
38** 103075 BALL; stainless steel,
0.438” (11.1 mm) dia. 1
39** 178847 GUIDE, coupler stem 1
40** 178848 BALL SEAT; PTFE 1
41n111279 BALL; stainless steel,
0.438” (11.1 mm) dia. 1
nRecommended “tool box” spare parts. Keep these spare
parts on hand to reduce down time.
* These parts are included in Repair Kit 208380, which may
be purchased separately.
** These parts are included in Repair Kit 217502, which may
be purchased separately.
{These parts are included in Repair Kit 210786, which may
be purchased separately.
KAccessory PTFE Diaphragm 185028 with PET Backing
Diaphragm 168880 is available. See page 9.

307016 5
Coupler Stems
Fluid Regulators
Ref.
No. Part No. Description Qty.
1n103337 O-RING; fluoroelastomer 1
2 168868 FITTING, coupler 1
3 168869 COUPLING NUT; 3/8 npsm(f) 1
223627 208085 223628
Model 223621 Series A
Includes items 1–25
Model 208082 Series D
Includes items 1–19, 26–34
Model 223622 Series A
Includes items 1–18, 35, 36
Model 223623 Series A
Includes items 1–18, 20, 24,
25, 37–40
COMMON PARTS FOR REGULATORS
2
3
1n
20
24
{23
{21
{22
{19
25
27
26
n19
28
31n
32
33
30
34
36
35n
20
24
39**
37**
40**
41n
25
14
*4 818
11
10*
12*{
13*
769
5
*15
17*
3
2
116
NOTES
Small hole faces down
Torque to 10–15 ft/lb (13.5–20 NSm)
Nylon side MUST face fluid
1/4 npsm(m)
Torque to 6–10 in/lb (0.7–1.1 NSm)
Torque to 20–30 in/lb (2.3–3.4 NSm)
Spring inside faces down
Large chamfer faces up
1
2
3
4
5
6
1
23
4
5
6
7
7
0228
7
29
8
8
