Installation
LineLazer™V Standard Series Kit for Adding a
Battery and Charging System
Kit Number 25A526.
For installation of a Battery and Charging System on LineLazer™V Standard Series.
For professional use only.
Important Safety Instructions
Read all warnings and instructions in this manual and in the equipment manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
ti28698a

Grounding Procedure (For Flammable Materials Only)
2 Installation
Grounding Procedure
(For Flammable Materials Only)
1. Position striper so that the tires are not on pave-
ment.
2. Ground sprayer with grounding clamp. Grounding
clamp must attach to grounded object (e.g. metal
sign post).
Pressure Relief Procedure
Before servicing the sprayer, pump pressure must be
relieved.
1. Perform Grounding Procedure if using flammable
materials.
2. Set pump switch to OFF. Turn engine OFF.
3. Turn pressure control to lowest setting. Trigger all
guns to relieve pressure.
4. Engage all gun trigger locks.Turn prime valve
down.
5. If you suspect the spray tip or hose is clogged or
that pressure has not been fully relieved:
a. VERY SLOWLY loosen the tip guard retaining
nut or the hose end coupling to relieve pressure
gradually.
b. Loosen the nut or coupling completely.
c. Clear the obstruction in the hose or tip.
FIRE AND EXPLOSION HAZARD
This equipment must be grounded to reduce the risk of
static sparking. Static sparking can cause fumes to
ignite or explode. Grounding provides an escape wire
for the electric current.
ti3306a
SKIN INJECTION HAZARD
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury from
pressurized fluid, such as skin injection, splashing fluid
and moving parts, follow the Pressure Relief
Procedure when you stop dispensing and before
cleaning, checking, or servicing the equipment.

Remove Cover
Installation 3
Remove Cover
ti28697a

LineLazer™V 3900, 5900 & 200HS
4 Installation
LineLazer™V 3900, 5900 & 200HS
Kit 25A526 - Charging Board Installation
Ref. Part Description Qty
7 25A495 KIT, repair, charger board 1
9 106520 SCREW, thd forming, pnh 5
109 17J123 PLATE, cover 1
114 128978 SCREW, mach, slot hex wash head 4
7
9
ti28412a
9
REDBLACK

LineLazer™V 3900, 5900 & 200HS
Installation 5
LineLazer™V 3900, 5900 & 200HS
Kit 25A526 - 12V, 22 AH Battery Installation
Ref. Part Description Qty
1 16U160 BATTERY, 22 AH, sealed 1
2 17H644 SHELF, battery 1
3 126949 STRAP, battery 1
4 107257 SCREW, thd forming 4
5 111307 WASHER, lock, external 2
6 128131 SCREW, cap, hex head 2
ti28411a
16
5
3
2
4

Connect Battery and Install Cover
6 Installation
Connect Battery and Install Cover
ti28520a

LineLazer™V 3900, 5900 & 200HS
Installation 7
LineLazer™V 3900, 5900 & 200HS
Kit 25A526 -Wiring Diagram
-+
RED
BLACK
BLACK RED
CHARGER BOARD
(24Y443 - HP AUTO)
30A AUTOMOTIVE FUSE
REGULAR ATO
FUSE HOLDER
ti28413a
