Installation
LineLazer lV 250SPS
3rd or 4th Gun Kit 24P930
3300 psi (22.7 MPa, 227.5 bar) Maximum Working Pressure
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions and warnings in this
manual and in 3A2090 or 3A2593. Save all
instructions.
ti21710a

Pressure Relief Procedure
2332561D
Pressure Relief Procedure
Follow the Pressure Relief Procedure whenever
you see this symbol.
1. Perform Grounding Procedure if using flammable
materials.
2. Set pump valve OFF. Turn engine OFF.
3. Turn pressure control to lowest setting.
4. Trigger gun to relieve pressure.
5. Engage gun trigger safety.
6. Turn prime valve down.
This equipment stays pressurized until pressure is
manually relieved. To help prevent serious injury
from pressurized fluid, such as skin injection,
splashing fluid and moving parts, follow the Pressure
Relief Procedure when you stop spraying and before
cleaning, checking, or servicing the equipment.
ti6740a
ti3441a
ti3305a
ti3324a
ti6473a

Installation
332561D 3
Installation
1. Perform Pressure Relief Procedure, page 2.
2. Install extension clamp support bracket (9).
3. Pull out existing gun arm support bracket.
4. Slide extension clamp onto existing gun arm
support bracket.
5. Install existing gun support bracket.
6. Install extension support bracket (9) and tighten
the clamp.
7. Install exposed cable through cable bracket slot.
8. Insert plastic cable retainer into cable bracket hole.
9. Install cable end onto trigger plate pin and install
clip.
10. Route cable around unit and up through cable holes
behind hose mount. Use tie straps (16) to secure
cable to unit.
ti21734a
ti21719a
ti21720a
ti21716a
ti21721a
ti18997a
ti18999a
ti18998a
ti21712a

Installation
4332561D
11. Route cable end loop through rectangular hole in
bracket and insert plastic cable retainer into the slot-
ted hole on the actuator bracket. Install cable end
onto actuator rod and install clip.
NOTE: Each gun actuator is capable of operating two
cables. For either gun installation, attach cable to the
actuator rod.
12. Remove plug from filter.
13. Connect paint hose to filter. Connect adapter fittings
(5, 7, 18) to filter. Connect hose (10) to adapter nip-
ple (18).
14. Align guns.
15. Position guns (up/down, forward/reverse, left/right).
16. Fourth Gun Placement: Mount spacer (22) to sup-
port bracket(9). Mount support bracket (9) to small
existing gun arm support.
17. Pointer Mount (opposite side) included to allow flex-
ibility in position the pointer.
ti21713a
ti21733a
ti21717a
ti21715a
ti21714a
ti21711a
ti21718a
ti23532a

Parts
332561D 5
Parts
19
22
28
23
24
21
20
25
26
27
1
9
3
4
5
6
7
8
2
10
11
12, 13
18
18
16
ti27327a
Ref. Part Description Qty .
1 16M671 CABLE, gun, solenoid 1
2 24M638 BAR, gun holder, LL IV 250 SPS 1
3 126111 RETAINER, clip, external, 8mm 1
4 287566 KIT, clamp 1
5 124490 FITTING, tee, street 1
6 188135 GUIDE, cable 1
7 196179 FITTING, elbow, street 1
8 235457 GUN, flex, basic 1
9 16T552 HOLDER, 3rd gun (same side) 1
10 245798 HOSE, cpld, 1/4 in. x 7 ft 1
11 243161 GUARD, RAC 5 1
12 LL5319 TIP, spray, RAC 5, striping 1
13 286421 TIP, spray, RAC 5 1
14 222385 TAG, warning 1
16 STRAP, tie 1
18 196177 ADAPTER, nipple 2
19 24U759 HOLDER, 3rd gun (opposite side) 1
20 24N170 BRACKET, mount, pointer 1
21 111145 KNOB, pronged 2
22 16Y970 SPACER, gun support 1
23 159346 WASHER 1
24 102040 NUT, lock, hex 1
25 114653 SCREW, cap, flange head 2
26 100527 WASHER, plain 6
27 111040 NUT, lock, insert, nylock, 5/16 2
28 118887 HOSE, air 1
