Graco FinishPro 290 User manual

www.graco.be
INBETRIEBNAHME
Attach fluid high pressure swivel and
gun air regulator to gun.
Connect blue fluid hose to fluid
inlet fitting on gun fluid tube.
Tighten securely.
Cut air hose to length
and couple to air connection on
air/fluid supply hose.
If air cap is installed
on gun, remove it.
Fill throat packing nut with TSL to
prevent premature packing wear.
Do this each time you spray.
Lock gun trigger safety. Turn
prime valve down.
Set function selection
switch to AIRLESS.
Turn prime valve
horizontal. Unlock
gun trigger sefety.
Hold gun against grounded metal
flushing pail.
Trigger gun and increase fluid pres-
sure to 1/2. Flush 1 minute.
Lock gun trigger safety.
Assemble tip and air cap.
Diese Vorgehensweise gilt für Reinigungsflüssigkeiten und Farben auf Wasserbasis. Für lösemittelhaltige Farben
und Reinigungsflüssigkeiten müssen Sie unbedingt die Sicherheitshinweise für Feuer- und Explosionsgefahr in der
Anleitung lesen! * Für nähere Angaben beachten Sie bitte die Bedienungsanleitung, die dem Gerät beiliegt.
INBETRIEBNAHME / DIRECT IMMERSION TUBE - 390 ONLY
ACHTUNG
Unscrew fluid hose set. Pull hose
down and remove from pump.
Tilt sprayer backward. Align end of direct
immersion tube with bottom of pump.
Push tube into bottom of pump
and tighten fitting securely.
Remove direct immersion
tube from brackets.
FinishPro™290/390/395
Kurzanleitung
Attach air hose to sprayer air fitting and
fluid hose to fluid fitting. Tighten securely.
Anschluss der Pistole an den Schläuchen.
Die verbundenen Schläuche flach
nebeneinander legen.
Das erste Schlauchband
0,5 bis 1 m vor dem
Spritzgerät anbringen.
Weitere Bänder in
Abständen von 0,5
bis 1 m anbringen.
Den Luftschlauch am
Haken am ufteinstell-
ventil anschließen.
nur 390/395
nur 290
Remove and
check
inlet straine
for clogs
and debris.
nur 390/395
Verify function selection switch
is OFF. Plug power supply cord
into properly grounded electrical
outlet.
nur 390/395
nur 290
Place suction tube in grounded metal
pail partially filled with flushing fluid and drain
tube in waste pail. Attach ground wire to pail
and to true earth ground.
WASTE
FLUSH
Turn fluid pressure
all the way down.
390/395
290 290
390/395
Increase pressure to start motor and
allow fluid to circulate through drain tube
for 15 seconds; then turn pressure down.
290
390/395
Place siphon tube in
paint pail. Trigger gun again
into flushing pail until paint
appears.
Move gun to paint pail
and trigger for 20 seconds.
WASTE
PAINT
Den Sitz (33a) ins Sitzgehäuse (35) einsetzen.
Das Sitzgehäuse (35) in die Luftkappe (6)
einsetzen. Die Dichtung (33b) über dem Sitz (33a) ein-
setzen. Für Materialien auf Wasserbasis die schwarze
Dichtung und für Materialien auf Lösungsmittel- und
Mineralölbasis die orange Dichtung verwenden.
6
Fill throat packing
nut with TSL™to prevent
premature packing wear.
35
33a
33b
33
Entfernen Sie die
RAC-Luftkappe
Montieren Sie die Zerstäuber-
düse in die Flachdüsen
Luft-kappe. Steg der Düse in
die Nut der Luftkappe.
Entfernen Sie den
Diffusor mittels des
Pistolen Werkzeug´s.
Montieren Sie den neuen
Diffusor an die Pistole.
Drehmoment 18-19Nm
Montieren Sie die
Flachdüsen Luftkappe

AIR-ASSISTED SPRAYING
AIRLESS SPRAYING
GRACO N.V. Industrieterrein Oude Bunders
Slakweidestraat 31 • B-3630 Maasmechelen
Tel: [phone] • Fax: [phone]
E-mail: [email protected] • http://www.graco.be
Alle Informationen, Illustrationen und Spezifikationen in diesem Dokument basieren auf den neuesten Produktinformationen die zum Zeitpunktder
Publikation erhältlich waren. Wir behalten das Recht vor, zu jeder Zeit Änderungen vornehmen zu können, ohne diese anzukündigen.
Plug in sprayer. Set function
selection switch to AIRLESS.
Turn prime valve horizontal.
Set funcion selection switch
to OFF. Lock trigger safety.
Hold gun against paint pail. Unlock
trigger safety. Trigger gun and increase
pressure until flushing fluid appears.
REINIGUNG
Set function selection switch to AA
(Air-Assisted). Trigger gun and slowly
increase air pressure to blow material
out of gun air passages.
Close drain valve. Unlock trigger
safety and trigger gun into flushing
pail to purge fluid from hose.
© 2009 Graco N.V. · Form No. 328035 G (rev.A) · 06/09 · Gedruckt in Europa.
Graco Inc. ist ISO 9001 zertifiziert.
Open prime valve.
Remove filters from gun
and sprayer, if installed.
Clean and inspect. Install
filters. Whipe sprayer, hose
and gun with a rag soaked
in water or mineral spirits.
Turn pressure to lowest setting.
Trigger gun to relieve pressure.
Lock trigger safety. Put drain tube
in pail. Turn prime valve down.
Remove tip and air cap
from gun.
Remove siphon tube set from
paint and place in flushing fluid.
Use water for water base paint
and miniral spirits for oil base paint.
WASTE WASTE
Turn off air
valve at gun.
Turn safety lever
of gun to OFF.
Point gun at area to be sprayed about 30 cm from surface, and begin moving gun before triggering.
A good spray pattern is evenly distributed as it hits surface. Set pressure just high enough to spray without heavy edges.
Use smaller tip size for thinner material and a larger tip size for thicker material if pressure adjustment cannot achieve even spray pattern.
Bring fluid pressure
up to eliminate tails.
Back pressure down
just to point of tails.
Den Funktionswahlschalter auf
luftunterstütztes Sprintzen
stellen.
Den Luftdruck erhöhen,
um die Ausläufer zu
beseitigen
Set function selection switch
to OFF. Unplug sprayer.
Move gun to flushing pail, hold gun against
pail, trigger gun to thoroughly flush system.
Release trigger and lock trigger safety.
While continuing to trigger gun, turn
prime valve down and allow flushing
fluid to circulate for 1 to 2 minutes
to clean drain tube.
Raise siphon tube above flushing fluid and
run sprayer for 15 to 30 seconds to drain fluid.
PAINT FLUSH
If flushing with water, flush again with mineral
spirits, or Pump Armor, to leave a protective
coating to prevent freezing or corrosion.
