Series 7150 Bariatric Recliner
Series 7155 Bariatric Recliner
GD_7150-7155-INS-LAB-RevA23
ASSEMBLY AND OPERATING
INSTRUCTIONS
SAVE THIS MANUAL FOR FUTURE USE.

CONTENTS
INTRODUCTION ...................................................................................................................................................................3
INTENDED USE ..............................................................................................................................................................3
IMPORTANT SAFETY PRECAUTIONS—PLEASE READ BEFORE USE .....................................................................3
WARNINGS...............................................................................................................................................................3
ASSEMBLY ............................................................................................................................................................................4
UNPACKING ...................................................................................................................................................................4
PRODUCT DESCRIPTION .............................................................................................................................................4
OPERATION ..........................................................................................................................................................................5
LOCKING CASTERS ......................................................................................................................................................5
RECLINER OPERATION.................................................................................................................................................5
GAS SPRING TROUBLESHOOTING GUIDE.................................................................................................................6
ADJUSTING CABLE TENSION................................................................................................................................6
CARE AND MAINTENANCE.................................................................................................................................................7
EVERY THREE MONTHS ...............................................................................................................................................7
UPHOLSTERY MAINTENANCE AND STAIN REMOVAL..............................................................................................7
UPHOLSTERY CARE AND CLEANING GUIDE — ADVANCED VINYL PROTECTION...............................................7
CDC RECOMMENDATIONS ..........................................................................................................................................8
DISPOSAL AND KEY TO SYMBOLS ...................................................................................................................................9
DISPOSAL.......................................................................................................................................................................9
KEY TO SYMBOLS.......................................................................................................................................................10
TECHNICAL SPECIFICATIONS..........................................................................................................................................10
LIMITED WARRANTY .........................................................................................................................................................11
2
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

INTRODUCTION
This manual contains assembly, operation, and maintenance instructions for the Gendron
Bariatric Recliners Series. Read the entire manual carefully before using your recliner, and refer
to it during use if you have questions. If you have further questions, please call GF Products, Inc.
("Graham-Field") / Gendron Technical Support at 1.770.368.4700.
INTENDED USE
Gendron Bariatric Recliners are intended to make the care, treatment and recovery of patients
easier and more comfortable. Gendron Bariatric Recliners are used in a wide range of healthcare
applications including Dialysis, Oncology, Drug Delivery, Same Day Surgery and Post-Operative
Recovery. Gendron Bariatric Recliners are ideal for use in hospitals, clinics and rehabilitation
centers.
Gendron Series 7150 and 7155 Bariatric Recliners support patient weights up to 850 lb (385.6 kg),
EVENLY DISTRIBUTED.
IMPORTANT SAFETY PRECAUTIONS—PLEASE READ BEFORE USE
The safety statements presented in this chapter refer to the basic safety information that the
user must pay attention to and abide by. There are additional safety statements in other chapters
or sections, which may be the same as or similar to the following, or specic to the operations.
Please note the following special statements, used throughout this manual, and their signicance:
WARNING: Indicates a potential hazard situation or unsafe practice that, if not avoided,
could result in death or serious personal injury.
CAUTION: Indicates a potential hazard or unsafe practice that, if not avoided, could result
in minor or moderate personal injury.
sNOTICE: Indicates a potential hazard or unsafe practice that, if not avoided, could result in
product or property damage.
Info: Provides application recommendations or other useful information to ensure that you get
the most from your product.
WARNINGS
WARNING: Read this entire manual before assembly or operation.
WARNING: Periodically inspect all parts and replace as needed.
WARNING: Do not use near an open ame, as the chair could be a combustion source,
resulting in re, property damage, and severe physical injury.
WARNING: Service and repair of the Gendron Series 7150 and 7155 Bariatric Recliner must
be performed by a Graham-Field authorized distributor. GF Health Products, Inc. ("GF") is
not responsible for any consequence resulting from any unauthorized service or repair.
WARNING: This product has a maximum weight capacity of 850 lb (385.6 kg), EVENLY
DISTRIBUTED.
3
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

WARNING: Casters must be locked at all times to prevent unwanted movements.
WARNING: Unauthorized modication of your recliner or the use of non-Gendron
replacement parts may change the structure of the recliner and could create a hazardous
condition, which may result in serious injury and will void the warranty.
WARNING: GF Health Products, Inc. specically disclaims responsibility for any bodily
injury or property damage which may occur during any use which does not comply with
federal, state or local laws or ordinances.
ASSEMBLY
UNPACKING
1. Check for obvious damage to the carton or its contents. If damage is evident, please notify the
carrier and your Graham-Field authorized distributor.
2. Carefully remove all packaging materials from recliner.
PRODUCT DESCRIPTION
Series 7150 Bariatric Recliner
Frame
Frame
Upholstered Armrests
Upholstered Seat
Side Panels
Casters
Actuator Tab
Upholstered Legrest
Upholstered Back
4
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

OPERATION
CASTERS
WARNING: Casters must be locked at all times to prevent unwanted movements.
Locking casters: Each Gendron Bariatric Recliner
features four total locking casters. To activate the
lock, simply press down on the actuator tab until
it locks. To release the lock, press on the raised
portion of the actuator tab until the lever is back in
the normal operating position.
RECLINER OPERATION
The Gendron Series 7150 and 7155 Recliners
feature in nite positions for patient comfort.
The in nite recline positions must be activated
by a caregiver. The recline Adjustment Lever is
located at the rear of the Recliner on the push
handle for easy caregiver access.
Casters
Actuator Tab
Recline Adjustment
Lever
5
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

GAS SPRING TROUBLESHOOTING GUIDE
Info: The gas spring has been pre-adjusted at the
factory.
The gas spring on your recliner provides
counterbalancing forces, and is self-locking for in nite,
precise positioning. Unlocking the gas spring is
controlled by actuating the lever located on the push
handle on the back of the recliner, shown on page  ve.
When the lever is actuated it pulls on the cable which
in turn pulls on a hinge, depressing a button at the end
of the gas spring rod. If the gas spring does not unlock
when the lever is actuated or if it remains permanently
unlocked when the lever is actuated, the cable must
be adjusted.
Adjusting Cable Tension
1. Remove the top gas spring pin from the recliner by
disassembling the bridge pin and the clevis pin that
secure the gas spring to the back / frame.
2. Loosen the lock nut on the gas spring.
3. Hold the hinge assembly while turning the gas
spring until the cable becomes taut. Back o the
gas spring an additional half turn.
Info: If the gas spring was not unlocking when the
lever was actuated, the gas spring must be turned
clockwise. If the gas spring was not locking when the
lever was released, the gas spring must be turned
counter-clockwise.
4. Retighten the lock nut.
5. Reassemble the gas spring to the back of the
recliner by replacing the clevis pin, bridge pin.
6. Actuate the recliner in accordance with the
operating instructions to verify correct adjustment.
Adjusting Cable Tension 2
Adjusting Cable Tension 1
Gas Spring
Gas Spring
Lock Nut
Clevis Pin
Bridge Pin
6
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

CARE AND MAINTENANCE
WARNING: Inspect all components periodically and replace as needed.
EVERY THREE MONTHS
• Check and clean casters.
• Tighten bolts in each leg that secure casters into frame.
• Check brakes on casters.
• Check and clean lock recline mechanism.
• Check recliner mechanism for operation in all positions with assistant seated in recliner.
UPHOLSTERY MAINTENANCE AND STAIN REMOVAL
• Ordinary dirt: wash with warm water and a mild soap or detergent.
• Stubborn dirt: using a soft bristle brush, wash with warm water and a mild soap or detergent.
• Ground-in dirt: scrub with powdered cleanser or similar detergent.
• Chewing gum: scrape carefully; remove with kerosene or naphtha.
• Nail polish and remover: Blot immediately to prevent damage.
• Ball point pen: blot immediately with a white cloth dampened in water or mineral oil.
• Paint, shoe polish, heel marks: remove immediately! Use a white cloth dampened in kerosene,
naphtha or turpentine. Do not use paint remover or liquid brush cleaners.
• Tars, asphalt, creosote: remove to prevent staining. Clean area with kerosene or naphtha.
WARNING: When using kerosene or naphtha, do so in a well ventilated area and keep it
away from re, ame, and recliner occupant.
WARNING: Never use the following: Solvents like paint thinner, Varsol, acetone, whiteners,
waxes, silicones or detergents and/or cleaning products that are not pH neutral.
WARNING: Never use cleaning tools like plastic or wire sponges, or hard-bristle brushes
that can damage the material permanently.
UPHOLSTERY CARE AND CLEANING GUIDE — ADVANCED VINYL PROTECTION
• We recommend cleaning at least once a week to extend the lifespan of the upholstery,
preventing dirt and contamination from building up and stains from becoming permanent.
Clean the whole surface in circular motions using liquid hand soap and water (1 part soap to
9 parts water). Rinse and wipe with a clean damp white cloth to get rid of any excess soap.
Repeat as needed and then let dry. Once a month, you can use a soft-bristle brush for a
deeper cleaning. Remember, light colors need more care, more often. For a list of approved
cleaning check the guide for recommended cleaning products.
• If you need to disinfect the upholstery because it has come into contact with organic material
(blood, urine or faecal matter).
1) Clean with a clean white cloth or fabric. If you choose to use a bleach solution, only use 0.5%
concentration, which can be prepared as follows: Dilution: 1 part bleach per 10 parts of water.
2) Rinse and wipe with a clean damp cloth or fabric to get rid of any excess.
3) Dry.
7
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

This information is not a guarantee and does not relieve the user from the responsibility of the
proper and safe use of the product and all cleaning agents. The use of certain agents can be
harmful to the surface appearance and lifespan of vinyl. Spradling, its agents, and assigns assume
no responsibility resulting from the use of such cleaning agents to the vinyl.
Please check compatibility when using this product in combination with painted or varnished
surfaces.
Spradling International is not sponsored by, aliated with, or endorsed by such trademark owners.
CDC RECOMMENDATIONS
CLEANING AND DISINFECTING STRATEGIES FOR ENVIRONMENTAL SURFACES IN PATIENT-
CARE AREAS FOR VINYL UPHOLSTERY, WALL COVERINGS AND FLOORING
• Select EPA-registered disinfectants, if available, and use them in accordance with the
manufacturer’s instructions.
• Do not use high-level disinfectants / liquid chemical sterilants for disinfection of either
noncritical instruments and devices or any environmental surfaces; such use is counter to label
instructions for these toxic chemicals.
• Follow manufacturers’ instructions for cleaning and maintaining noncritical medical
equipment.
• In the absence of a manufacturer’s cleaning instructions, follow certain procedures:
• Clean noncritical medical equipment surfaces with a detergent / disinfectant.
• Do not use alcohol to disinfect large environmental surfaces.
• Use barrier protective coverings as appropriate for noncritical surfaces that are:
• Touched frequently with gloved hands during the delivery of patient care.
• Likely to become contaminated with blood or body substances.
• Dicult to clean (e.g., computer keyboards).
• Keep housekeeping surfaces (e.g., oors, walls, tabletops) visibly clean on a regular basis and
clean up spills promptly.
• Use a one-step process and an EPA-registered hospital detergent / disinfectant designed for
general housekeeping purposes in patient-care areas where:
• Uncertainty exists as to the nature of the soil on the surfaces (whether it is blood or body
uid or just normal dust or dirt).
• Uncertainty exists regarding the presence of multi drug resistant organisms on such
surfaces.
• Detergent and water are adequate for cleaning surfaces in non patient-care areas (e.g.,
administrative oces). Clean and disinfect high-touch surfaces on a more frequent
schedule than minimal-touch housekeeping surfaces. Clean walls, blinds, and window
curtains in patient-care areas when they are visibly dusty or soiled.
• Do not perform disinfectant fogging in patient-care areas.
• Avoid large-surface cleaning methods that produce mists or aerosols, or disperse dust in
patient-care areas.
• Follow proper procedures for eective uses of mops, cloths, and solutions.
• Prepare cleaning solutions daily or as needed, and replace with fresh solution frequently
according to facility policies and procedures.
8
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

• Change the mop head at the beginning of each day and also as required by facility policy,
or after cleaning up large spills of blood or other body substances.
• Clean mops and cloths after use and allow to dry before reuse; or use single-use,
disposable mop heads and cloths.
• When performing low- or intermediate-level disinfection of environmental surfaces in
nurseries and neonatal units, avoid unnecessary exposure of neonates to disinfectant residues
on these surfaces by using EPA-registered germicides in accordance with manufacturers’
instructions and safety advisories.
DISPOSAL AND KEY TO SYMBOLS
DISPOSAL
Gendron Recliner equipment and accessories can be disposed of.
We recommend disassembling and dividing the equipment and components into dierent
waste groups such as: metal, cable, electronic, recoverable resource and plastic for recycling or
combustion.
Most plastic components are provided with a plastic types code and ber content to aid sorting of
plastic parts.
Product Metal Scrap Cable Scrap Electronic Scrap Plastic Recycling or Combustion
7150 X X N/A X
7155 X X N/A X
9
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

GENERAL WARNING SIGN
KEEP DRY
ELECTRICAL AND ELECTRONIC
EQUIPMENT
CONSULT INSTRUCTIONS FOR USE
MD
MEDICAL DEVICE
KEY TO SYMBOLS
The following symbols are used on Gendron Recliner product labels.
MANUFACTURER
FRAGILE, HANDLE WITH CARE
CE MARK
CAUTION
EC REP EUROPEAN AUTHORIZED
REPRESENTATIVE
UDI
UNIQUE DEVICE IDENTIFIER
TECHNICAL SPECIFICATIONS
7150 7155
Overall Width 38.25" (97.16 cm) 34.25" (87 cm)
Seat Width 29.25" (74.30 cm) 25.25" (64.14 cm)
Seat Depth 19.25" (48.90 cm) 19.25" (48.90 cm)
Maximum Weight Capacity 850 lb (385.55 kg),
EVENLY DISTRIBUTED
850 lb (385.55 kg),
EVENLY DISTRIBUTED
For complete technical speci cations, please call the Graham-Field Technical Support Group at
1.770.368.4700.
10
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

LIMITED WARRANTY
SCOPE OF WARRANTY
GF Health Products, Inc. ("GF") warrants to the original purchaser only that it will replace or repair components, at GF’s sole discretion,
that are defective in material or workmanship under normal use and service. All warranties are conditioned upon the proper use of the
products strictly in accordance with good commercial practice and applicable GF instructions and manuals, including proper use and
maintenance. To the extent that a component is warranted by a third party, GF conveys all of its rights under that warranty to the original
purchaser, to the extent permitted.
This limited warranty shall only apply to defects that are reported to the appropriate party listed in the OBTAINING WARRANTY SERVICE
section that follows, within the applicable warranty period and which, upon examination by GF or its authorized representative, prove to be
a warranty item. This limited warranty is not transferable.
Within the guidelines set forth in this document, the following components are warranted for the time period set forth below:
Steel Frame: ......................................three (3) years
Mechanical Components:.......three (3) years
Casters: .................................................one (1) year
Upholstered Components: ....one (1) year
Replacement Parts:.....................Ninety (90) Days
* Labor is not included in the warranty.
† Upholstery is only warranted on material supplied by GF.
‡ The warranty period is as designated above. If a part is replaced under warranty, the original warranty period will not
be aected. All other replacement parts will be subject to the warranty period specied.
The applicable warranty period shall commence from date of shipment to the original customer, unless there is an expiration date on the
component in which case the warranty shall expire on the earlier of warranty period or the expiration date.
OBTAINING WARRANTY SERVICE
Customers located in the United States who wish to report a warranty issue, must contact GF directly by calling 1.770.368.4700 or by
e-mailing a request to cs@grahameld.com.
Customers located outside the United States who wish to report a warranty issue, must contact the Distributor from whom they purchased
the products.
In both cases, further directions will be provided once the initial contact is made. This limited warranty shall only apply to defects that are
reported within the applicable warranty period. Failure to abide by the specic directions will result in denial of the warranty claim.
EXCLUSIONS
The warranty does not cover and GF shall not be liable for the following:
1. Defects, damage, or other conditions caused, in whole or in part, by misuse, abuse, negligence, alteration, accident, freight damage,
tampering or failure to seek and obtain repair or replacement in a timely manner;
2. Products which are not installed, used, or properly cleaned and maintained as required in the ocial manual for the applicable
product;
3. Products considered to be of a non-durable nature including, but not limited to: lters, fuses, gaskets, lubricants, and charts;
4. Accessories or parts not provided by GF;
5. Matching of color, grain or texture except to commercially acceptable standards;
6. Changes in color caused by natural or articial light;
7. Charges by anyone for adjustments, repairs, replacement parts, installation or other work performed upon or in connection with such
products which are not expressly authorized in writing, in advance, by GF;
8. Any labor or shipping charges incurred in the replacement part installation or repair;
9. Costs and expenses of regular maintenance and cleaning; and
10. Representations and warranties made by any person or entity other than GF.
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES DISCLAIMER
THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. GF MAKES NO IMPLIED
WARRANTIES OF ANY KIND INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IF ANY MODEL OR SAMPLE WAS SHOWN TO THE CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY TO ILLUSTRATE THE
GENERAL TYPE AND QUALITY OF THE PRODUCT AND NOT TO REPRESENT THAT THE PRODUCT WOULD NECESSARILY CONFORM
TO THE MODEL OR SAMPLE IN ALL RESPECTS. THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE
PARTS. GF SHALL NOT BE LIABLE FOR AND HEREBY DISCLAIMS ANY DIRECT, SPECIAL, INDIRECT, INCIDENTAL, EXEMPLARY OR
CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT LIMITED TO: DAMAGES FOR LOSS OF PROFITS OR INCOME, LOSS OF USE,
DOWNTIME, COVER, OR EMPLOYEE OR INDEPENDENT CONTRACTOR WAGES, PAYMENTS AND BENEFITS.. CERTAIN STATES
MAY CONFER ADDITIONAL RIGHTS REGARDING WARRANTIES AND IN THOSE STATES GF’S LIABILITY AND THE LIABILITY OF GF’S
SUPPLIERS, SHALL BE LIMITED TO THE FULLEST EXTENT PERMITTED BY LAW.
The warranties contained herein, together with GF’s current Terms and Conditions, contain all the representations and warranties with
respect to the subject matter of this document, and supersede all prior negotiations, agreements and understandings with respect
thereto. The recipient of this document hereby acknowledges and represents that it has not relied on any representation, assertion,
guarantee, warranty, collateral contract or other assurance, except those set out in this document.
For additional information on this product or this warranty, please contact a GF Customer Service Representative.
NOTES:
1) Additional terms and conditions may apply. See GF’s General Terms and Conditions on its website: www.grahameld.com.
2) Freight claims must be notated on the appropriate shipping documents and must be made with immediacy. International, federal and
state regulations govern specic requirements for freight claims. Failure to abide by those regulations may result in a denial of the
freight claim. GF will assist you in ling the freight claim.
3) Claims for any short shipment must be made within three (3) days of the invoice date.
11
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com

+1 770.368.4700
Information contained herein is subject to change without notice.
The most current and complete product information can be found on our website.
GD_7150-7155-INS-LAB-RevA23 www.gendroninc.com | www.grahameld.com
© 2023, GF Health Products, Inc. All Rights Reserved.
Gendron is a trademark of GF Health Products, Inc.
GF Health Products, Inc.
One Graham-Field Way, Atlanta, GA 30340
Made in U.S.A.
Manufactured By:
