Graham Field LUMEX SELECT Series User manual

LS300-INS-LAB-RevD19
Read this manual before operating your Mattress System.
Save this manual for future use.
SELECT SERIES
LS300 ALTERNATING PRESSURE /
LOW AIR LOSS MATTRESS SYSTEM
USER MANUAL

LS300-INS-LAB-RevD19 2
CONTENTS
1 INTRODUCTION .............................................................................................................................................................3
INTENDED USE........................................................................................................................................................3
CONTRAINDICATIONS FOR USE ...........................................................................................................................3
SYMBOL DEFINITION..............................................................................................................................................3
2 SAFETY PRECAUTIONS................................................................................................................................................4
SIGNIFICANCE OF SAFETY STATEMENTS...........................................................................................................4
DANGER — TO REDUCE THE RISK OF ELECTROCUTION ................................................................................4
WARNING — TO REDUCE THE RISK OF BURNS, ELECTROCUTION, FIRE, OR PERSONAL INJURY ...........4
3 FEATURES......................................................................................................................................................................7
PUMP AND MATTRESS SYSTEM ...........................................................................................................................7
DESCRIPTION....................................................................................................................................................7
PUMP FEATURES ....................................................................................................................................................7
PUMP FRONT PANEL .......................................................................................................................................7
PUMP REAR VIEW ............................................................................................................................................7
MATTRESS FEATURES...........................................................................................................................................7
4 HANDLING PROCEDURES: UNPACKING, STORAGE, AND WASTE DISPOSAL .....................................................8
UNPACKING .............................................................................................................................................................8
STORAGE.................................................................................................................................................................8
CONTROL UNIT (PUMP) ...................................................................................................................................8
MATTRESS OVERLAY.......................................................................................................................................8
WASTE DISPOSAL ..................................................................................................................................................8
5 SETUP .............................................................................................................................................................................9
MATTRESS INSTALLATION ...................................................................................................................................9
PUMP INSTALLATION .............................................................................................................................................9
6 OPERATING INSTRUCTIONS......................................................................................................................................10
OPERATION ...........................................................................................................................................................10
SKIN CARE ......................................................................................................................................................10
INCONTINENCE / DRAINAGE.........................................................................................................................10
GENERAL OPERATION ..................................................................................................................................10
STATIC FUNCTION .......................................................................................................................................... 11
ALTERNATE FUNCTION ................................................................................................................................. 11
CPR DEFLATION....................................................................................................................................................12
7 CARE AND MAINTENANCE.........................................................................................................................................13
CLEANING AND DISINFECTION...........................................................................................................................13
CLEANING AND DISINFECTION OF THE MATTRESS AND COVER ...........................................................13
CLEANING AND DISINFECTION OF THE PUMP...........................................................................................14
INSPECTION / SYSTEM CHECK-OUT ..................................................................................................................14
MAINTENANCE ......................................................................................................................................................15
REPLACE AIR FILTER.....................................................................................................................................15
STORAGE...............................................................................................................................................................15
8 TROUBLESHOOTING ..................................................................................................................................................16
9 SPECIFICATIONS .........................................................................................................................................................17
10 LIMITED WARRANTY...................................................................................................................................................18
11 EMC RELATED NOTIFICATION ...................................................................................................................................19
12 INDEX ............................................................................................................................................................................23

LS300-INS-LAB-RevD19 3
1 INTRODUCTION
Congratulations on your purchase of the Lumex LS300 Alternating Pressure / Low Air Loss
Mattress System. This guide covers its use. The following pages will provide you with important
safety, setup and operating instructions as well as maintenance and warranty information. Read
this manual carefully before operating your Mattress System and refer to it as often as needed.
Consult your authorized distributor or healthcare professional with any questions or concerns
regarding safe and effective techniques for operating your Mattress System. This mattress system
is intended for homecare use ONLY.
INTENDED USE
The Lumex LS300 Alternating Pressure / Low Air Loss Mattress System is designed to aid in the
treatment and prevention of pressure ulcers while optimizing user comfort. The Mattress System
is intended for use by those who are at least fteen years in age.
Info: This device can be used in home healthcare and professional healthcare environments.
CONTRAINDICATIONS FOR USE
WARNING: Certain patient conditions, such as unstable fractures of vertebrae and
conditions of the vertebrae, are not suitable for using this type of device. Always consult a
physician or health professional before using this device.
WARNING: The Mattress System has a minimum weight capacity of 88 lb (40 kg) and
maximum weight capacity of 450 lb (205 kg), EVENLY DISTRIBUTED.
SYMBOL DEFINITION
Symbol Meaning
Type BF Protection against
electronic shock
Refer to Instruction Manual /
Booklet
Caution, consult accompanying
documents
Keep dry
Symbol Meaning
Class II equipment
Waste disposal
Alternating current
SGS product certication mark

LS300-INS-LAB-RevD19 4
2 SAFETY PRECAUTIONS
WARNING: IMPORTANT: Before using this device, read and adhere to the following safety
precautions and warnings. Failure to do so could result in serious personal injury or
damage to your Mattress System.
Always consult your healthcare professional to determine safe methods most suitable for your
individual abilities. Protect yourself, your attendant and Mattress System by having it serviced
regularly. If you experience any malfunction, contact GF Tech Support at 1.770.368.4700 or your GF
authorized distributor immediately, as a hazardous condition could result, causing personal injury
or damage to your Mattress System.
Periodic inspection, adjustment and replacement of worn parts are necessary to provide years of
excellent service. Refer to CARE AND MAINTENANCE section of this manual.
Maintenance MUST be performed by qualied personnel ONLY.
SIGNIFICANCE OF SAFETY STATEMENTS
Note the following special statements, used throughout this manual, and their signicance:
DANGER: Indicates a potential hazard situation or unsafe practice that, if not avoided, will
result in death or serious personal injury.
WARNING: Indicates a potential hazard situation or unsafe practice that, if not avoided,
could result in death or serious personal injury.
CAUTION: Indicates a potential hazard situation or unsafe practice that, if not avoided,
could result in minor or moderate personal injury.
sNOTICE: Indicates a potential hazard situation or unsafe practice that, if not avoided, could
result in product or property damage.
Info: Provides application recommendations or other useful information to ensure that you
get the most from your product.
DANGER — TO REDUCE THE RISK OF ELECTROCUTION
DANGER: Always unplug this product immediately after using.
DANGER: Do not use this product while bathing.
DANGER: Do not place or store product where it can fall or be pulled into a tub or sink.
DANGER: Do not place product in or drop into water or other liquid.
DANGER: Do not reach for product that has fallen into water. Unplug immediately.
WARNING — TO REDUCE THE RISK OF BURNS, ELECTROCUTION, FIRE, OR
PERSONAL INJURY
WARNING: Important! Read and understand these instructions before assembling or using
the Select Mattress System. If you do not understand any part of these warnings, cautions
or instructions, contact a healthcare professional for direction in the use of this product. If
the Select Mattress System is not properly assembled, personal injury and damage to the
Select Mattress System could result.
WARNING: Do not leave this product unattended when plugged in.
WARNING: Always use close supervision when this device is used by or near children, the
physically challenged, or those who require close supervision.

LS300-INS-LAB-RevD19 5
WARNING: If components are damaged or missing, contact your GF authorized distributor
immediately. DO NOT use substitute parts. Use only Lumex replacement parts. The use of
non-Lumex replacement parts could cause personal injury, property damage, and void the
warranty.
 WARNING:Donotmodifythisproduct.UnauthorizedmodicationofyourMattressSystem
could cause personal injury, property damage, and void the warranty.
WARNING: The Mattress System has a minimum weight capacity of 88 lb (40 kg) and
maximum weight capacity of 450 lb (205 kg), EVENLY DISTRIBUTED.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper assembly or use of this product.
WARNING: Check all parts for shipping damage before using. In case of damage, DO
NOT USE the equipment. Contact the carrier or your GF authorized distributor for further
instructions.
 WARNING:Keepopenameandheatingdevicesawayfromthemattresssystem.
 WARNING:AvoidFireHazards–Tominimizeriskofre,connectthepowercorddirectly
into a wall-mounted outlet. Do not use extension cords or multiple outlet strips.
WARNING: No Smoking in Bed – Smoking in bed can be dangerous. To avoid the risk of
re,smokinginbedmustneverbeallowed.
WARNING: Keep sharp objects away from the mattress system.
WARNING: If pain, irritation, numbness, swelling, or redness occur, discontinue use and
contact a healthcare professional.
WARNING: Position power cable and pump at the foot end of bed to prevent any risk of
strangulation by cable.
WARNING: Ensure this device is used with stable power or UPS.
WARNING: This device should not be used adjacent to or stacked with other equipment.
WARNING: Medical electrical equipment needs special precautions regarding EMC and
needs to be installed according to the EMC information provided.
WARNING: Patient Entrance / Exit – Caregiver should always aid patient in exiting the bed.
Make sure a capable patient knows how to get out of bed safely (and, if necessary how to
releasethesiderails)incaseofreorotheremergency.
WARNING: Brakes – Caster brakes should always be locked once the bed is in position.
Verify wheels are locked before any patient transfer to or from the bed.
WARNING: Bed Height – To minimize risk of falls or injury, the bed should always be in the
lowest practical position when patient is unattended.
WARNING: Head of Bed Elevation – Keep head of bed as low as possible to help prevent
patient migration.
WARNING: Bed Frame – Always use a standard healthcare bed frame with safeguards or
protocols that may be appropriate. Frame and side rails must be properly sized relative
tothemattresstohelpminimizeanygapsthatmightentrapapatient’sheadorbody.
Check the bed frame labeling or with the manufacturer for dimensions prior to mattress
placement.

LS300-INS-LAB-RevD19 6
WARNING: Side Rails / Patient Restraints – Whether and how to use side rails or restraints
isadecisionthatshouldbebasedoneachpatient’sneedsandshouldbemadeby
thepatientandthepatient’sfamily,physicianandcaregivers,withfacilityprotocolsin
mind.Caregiversshouldassessrisksandbenetsofsiderail/restraintuse(including
entrapment and patient falls from bed) in conjunction with individual patient needs and
should discuss use or non-use with patient and / or family. Consider not only the clinical
and other needs of the patient but also risks of fatal or serious injury from falling out of bed
and from patient entrapment in or around the side rails, restraints or other accessories.
 Consultacaregiverandcarefullyconsidertheuseofbolsters,positioningaidsoroor
mats, especially with confused, restless or agitated patients. It is recommended that
side rails (if used) be locked in the full upright position when the patient is unattended.
Make sure a capable patient knows how to get out of bed safely (and, if necessary, how
toreleasethesiderails)incaseofreorotheremergency.Monitorpatientsfrequentlyto
guard against patient entrapment.
WARNING: To help prevent inadvertent bed exits or falls, ensure the distance between the
top of side rails (if used) and top of mattress (without compression) is approximately 4.5
inches / 11.4 cm. Consider individual patient size, position (relative to the top of the side
rail), and patient condition in assessing fall risk.
WARNING: I.V. and Drainage Tubes – I.V. and drainage tubes should always have slack for
Alternating Pressure and other patient movements.
WARNING: Skin Care – Monitor skin conditions regularly and consider adjunct or
alternative therapies for high acuity patients. Give extra attention to skin over any raised
side bolster and to any other possible pressure points and locations where moisture or
incontinence may occur or collect. Early intervention may be essential to preventing skin
breakdown.
 WARNING:Fluids–Avoidspillinguidsonpumpcontrols.Ifspillsdooccur,unplugunit
immediatelyandcleanuidfrompumpwearingrubbergloveswhileitisunpluggedto
avoidanypossibilityofshock.Onceuidisremoved,checkoperationofcomponents
in area of spill. Fluids remaining on controls can cause corrosion, which may cause
components to fail or operate erratically, possibly producing potential hazards for patient
and staff.
WARNING: Power Cord – Ensure power cord is kept free from all pinch points and moving
parts and is not trapped under casters. Improper handling of the power cord can cause
damagetothecord,whichmaypossiblyproduceriskofreorelectricshock.
 WARNING:WasteDisposal–Attheendofthisproduct’susefullife,disposeofitin
accordance with local requirements, or contact the manufacturer for advice.
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov.
 WARNING:GFHealthProducts,Inc.specicallydisclaimsresponsibilityforanybodily
injury or property damage which may occur during any use which does not comply with
federal, state or local laws or ordinances.

LS300-INS-LAB-RevD19 7
3 FEATURES
PUMP AND MATTRESS SYSTEM
Description
The Lumex LS300 Alternating Pressure / Low Air Loss Mattress System is a specialized mattress
replacement unit that utilizes low air loss technology with specialized mattress design that
provides pressure management for the treatment of pressure ulcers. The 2:1 alternating function
also provides active prevention for pressure relief, especially for those in acute care and long
term care settings (the cells inate and deate in a 2:1 cycle, meaning 1/2of the body is always
supported at any one time). The Lumex LS300 Alternating Pressure / Low Air Loss Mattress System
offers “cell on cell therapy”, whereby the cell is split in two where the bottom cells do not deate
if the upper cells are completely deated in order to provide extra protection and “zero” pressure
comfort for the patient in the event of a power failure and the mattress deates. The soft-rm
adjustment allows the patient to adjust the rmness or softness of the surface for optimal comfort
with a comfort level dial.
PUMP FEATURES
• Alternation time is set to 10, 15, or 20 minute cycle (see ALTERNATE function on page 12); or
instead, the caregiver can select the STATIC function (see STATIC function on page 12).
• Low Pressure failures will produce an audio alarm for added safety. The alarm can be
temporarily muted by pushing the front panel ALARM RESET Button, resetting the alarm for 20
min.
• The foot board mounting hanger provides convenient placement on the bed.
Pump front panel Pump rear view
MATTRESS FEATURES
• Individual air cushion design for maximum pressure distribution.
• Vented air cushion provides true low air loss therapy.
• Cell on cell design for “zero” pressure comfort during loss of power.

LS300-INS-LAB-RevD19 8
4 HANDLING PROCEDURES: UNPACKING, STORAGE, AND WASTE DISPOSAL
UNPACKING
1. Check for any obvious damage to the carton or its contents. If damage is evident, notify the
carrier or your GF authorized distributor.
2. Open shipping container.
sNOTICE: Do not use sharp instruments to open boxes. Damage to mattress could result.
3. Remove contents.
4. Remove Mattress System from protective plastic cover.
The mattress may appear wrinkled when unpacked. To remove wrinkles, allow mattress up to
24 hours to accommodate. Wrinkles will not affect ination or function. Mattress may be used
immediately if needed.
5. Check mattress surface for tears or cracking; do not use if tears or cracking are present.
STORAGE
Follow the guidelines below whenever this system is being stored or transported to another
location:
Temperature Storage / Transport 41°F ~ 140°F (5°C ~ 60°C)
RH (Relative Humidity) Storage / Transport 15% ~ 90% non-condensing
Control Unit (Pump)
1. Check the power cord and plug for abrasions or excessive wear.
2. Plug in the unit and verify air ows from the units hose connection ports.
3. Place in plastic bag for storage.
Mattress Overlay
1. Check the air manifold for kinks or breaks. Replace if necessary.
2. Twist open the CPR plug at the head of the mattress and disconnect the air feed tubes. All of
the air will be expelled. Starting at the head of the mattress roll towards the foot of the bed.
Use the base mounted straps to secure.
3. Place the system in a plastic bag for storage.
4. Store in a dry, controlled climate room.
5. DO NOT place other objects on top of the repackaged Mattress System.
WASTE DISPOSAL
This Product has been supplied from an environmentally aware manufacturer that
complies with the WEEE. This product may contain substances that could be harmful to
theenvironmentifdisposedofinplaces(landlls)thatarenotappropriateaccordingto
local legislation. Please be environmentally responsible and recycle this product
through your recycling facility at its end of life or dispose of it in accordance with local
regulations.

LS300-INS-LAB-RevD19 9
5 SETUP
WARNING: Always use a standard healthcare bed frame with appropriate safeguards and
protocols. Frame and side rails must be properly sized relative to the mattress to help
minimizeanygapsthatmightentrapapatient’sheadorbody.
MATTRESS INSTALLATION
1. Ensure bed is level and brakes are locked.
2. Remove existing mattress from bed frame.
3. Replace the mattress with the mattress replacement system. Orient mattress so that the air
tube is at the foot of the bed.
If re-installing the Select Mattress System onto a new frame or for a new patient, check
mattress surface for staining and soiling; clean and / or disinfect as required (see
CARE AND MAINTENANCE section).
4. Ensure mattress is properly positioned with no gaps between mattress and bed frame or side
rails.
5. Secure straps on bottom of mattress to the bed frame.
PUMP INSTALLATION
Power SwitchHanger
Pump Rear View Pump Front Panel
1. Place pump on a horizontal surface or hang the pump on the foot board of the bed frame with
built-in hanger on back of pump.
2. Connect pump hoses to mattress — attach the air tube connectors
to the socket on the right pump front panel as shown at right.
Ensure air hoses are not kinked and will not be pinched by any
articulated bed mechanisms.
3. Attach cover to mattress.
4. Ensure POWER switch is in the OFF position.
5. Plug pump into a properly grounded wall outlet; ensure power to this outlet is not controlled
by a wall switch. The unit will turn on initiating compression, then turn off.

LS300-INS-LAB-RevD19 10
6 OPERATING INSTRUCTIONS
OPERATION
Skin Care
• Remove excess moisture and keep skin dry and clean.
• Check patient’s skin regularly, particularly in areas where incontinence and drainage occur.
• Ensure linens under patient are not wrinkled.
• Early intervention may be essential to preventing serious skin breakdown.
Incontinence / Drainage
• Use moisture-impermeable underpads for incontinent patients.
• Wipe mattress surface clean and replace bed linens as required (see Care and Cleaning section
for cleaning instructions, if needed).
General Operation
Pump front panel is shown above; descriptions follow of button functions.
1. Press and hold the front panel POWER button (shown above) for one second — the
POWER LED will now illuminate green indicating that the pump is operating.
2. Press the front panel MAX button (shown above) for AUTO FIRM ination — comfort level and
therapy lights will not illuminate during MAX ination. Allow time for full mattress ination.
After the mattress is fully inated, the patient can be transferred to the mattress. Note: the
mattress can be inflated while a patient is lying on it.
3. Press the front panel MAX button again to release the AUTO FIRM ination mode. If not
released, the AUTO FIRM mode will stay activated for twenty minutes before reverting to
previous memory or default setting (default setting is ALTERNATE).
4. ALTERNATE time can be adjusted with the front panel TIME button, shown above.

LS300-INS-LAB-RevD19 11
STATIC function
Press the front panel MODE button, shown at above left, to select STATIC mode. Adjust the Comfort
Control by pressing the front panel SOFT / FIRM button to achieve the optimum patient comfort.
Perform a pressure hand check by placing your hand under the patient buttocks between cells
and bottom of mattress. The patient should have at least 1 1/2in. (4 cm) of clearance between the
buttocks and the bottom of the mattress.
ALTERNATE function
Press the front panel MODE button to select ALTERNATE mode and enable the two-one alternate
function. Adjust the Comfort Control by pressing the front panel SOFT / FIRM button to achieve the
optimum patient comfort. The ALTERNATE time cycle can be adjusted by pressing the front panel
TIME button, shown at above right. The time can be ten, fteen, or twenty minutes.
If STATIC Function is selected, the time LED will not illuminate; the time selected is the alternation
time per cycle, as shown and explained below.
ALTERNATE MODE TIME 10 minutes 15 minutes 20 minutes
PHASE
phase 1 4 minutes deate A cells 6.5 minutes deate A cells 9 minutes deate A cells
phase 2 2 minutes STATIC 2 minutes STATIC 2 minutes STATIC
phase 3 4 minutes deate B cells 6.5 minutes deate B cells 9 minutes deate B cells
phase 4 2 minutes STATIC 2 minutes STATIC 2 minutes STATIC
* Info: The first three cells on the mattress head end ALWAYS remain in STATIC mode.
Info: Cycle time (10, 15, or 20 minutes) does not include phase 4, 2 minutes STATIC.

LS300-INS-LAB-RevD19 12
Low pressure alarm
The pump is equipped with an audible LOW PRESSURE alarm which enables the pump to audibly
alert the caregiver to a low pressure issue with the mattress system.
The low pressure alarm can be muted for twenty minutes by pressing the pump front panel
ALARM RESET button shown above.
WARNING: The low pressure alarm requires operator response to prevent the patient from
bottoming out.
Info: The low pressure alarm is automatically disengaged for 45 minutes when control unit
is first powered on to ensure no alarms are raised during initial inflation.
Lockout
The pump is also equipped with a manual lock function. All function keys will be automatically
disabled if the LOCKOUT function is activated. When lockout has been engaged, the LOCK LED,
shown above, will illuminate.
To unlock the pump, press and hold the front panel LOCK button, shown above, for three seconds.
The LOCK LED will then de-illuminate, indicating the pump is unlocked.
CPR DEFLATION
 WARNING:Forquickmattressdeation:
1. Disconnect the hose connector from the pump.
2. ReleasetheCPRquickdeationvalveatheadendofthemattress(patientleft).
WARNING: During a power outage, the pump will stop functioning and the POWER LED
mayashandthepowerfailurealarmmaybetriggeredifsoequipped;thisisnormal.The
pump will return to normal operation when power is restored.

LS300-INS-LAB-RevD19 13
7 CARE AND MAINTENANCE
Proper care and maintenance are essential to keeping your Select Mattress System in a safe
operating condition. In addition to inspecting the unit before each use, periodic maintenance
checks should be done.
It is very important to have a strict cross infection, cleaning and disinfection policy in line with
current infection control guidelines.
WARNING: Inspect the mattress before each use. Ensure all hardware and accessories are
secure and the pump is functioning properly.
WARNING: Service and repair of the Select Mattress System MUST be performed by
qualiedpersonnelONLY.
 WARNING:UnauthorizedmodicationoftheMattressSystemortheuseofnon-Lumex
replacement parts may change the structure of the Mattress System and could create a
hazardous condition, which may result in serious injury and will void the warranty.
WARNING: The pump contains no serviceable components. DO NOT attempt to open
the pump. If service is required, consult GF Tech Support at 1.770.368.4700 for further
information.
When you believe a component or part is not functioning properly, immediately contact GF Tech
Support at 1.770.368.4700, as a potentially hazardous condition could exist.
CLEANING AND DISINFECTION
Cleaning and Disinfection of the Mattress and Cover
WARNING: Ensure pump power is off and unplug the power cord from the wall outlet
before cleaning any part of the mattress system.
sNOTICE: Do not use Phenol based cleaning solutions.
1. Remove the bedding.
2. Examine the surface of the mattress assembly components for visible blood or body uids.
3. Perform one of the following:
a. If blood is present, decontaminate the whole mattress product in line with current hospital
or Nursing Home Guidelines.
b. If blood is not present, remove any soil from the cover with paper towels.
WARNING: If grossly soiled, the cover should be removed, cleaned and decontaminated.
4. Using a clean sponge or paper towel, wipe down the cover surface and cells with a diluted
detergent solution or recommended cleaner disinfectant or other germicidal detergent
solution.
5. Cleaning and disinfection may be carried out on the cover with hand hot water and a neutral
detergent or with a sodium hypochlorite solution (0.1% or 1000 parts per million available
chlorine).
6. Alternatively remove the cover and launder, at 160° F / 70° C using normal detergents. It is
essential that articles be thoroughly dried after all cleaning procedures and before storage.

LS300-INS-LAB-RevD19 14
Cleaning and Disinfection of the Pump
WARNING: Ensure pump power is off and unplug the power cord from the wall outlet
before cleaning the pump.
s NOTICE:Donotoodanypartofthepumpwithcleaningsolution.Donotimmersethe
pump in liquid.
s NOTICE:Avoidspillinganyliquidonpump.Ifspillsdooccur,cleanuidfrompump
wearing rubber gloves or while unit is unplugged to avoid any possibility of shock. Once
liquid is removed, check operation of components in area of spill. Any liquid remaining
on pump can cause corrosion, which may cause components to fail or operate erratically,
possibly producing potential hazards for patient and staff.
Clean the pump weekly using a clean, damp soft cloth and mild detergent.
1. Wipe all controls, chassis and hose ttings with a damp cloth and a mild detergent.
2. Using a clean nylon brush, gently clean all crevices, as they can harbor micro organisms.
3. Air dry all treated surfaces.
The pump casing is manufactured from ABS plastic; if the case is soiled, the pump can be wiped
down with a sodium hypochlorite solution to dilution of 1000 ppm or any EPA-approved hospital
grade disinfectant (do not use phenol base cleaning solution).
INSPECTION / SYSTEM CHECK-OUT
Check each of the following before placing the Mattress System with a new patient:
1. Check mattress surface for tears or cracking; do not use if tears or cracks are present.
2. Ensure mattress is free of stains and is not overly faded.
3. Ensure air inlet hoses and connectors on mattress and pump are clean and undamaged.
4. Ensure pump and power cord are clean and undamaged.
5. Ensure pump hanger brackets are secure and operate correctly.
6. Ensure ON / OFF Power switch and comfort control knob both operate correctly.
7. Attach pump to Alternating Pressure hoses and power up to ensure there are no air leaks.

LS300-INS-LAB-RevD19 15
MAINTENANCE
Replace Air Filter
WARNING: Switch off the electrical supply to the pump and disconnect the power cable
fromthewallbeforereplacingtheairlter.
Air Filter
Cover
Pump Rear View
1. Remove air lter cover (shown above).
2. Replace air lter cover.
3. Replace air lter cover.
STORAGE
See section 4: HANDLING PROCEDURES: UNPACKING, STORAGE, AND WASTE DISPOSAL.

LS300-INS-LAB-RevD19 16
8 TROUBLESHOOTING
The following list of problems, their causes and solutions will assist you in determining what may
be causing your Select Air Mattress not to function as designed. If a problem occurs which is not
listed below, contact GF Tech Support at 1.770.368.4700 for further information. Do not attempt to
repair components or parts, as this may invalidate your warranty or cause further problems that
may result in patient injury. Stop using your mattress immediately if it is not functioning correctly
or any warning beeps are heard.
If any of the following notications occurs, follow the steps below to troubleshoot:
Review all selections of this manual before troubleshooting any Select Mattress System.
Do not attempt any troubleshooting not shown in this manual or where the remedy recommends
contacting a GF authorized distributor. Any unauthorized service, modication, alteration, or
misuse may lead to serious injury and / or product damage and will void all applicable warranties.
SYMPTOM POSSIBLE CAUSE SOLUTION
Air is pumping out from the control unit
but mattress is not inating
Faulty power source — improper
voltage may cause the pump to
function abnormally and damage the
control unit
Use a power regulator
Kinks in the air tubes Adjust the air tubes to enable smooth
air ow
Leakage from the air cells Replace air cell if faulty
Leakage from air tube between
mattress and pump
Replace with new air tubes
Improper air tube connection Re-connect the air tubes
The pump is not functioning Power cord or power voltage Use a power regulator
Faulty fuse Replace the fuse
Some of the air cells are not properly
inated
Kinked connection between air cells
and manifold
Correct kinking between air cells and
manifold
Leakage from the air cells Replace air cell if faulty
WARNING: If you experience a problem with your mattress system and are unable to service
it yourself, contact GF Tech Support at 1.770.368.4700 or your GF authorized distributor.

LS300-INS-LAB-RevD19 17
9 SPECIFICATIONS
MATTRESS OVERLAY (Applied Part)
Model Description Specication
LS300M Dimensions (L x W x H) 80 in. x 36 in. x 8 in. (203.2 cm x 91.4 cm x 20.3 cm)
Weight 16.3 lb (7.4 kg)
Top Cover Material Navy Nylon coated with PU + Single Quilting
Base Cover Material Black polyester laminated with PVC, 4 corner elastic strap
PUMP (UL Listed)
Model Description Specication
LS300P Dimensions (L x W x H) 10.16 in. x 4.13 in. x 6.38 in. (25.8 cm x 10.5 cm x 16.2 cm)
Weight 4.85 lb (2.2 kg)
Cycle Time 10, 15 or 20 min.
Flow Rate (direct from pump) 6L / min. compressor
Pressure 16 ~ 32 (±6) mmHg 5 Pressure Level
Rated Voltage & Frequency AC 110-120V 60 Hz
Fuse Rating T1AL 250V
Maximum Current 0.1A
Power Cable 12.5 ft, non-shielding, AC powered
Classication (Electrical) Class II, Type BF
Not AP or AGP type
Temperature Operation 59°F ~ 104°F (15°C ~ 40°C)
Storage / Transport 41°F ~ 140°F (5°C ~ 60°C)
RH (Relative
Humidity)
Operation 30% ~ 75% non-condensing
Storage / Transport 15% ~ 90% non-condensing
Operation Atmospheric Pressure Range 700 hPa to 1060 hPa
Operation Altitude -1017 feet to 9,843 feet (-310 meters to 3000 meters)
Mode of Operation Continuous
Safety Standard IEC60601-1 / IEC60601-1-2 / IEC60601-1-11
Expected Service Life Three years
International Protection Rating /
Ingress Protection Rating
IP21 Protection against solids: 12.5mm; ngers or similar
objects
Protection against liquids: Dripping water (vertically falling
drops) shall have no harmful effect

LS300-INS-LAB-RevD19 18
10 LIMITED WARRANTY
SCOPE OF WARRANTY
GF Health Products, Inc. (“GF”) warrants to the Original Purchaser only that it will replace or repair components, at
GF’s sole discretion, that are defective in material or workmanship under normal use and service. All warranties are
conditioned upon the proper use of the products strictly in accordance with good commercial practice and applicable
GF instructions and manuals, including proper use and maintenance. To the extent that a component is warranted by a
third party, GF conveys all of its rights under that warranty to the original purchaser, to the extent permitted. Original
Purchaser is one who purchases this product new and unused from GF or a GF Distributor.
This limited warranty shall only apply to defects that are reported within the applicable warranty period and which, upon
examination by GF or its authorized representative, prove to be a warranty item. This limited warranty is not transferable.
The warranted components and time period are set forth below:
Mattress: eighteen months
Pump: two years
The applicable warranty period shall commence from date of shipment to the Original Purchaser, unless there is an
expiration date on the component in which case the warranty shall expire on the earlier of warranty period or the
expiration date.
OBTAINING WARRANTY SERVICE
This limited warranty shall only apply to defects that are reported to the Distributor from whom the Customer purchased
the product within the applicable warranty period. If there is not a Distributor, you must contact GF directly by calling
1.770.368.4700, sending a fax request to 1.770.368.2386, or by e-mailing a request to cs@grahameld.com. Specic
directions will be provided by the Customer Service Representative. Failure to abide by the specic directions will result
in denial of the warranty claim.
EXCLUSIONS
The warranty does not cover and GF shall not be liable for the following:
1) Defects, damage, or other conditions caused, in whole or in part, by misuse, abuse, negligence, alteration, accident,
freight damage, tampering or failure to seek and obtain repair or replacement in a timely manner;
2) Products which are not installed, used, or properly cleaned and maintained as required in the ofcial manual for the
applicable product;
3) Products considered to be of a non-durable nature including, but not limited to: casters, lters, fuses, gaskets,
lubricants, and charts;
4) Accessories or parts not provided by GF;
5) Charges by anyone for adjustments, repairs, replacement parts, installation or other work performed upon or in
connection with such products which are not expressly authorized in writing, in advance, by GF;
6) Any labor or shipping charges incurred in the replacement part installation or repair;
7) Costs and expenses of regular maintenance and cleaning; and
8)
Representations and warranties made by any person or entity other than GF.
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL DAMAGES DISCLAIMER
THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. GF MAKES
NO IMPLIED WARRANTIES OF ANY KIND INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE.
IF ANY MODEL OR SAMPLE WAS SHOWN TO THE CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY TO
ILLUSTRATE THE GENERAL TYPE AND QUALITY OF THE PRODUCT AND NOT TO REPRESENT THAT THE PRODUCT
WOULD NECESSARILY CONFORM TO THE MODEL OR SAMPLE IN ALL RESPECTS.
THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE PARTS. GF SHALL NOT BE LIABLE
FOR AND HEREBY DISCLAIMS ANY DIRECT, SPECIAL, INDIRECT, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL
DAMAGES, INCLUDING, BUT NOT LIMITED TO: DAMAGES FOR LOSS OF PROFITS OR INCOME, LOSS OF USE, DOWNTIME,
COVER, OR EMPLOYEE OR INDEPENDENT CONTRACTOR WAGES, PAYMENTS AND BENEFITS.
The warranties contained herein contain all the representations and warranties with respect to the subject matter of this
document, and supersede all prior negotiations, agreements and understandings with respect thereto. The recipient of
this document hereby acknowledges and represents that it has not relied on any representation, assertion, guarantee,
warranty, collateral contract or other assurance, except those set out in this document. Some states do not allow the
exclusion of certain remedies; in those instances that state’s law will control. This warranty gives you specic legal
rights, and you may also have other rights which vary from state to state.
For additional information on this product or this warranty, please contact a GF Customer Service Representative.
NOTES:
1) Additional terms and conditions may apply.
2) Freight claims must be notated on the appropriate shipping documents and must be made with immediacy.
International, federal and state regulations govern specic requirements for freight claims. Failure to abide by those
regulations may result in a denial of the freight claim. GF will assist you in ling the freight claim.
3) Claims for any short shipment must be made within three (3) days of the invoice date.

LS300-INS-LAB-RevD19 19
11 EMC RELATED NOTIFICATION
WARNING: Medical electrical equipment needs special precautions regarding EMC and
needs to be installed according to the EMC information provided. Careful consideration
of this information is essential when stacking or collocating equipment and when routing
cables and accessories.
WARNING: RF mobile communications equipment can affect medical electrical equipment.

Recommended separation distance between
portable and mobile RF communications equipment and the LS300
The LS300 is intended for use in an electromagnetic environment (for home and professional
healthcare) in which radiated RF disturbances are controlled. The customer or the user of the
LS300 can help prevent electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment (transmitters) and the LS300 as
recommended below, according to the maximum output power of the communications
equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d =1,2√P
80 MHz to 800 MHz
d =1,2√P
800 MHz to 2,7 GHz
d =2,3√P
0,01 0,12 0,12 0,23
0,1 0,38 0,38 0,73
1 1,2 1,2 2,3
10 3,8 3,8 7,3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance din
meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where p is the
maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption
and reflection from structures, objects and people.
Manufacturer’s declaration-electromagnetic emissions
The LS300 is intended for use in the electromagnetic environment (for home and professional
healthcare) specified below.
The customer or the user of the LS300 should assure that it is used in such an environment.
Emission test Compliance Electromagnetic environment-guidance
(for home and professional healthcare environment)
RF emissions CISPR 11 Group 1 The LS300 uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not
likely to cause any interference in nearby electronic
equipment.
RF emissions CISPR 11 Class B The LS300 is suitable for use in all establishments,
including domestic establishments and those directly
connected to the public low-voltage power supply
network that supplies buildings used for domestic
purposes.
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage fluctuations
/flicker emissions IEC
61000-3-3
Not applicable

LS300-INS-LAB-RevD19 20
Manufacturer’s declaration-electromagnetic immunity
The LS300 is intended for use in the electromagnetic environment (for home and professional
healthcare) specified below.
The customer or the user of the LS300 should assure that it is used in such an environment.
Immunity test IEC 60601
test level
Compliance level Electromagnetic
environment-guidance
(for home and professional
healthcare environment)
Electrostatic
discharge(ESD)
IEC 61000-4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8 kV,±15
kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 kV
Floors should be wood,
concrete or ceramic tile. If
floors are covered with
synthetic material, the
relative humidity should be at
least 30%
Electrical fast
transient/burst
IEC 61000-4-4
+ 2kV for power supply
lines
+ 1kV for input/output
lines
+ 2kV for power supply
lines
Not applicable
Mains power quality should
be that of a typical home
healthcare environment.
Surge
IEC 61000-4-5
+ 0.5kV, +1kV line(s) to
line(s)
+ 0.5kV, +1kV,+ 2kV
line(s) to earth
+ 0.5kV, +1kV line(s) to
line(s)
Not applicable
Mains power quality should
be that of a typical home
healthcare environment.
Voltage Dips, short
interruptions and voltage
variations on power
supply input lines
IEC 61000-4-11
Voltage dips:
0 % UT; 0,5 cycle
0 % UT; 1 cycle
70 % UT; 25/30 cycles
Voltage interruptions:
0 % UT; 250/300 cycle
Voltage dips:
0 % UT; 0,5 cycle
0 % UT; 1 cycle
70 % UT; 30 cycles
Voltage interruptions:
0 % UT; 300 cycle
Mains power quality should
be that of a typical home
healthcare environment. If
the user of the LS300
requires continued operation
during power mains
interruptions, it is
recommended that the
LS300 be powered from an
uninterruptible power supply .
Power frequency(50, 60
Hz) magnetic field
IEC 61000-4-8
30 A/m
50 Hz or 60 Hz
30 A/m
60 Hz
The LS300 power frequency
magnetic fields should be at
levels characteristic of a
typical location in a typical
home healthcare
environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
*DuringDIPinterference,thepumpwilloutage.Theaircellsconnectedwithpumpstill
haveairinsidewhichwon’taffecttheuseandfunctionofthesystem.
*DuringDIP,pumpwillshowabnormalbutwon’taffectessentialperformanceandno
needtoworrythebasicsafety. 
