GF8903P-INS-LAB-RevB11 1
GF8903P: OVERBED TABLE, NON-TILT
ASSEMBLY & OPERATION INSTRUCTIONS
PLEASE SAVE THESE INSTRUCTIONS FOR FUTURE USE
Note: The most current version of these instructions can be found online at www.grahamfield.com
Tools needed: 5/8 wrench, M6 hex key (included)
IMPORTANT SAFETY INFORMATION: PLEASE READ
WARNING: Important! Read and understand these instructions before assembling or using the
GF8903P Overbed Table. If you do not understand any part of these instructions, contact a
healthcare professional for direction in the use of this product. If the overbed table is not prop-
erly assembled and adjusted, personal injury and/or damage to the overbed table could result.
WARNING: If components are damaged or missing, contact your dealer immediately. DO NOT
use substitute parts. Use only Lumex® replacement parts. Non-Lumex® replacement parts
could cause personal injury and/or damage to overbed table.
WARNING: GF Health Products, Inc. assumes no responsibility for any damage or injury
caused by improper assembly or use of this product.
UNPACKING
Check for any obvious damage to the carton or its contents. If damage is evident, DO NOT USE. Con-
tact carrier / distributor for further instruction.
ASSEMBLY
WARNING: The column is telescoping and
spring-loaded — handle with care during
assembly. DO NOT disassemble the column;
this could cause serious personal injury.
1. Place table top upside down on a level surface
as shown at right.
2. Position column bracket above table top brack-
et as shown at right, with holes matched, and
lower column onto table top. Insert socket head
cap screws through column bracket into table
top bracket as shown. Use M6 hex key to tighten
the screws.
3. Place the base upside down above the col-
umn as shown at right. Install the two large
hex bolts through the bolt plate, base, and into
column end as shown. Use 5/8 wrench to tighten
the bolts.
4. Note position of casters, facing away from table
top, with the two locking casters at the column
end of the base. Insert caster bolts into base as
shown at right. Screw casters in securely.
5. TURN THE TABLE UPRIGHT and place it on the
oor.
WARNING: Ensure that the table is assem-
bled as described, and that all components
are securely attached, before use.
Assembly
column bracket
socket head cap screw
(3 each)
release lever
table top
bolt plate
large hex bolt
(2 each)
table top bracket
column
non-locking caster
(2 each)
locking caster
(2 each)
base

www.grahamfield.com
GF Health Products, Inc. is not responsible for typographical errors. Packaging, warranties, products and specifications are subject to change
without notice. Graham-Field and Lumex are registered trademarks of GF Health Products, Inc.
© 2011 GF Health Products, Inc. • 2935 Northeast Parkway • Atlanta, GA 30360 • tel [phone] • fax [phone]
GF8903P-INS-LAB-RevB11 2
OPERATION
WARNING: Do not lean on the suspended end of the table top; this may cause the table to tip.
WARNING: The table supports up to 22.7 kg (50 lb) of dispersed weight. Do not exceed this
limit.
Raise the table top
Table height is adjustable from 72 cm to 106 cm (28.3" to 41.7"). To raise the table top, apply light pres-
sure upward at any point on bottom of table top and stop when the table top has reached the desired
height.
Lower the table top
With one hand, squeeze the release lever and table top edge together and push the table top down
until it has reached the desired height. The table top will lock into place when the lever is released.
Lock and unlock casters
The two column-end casters have step-on locks. Step on the locks to lock the casters; pull the locks up
to unlock the casters.
MAINTENANCE
Check the t and tightness frequently of all fasteners, and tighten as necessary, to ensure that the table
is securely assembled.
Cleaning
1. To clean: Gently wipe the table with a soft, clean, damp cloth.
CAUTION: Do not use cleansers that could damage the table's finish.
2. To wash more thoroughly: Clean with mild soap and water.
3. Dry table with a clean, soft cloth.
WARRANTY
GF Health Products, Inc. (“Graham-Field”) offers a one-year limited warranty against manufacturer's
defects on the Lumex® GF8903P Overbed Table. If a product is deemed to be under warranty, GF Health
Products, Inc. shall provide, at its option, (1) replacement of any defective part or product or (2) a
credit of the original selling price made to GF Health Products, Inc.'s initial customer. The warranty
does not include any labor charges incurred in replacement part(s) installation or any associated
freight or shipping charges to GF Health Products, Inc.
The warranties contained herein contain all the representations and warranties with respect to the
subject matter of this document, and supersede all prior negotiations, agreements and understandings
with respect thereto. The recipient of this document hereby acknowledges and represents that it has
not relied on any representation, assertion, guarantee, warranty, collateral contract or other assur-
ance, except those set out in this document.
