Graham Field LUMEX GF13702 Manual instruction

GF13702-INS-LAB-RevA10
1
GF13702: ADVANCED PATIENT ALARM
SETUP & OPERATION INSTRUCTIONS
PLEASE SAVE THESE
INSTRUCTIONS FOR FUTURE USE
GF13702-INS-LAB-RevA10
2
CAUTION: Seat cushions, sling seats, and other environmental fac-
tors may negatively affect alarm operation.
ALARM SETUP
Fig. BFig. A Fig. C Fig. D
Delay
Switch
Volume
Switch
Low
Battery
Indicator
Advanced Patient Alarm Monitor
AC Adapter
Jack
Sensor Mat
Jack
Battery
Compartment
Strain
Relief
Nurse Call
Button
Reset
Button
Monitor
Positioning
Clip
1. Remove the screw that holds the battery compartment cover in place.
2. Inside the battery compartment (see Fig. B):
a. Set the volume switch to LO, HI, or RE (remote) volume. For de-
scription of the remote alarm feature, see next page.
b. Set the delay switch to either 0 or 2 seconds. Selecting 2-second
alarm delay may reduce the likelihood of false alarms when used
with restless patients.
c. Install a new 9V alkaline battery (not included).
d. Replace battery compartment cover and reinstall screw.
Alarm Testing
WARNING: Test alarm before each use.
1. Insert the sensor pad’s telephone-style plug into the monitor’s sensor
mat jack (see Fig. C) until it clicks into place.
2. To protect the cable plug end from accidental pull force, route the
cable through the strain relief (see Fig. C).
3. Use your hand to apply pressure to the sensor pad. The monitor will
automatically sense the pressure and beep when activated.
4. Remove the pressure and the alarm will sound. To silence the alarm,
press the reset button on the side of the monitor (see Fig. D).
Patient Setup
1. Follow this procedure before each use.
a. If using a chair sensor pad, center the chair sensor pad under the
patient’s buttocks.
b. If using a bed sensor pad, center the bed sensor pad under the
patient’s buttocks.
Note: The most current version of these instructions can be found online
at www.grahamfield.com
IMPORTANT SAFETY INFORMATION: PLEASE READ
WARNING:
Important! Read and understand these instructions
before installing or using the GF13702 Advanced Patient Alarm.
If you do not understand any part of these instructions, contact
a healthcare professional for direction in the use of this product.
If the patient alarm is not properly set up and adjusted, personal
injury and/or damage to the patient alarm could result.
WARNING: If components are damaged or missing, contact
your dealer immediately. DO NOT use substitute parts. Use only
Lumex® replacement parts. Non-Lumex® replacement parts
could cause personal injury and/or damage to patient alarm.
WARNING: GF Health Products, Inc. assumes no responsibility
for any damage or injury caused by improper assembly or use of
this product.
UNPACKING
Check for any obvious damage to the carton or its contents. If damage is
evident, DO NOT USE. Contact carrier / distributor for further instruction.
INTENDED USE
The intended use of the GF13702 Advanced Patient Alarm is to alert care-
givers when a patient attempts to exit a wheelchair, chair or bed without
assistance. Removal of pressure from the sensor pad beneath the patient
activates the alarm.
Contraindications
WARNING: This device is not a substitute for routine visual
monitoring by caregiver, and is intended to be used in conjunc-
tion with a comprehensive fall management program.
WARNING: No claim is made that this device will prevent patient
falling or reduce the likelihood of injury as a result. The care-
giver is responsible for ensuring that this product is properly
installed, tested, and functioning before each use.
CAUTION: This device is not suitable for all patients, including but
not limited to, those wishing to defeat the alarm system.
CAUTION: This product is designed for individuals weighing 74 lb
or more.

GF13702-INS-LAB-RevA10
3
GF13702-INS-LAB-RevA10
4
www.grahamfield.com
GF Health Products, Inc. is not responsible for typographical errors. Packaging, warranties,
products and specifications are subject to change without notice. Graham-Field and Lumex
are registered trademarks of GF Health Products, Inc.
Manufactured by Arrowhead Healthcare Supply, Duluth, MN 55802 • Made in China
© 2010 GF Health Products, Inc. • 2935 Northeast Parkway • Atlanta, GA 30360
tel 800-347-5678 • fax 800-721-0601
2. The monitor will automatically sense the pressure and beep when
activated.
3. Have the patient attempt to stand to remove pressure from the sensor
pad. The alarm will sound. To silence the alarm, press the reset button
on the side of the monitor (see Fig. D).
4. Place monitor out of reach of patient.
WARNING: If alarm fails to sound, immediately discontinue use
and review alarm setup.
Note: False alarms are often the result of poor pad placement. For
instance, patients may position themselves differently on a bed with
a raised head section than on a completely flat mattress.
To reduce the likelihood of false alarms, the caregiver must ensure that
the pad is correctly placed for each patient’s unique positioning needs.
Remote Alarm (Optional)
The remote alarm option allows the caregiver to silence the local alarm
and sound the alarm remotely through the nurse call system.
1. Select the remote alarm option: Open the battery compartment and
move the volume switch to “RE” (remote) position.
2. Connect the monitor to the nurse call system using an adapter cable
and splitter (not included).
WARNING: Test the alarm in the nurse call system before each
use. If alarm fails to sound, immediately discontinue use and
review alarm setup.
Note: Optional accessories (adapter cable and AC adapter) are avail-
able through GF Health Products, Inc.
MAINTENANCE
WARNING: Test the alarm before each use. If alarm fails to
sound, remove it from service immediately.
Check before each use that all alarm components are functional and bat-
tery is charged. To replace battery, see ALARM SETUP section on previ-
ous page.
Note: The low battery indicator on the front of the alarm will flash
when battery is low and needs to be replaced. Replace battery imme-
diately if indicator flashes (see Fig. A).
Cleaning
1. To clean: Gently wipe alarm components with a soft, clean cloth.
CAUTION: Do not use cleansers that could damage the alarm's fin-
ish. Do not submerge any alarm components in liquid.
WARRANTY
GF Health Products, Inc. (“Graham-Field”) offers a one-year limited war-
ranty against manufacturer's defects on the Lumex® GF13702 Advanced
Patient Alarm.
The warranty does not apply to damage resulting from failure to follow
the operating instructions, accidents, abuse, alterations or disassembly
by unauthorized individuals.
If a product is deemed to be under warranty, GF Health Products, Inc.
shall provide, at its option, (1) replacement of any defective part or
product or (2) a credit of the original selling price made to GF Health
Products, Inc.'s initial customer. The warranty does not include any labor
charges incurred in replacement part(s) installation or any associated
freight or shipping charges to GF Health Products, Inc.
The warranties contained herein contain all the representations and war-
ranties with respect to the subject matter of this document, and super-
sede all prior negotiations, agreements and understandings with respect
thereto. The recipient of this document hereby acknowledges and repre-
sents that it has not relied on any representation, assertion, guarantee,
warranty, collateral contract or other assurance, except those set out in
this document.
Manufactured for
GF Health Products, Inc.
Atlanta, GA 30360
