Granberg Baselift 6210 User manual

Worktop lift Baselift 6210
Doc. No: M6210
Edition: 5
Datum: 2017-06-19
English
INSTUCTION MANUAL
Floor-standing worktop lift Baselift 6210

For more information, see:
www.granberg.se

Section: Headline: Page:
1. Introduction ...................................................................................................................................................4
2. Declaration of conformity with EU directives....................................................................................4
3. Intended use - Technical data..................................................................................................................4
Mounting Instructions::
4.1 Mechanical construction...........................................................................................................................5
4.2 Modules delivered .......................................................................................................................................6
4.3 Planning sketch, location of electrical outlets, water and sewer................................................7
4.4 Electrical connection...................................................................................................................................8
4.5 Water and sewer connection ...................................................................................................................8
4.6 Assembly .........................................................................................................................................................9
4.7 Mounting the fronts................................................................................................................................. 13
4.8 Installing the control button ALU recessed ..................................................................................... 13
4.9 Mounting the trailing edge Aluminum............................................................................................. 14
4.10 Mounting the worktop............................................................................................................................ 14
4.11 Mounting of complete sink units ........................................................................................................ 15
4.12 Installation of the cover plates ............................................................................................................. 16
4.13 Operation test............................................................................................................................................. 17
User Info:
5.1 Safe use......................................................................................................................................................... 18
5.2 Safety arrangements................................................................................................................................ 18
5.3 Load distribution and lateral forces.................................................................................................... 19
5.4 Actions after use........................................................................................................................................ 19
5.5 Alternative Controls.................................................................................................................................. 19
5.6 Cleaning........................................................................................................................................................ 20
5.7 Maintenance ............................................................................................................................................... 20
6. Instructions for recycling........................................................................................................................ 20
7. Stickers.......................................................................................................................................................... 20
8. Warranty ....................................................................................................................................................... 21
9. Services and maintenance records..................................................................................................... 21
10. Troubleshooting ........................................................................................................................................ 22
11. Spare Parts List ........................................................................................................................................... 22
12. Electric system / Electric circuit diagram .......................................................................................... 23
13. EC declaration of conformity ................................................................................................................ 23
Contents

4
1. Introduction
We have the pleasure to deliver a Granberg worktop lift Baselift, an electrically operated lifting and lowering system . The
worktop lift used separately, or together with the Granberg Wall cabinet lifts and becomes then a total adaptation of the kit-
chen. The unit ts kitchens of various makes, which are made according the standards EN 1116 and EN 1153
Only authorized persons may use the worktop lift!
Authorization means obligation to read the instructions and follow them. It is very important that you read and understand
the instructions before using the worktop lift. If you have any questions - contact your supplier.
This instruction should be available for authorized personnel, stored in a protected place and shall follow the product, if it is
moved to another installation site or another house owners.
Correct use, operation, inspections and maintenance
are decisive for ecient and safe work.
2. Declaration of conformity with EU directives
This product is in its basic conguration the CE-marked and is granted to be in compliance with the essential requirements of
safety and operation, in accordance with the current Machinery, EMC and Low Voltage. Separate ”EC Declaration of Confor-
mity” can be found in section 13. The installer is responsible for security in the environment worktop lift installed in and for
the equipment that it be provided with. It is important that a risk analysis is performed for the total installation, and that the
necessary measures for safe use not taken.
3. Intended use - Technical data
Worktop lift is adapted to a vertical motion by operating the work top and drawers *, chopping boards, etc., mounted on it, for
performing normal cooking tasks. The operation shall be indoors, under normal housing conditions regarding temperature,
humidity and lighting. In the worktop cassette e.g. electric hob and a sink can be incorporated.
Bench lifter is not intended for use in moist environments.
It is assumed that the work top benches and the cabinets are made according the standards EN 1116 and EN 1153.
Worktop on adjacent cabinets must not protrude over its cabinet frame. Overhang of the worktop to the adjacent cabinets
constitute a risk of crushing and will not be accepted!
Any other use than the above requires approval by Granberg and denition of the particular allowed operating conditions.
Contact Granberg to get the planned change approved!
* Massive wooden bench boards are not recommended.

5
4.1 Mechanical construction
The worktop lift consists of oor-mounted motor pillars and a frame system in aluminum. Drawers, buttons, hob and sink can
be mounted in the frame system.
Lifting and lowering motion is achieved with motorized actuators, which are integrated in the aluminum pillars.
Technical data
Model: 6210
Build Form Straight
Width 590 - 3400 mm
Worktop height, excl. top 650 - 950 mm
Depth, from wall, excl. front 560 - 580 mm
Vertical stroke, max 300 mm
Time for lifting or lowering movement approx. 20 sec.
Power Supply 230 V / max 2,5 A
Max. Power Consumption 575 W
Max no. of full wok cycles per hour 5
Control voltage 24 V DC
Weight 20 kg / meter
Max load on the worktop lift * 150 kg
* Worktop and other equipment to be included in the load.
Load refers to the load is evenly distributed over the entire load space. Point loads are not allowed!

6
1
2
1
2
3
3
1
4.2 Modules delivered
The worktop lift is delivered in boxes, parts should be installed according to instructions. All installation work must be perfor-
med by persons with the necessary expertise. Installers should have red these instructions, and perform the installation in the
prescribed manner. The packaging material shall be handed over to an organized material re-cycling organisation.
Frame system in aluminum Control button (The button
in the picture is for ush
mounting)
Examples of additional accessories:
Countertops, stove, sink, faucet, boxes, cutting boards, pedestals, actuators, additional clamping protection devices.
Flexible water hoses
(optional)
Flexible drain hose
(optional)
1) Motor
2) Control board with clamp closure list
3) Power cord
Engine Package, 1 motor pillar Engine Package, 2 motor pillars
Cover panels with brackets and screws
(optional)
1) Motor
2) Control board with clamp closure list
3) Power cord
Floor plates to motors

7
400
400
400(B - 400) / 2
30
340
340
30
30
340
340
30
4.3 Planning sketch, location of electrical outlets, water and sewer
Electrical outlets, water and sewer connection must be placed in the marked spaces below.
400 400B - 800 mm
FREE SPACE FOR ELECTRICITY, WATER AND
SEWAGE
FREE SPACE FOR
ELECTRICITY,
WATER AND
SEWAGE
FREE SPACE FOR
ELECTRICITY,
WATER AND
SEWAGE
350
350
Tile Height: 650
Baselift 6210 with one motor pillar (59,0 - 180 cm)
Baselift 6210 with two motor pillars (189,0 - 340,0 cm)
Tile Height: 650
Sketch of the floor plate
from above
Sketch of the floor plate from above
B = Width of worktop lift
B = Width of worktop lift
30 mm free space behind the
motor pillar against the wall.
30 mm free space behind the
motor pillars against the wall.

8
A
4.4 Electrical Connection
The worktop lift is to be connected to a separate mains switch, which is placed in the kitchen or its vicinity. Electrical outlet,
230V, 50 Hz is placed in the space marked in Section 4.3.
* Power requirements 230 W
Electrical connections must be made by a qualied electrician!
Water connection
The water connection shall be made to a 1/2” ballox coupling.
See section 4.3 for correct location.
Note!
Fix the pipes with the clamp (A) in the aluminium frame.
Connect exible water hoses between the pipes from the mixer tap to the
ballox coupling.
Run the lift and check that the hoses moves freely.
4.5 Water and sewer connection
Note!
Professionals must make the connection of the water and sewer pipes, to prevent water damages. It is important that the right
materials are used, and that location and xing ismade properly. The use of Granberg original installation materials, and the
instructions in this manual, ensures correct execution, if a competent tter carries out the installation work.
Make sure that the carpet is going up at the wall a bit to prevent water damages if there should be leakage.
Connecting the drain
All connections must be secured well to cope with the raising and lowering of the bench without the risk of the couplings
dier greatly.
In section 4.3 shows the free space available on the wall under worktop lift installations.

9
B
B
4.6 Mounting a straight Baselift 6210
Note!
- Check if the oor is equipped with oor heating before installation!
- Tiles on the wall will be put before the assembly of the worktop lift begins.
- To facilitate the placement laterally mounted cabinets on one side before bench lifter mounted.
- Worktop lift should have a gap of 5-8 mm to adjacent cabinets or wall.
- See section 4.3 for correct positioning of the motor pillars.
4.6.1
Place the motor pillars on the oor where worktop lift is to be installed.
Strive to place the motor pillars as far apart as possible. Motor pillars are re-
movable during installation and therefore can be moved inwards if anything
prevents placement at the far end.
Installation must be done by competent personnel!
4.6.1
Fit the oor plates for motor pillars.
Use 4 M8 x18 mm / oor plate.
(Included with delivery).

10
12 3
4.6.3
1. Install the control center on the metal bracket supplied.
2. Install metal bracket on the aluminum beam. Screws are prepared in the slot nuts in the aluminum beam.
If the worktop lift is over 180 cm wide supplied extension cables to the motor pillars.
4.6.1
Check the type of oor and the oor’s stability before xation.
If the oor’s condition is poor, an additional wall mount can be ordered.
The wall bracket secures stability
4.6.2
1. Remove the screws and washers that are slotted nuts in the aluminum prole.
2. Apply the factory-tted bench plane on the motor pillars.
3. Push the groove nuts and tighten loose screws (4 screws / motor pillars).

11
Motor 1
Motor 2
(Motor 3)
Anschluss: 230 V / 50Hz / 2,5A
4.6.4
Connect the motors, the security strip, push button and the electricity cable according the instructions below.
Synchronise the motors (if the lifting system have two motors):
Run the lift to it’s lower position and hold the button (at least 5 sec.) until you hear a click from the control box.
The synchronisation has succeed when you hear the click sound.
Run the lift up and down and check that the motors are moving at the same time.
Note!
The security strip must be connected to be able to run the lift.
Run the lift to it’s highest position.
1. Connect the motors
2. Connect the security strip
3. Connect the push button
4. Connect the electricity
Push button (up / down)
Security strip
Power

12
min 5 mm
min 5 mm
=
4.6.5
Adjust the aluminium frame in depth and side wise.
Adjust the depth so it suits with the rest of the kitchen.
(The depth is adjustable between 560 to 580 mm).
A gap of at least 5 mm must exist around the bench lifter!
Lock the position when the adjustment is ready. See sketch below.
Tighten the screws between the motors and the aluminium frame when the adjustment is ready.
4 screws per motor.

13
1
2
3
45
(mm)
min 100
59
60
72
26
32 17
(mm)
4.8 Installing the control button ALU recessed
The position of the push button is chosen together with the person that is going to use the
worktop lift.
Use a 60 mm drill to make the hole in the front. The measure from the centre of the hole to
the edge of the front are not allowed to be less than 100 mm.
It is a good idea to place push buttons next to each other if several lifting systems from
Granberg are used in the same kitchen.
Two- or three-compartment frame are then used instead of one-compartment frame (2).
The distance between the holes shall be 72 mm centre - centre.
Power switch can also be used in combination with buttons. Power switch must be moun-
ted together with a damp-proof cover that is delivered from Granberg. The hole for power
switch shall be 73 mm.
Note that the inner part of the push button (1) shall be mounted with the text
“TOP, OBEN” downwards.
4.7 Mounting the fronts
OIf you need to adjust the sides to fit you fronts and drawers:
Loosen 6 screws in the aluminium beam and 2 screws under the
aluminium profile that is holding the security strip.
Adjust the sides side wise to the correct position and lock the position.
Brackets and screws to mount the fronts at the aluminium frame are
included in the delivery. Mount the screws at the back of the fronts.
See measurements according to the picture below.

14
1
2
3
max 400 mm
4.10 Mounting the worktop
Place the top board at the worktop lift and mark where the hob and sink are going to be
placed.
Note!
Do not saw in the top board when it is placed on the aluminium frame.
The worktop lift can be damaged!
Fix the position of the top board in the aluminium frame by using the bracket and
screws supplied. Adjust the top board so the front edge is in the same position as the
adjacent top boards.
4.9 Mounting the trailing edge Aluminum
If the trailing edge Aluminum is mounted on complete sink, the metal must be predrilled with a 2 mm drill.

15
4.11 Installing a full sink
Granberg worktop lifts do only suit complete sinks delivered from Granberg.
(These sinks are special made to suit the worktop lift).
Do always contact granberg before use of a complete sink that is not delivered by Granberg.
See section 4.5 for correct drain connection.
Things to note if the sink is not delivered from Granberg:
The depth of the sink must be maximum 120 mm. The function of the security strip does not work by use of
deeper sinks.
The back side of the sink
Fix the front edge of the sink at the left and right edges.
In some cases it is easier to remove the front to be able to reach.
Mount the support bracket on the back of the sink.

16
438
(mm)
30
225
12,5
12,5
12
128 200
4.12.2
Installation of the upper cover plate.
1. Fit the brackets on the motor pillars (1 piece / motor column).
The bracket is clamped between the nuts and the plate on the motor pillar.
2. Attach end plates on the disc.
3. Mark and drill holes with 6 mm drill according to sketch.
4.12 Installation of the cover plates
The cover plates are two plates, one placed at the floor and one that is
following the movement of the worktop lift.
The upper and lower cover plate has the same dimension. The thickness
of the plate can be 12 - 16 mm.
If cover plates are not ordered from Granberg, see dimensions according
the sketch to the right.
4.12.1
Mounting the lower cover plate
1. Screw the end brackets to the wall with the lower disc measurements
between the brackets inside.
2. Screw the plate between the brackets.
Lower cover plate: lift width -13 mm
Upper cover plate: lift width -3 mm
Lower Plate dimensions (internal)
123

17
4.13 Operation Test
After installation a complete functional test with full load shall be made:
• Run the worktop lift up and down all the way to respectively end position. Check that the bench runs freely without
trapping risks and jarring sounds. Make sure it stays in the lower respective upper positions.
• Check that the motor pillars moves exactly the same bench lifter has two motor pillars.
• Check that no cables or hoses are jammed or imprison themselves.
• Run the worktop lift down and check that the terminal strip under the worktop front edge works by tapping on it.
• The bench should stop immediately and turn upwards to release space.

18
5.1 Safe Use
The Worktop lift unit is provided with safety arrangements in order to prevent and avoid damages and accidents. It is however
still very important that the operator is well instructed in how to install and operate the Worktop lift unit. In the following the
Worktop lift unit means the lifting machine and the tted accessories, such as drawers and chopping boards.
•OnlyusetheWorktopliftunitforitsintendedpurpose.
•Theoperationandusemustbemadeinsuchwaythatthereisnoriskfordamagesonpersonsandproperty.
•TheWorktopliftunitmayonlybeoperatedbypersonswhohavereadandunderstoodtheseinstructions,andareauthorized
to use it.
•Beawareofthatyouasanoperatorareresponsibleforthatnobodyisdamaged.
•TheWorktopliftunitandtheworkareamustbeinpropercondition.TheWorktopliftunitmustnotbeusedifanyfaulthas
appeared which inuences the functions or the operation safety. It shall also not be used if it has been repaired, altered or
adjusted without permission of a responsible person.
•Donottouchanypartoftheliftwhenoperatingit.Onlypressthebuttonfordesiredmotiondirection.
•Donotputhands,arms,oranyotherpartofthebodyoranyobjectundertheworktoporthecabinetswhenitisoperated.
•Donotoperatewithdrawnoutdrawersorchoppingboards.
•DonotraisetheWorktopliftunitunlessthespaceaboveitisfreefrompersonsorobstacles.InparticulariftheWorktoplift
unit is installed under a Wall cabinet lift with adjustable height there is an imminent risk that you do not notice objects or
equipment that might be trapped.
•NoticethejammingriskbetweentheWorktopliftunitsandadjacentworktopsandcabinets.
•Onlystableandsecurelyloadeditemsmaybehandled.Mindthetiltingriskforobjectsontheworktop,whichareunstable,
e.g. carelessly piled.
•Safetydevicesmustnotbetakenoutofserviceorremoved.
•AlterationsoftheWorktopliftunitthatinuencetheoperationalsafetyorthefunctionsarenotallowed.
•DonotoverloadtheWorktopliftunitandmakesurethattheloaddistributioniscorrect.
•Itisabsolutelyforbiddenforpersonstostayontheworktop,tostandonextendeddrawersandchoppingboardsortouse
the lift for lifting persons.
•Alwaysdistributetheloaduniformlyontheworktop,toavoidcantileveredloading.Considertheriskthattheloadcanroll,
slide or fall over.
•UsesafeandsucientliftingmethodswhenhandlingloadtoandfromtheWorktopliftunit.Inparticularbewarewhen
handling heavy items, and goods with hazardous content or with sharp corners and edges.
•BeawareoftheriskswhenyouworkonWorktopliftunit.Therisksaredependingonthearrangementsontheworktop.
•TheWorktopliftunitshallregularly,onceayear,beinspectedinordertopreventaccidents.
•ApplicableBuildingandSafeuseRegulationsmustbecompliedwith.
•DonotusetheWorktopliftunitasaliftingjack,e.g.forliftingthingsfromtheoor.
•DonotusetheWorktopliftunitinapotentiallyexplosiveenvironment.
•Whentheoperationisinapubliclocation,particularlywhenchildrencanentertheworkarea,theoperatorshallmakesat-
isfactory arrangements to prevent persons from entering the hazardous area when the lift is being operated, or it has been
lowered from the parking position, e.g. by means of blocking the work area or by means of adding protection devices.
•Decalsandmarkingsmustnotberemovedormadeillegible.
•Duringinspections,serviceandrepairworkthereshallbenoloadontheworktoporinthecabinets.Themostcommonfunc-
tions can be reached when the cover panels have been removed.
•Competentpersonsonlymustcarryoutinstallation,serviceandrepairworks.
•OnlyGranbergoriginalsparepartsshallbeusedwhenreplacinganyparts.Ourwarrantycommitmentcanotherwisebe
invalidated.
5.2 Safety arrangements
The underside of the Worktop lift unit is provided with a se-
curity strip. If the security strip is pressed during lowering, the
worktop lift unit shall stop immediately.
Check the security strip function often.

19
5.3 Load distribution and side forces
Note that the max. rated load means that the load is distributed over and inside the entire Worktop Lift. Point loads are not
allowed.
It is absolutely forbidden for persons to stay on the worktop, to stand on extended drawers and chopping boards or to use the
lift for lifting persons.
Basic loading requirements:
* 100 %of the rated load distributed over the entire cabinet volume.
* Horizontal forces are not allowed.
Horizontal forces can appear, for example,when pressing onto the shelves or the load.
Itisdiculttoestimatethesizeoftheactualhorizontalforce,soutmostcaremustalwaysbetaken.
Further to the incorporated safety arrangements additional can safety actions may be required on or at the Worktop lift unit.
Discuss suitable actions with your Granberg representative or with the health and safety inspection.
We recommend that a Risk assessment in accordance with the Machinery Directive shall be made for the actual working con-
ditions. If the owner ts accessories, contact Granberg to get approval for the loading conditions.
5.4 Actions after use
TheWorktop lift unit shall after use be left in its current position.
Switch o the main switch and lock it in closed position, if unauthorized use can occur.
To prevent unauthorized use can it is also possible to furnish the control panel with a key switch, by means of which the con-
trol circuit is disconnected.
5.5 Alternative control devices
The operator shall have a clear view of the hazardous parts of the Worktop lift unit and its motions, but not directly within
the work area, as there is a risk that objects may fall out from it. (Due to limited space it can be necessary to place the control
devices is placed within the work area).
Control buttons UP /
DOWN of aluminium,
recessed.
The button unit is mounted
recessed in workbench front,
cabinet side etc.
Frame for several control devices
If the control devices have been brought together to a common
control station is it important to clearly mark which buttons control
resp. lifting device.This will decrease the risk for operating another
lifting device than the desired.
In order to prevent unauthorized use the control position can be
provided with a key switch
See also section 5.1, ”Safe use”, regarding safe conditions and risks at handling the machine and
the load!

20
5.6 Cleaning
In its use in a kitchen environment the mechanism can be exposed to dirt. As the worktop lift unit contains electrical compo-
nents it is very important that cleaning ismade according this instruction.
WARNING!
* TheWorktop lift unit must absolutely not be connected to the electric supply when cleaning is carried out.
* TheWorktop lift unit must absolutely not be rinsed with water! (not applicable for the sink).
Care instructions:
Remove the cover panels under the Worktop unit, in front of the mechanism. TheWorktop lift unit is cleaned with lukewarm
water and a non-scratching detergent containing soap or similar.Use aWettex swab or similar. After cleaning the surfaces shall
be dried to avoid lime deposits.
5.7 Maintenance
TheWorktop lift unit ismaintenance-free.Greasing and other actions are made during the manufacturing for the lifetime of the
lift. From safety point of view however some components shall be inspected each year.
* Inspections, service and repair work shall be made by competent persons.
* Remove the objects from the Worktop unit before maintenance and repair works are made.
1. Run the lift down and up all the way to resp. end position. Check that it runs freely without trapping risks and jarring sounds.
2. Lower the Worktop unit and lift the safety frame under Worktop unit to check that this operates properly. TheWorktop unit
shall stop immediately.
3. Check that the cables are not chafed, squeezed or breaking.
4. Check that the wall attachments are in proper order.
5. If the Worktop is inclined adjustment can be made according to the installation instructions.
6. Instructions for recycling
When the Worktop lift unit is reused make sure that safety trip panel is the right size.
When the Diagonal lift unit shall be re-used shall it must be cleaned, inspected and go through a full operation test before it is
installed on the new site.
We recommend the machine to be sent to Granberg or to the Granberg distributor to get this done. The machine ismanufac-
tured from re-usable materials or from materials that can be recycled.
7. Stickers
Two decals are included in the instruction manual envelope, and these must be placed in the kitchen.
The decal that explains that the
kitchen is specially equipped shall
be placed close to the control the
button.
The Max. load decal shall be placed
at the push button box.
Check that it stops and stays in the
lower resp. upper positions.
Risk of crushing at the front of the countertop
If the countertop on the worktop lift and countertop to
adja- cent cabinets stand out in front of each cabinet
frame, there is a risk of crushing.
Place the sign that warns of the risk of crushing on the
short side of the countertop on the worktop lift.
Accomplished inspections and repair works shall be specied in the service records in section 9.
