Grandinroad Sheridan 3637 SKD User manual

grandinroad®
EMAIL
[email protected]
CONTACT 1.800.491.4958
for assembly questions on
Weekdays // 8am-8pm EST
Saturday // 9am-6:30pm EST
WARNING: Failure to follow these directions and
warnings can result in serious injury and/or product damage.
If any parts become missing, damaged or worn, discontinue use until
they are replaced with identical parts.
Never stand on or use this chair as a ladder.
!
Do not tip this chair when seated.
!
!
This item is intended for indoor use only.
!
3637 SKD
Sheridan Dining Chair
Assembly Instructions
Item #176616

WORK
SPACE
TOOLS
PARTS
Please conrm you have the necessary parts to complete the assembly.
1
1.800.491.4958
ALLEN
WRENCH
Back Frame
HARDWARECOMPONENTS
ABolts (x8) F
Seat Frame
B
Left Leg
C
Right Leg
D
Lock Washers (x8)
G
Flat Washers (x8)
H

WORK
SPACE
2
ASSEMBLE
Sheridan Dining Chair
Seat Frame
B
Left Leg
CC
Right Leg
D
D
Bolts (x4)
F
Lock Washers (x4)
G
Flat Washers (x4)
H
HELP?
1.800.491.4958
FASTEN the Left Leg (C) and Right Leg
(D) to Seat Frame (B) by using an allen
wrench and 4x sets of a Bolt (F), a Lock
Washer (G) and a Flat Washer (H).
NOTE: Do Not Over Tighten.
2
OPEN the Dust cover on bottom of Seat Frame (B) to reveal frame.
INSERT the Left Leg (C) and Right Leg (D) into Seat Frame (B) as
shown.
1
B
HGF
HGF

3
ASSEMBLE
Sheridan Dining Chair
HELP?
1.800.491.4958
Bolts (x4)
F
Back Frame
A
Lock Washers (x4)
G
Flat Washers (x4)
H
Seat Frame
with Legs
CONNECT the Seat Frame with Legs to
the Back Frame (A) by using an allen
wrench and 4x sets of a Bolt (F), a Lock
Washer (G) and a Flat Washer (H).
NOTE: Do Not Over Tighten.
3
H
G
F
H
G
F
COVER frame with dust cover as shown.
4

WORK
SPACE
4
ASSEMBLE
Sheridan Dining Chair
ASSEMBLY is now complete.
6
With Help, Flip Dining Chair right side up and place in desired
location.
5
HELP?
1.800.491.4958
Dining Chair
