Analogue Ultrasonic
Bath
XUBA Series
Operating Manual

XUBA Series 1 29667 V1
Operating Manual
EN
Contents
Contents.....................................................................................................................1
Safety instructions....................................................................................................2
Installation .................................................................................................................3
Quick guide................................................................................................................4
XUBA1 Control panel instructions..........................................................................6
XUBA3 Control panel instructions..........................................................................7
Technical information...............................................................................................8
Specifications............................................................................................................9
Ultrasonic detergents .............................................................................................10
Maintenance ............................................................................................................11
Disposal of this ultrasonic bath ............................................................................11
Returning equipment to Grant...............................................................................12
Warranty...................................................................................................................13
Troubleshooting......................................................................................................14
Fuse ratings.............................................................................................................15
Temperatures of touchable hot surfaces .............................................................16
Service record .........................................................................................................17
Grant ultrasonic baths are manufactured in the United Kingdom.
Grant ultrasonic baths are manufactured to exacting standards and conform to inter-
national standards.

XUBA Series 29667 V1
Operating Manual
2
Safety instructions
Use of products
The following products are covered by this operating manual:
XUBA1, XUBA3
The products listed above are a series of general purpose ultrasonic cleaning baths
designed for indoor use by a professional user.
Electrical
Connect to a 230VAC fully earthed supply via a 3 pin plug. It can be dangerous to
operate an ultrasonic bath without an earth connected.
The mains plug is fitted with a 5A fuse. NEVER FIT A FUSE OF A HIGHER RATING.
Some baths are fitted with a detachable mains lead. These baths have a mains socket
on the rear of the bath fitted with two 20mm fuses. See rating information on page 15.
NEVER FIT A FUSE OF A HIGHER RATING.
Ensure that excess mains cable is stored neatly.
General use
Ensure that the bath is at least ¾ full of liquid before you switch it on.
Always use a basket to support items to be cleaned. Not doing so may damage the
bath and invalidate the warranty.
Do not place hands or fingers in the bath.
Care should be taken when operating the bath at higher temperatures as external sur-
faces may become hot.
Never use toxic, flammable, acidic, caustic or corrosive solutions in the bath.
Where the bath is fitted with a detachable mains lead disconnect the bath from the
mains supply before emptying. When emptying baths with no waste outlet, tip the bath
AWAY from the electrical connector and lead.
Read the whole of these instructions. Safety may be impaired if they are not followed.
Contact to Grant or its agent for advice on cleaning techniques and detergents.
Grant will not be responsible for damage or injury caused by incorrect use of the
equipment.

XUBA Series 3 29667 V1
Operating Manual
EN
Installation
The following parts and accessories are included with the Grant analogue ultrasonic
baths:
-1 x basket
-1 x lid
-1 x Grant M2 detergent sample
How to install
Locate the bath close to a drain or sink to allow easy drainage of the tank.
Connect the mains lead into a suitable mains socket.
Ensure that the mains plug and the switch are easily accessible.
Fill the bath with water and the correct dose of detergent. The bath is now ready to
use.

XUBA Series 29667 V1
Operating Manual
4
Fill Line
Quick guide
Pour cold water into the bath so that it reaches the
minimum tank fill line (but does not go over the
maximum fill line).
Add the required dose of detergent (see page 10).
Operate the ultrasonics by turning the timer dial to
the required time and pressing the SONICS button
(where applicable).
Operate the heater, if the bath has a heating func-
tion, by turning the heater dial to the required tem-
perature and pressing the HEAT button.
Turn on the ultrasonics for approximately 5-10 min-
utes to degas the cleaning liquid. (See page 8 for
more details on degassing).
The bath is now ready to use.
At the end of the cycle, remove the basket from the
bath and rinse the items under clean running water.
The lid can be inverted and the basket placed on top
to catch excess fluid as the items dry.
Please refer to the following pages in this manual for more detailed instructions.
Change the cleaning liquid at regular intervals. Your cleaning process will determine
how often to change the liquid the more soiled your items, the more often you will
need to change the liquid.
Grant recommends changing the cleaning liquid at least on a daily basis.

XUBA Series 5 29667 V1
Operating Manual
EN
REMEMBER
-Always keep the bath full of liquid when in operation.
-Do not put hot water above 50°C into the bath.
-Always use the basket to support items in the bath.
-Never expose hands, fingers or other body parts to cleaning solutions.
-Never use toxic, flammable, acidic, caustic or corrosive solutions.
-Never breathe the fumes from strong solutions.
-Rinse the items in clean water once the cycle is complete.
Subjecting the bath to improper treatment or misuse will invalidate the warranty.

XUBA Series 29667 V1
Operating Manual
6
XUBA1 Control panel instructions
To switch on the ultrasonics:
Turn the TIME dial to the desired time, and then press the SONICS button.
The SONICS button and the SONICS light will glow. Ultrasonic activity will then
commence in the liquid inside the tank and the TIME dial will be heard ticking.
At the end of the timed period, the TIME will click off, the SONICS light will go out, and
the ultrasonic activity in the liquid will stop.
To stop the ultrasonic activity at any time, press the SONICS button while in opera-
tion.

XUBA Series 7 29667 V1
Operating Manual
EN
XUBA3 Control panel instructions
To switch on the ultrasonics:
Turn the TIME dial to the desired time, and the press the SONICS button.
The SONICS button and the SONICS light will glow. Ultrasonic activity will then
commence in the liquid inside the tank and the Timer dial will be heard ticking.
At the end of the timed period, the TIME will click off, the SONICS light will go out, and
the ultrasonic activity in the liquid will stop.
To stop the ultrasonic activity at any time, press the SONICS button while in opera-
tion.
To operate the heater:
Turn the HEATER dial to the desired temperature, and press the HEAT button.
The HEAT button and the HEAT light will glow, and the liquid will start to heat up.
When the set temperature is reached, the HEAT light will go out.
To stop the heater at any time, press the HEAT button while in operation (ie. when the
HEAT light is already on).
NOTE: Ultrasonic activity itself will heat the liquid. This means that the liquid tempera-
ture may rise above the level indicated on the temperature dial.
The temperature dial only controls the heater cut-out temperature.
If in doubt, check the actual temperature with a thermometer.

XUBA Series 29667 V1
Operating Manual
8
Technical information
The need to degas
In order to allow optimum ultrasonic activity, the gases present in ordinary tap water
need to be driven out of the cleaning solution.
The time needed to degas the liquid varies depending on the amount of gas present in
the liquid and the quantity of water in the tank. Grant recommends a degas period of
at least 10 minutes.
During the degas cycle, you will see bubbles of gas forming on the inside of the bath,
and slowly rising to the surface. Degassing is complete when you can no longer see
these bubbles. Another indication that the liquid in the bath has degassed is an in-
 .
Once the liquid is degassed, the bath is ready for use.
The effect of heat
Heating the liquid in the bath will aid
the cleaning process.
Normally a temperature of between 30
to 60°C is sufficient to accelerate the
process. You will see from the graph
that optimum cleaning will be obtained
at 60°C.
If you are using your bath to clean medical equipment, it is recommended to limit the

Ultrasonic activity itself will heat up the liquid at a rate of approximately 10-15°C per
hour if in continuous use. In order to heat the fluid in the tank at a faster rate, it is rec-
ommended to run the ultrasonics as well as turn on the heating.
Cleaning time
Cleaning time will depend on application, type and amount of contamination. General
light contamination should be removed in less than 10 minutes.
An indication of cleanliness is when stains are no longer visible, and contamination no
longer appears in a stream from the item being cleaned.
Average power
0
20
40
60
15 25 35 45 55 65 75 85
Temp (Deg C)
Power
(Watts/Inch^2)
Av Power
-3dB point

XUBA Series 9 29667 V1
Operating Manual
EN
Specifications
Ambient temperature
5 to 40°C
Maximum relative humidity
80% R.H. in room temperatures up to 31°C
decreasing linearly to 50 % R.H. at 40°C
Altitude above sea level
Up to 2,000 m (6,500 ft)
Operating enviroment
Indoor use only
Working
capacity
(litres)
Tank
capacity
max.
(litres)
Unit external
dimensions
(mm)
Tank internal
dimensions
(mm)
Basket internal
dimensions
(mm)
XUBA1
1.5
1.75
180x160x190
150x140x100
120x96x55
XUBA3
2.5
2.75
270x170x210
240x140x100
200x108x55
Electrical details
Mains supply: 230V @ 50-60 Hz
Pollution degree: 2
Installation category: II
Note: Mains supply voltage fluctuations are not to exceed ±10% of the nominal supply
voltage.
Operating
Freq.
(KHz)
Heater
Range
(°C)
Total Power
consumption
(W)
Ultrasonic
power
(W)
Heating
power
(W)
Mains
voltage
(Vac)
XUBA1
44
ambient
+5 to 70
115
35
80
230
XUBA3
44
ambient
+5 to 70
185
35
150
230

XUBA Series 29667 V1
Operating Manual
10
Ultrasonic detergents
Detergents are a vital component in the ultrasonic process, aiding the removal and
loosening of debris from the surfaces of items placed in the tank while also intensify-
ing the power of the ultrasonic activity.
Grant offers a specially formulated ultrasonic detergent for use in many applications.
Grant M2 is a general purpose detergent for all plastics, glass and metals (expect
aluminium and other soft metals) which is also suitable for use on medical instru-
ments.
Dosing matrix (ml of detergent per tank)
Grant recommends a dosage of between 2 and 5% for all detergents.
Detergent dose (ml)
2%
5%
XUBA1
30
75
XUBA3
50
125
Directions for use: Add 25-50ml of M2 per litre of water in the ultrasonic bath.
Warning: Grant M2 may cause etching to aluminium and other soft metals.
Shelf life: 6 months when stored in a cool, dark environment.
Precautions for use: In case of contact with eyes, rinse immediately with plenty of
water and seek medical advice. If swallowed, seek medical advice immediately and
show the bottle label. Keep out of reach of children.
Refer to safety data sheets available from Grant.
Grant M2 is biodegradeable

XUBA Series 11 29667 V1
Operating Manual
EN
Maintenance
It is important to keep your bath clean. Not only will contaminated liquid reduce the
performance of the bath, it may also damage it. Change the cleaning liquid regularly.
Your cleaning process will determine how often to change the liquid the more soiled
your items, the more often you will need to change the liquid. Change the cleaning
liquid at least daily.
The base of the bath generates the ultrasonic activity by vibrating at very high speeds.
If any contaminants are in contact with the bath, they act as an abrasive, causing wear
on the metal surface. In extreme cases, the bath will develop holes and start to leak.
portable appliance testing should be conducted with water in the bath.
There are no user serviceable parts inside. All service and repair should be referred to
qualified Grant engineers only.
Service contracts for your ultrasonic bath are available from Grant. Contact us for
more information ([phone]).
Disposal of this ultrasonic bath
At the end of its useful life, please ensure that you dispose of this product in accor-
dance with national regulations.
WEEE Compliance
Grant Instruments complies fully with the Waste Electrical & Electronic Equipment
(WEEE) regulations 2006. We are a member of the B2B compliance scheme
(Scheme Approval Number WEE/MP3338PT/SCH), which handle our WEEE obliga-
tions on our behalf. Grant Instruments have been issued with a unique registration
number by the Environmental Agency, this reference number is WEE/GA0048TZ.
For information regarding WEEE collections in the UK please contact our B2B
Compliance Scheme directly on 01691 676 124. For other countries please contact
your equipment supplier.

XUBA Series 29667 V1
Operating Manual
12
Returning equipment to Grant
All equipment being returned to Grant for service, repair or other reason MUST BE
FULLY DECONTAMINATED prior to return and include a certificate of decontamina-
tion.
Failure to do so may result in additional charges or the equipment being returned to
the user/sender at Grants discretion.
Ultrasonic baths which have been used in medical/healthcare applications should be
decontaminated/packaged in accordance with MHRA guideline document DB2003(5)
Management of Medical Devices prior to Repair, Service or Investigation. This can
be found at www.mhra.gov.uk.
This policy is designed to protect the health and safety of Grant employees, reducing
the risk of potential injury or infection.
More information on decontamination guidelines, as well as copies of decontamination
certificates can be found at www.grant.co.uk.
If you require further information, please contact the
Grant Service Department
Grant Instruments (Cambridge) Ltd
Shepreth
Cambridgeshire
England
SG8 6GB
Tel: [phone] Fax: [phone]
E-mail: [email protected]

XUBA Series 13 29667 V1
Operating Manual
EN
Warranty
The warranty on this Grant ultrasonic bath applies to defects appearing within 12
months of the date of sale because of faulty material or manufacture. Genuine defec-
tive items returned to Grant or its agents premises will be replaced or repaired free of
charge at their discretion.
The warranty is extended to two years on transducer assemblies and to 5 years on
the bonding process. If the transducers or bonding material are exposed to liquid or
cleaning chemicals, the warranty will be invalidated.
The warranty does not apply to:
-normal wear and tear
-damage caused by misuse
-non-observance of maintenance, service or connection instructions
-damage caused by the use of toxic, flammable, acidic, caustic or corrosive chemi-
cals or fluids not recommended by Grant
The user should familiarise themselves with this instruction booklet before operating
the equipment and should apply to Grant or its agent for advice on cleaning tech-
niques or chemicals.
Grant will not be responsible for damage or injury caused by incorrect use.
Statutory rights are not affected.

XUBA Series 29667 V1
Operating Manual
14
Troubleshooting
Grant has a dedicated service team who are able to resolve any problems that occur
with your bath. However, on many occasions it is possible that the problem can be
rectified by the operator.
The unit fails to turn on
(no display is shown)
Check that the unit is plugged in and that mains electricity
is present.
The unit stops working
Check that the indicators illuminate when the unit is
switched on.
If the indicators fail to illuminate, check the mains supply
and fuse in the mains plug, as well as the fuses in the
mains socket (if fitted) on the rear of the bath.
If the fuses and mains electricity supply are OK, and the
unit fails to operate, the bath should be returned to your
supplier for service.
If any of these problems persist, the Grant Service Department can be contacted on
[phone] or [e-mail].

XUBA Series 15 29667 V1
Operating Manual
EN
Fuse ratings
IEC Socket fuse ratings
The XUBA1 and XUBA3 baths are fitted with an IEC socket. This IEC socket is fitted
with two 20mm fuses.
Should these fuses need to be replaced, the replacement fuses should ALWAYS be
anti-
Fitting fuses of the incorrect rating in the IEC socket will invalidate the warranty. If you
have any doubt, please contact the Grant Service Department
UK Mains plug fuse ratings
As well as the fuses in the IEC socket, the XUBA1 and XUBA3 are fitted with a 5A
fuse in the mains plug.
Should these fuses need to be replaced, the replacement fuses should ALWAYS be
5A.
Fitting fuses of the incorrect rating in the plug will invalidate the warranty. If you have
any doubt, please contact the Grant Service Department
Model number
Fuse rating
XUBA1
1.6A
XUBA3
1.6A
Model number
Fuse rating
XUBA1
5A
XUBA3
5A

XUBA Series 29667 V1
Operating Manual
16
Temperatures of touchable hot surfaces
BS EN 13202:2000 gives the recommended maximum surface temperatures for dif-
ferent materials at various exposure times (see below)
Your Grant ultrasonic cleaning bath can be set so that the cleaning fluid is up to 70°C.
This means that parts of your ultrasonic cleaner will be above the recommended max-
imum temperature.
If you operate your ultrasonic cleaner at temperatures above the recommended max-
imum, then Grant advise that you conduct a risk assessment, and if appropriate fix a
 
The following limit values are based on the harmonized standards -
BS EN 13202:2000 Ergonomics of the thermal environment - Temperatures
of touchable hot surfaces - Guidance for establishing surface temperature
limit values in production standards with the aid of -
EN 563: 1994 Safety of machinery - Temperatures of touchable surfaces -
Ergonomics data to establish temperature limit values for hot surfaces
Materials/time-temp*
1 sec
4 sec
10 sec
10 min
8 hr
uncoated metal
65°C
58°C
55°C
48°C
43°C
painted metal
83°C
64°C
55°C
48°C
43°C
enamelled metals
74°C
60°C
56°C
48°C
43°C
ceramics, glass, stone
80°C
70°C
66°C
48°C
43°C
plastics
85°C
74°C
70°C
48°C
43°C
wood
110°C
93°C
89°C
48°C
43°C
Time
Contact
Part
1 sec
accidental contact
Outer case, tank flange
4 sec
parts held for short periods
knobs, switches
10 sec
parts continuously held in normal
use
handles
10 min
prolonged use
handles
8 hr
continuous use
handles

XUBA Series 17 29667 V1
Operating Manual
EN
Compliance with the Control of Noise at Work regulations
The Control of Noise at Work Regulations 2005 (the Noise Regulations[1]) came into
force for all industry sectors in Great Britain on 6 April 2006. The Control of Noise at
Work Regulations 2005 replaces the Noise at Work Regulations 1989.
The aim of the Noise Regulations is to ensure that workers' hearing is protected from
excessive noise at their place of work, which could cause them to lose their hearing
and/or to suffer from tinnitus (permanent ringing in the ears).
The level at which employers must provide hearing protection and hearing protection
zones is now 85 decibels (daily or weekly average exposure) and the level at which
employers must assess the risk to workers' health and provide them with information
and training is now 80 decibels. There is also an exposure limit value of 87 decibels,
taking account of any reduction in exposure provided by hearing protection, above
which workers must not be exposed.
Grant publish the noise generated by
your ultrasonic cleaner on the Certificate of Test. The figure is that experienced by a
worker standing in the operating position.
The full text of the Control of Noise at Work Regulations 2005[2] and the full text of the
Noise at Work Regulations 1989[3] can be viewed online.
Guidance on the 2005 Regulations can be found in the free HSE leaflet 'Noise at
Work'(INDG362 (rev 1)[4] and in HSE's priced book 'Controlling Noise at Work' (L108)
(ISBN 0 7176 6164 4) available from HSE Books[5] or from bookshops.
[1] http://www.hse.gov.uk/noise/regulations.htm
[2] http://www.opsi.gov.uk/si/si2005/20051643.htm
[3] http://www.opsi.gov.uk/si/si1989/Uksi_19891790_en_1.htm
[4] http://www.hse.gov.uk/pubns/indg362.pdf
[5] http://www.hsebooks.co.uk

XUBA Series 29667 V1
Operating Manual
18
Service record
Grant recommends that your ultrasonic bath is serviced at least once every 12
months. This record must be maintained by the engineer conducting the service.
There are no user serviceable parts inside. All service and repair should be referred to
qualified Grant engineers only.
Date
Cycle count
Engineer
Details
Next service due
Date
Cycle count
Engineer
Details
Next service due
Date
Cycle count
Engineer
Details
Next service due
Date
Cycle count
Engineer
Details
Next service due
Date
Cycle count
Engineer
Details
Next service due
