GRAPHTEC FCX2000 SERIES User manual

CUTTING MACHINE
SERVICE MANUAL
FCX2000
FCX2000-UM-251-10-9370

FCX2000-UM-251-9370 i
HISTORY OF REVISIONS
No. Date issued Description of revision Page Edition
116.11.22 First Printing All 01
216.12.05 The packing style was changed. 2-2 02
317.01.10 Effective cutting area for the FCX2000-180 was corrected. 1-1,1-3 03
417.02.09 Drawing is added for parts of hangers. 11-15 03
517.02 .13 Note was added for the X flexible cable damage. 2-8 03
617.02 .13 Confirming the Conditions of X flexible cable was added. Section 2.5 03
717.10.17 The part number for Slider Fix Plate was added. 11- 8 04
817.10.17 The part name for U622623151 was corrected. 11- 8 04
917.10.19 The Y bar height adjustment procedure was added. 8-64 to 65 04
10 18.01.17 The procedure added to install the X flexible cable. 8-26 04
11 18.01.17 The part name for X flexible cables were corrected. 6 -1, 11- 8 , 11-13 04
12 18.01.17 The Note is added for the linear bearing of RMS. 8-38 04
13 18.0 4.12 The part name for Pen Block Assembly was corrected. 6-1,11-10 05
14 18.0 4.12 The Pen Block Height Adjustment Plate was added. 11-16 05
15 18.05.22 Procedure was corrected to replace the Electrostatic Adhesion Panel. 8-63 to 8-67 06
16 18.05.22 The parts number for the Electrostatic Adhesion Panel was corrected. 11-12 06
17 18.05.30 The parts number for the Stopper,Pen was corrected. 11-10 06
18 18.09.20 Installation procedure of optional warning light was added. Section 2.7 07
19 18.09.20 The parts numbers are added for the warning light. 11-1,11-3,11-16 07
20 18.09.20 The Y bar right angle adjustment procedure was added. Section 8.10 08
21 19.04.26 Typing miss was corrected. 9-14,9-15 09
22 20.06.29 The parts number for the Nylon washer, NNS-0410-10 was added. 11-10,11-11 09
23 21.09.17 The part number for Adjuster, TM-73-2 was corrected. 11-10 10

FCX2000-UM-251-9370 ii
CONTENTS
1 INTRODUCTION.............................................................1-1
1.1 ModelNamesandBasicSpecications .........................................................1-1
1.2 StandardAccessories ......................................................................................1-1
1.3 MainSpecications ..........................................................................................1-3
1.4 ExternalDimensions ........................................................................................1-4
1.5 RegardingtheBlower(VacuumPump) ..........................................................1-6
2 SetupProcedure ...........................................................2-1
2.1 InstallationSpace .............................................................................................2-1
2.2 Unpacking .........................................................................................................2-2
2.2.1 Takeoutthestandpartsfromthebox................................................................................................... 2-2
2.3 Assemblingthestand ......................................................................................2-5
2.4 Installingthemainunitontothestand...........................................................2-6
2.4.1 Takeoutthemainunitfromthebox...................................................................................................... 2-6
2.4.2 Removingthepackingmaterialfromthemainunit ............................................................................. 2-8
2.5 ConrmingtheconditionsofXexiblecable................................................2-9
2.6 Installingtherollmediastocker....................................................................2-10
2.7 InstallingtheWarningLightOption ..............................................................2-11
2.7.1 InstallingtheWarningLightOptionOPH-A40 .................................................................................... 2-12
2.7.2 InstallingtheWarningLightOptionOPH-A41 .................................................................................... 2-14
2.7.3 InstallingtheWarningLightOptionOPH-A42 .................................................................................... 2-19
3 DescriptionofParts ......................................................3-1
3.1 PlotterNomenclature .......................................................................................3-1
3.2 CutterPlunger...................................................................................................3-3
4. BasicOperation.............................................................4-1
4.1 HowtoUsetheControlPanel .........................................................................4-1
4.2 MenuTree ..........................................................................................................4-5
4.3 ReplacingtheCutterBlade............................................................................4-12
4.4 AdjustingtheBladeLength ...........................................................................4-13
4.5 AttachingaTool..............................................................................................4-14
4.6 AdjustingtheToolCarriageHeight...............................................................4-15

FCX2000-UM-251-9370 iii
4.7 AbouttheInitialSetupScreen.......................................................................4-16
4.8 SelectingToolCondition................................................................................4-17
4.8.1 Selectingthetoolconditionnumber ................................................................................................... 4-17
4.8.2 SettingtheToolCondition .................................................................................................................... 4-19
4.9 RunningCuttingTests ...................................................................................4-23
4.9.1 CuttingTest............................................................................................................................................ 4-23
4.9.2 ConrmtheResultsoftheCuttingTest .............................................................................................. 4-25
5 DailyMaintenance.........................................................5-1
5.1 DailyMaintenance ............................................................................................5-1
5.2 StoringthePlotter ............................................................................................5-1
5.3 CleaningtheCutterPen ...................................................................................5-1
6 RECOMMENDEDPARTSLIST......................................6-1
7 LISTOFTOOLS .............................................................7-1
7.1 Tools ..................................................................................................................7-1
8 DISASSEMBLYANDASSEMBLY .................................8-1
8.1 OuterPart ..........................................................................................................8-1
8.1.1 RightFrontCornerCover ....................................................................................................................... 8-1
8.1.2 RightRearCornerCover ........................................................................................................................ 8-1
8.1.3 LeftFrontCornerCover.......................................................................................................................... 8-2
8.1.4 LeftRearCornerCover ........................................................................................................................... 8-2
8.1.5 RightTopCover....................................................................................................................................... 8-3
8.1.6 LeftTopCover.......................................................................................................................................... 8-3
8.1.7 RightSideCover...................................................................................................................................... 8-4
8.1.8 LeftSideCover ........................................................................................................................................ 8-5
8.1.9 HowtoOpentheFrontBottomCover ................................................................................................... 8-5
8.1.10 FrontTopCover....................................................................................................................................... 8-6
8.1.11 RearTopCover ........................................................................................................................................ 8-7
8.1.12 RearBottomCover.................................................................................................................................. 8-8
8.1.13 YBarCover ............................................................................................................................................ 8-10
8.1.14 PenBlockCover .....................................................................................................................................8-11
8.1.15 FrontYBarEndCover .......................................................................................................................... 8-12
8.1.16 RearYBarEndCover ........................................................................................................................... 8-12
8.1.17 HowtoopentheControlBox ............................................................................................................... 8-13
8.2 X-AxisDrivePart.............................................................................................8-14
8.2.1 XMotor ................................................................................................................................................... 8-14
8.2.2 XMotorBelt ........................................................................................................................................... 8-16

FCX2000-UM-251-9370 iv
8.2.3 FrontXBelt ............................................................................................................................................ 8-18
8.2.4 RearXBelt ............................................................................................................................................. 8-21
8.2.5 XHomeSensorBoard........................................................................................................................... 8-24
8.2.6 XFlexibleCable ..................................................................................................................................... 8-25
8.3 Y-AxisDrivePart.............................................................................................8-29
8.3.1 YMotor ................................................................................................................................................... 8-29
8.3.2 YMotorBelt............................................................................................................................................ 8-31
8.3.3 YHomeSensorBoard........................................................................................................................... 8-33
8.3.4 YRelayBoard ........................................................................................................................................ 8-34
8.3.5 PenBoard............................................................................................................................................... 8-35
8.3.6 PenBlock ............................................................................................................................................... 8-36
8.3.7 RegistrationSensorBoards ................................................................................................................. 8-38
8.3.8 YFlexibleCable ..................................................................................................................................... 8-39
8.3.9 YBelt....................................................................................................................................................... 8-41
8.4 Belttension&GearAdjustment....................................................................8-43
8.4.1 AdjustingtheXMotorBeltTension..................................................................................................... 8-43
8.4.2 AdjustingtheYMotorBeltTension ..................................................................................................... 8-44
8.4.3 AdjustingtheFrontXBeltTension...................................................................................................... 8-45
8.4.4 AdjustingtheRearXBeltTension....................................................................................................... 8-47
8.4.5 AdjustingtheYBeltTension ................................................................................................................ 8-49
8.4.6 AdjustingthePlayofXMotorDriveGear ........................................................................................... 8-51
8.4.7 AdjustingthePlayofYMotorDriveGear ........................................................................................... 8-53
8.5 ControlBox .....................................................................................................8-54
8.5.1 MainBoard ............................................................................................................................................. 8-54
8.5.2 PowerSupplyBoard ............................................................................................................................. 8-55
8.5.3 Fan .......................................................................................................................................................... 8-56
8.6 ControlPanel ..................................................................................................8-57
8.6.1 ControlPanelBoard.............................................................................................................................. 8-57
8.6.2 LCD ......................................................................................................................................................... 8-60
8.6.3 ControlPanelkeys ................................................................................................................................ 8-60
8.7 ElectrostaticAdhesionPart(FCX2000-120ESonly) ....................................8-61
8.7.1 HighVoltageBoard................................................................................................................................ 8-61
8.7.2 Electrostaticrelayboard....................................................................................................................... 8-62
8.8 ReplacingtheWritingPanel ..........................................................................8-63
8.8.1 ReplacingtheElectrostaticAdhesionPanel(FCX2000-120ES) ........................................................ 8-63
8.8.2 ReplacingtheVCPanel ........................................................................................................................ 8-68
8.9 AdjustingtheYBarHeight ............................................................................8-69
8.10 AdjustingtheYBarRightAnglePrecision ..................................................8-71

FCX2000-UM-251-9370 v
9 ELECTRICALADJUSTMENTS......................................9-1
9.1 ListofItemsRequiringReadjustment ............................................................9-1
9.2 FlowchartoftheAdjustmentSequence .........................................................9-2
9.2.1 Themainboardwasreplaced(Normalprocedure).............................................................................. 9-2
9.2.2 Themainboardwasreplaced (IftheadjustmentvaluescouldnotcopyfromtheSUB-NVRAM.) ......................9-3
9.2.3 Thepenblockwasreplaced................................................................................................................... 9-4
9.2.4 TheXhomesensorwasreplaced.......................................................................................................... 9-4
9.2.5 TheYhomesensorwasreplaced .......................................................................................................... 9-4
9.2.6 Theregistrationmarksensorwasreplaced ......................................................................................... 9-4
9.2.7 TheXorYmotorwasreplaced .............................................................................................................. 9-5
9.2.8 TheXorYbeltwasreplaced .................................................................................................................. 9-5
9.3 LocationoftheBoards.....................................................................................9-6
9.4 ExplanationoftheValuesoftheMainBoard.................................................9-7
9.5 SettingtheDIPSwitches..................................................................................9-8
9.6 UpdatingtheSystemFirmware .......................................................................9-9
9.7 ClearingtheNV-RAM......................................................................................9-11
9.8 SelectingDisplayLanguage&LengthUnit .................................................9-13
9.9 CopyingtheAdjustmentvalueformtheSUB-NVRAM................................9-14
9.10 AdjustingtheHomePosition.........................................................................9-16
9.11 AdjustingthePenForce ................................................................................9-19
9.12 AdjustingtheDistanceandthePerpendicularityAccuracy.......................9-23
9.13 AdjustingtheToolInterval.............................................................................9-28
9.14 AdjustingtheRegistrationMarkSensorSensitivity ...................................9-32
9.15 AdjustingtheOffsetofRegistrationMarkSensor ......................................9-34
9.16 BackuptotheSUB-NVRAM ..........................................................................9-38
9.17 TestingtheControlPanelKeysandHomeSensors ...................................9-40
9.18 AboutStartUpMode ......................................................................................9-41
10 TROUBLESHOOTING..................................................10-1
10.1 Thepowerisnotturnedon............................................................................10-1
10.2 Whenitdoesnotworkrightly .......................................................................10-2
10.3 TheCuttingResultisNotGood ....................................................................10-6
10.4 ErrorMessagesinGP-GLCommandMode .................................................10-8
10.5 ErrorMessagesinHP-GLCommandMode .................................................10-9

FCX2000-UM-251-9370 vi
10.6 ARMSErrorMessages .................................................................................10-11
10.7 Hardwareerrors ............................................................................................10-15
10.8 OperationalError ..........................................................................................10-19
10.9 CautionMessage ..........................................................................................10-20
10.10 SelfDiagnosticTest......................................................................................10-21
11. PARTSLISTS ...............................................................11-1
11.1 MainOuter .......................................................................................................11-1
11.2 MainFrame......................................................................................................11-3
11.3 ControlBox .....................................................................................................11-5
11.4 ControlPanel ..................................................................................................11-6
11.5 YBarOuter......................................................................................................11-7
11.6 YBarPart ........................................................................................................11-8
11.7 PenBlock ......................................................................................................11-10
11.8 WritingPanel.................................................................................................11-12
11.9 WiringHarness .............................................................................................11-13
11.10 Stand..............................................................................................................11-14
11.11 MediaHanger ................................................................................................11-15
11.12 WarningLightOption ...................................................................................11-16
11.13 StandardAccessories ..................................................................................11-17
12 BLOCKDIAGRAMSANDCIRCUITDIAGRAMS ........12-1
12.1 BlockDiagram.................................................................................................12-1
12.2 MainBoard(PN4031-01)................................................................................12-2
12.3 ControlPanelBoard(PN4031-02) ...............................................................12-15
12.4 YRelayBoard(PN4031-03)..........................................................................12-16
12.5 PenRelayBoard(PN4031-04)......................................................................12-17
12.6 HomeSensorBoard(PN4031-05)................................................................12-18
12.7 XRegistrationSensorBoard(PN4031-07) .................................................12-18
12.8 YRegistrationSensorBoard(PN4031-08) .................................................12-18
12.9 USBRelayBoard(PN4031-09).....................................................................12-19
12.10 HighVoltageBoard(PN4031-10) .................................................................12-19
12.11 HighVoltageRelayBoard(PN4031-15) ......................................................12-20

FCX2000-UM-251-9370 vii
13 TargetelectricalcomponentforWEEEinstruction .13-1

FCX2000-UM-251-9370 1-1
1 INTRODUCTION
1 INTRODUCTION
1.1 Model Names and Basic Specications
Model Media hold down method Cutting area Loadable media width
FCX2000-60VC Vacuum suction 610 (X) x 920 (Y) mm
950 mm
FCX2000-120ES Electrostatic adhesion 1200 (X) x 920 (Y) mm
FCX2000-120VC Vacuum suction
FCX2000-180VC Vacuum suction 1800 (X) x 920 (Y) mm
1.2 Standard Accessories
Item Q’ty Item Q’ty
Power cable 1 pc. USB cable 1 pc.
DVD
• Various software
• User’s Manual (pdf)
1 pc. TO ENSURE SAFE AND CORRECT
USE SETUP MANUAL
Cutter Blade Manual
1 set
Cutter plunger (PHP35-CB15-HS) 1 pc. Cutter blades: CB15U-2, CB15U-K30-5 1 of each
Water-based ber pen adapter (PHP31-
FIBER)
1 set Water-based ber pen (KF700-BK [1P]) 1 pc.
Cutter blade adjustment magnier (PM-
CT-001)
1 pc. Height adjustment plates, Hexagon
driver
1 set
Media stocker 1 set Stand 1 set
Blower hose (For VC models only)
Connection bore diameter: Ø50.8mm
(2 inch)
1 pc. Hose band(For VC models only) 1 set

FCX2000-UM-251-9370 1-2
1 INTRODUCTION
Item Q’ty Item Q’ty
Blower mounting stand
(For VC models only)
1 pc.
Note:
• The vacuum pump is not supplied by the VC models. Prepare the vacuum pump locally.
• Usually the hose adapter between the vacuum pump and the hose will not be including to the vacuum
pump. Prepare the vacuum pump hose adapter locally. The connection bore diameter is Ø50.8 mm (2
inches).

FCX2000-UM-251-9370 1-3
1 INTRODUCTION
1.3 Main Specications
FCX2000-60VC FCX2000-120VC/ES FC2000-180VC
Conguration Flatbed
Drive system Digital servo
Media hold-down method VC models: Vacuum suction
ES models: Electrostatic adhesion
Effective cutting area 610 x 920 mm 1200 x 920 mm 1800 x 920 mm
Mountable media (Y-axis) 950 mm
Maximum cutting speed 400 mm/sec (Omnidirection)
Max. acceleration 5.88 m/s2 (Omnidirection)
Speciable speeds 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 25, 30, 35, 40 cm/s 16 steps
Max. force TOOL 1: Max. 4.9N (500gf) TOOL 2: Max. 9.8N (1Kgf)
Settable force TOOL 1: Set 40 steps TOOL 2: Set 40 steps
Min. character size About 10mm2 alphanumeric characters (depending on the materials and font)
Mechanical resolution 0.0025 mm
Programmable resolution GP-GL mode: 0.1/0.05/0.025/0.01 mm, HP-GLTM mode: 0.025 mm
Distance accuracy Distance moved within ±0.1% or less or within ±0.1 mm or less, whichever is larger (Plotter mode)
Perpendicularity 0.5mm/900 mm or less (Plotter mode)
Repeatability 0.1 mm or less: Expansion and contraction of the media are excluded (plotter/cutting mode)
Interfaces USB2.0 (full speed) , RS-232C, Ethernet 10BASE-T / 100BASE-TX
Buffer memory 2 MB
Command sets GP-GL and HP-GLTM emulation
Number of cutters/pens 2
Tool type VC models: Cutter Plunger, Water based ber-tip pen, Oil-based ballpoint pen, Creasing tool
ES models: Cutter Plunger, Water based ber-tip pen, Oil-based ballpoint pen, Creasing tool
MG models: Cutter Plunger, Water based ber-tip pen, Oil-based ballpoint pen
Compatible media VC models
• Marking film (PVC/fluorescence/reflection)
• Thickness less than 1 mm paper *2
• Thickness less than 0.8 mm compressed
foam sheet *4
• Thickness less than 1 mm sandblasting
rubber
• F, G flute *2
• Clear package sheet
• High-intensity reflective film *3
ES models
• Marking film (PVC/fluorescence/reflection)
• Thickness less than 1 mm paper *2
• Thickness less than 1 mm sandblasting
rubber
• F, G flute *2
• Clear package sheet *5
Ofine output function USB memory - 64 files
Bar code data management function
Yes
LCD display Graphic type (240 × 128 dot)
Usable roll paper Roll paper hanger
Usable roll paper width: 950 mm, weight: 5 kg
Power supply 100 to 240V AC 50/60Hz
Operating environment 10 to 35˚C, 35 to 75% RH (non-condensing)
Guaranteed precision operating
environment
16 to +32˚C, 35% to 70% RH (non-condensing)
External dimensions
(H x W x D)
1344 mm × 1409 mm × 930 mm
(Including media stocker)
193 4mm × 1409 mm × 93 0mm
(Includeding media stocker)
2534 mm × 1409 mm × 930 mm
(Includeding media stocker)
Weight (including stand) Approx. 76 kg VC model : Approx. 99kg
ES model : Approx. 95kg
Approx. 116 kg
*1 : HP-GL is a registered trademark of the US Hewlett Packard Company.
*2 : Use CB30UC-1 without warpage
*3 : Use cutter blade CB15UA
*4 : Use Cutter blade CB15U-K30
*5 : Cut material that can be fixed by electrostatic adhesion

FCX2000-UM-251-9370 1-4
1 INTRODUCTION
1.4 External Dimensions
FCX2000-60
1344
1409
930
Unit : mm
Dimensional accuracy : ± 5mm
FCX2000-120
1934
1409
930
Unit : mm
Dimensional accuracy : ± 5mm

FCX2000-UM-251-9370 1-5
1 INTRODUCTION
FCX2000-180
2534
1409
930
Unit : mm
Dimensional accuracy : ± 5mm

FCX2000-UM-251-9370 1-6
1 INTRODUCTION
1.5 Regarding the Blower (Vacuum Pump)
The blower is not supplied by the VC models, therefore prepare the blower from local distributer of blower.
Select the blower according to the guidelines listed in the table below.
Item FCX2000-60VC FCX2000-120VC FCX2000-180VC
Ratings Airow (m3/min) 0.3 0.5 0.5
Static pressure (kPa) 5.4 6.4 6.4
Hose connection bore 50.8 mm (2 inches)
Usually the connecting adapter which is between the hose and the blower is not including to the blower.
Prepare the connecting adapter from local distributer of blower.
The following picture is showing the connection of the blower and the FCX2000.
Hose band
Hose band
Durable flexible hose
Blower mounting stand
Blower
Connect to the
power outlet
Hose adapter
Prepare the blower and the hose adapter locally.

FCX2000-UM-251-9370 2-1
2 Setup procedure
2 Setup Procedure
2.1 Installation Space
Please secure a space for installation as according to the below illustration.
Leave sufcient space for operations in front of and behind the plotter.
100 mm
500 mm
600 mm
600 mm

FCX2000-UM-251-9370 2-2
2 Setup procedure
2.2 Unpacking
The FCX2000 is packed as like as the picture below.
(The packing is different that depends on the shipping destination. But the outline of unpacking will be
same.)
2.2.1 Take out the stand parts from the box
(1) Remove the rapping which is covering the stand box and the main unit box.
(2) Take out the stand box from the top part of box.
Stand box

FCX2000-UM-251-9370 2-3
2 Setup procedure
(3) Take out the side stays from the stand box.
(4) There is a plastic bag for the screws and the wrench on the bottom of the stand box.
Don’t forget to take from the stand box.
There are the twelve M5L20 socket screws and the one wrench in a plastic bag.
The eight M5L20 socket screws are used to assemble the stand and the four M5L20 socket screws are
used to x the main unit on the stand.

FCX2000-UM-251-9370 2-4
2 Setup procedure
(5) The center bars of stand are packing into the main unit box.
(6) Open the main unit box.
There are center bars
in this box.
(7) Take out the two center bars from the main unit box.

FCX2000-UM-251-9370 2-5
2 Setup procedure
2.3 Assembling the stand
Procedure
(1) Install the two center-bars onto the right side stay and the left side stay by using the eight M5L20 socket
screws as shown in the picture below.
2
1
3
(2) Don’t tighten the screws securely until the main unit was put onto the stand.
