FCX4000-UM-251-9370 1-2
1 INTRODUCTION
1.3 Main Specications
FCX4000-50ES FCX4000-60ES
Conguration Flatbed
Drive system Digital servo
Media hold-down method Electrostatic adhesion
Effective cutting area 660 x 488 mm 976 x 660 mm
Mountable media (Y-axis) 536 mm 708 mm
Maximum cutting speed 75 cm/sec (Omnidirection)
Max. acceleration 9.8 m/s2(Omnidirection)
Speciable speeds
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65, 70, 75cm/s 23 steps
Max. force Max. 5.88N (600gf)
Settable force 48 steps
Min. character size About 10 mm2alphanumeric characters (depending on the materials and font)
Mechanical resolution 0.005 mm
Programmable resolution GP-GL mode: 0.1/0.05/0.025/0.01 mm, HP-GLTM mode: 0.025 mm
Distance accuracy
Distance moved within ±0.2% or less or within ±0.1 mm or less, whichever is larger (Plotter mode)
Perpendicularity 0.3 mm/430 mm or less (Plotter mode) 0.4 mm/610 mm or less (Plotter mode)
Repeatability
0.1 mm or less: Expansion and contraction of the media are excluded (plotter/cutting mode)
Interfaces USB2.0 (full speed) , RS-232C, Ethernet 10BASE-T / 100BASE-TX
Buffer memory 2 MB
Command sets GP-GL and HP-GLTM emulation
Number of cutters/pens 2
Tool type
Cutter Plunger, Water based ber-tip pen, Oil-based ballpoint pen, Creasing tool
Compatible media
• Marking film (PVC/fluorescence/reflection)
• Thickness less than 0.5 mm paper *2
• Thickness less than 0.8 mm compressed foam sheet *3
• Thickness less than 1 mm sandblasting rubber *3
• F, G flute
• Clear package sheet
• High-intensity reflective film *4
Ofine output function USB memory - 64 files
Bar code data management function
Yes
LCD display Graphic type (240 × 128 dot)
Power supply 100 to 240V AC 50/60Hz
Operating environment 10 to 35˚C, 35 to 75% RH (non-condensing)
Guaranteed precision operating
environment
16 to +32˚C, 35% to 70% RH (non-condensing)
External dimensions
(W x D x H)
1089 mm × 897 mm × 204 mm
(Including media stocker)
1405 mm × 1069 mm × 204 mm
1405 mm × 1069 mm × 895 mm (with optional stand)
Weight (Approx.) 29 kg 37 kg
53 kg
(with optional stand)
*1 : HP-GL is a registered trademark of the US Hewlett Packard Company.
*2 : Please use cutter blade CB15U or CB15U-K30.
*3 : Use cutter blade CB15U-K30.
*4 : Use Cutter blade CB15UA.
*5 : It depends on our specified paper and conditions.
*6 : The accuracy read with the pattern prepared for this plotter, using the attached pen and coated (glossy) paper.
