GRAUPNER MZ-10 HOTT User manual

mz-10
Manual
mz-10 HoTT
No. S1001
Manual
EN

2 / 40 S1001_jp_V1

3 / 40
S1001_jp_V1
Index
Introduction......................................................................... 5
Service Centre .................................................................... 5
Intended use ....................................................................... 6
Target group..................................................................... 6
Package content ................................................................ 6
Technical Data .................................................................... 7
Symbols explication ........................................................... 8
Safety notes ........................................................................ 8
For your safety by handling the transmitter ....................... 9
For your safety by handling the batteries........................... 9
Description of the transmitter......................................... 10
Control elements on the transmitter................................ 10
Connections and fixtures ................................................ 12
Attaching the transmitter neck-strap........................ 12
Socket "DATA / S + -".............................................. 12
Digital trim ...................................................................... 12
Commissioning................................................................. 13
Opening/closing the transmitter housing.................. 13
Control sticks length adjustment.............................. 14
Neutralizing the control sticks .................................. 14
Brake spring and ratchet ......................................... 15
Control sticks centering force .................................. 15
Aligning the transmitter antenna............................... 15
Transmitter power supply ............................................... 16
Installing the batteries .............................................. 16
Optional power supply with battery pack ................. 17
Transmitter commissioning............................................. 18
Transmitter status indications ......................................... 18
LED panel and keys........................................................ 19
Use mode selection........................................................ 19
Binding........................................................................... 21
Binding the mz-10 transmitter.................................. 21
Binding several receivers per model......................... 21
Range warning ........................................................ 22

4 / 40 S1001_jp_V1
Range and function test ................................................. 22
Operation and settings .................................................... 24
Supported model types .................................................. 24
Receiver configuration .................................................... 25
Transmitter programming................................................ 27
Country setting ........................................................ 27
Control mode .......................................................... 28
Servo direction and model type ............................... 29
Fail Safe................................................................... 31
Teacher/Student (T/S).............................................. 34
T/S mode ................................................................ 36
Firmware update .............................................................. 37
Transmitter software update ........................................... 37
Declaration of conformity................................................ 38
Notes on environmental protection ................................ 39
Care and maintenance..................................................... 39
Warranty certificate.......................................................... 39

5 / 40
S1001_jp_V1
Introduction
Thank you very much for purchasing the Graupner mz-10 HoTT
transmitter.
Read this manual carefully to achieve the best results with your
transmitter and first of all to safely control your models. If you
experience any trouble during operation, take the instructions to
help or ask your dealer or Graupner Service Centre.
Due to technical changes, the information may be changed in
this manual without prior notice. Be always updated by check-
ing periodically on our website, www.graupner.de to be always
uptodate with the products and firmwares.
This product complies with national and European legal require-
ments.
To maintain this condition and to ensure safe operation, you must
read and follow this user manual and all the safety notes before using
the product!
Note
This manual is part of that product. It contains important information
concerning operation and handling. Keep these instructions for future
reference and give it to third person in case you gave the product.
Service Centre
Graupner Central Service
Graupner/SJ GmbH
Henriettenstraße 96
D-73230 Kirchheim / Teck
Servicehotline
(+49) (0)7021/722-130
Monday - Thursday
9:15 am - 5:00 pm
Friday
9:15 am - 1:00 pm
Graupner USA
OPENHHBBY LLC
3245 University Ave
Suite 1520
San Diego, CA 92104
Website: www.graupnerusa.com

Phone: [phone]
Email:[email protected]
Graupner in Internet For the service centers outside Germany please refer to our web
site www.graupner.de


6 / 40 S1001_jp_V1
Intended use
This remote-control system may only be used for the purpose
specified by the manufacturer for operation of remote control
models without passengers. Any other type of use is impermis-
sible and may damage the system and cause significant prop-
erty damage and/or personal injury. No warranty or liability is
therefore offered for any improper use not covered by these pro-
visions.
Read through this entire manual before you attempt to install or
use the transmitter.
Graupner/SJ constantly works on the development of all prod-
ucts; we reserve the right to change the item, its technology and
equipment.
Target group
The product is not a toy. It is not suitable for children under 14
years. The operation of the mz-10 HoTT transmitter must be per-
formed by experienced modelers. If you do not have sufficient
knowledge about dealing with radio-controlled models, please
contact an experienced modeler or a model club.
Package content
Transmitter mz-10 HoTT
4 batteries AA type (not rechargeable)
Battery box
Programming connector
Receiver (optional)
Transmitter manual (Part 1)
Receiver manual (optional)

7 / 40
S1001_jp_V1
Technical Data
Transmitter mz-10 HoTT
Frequency band 2,4 … 2,4835 GHz
Modulation FHSS
Controller 16-Bit-Microcontroller
Resolution 1024
Transmitting power 100 mW
Model memory 1
Control functions 5 functions of which 4 can be
trimmed
Teacher/Pupil function Wireless
Temperature range -10 … +55 °C
Antenna folding and rotating
Operating voltage 3,4 … 6 V
Power consumption approx. 130 mA
Charging socket only for rechargeable batteries
(available separately)
Dimensions approx. 184 x 259 x 96 mm
Weight approx. 630 g
Note
The technical data of the optional receiver are available in the
manual included in the receiver package content.

8 / 40 S1001_jp_V1
Symbols explication
!
Always observe the information indicated by this warning sign.
Particularly those which are additionally marked with the CAU-
TION or WARNING. The signal word WARNING indicates the poten-
tial for serious injury, the signal word CAUTION indicates possibil-
ity of lighter injuries.
The signal word Note indicates potential malfunctions.
Attention indicates potential damages to objects.
Safety notes
!
These safety instructions are intended not only to protect the
product, but also for your own and other people’s safety. There-
fore please read this section very carefully before using the prod-
uct!
Do not carelessly leave the packaging material lying around,
since it might become a dangerous toy for children.
Persons, including children, with reduced physical, sensory
or mental capabilities, or lack of experience or knowledge,
or not capable to use safely the transmitter must not use the
transmitter without supervision or instruction by a responsi-
ble person.
Operation and use of radio-controlled models needs to be
learned! If you have never operated a model of this type
before, start carefully and make yourself familiar with the
model's reactions to the remote control commands. Pro-
ceed always responsibly.
Before you start using the remote control model, you have
to check the further relevant laws and regulations. These
laws you must obey in every case. Pay attention to the pos-
sibly different laws of the countries.
The insurance is mandatory for all kinds of model operation.
If you already have one, so please inform yourself if the oper-
ation of the respective model is covered by your insurance.
If this is not the case, conclude a special liability insurance
policy for models.
Inform yourself before flying
your model on which maximum
altitude you can fly in the
uncontrolled airspace over the
starting position and do not
exceed it.

9 / 40
S1001_jp_V1
Protect all equipment from dust, dirt, moisture. All equip-
ment must be protected from vibration as well as excessive
heat or cold. The models may only be operated remotely in
normal outside temperatures such as from -10°C to +55°C.
For your safety by handling the transmitter
!
WARNING
Also while programming the transmitter, make sure that a con-
nected motor cannot accidentally start. Disconnect the fuel sup-
ply or drive battery beforehand.
!
CAUTION
Risk of fire! Avoid every kind of short-circuit in all sockets of the
transmitter! Use only the suitable connectors. In no case the
electronic component of the transmitter may be changed or
modified. Due to licensing reasons, any reconstruction and/or
modification of the product is prohibited.
Note
During transport protect the model and the transmitter from
damages.
For your safety by handling the batteries
!
CAUTION
Protect the batteries from dust, moisture, heath and vibra-
tions. Only use in dry locations.
Do not use any damaged battery.
Batteries may not be heated, burned, short-circuited.
If handled improperly, there is a danger of fire, explosion, irri-
tation and burns.
Leaked electrolyte is caustic and should not be touched or
come into contact with your eyes. In case of emergency,
rinse with a large quantity of water and consult a Med. Doc-
tor.
Do not try to recharge the batteries included in the package!
Those are non-rechargeable batteries.
Stock the batteries in dry and fresh conditions.
Dispose of the battery in the proper disposal centers.

10 / 40 S1001_jp_V1
Description of the transmitter
Control elements on the transmitter
1 Antenna with folding and swivel joint
2 Eyelet for neck strap
3 Dual rate switch
(70 % / 100 % servo travel of the control functions 2, 3 and 4)
4 TRAINER switch (see use mode)
5 Right control stick
6 ARROW buttons
7 Trim
8 On/off switch
9 LED indicators field
10 MODE buttons
11 Left control stick
12 Control channel 5
13 Carrying handle
14 Central status LED
mz-10
75
1
2
34
6
8
97
10
11
12
13 14

11 / 40
S1001_jp_V1
1 Case screws
2 Battery case cover
3 Data socket to connect:
- programming connector
- optional SMART BOX
- Bluetooth module
- Interface adapter to update the transmitter
4 Charge port (to charge an optional battery pack, NOT for non-re-
chargeable batteries)
mz-10
11 111
1
1 2 3 41

12 / 40 S1001_jp_V1
Connections and fixtures
Attaching the transmitter neck-strap
On the upper side of the transmitter there is an eyelet which can
be used to hook a neck-strap.
Socket "DATA / S + -"
For the socket "DATA / S + -“ there are 3 possible connection
options:
1. Optional available SMART BOX
Allows the use of other HoTT functions
2. Optional available USB adapter
Allows the connection between transmitter and PC for a firm-
ware update
3. Optional available Bluetooth module for the transmission of
telemetry data to a compatible smartphone
Note for the polarity of the socket "DATA / S + -“:
S = signal line (orange)
+ = Plus line (red)
- = Minus line (brown or black)
You can find more information about the listed accessories on
www.graupner.de.
Digital trim
Digital trim with an acoustic feedback
The two control sticks have digital trimming.
Briefly touch the trimming switch to move the neutral position of
the control stick by a specific value with each click. If it is held,
the trimming moves in the corresponding direction with increas-
ing speed.
The adjustment is made audible by tones of varying levels. It is
therefore easy to find the middle position during flight. If you go
past the middle position, a brief pause is inserted.
The current trimming values are saved.
The digital trim reacts to a trim lever movement only if the trans-
mitter is switched on.

13 / 40
S1001_jp_V1
Commissioning
1 Adjust screws for brake spring and ratchet
2 Neutralization lever
3 Screw to convert from neutralizing to non neutralizing
4 Stick self centering force adjust screws
5 Brake spring and ratchet
Opening/closing the transmitter housing
The transmitter should be opened only in the following cases:
If a self centering stick has to be converted in non self cen-
tering
If a non self centering stick has to be converted in self cen-
tering
To set the control stick centering force
!
CAUTION
Never switch the transmitter on while the housing is open!
1
1
2
3
3
4
4
5

14 / 40 S1001_jp_V1
Open step by step:
Before opening the housing switch the transmitter off.
Open the battery case.
Remove the battery box lifting it from one side and gently release
it from the velcro tape.
Unplug the connector.
Unscrew the eight screws with a cross screwdriver.
Hold both housing halves with both hands and let the screws
fall on a proper surface turning the transmitter upside-down.
Rotate the lower half carefully and fold it to the bottom.
Note
Cables connect the lower half of the housing with the upper part
electronic components. This connection must not be damaged! Do
not touch the electronic boards.
Closing step by step:
Check if the upper and the lower part of the transmitter housing
are correctly coupled and the tiny cables are properly placed.
Screw the housing screws in their shrouds.
Reconnect the battery box.
Control sticks length adjustment
Length of both control stick can be adjusted. Hold down the
bottom half of the knurled grip, and loosen the screwed connec-
tion by turning the top part:
You can now lengthen or shorten the control stick by screwing
it up or down. Then clamp the top and bottom part of the grip
by rotating them against each other.
Neutralizing the control sticks
Neutralizing step by step:
Locate in the left control stick gimbal the screw surrounded by
a white circle in the picture.
Turn the screw toward the inside of the transmitter until the rel-
evant control stick can move freely from stop to stop, or turn it
outward until the control stick resets itself independently.

15 / 40
S1001_jp_V1
Note
The right control stick gimbal is specular to the left one, so that here
the screw is located left under the middle.
Brake spring and ratchet
The outboard screw of the two marked in the figure adjust the
braking force.
The inboard screw adjusts the strength of the ratchet for the
respective control stick.
Note
The right control stick gimbal is specular to the left one, so that here
the screws are located right on the top side.
Control sticks centering force
The control sticks' restoring force can also be adjusted. The
adjustment is located next to the return springs.
By turning the respective adjust screw the spring force can be
adjusted.
Right turn = return harder
Left turn = return softer
Note
The right control stick gimbal is specular to the left one, so that here
the screws are located left in the middle.
Aligning the transmitter antenna
The antenna can be turned up to 90°. The antenna top should
never be oriented directly in the direction of the model, because
in the front of the antenna is emitted only a labile signal.
The bent antenna can also be turned around its axis up to 180°.
Turn the bent antenna using two fingers on the junction, not on
the top of the antenna.

16 / 40 S1001_jp_V1
Transmitter power supply
The mz-10 HoTT transmitter normally includes normally 4 non-re-
chargeable batteries.
Installing the batteries
!
WARNING
Alkaline batteries (dry batteries) should not be recharged. Acute risk
of explosion!
Note
Pay attention when inserting the batteries to the correct position
and make sure the contacts are solid.
Interruptions of the power supply to the transmitter during the use of
the models can lead to big danger for your self and for other people!
Replacing the batteries step by step:
Locate the battery case in the back of the transmitter.
Slide the battery case cover.
Remove the cover.
The battery box is fixed in the battery case through velcro tape.
Lift the lower side of the battery box carefully.
Loosen the connection between the battery box and the trans-
mitter by carefully pulling the battery plug.
Remove the used batteries from the battery box.
Replace the batteries with full batteries of the AA type.
Reconnect the plug to the socket in the inside of the battery
case. (Plus pole = red cable, minus pole = brown or black cable).
Place the battery box in the battery case.
Close the battery case with the cover.
If you have inadvertently connected the plug in wrong position, the
transmitter will not switch on.

17 / 40
S1001_jp_V1
Optional power supply with battery pack
Instead of batteries you can use rechargeable NiMH batteries.
For the recharge you can use the charging port located on the
back of the transmitter.
!
WARNING
Follow the safety instructions included with the batteries!
Polarity of the mz-10 HoTT charging socket
The charging cables available on the market by other manufac-
turers frequently have different polarities. For this reason, you
should only use original Graupner charging cable.
Note
The charging socket comes standard with a protection switch that
protects against polarity reversal. Original Graupner automatic char-
gers recognize the battery charge. In order to prevent damage to the
protection switch and to the other components, charging current
should never exceed 1 A.

18 / 40 S1001_jp_V1
Transmitter commissioning
Transmitter status indications
The transmitter is normally delivered in "NORMAL" use mode
and "GENERAL" land setting. For the "normal" use you do not
need to change anything.
After switching the transmitter on the central status LED in the
top blinks red and an acoustic signal is emitted, to indicate the
last programming status, see following chart.
Graupner LED (red) Buzzer Description
Solid on
(factory setting)
short power on melody Transmitter switched on
Solid on No melody Country setting: GENERAL
blinks each second No melody Country setting: FRANCE
on or blinks 1 beep each second Receiver battery voltage too low
blinks each 2 seconds 2 beeps after power on Transmitter in Pupil mode
blinks 2 times each 2
seconds
2 times 2 short beeps after
power on
Transmitter in teacher mode
blinks 3 times 3 short beeps consecutively bad signal power from receiver
blinks 4 times 4 short beeps consecutively bad receiver back channel signal power (yellow
BIND LED lights)
blinks 5 times 5 short beeps consecutively Transmitter battery or battery voltage too low
After switching on the transmitter the LEDs on the LED panel
blink or light for approx. 5 seconds to indicate the actual correct
settings.

19 / 40
S1001_jp_V1
LED panel and keys
12345
1MODE buttons
allows the binding between transmitter and receiver so as selection
and to confirm different settings as control mode, fail safe, servo
reverse, tail, etc...
2Servo reverse channel (CH) 1 - 5
red LED blinking = normal direction
red LED solid on = reverse
3BIND LED
indicates if transmitter and receiver are bound
(lights only by active receiver's back channel)
42AILE, DELTA or V-Tail
2AILE- and DELTA-LED blink = no mixer active
2AILE LED solid on, DELTA LED blinks = Aileron mixer active (2AILE)
2AILE LED blinks, DELTA LED solid on = Delta mixer active
2AILE- and DELTA LED solid on = V-Tail mixer active (V-TAIL)
5Arrow buttons
Changes in the programming mode and pages between different
settings in rotation at each push
Use mode selection
mz-10
Mode Normal
Mode Teacher
Mode Pupil
To change the use mode, move the "TRAINER" switch in the
desired position with the transmitter in switched off, push and
hold the MODE button and switch subsequently the transmitter
on.
The last selected model settings, control mode so as an
eventually set receiver binding remain unchanged. The bind-
ing of a receiver is however possible only in "NORMAL"
mode.
The use of a model in teacher or pupil mode is only possible
in connection with the Trainer system.

20 / 40 S1001_jp_V1
After every activation of the "NORMAL" use mode:
- The transmitter will be in program mode "Fail safe".
- The buzzer beeps each 2 seconds and contemporary
the status LED blinks.
- The country setting, even if changed to "FRANCE", will
be set to "GENERAL" so as the position of the digital trim
will be set to "neutral".
- The warning threshold for transmitter battery will be set
to 4,5 V, as long this has been changed through the
optional SMART BOX.
If the fail safe settings saved in the receiver have to be retained,
switch the transmitter off and after a short pause again on. Oth-
erwise proceed as described in "Fail safe".
The mz-10 transmitter remains after every conversion of the
control mode, completely independently from the occurred set-
ting of the TRAINER switch and even after switching on again
the transmitter, in the last selected use mode until this will be
changed.
