Gree GK-C03TC1AD User manual

ROOFTOP PACKAGED SERVICE MANUAL
T3/R22/50&60Hz
(GC201205-І)

PRODUCT .....................................................................................................2
1 MODELS LIST .............................................................................................. 2
2 NOMENCLATURE .................................................................................................... 3
3 FUNCTION ............................................................................................................... 3
4 PRODUCT DATA ...................................................................................................... 4
4.1 PRODUCT DATA AT RATED CONDITION ............................................................. 4
4.2 ELECTRICAL DATA.............................................................................................. 17
5 PIPING DIAGRAM .................................................................................................. 18
5.1 COOLING ONLY................................................................................................... 18
5.2 HEAT PUMP ........................................................................................................ 19
INSTALLATION............................................................................................21
1 UNITS INSTALL...................................................................................................... 21
1.1 INSTALLATION POSITIONS ............................................................................... 21
1.2 MATTERS NEED ATTENTION ............................................................................ 21
1.3 DIMENSION.......................................................................................................... 24
1.4 INSTALLATION CLEARANCE DATA................................................................... 28
2 DRAIN PIPING WORK ........................................................................................... 31
2.1 INSTALLATION PROCEDURE............................................................................. 31
2.2 MATTERS OF ATTENTION .................................................................................. 31
3 ELECTRIC WIRING WORK.................................................................................... 31
3.1 WIRING PRINCIPLE............................................................................................ 31
3.2 ELECTRIC WIRING DESIGN ............................................................................... 32
MAINTENANCE...........................................................................................37
1 BLE TABLE ............................................................................................................. 37
2 FLOW CHART OF TROUBLESHOOTING ........................................................... 38
3 WIRING DIAGRAM................................................................................................ 42
4 DISASSEMBLY AND ASSEMBLY PROCEDURE OF MAIN PARTS..................... 69
5 EXPLODED VIEWS AND PART LIST.................................................................... 84
CONTENTS

1
Rooftop Packaged
Service Manual
PRODUCT
PRODUCT

2
Rooftop Packaged
Service Manual
PRODUCT
PRODUCT
1 MODELS LIST
Nominal
Capacity
(Ton)
Model
Power Supply
(V, Ph, Hz) Appearance
Refrigerant Model Name Product Code
3 R22 GK-C03TC1AD EJ51000160 220V，1Ph, 60Hz
3 R22 GK-C03TC1AD EJ51000161 220V，1Ph，60Hz
3 R22 GK-C03TC1AK EJ51000200 220V，1Ph，50Hz
4 R22 GK-C04TC1AD EJ51000170 220V，1Ph，60Hz
4 R22 GK-C04TC1AF EJ51000470 220V，3Ph，60Hz
4 R22 GK-C04TC1AM EJ51000210 380~415V， 3Ph， 50Hz
5 R22 GK-C05TC1AF EJ51000190 220V，3Ph，60Hz
5 R22 GK-C05TC1AF EJ51000191 220V，3Ph，60Hz
5 R22 GK-C05TC1AM EJ51000220 380~415V， 3Ph， 50Hz
5 R22 GK-H05TC1AM EJ51000320 380~415V， 3Ph， 50Hz
8 R22 GK-C08TC1AF EJ51000151 220V，3Ph，60Hz
8 R22 GK-C08TC1AM EJ51000230 380~415V， 3Ph， 50Hz
8 R22 GK-H08TC1AM EJ51000311 380~415V， 3Ph， 50Hz
10 R22 GK-C10TC1AF EJ51000061 220V，3Ph，60Hz
10 R22 GK-C10TC1AM EJ51000240 380~415V， 3Ph， 50Hz
10 R22 GK-H10TC1AM EJ51000331 380~415V， 3Ph， 50Hz
13 R22 GK-C13TC1AF EJ51000300 220V，3Ph，60Hz
15 R22 GK-C15TC1AF EJ51000180 220V，3Ph，60Hz
15 R22 GK-C15TC1AF EJ51000181 220V，3Ph，60Hz
15 R22 GK-C15TC1AM EJ51000250 380~415V， 3Ph， 50Hz
15 R22 GK-H15TC1AM EJ51000340 380~415V， 3Ph， 50Hz
20 R22 GK-C20TC1AF EJ51000260 220V，3Ph，60Hz
20 R22 GK-C20TC1AM EJ51000280 380~415V， 3Ph， 50Hz
20 R22 GK-H20TC1AM EJ51000350 380~415V， 3Ph， 50Hz
25 R22 GK-C25TC1AF EJ51000270 220V，3Ph，60Hz
25 R22 GK-C25TC1AM EJ51000290 380~415V， 3Ph， 50Hz
30 R22 GK-C30TC1AM EJ51000450 380V，3Ph，50Hz
25 R22 GK-H25TH1AM EJ51000361 380~415V， 3Ph， 50Hz
30 R22 GK-H30TH1AM EJ51000370 380~415V， 3Ph， 50Hz
Note:
a. Above pictures may be different from actual model.
b. 1Ton =12000Btu/h = 3.517kW.

3
Rooftop Packaged
Service Manual
PRODUCT
2 NOMENCLATURE
GK －C 10 TC 1 AF
1 2 3 4 5 6 78
NO. Description Options
1 Product Category GK=GREE Rooftop Packaged Air-condition
2Product Function Code C = Cooling only type;
H = Heat pump type.
3Cooling/Heating Capacity
03=3Ton;
05=5Ton;
10=10Ton......
4Operating Condition T=T3 Condition;
N=T1 Condition.
5Airow Options H=Horizontal;
C=Convertible.
6Refrigerant Options
1=R22;
2=R407C;
3=R410a;
4=R134a.
7Design Code A,B,C......
8Voltage Options
D=220V,60Hz,1ph;
K=220V,50Hz ,1ph
F=220V,60Hz,3ph
M=380~415V,50Hz,3ph
3 FUNCTION
Function Description
OPERATING EFFICIENCY All units provide high operating efciencies and have a minimum EER of 8 or above.
ON SITE FLEXIBILITY
The series of model are divided into several sizes, which approximate tons share a common,
compact design cabinet with a single footprint. The installer has the exibility of setting one curb
and placing the proper tonnage unit on that curb after the standard load has been determined.
CONVERTIBLE
AIRFLOW DESIGN
The Bottom duct openings are covered when they leave the factory ready to be used for a
side supply / side return application. If a bottom supply / bottom return application is desired,
you simply remove the two panels from the bottom of the unit and place them in the side
supply / side return duct openings. No panel cutting is required and no accessory panel is
necessary. Convertible airow design allows maximum eld exibility and minimum inventory.
EXCLUSIVE COIL DESIGN Grooved copper tubes and enhanced aluminum n construction
improves heat transfer for maximum efciency and durability.
TOP DISCHARGE
The top discharge condenser fan does not disrupt neighboring areas and does not dry-out
vegetation surrounding the unit. The warm air from the top mounted fan is blown up away from
the structure and any landscaping. This allows compact location on multi-unit applications.
LOW OPERATING
SOUND LEVEL
The upward air ow carries the normal operating noise up and away from
the living area. The rigid and unique shock absorption structure greatly
reduces the vibration and effectively isolates motor sound.
SPACE SAVING With compact and unitary structure, the unit can be connected and assembled at
eld, which is in favor of transport and installation and saves indoor space.

4
Rooftop Packaged
Service Manual
PRODUCT
4 PRODUCT DATA
4.1 PRODUCT DATA AT RATED CONDITION
Nominal Capacity (Ton) 3 3 4
Model Name GK-C03TC1AD GK-C03TC1AD GK-C04TC1AD
Product Code EJ51000160 EJ51000161 EJ51000170
Performance
Net Cooling
Capacity
Btu/h 35830 35830 47770
W 10500 10500 14000
Air Circulation CFM(m3/h) 959(1630) 1176(2000) 1029(1750)
Rated ESP In.wg (Pa) 0.1(25) 0.15(37) 0.1(25)
EER Btu/h /W 8 7.63 8
Electrical Data
Power Supply V, PH, Hz 220V,1PH,60Hz 220V,1PH,60Hz 220V,1PH,60Hz
M.C.A Amps 25 32 37
Power Input W 4300 4720 6000
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 3.01(0.28) 2.98(0.277) 3.01(0.28)
Row/FPI 3/16 3/16 3/16
Indoor fan
Type Centrifugal Centrifugal Centrifugal
Quantity 1 1 1
Diameter inch 9 9.84 9
Drive Type Direct Direct Direct
Motor output Hp 1/3 1/3 1/2
Motor rpm rpm 1030 1030 970
Compressor
Type Scroll Scroll Scroll
Quantity 1 1 1
Oil type SAY56T SAY56T SAY56T
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 8.06(0.75) 8.23(0.765) 7.85(0.73)
Row/FPI 1/16 1/16 2/16
Outdoor Fan
Type Axial fan Axial fan Axial fan
Quantity 1 1 1
Diameter inch 23 23 23
Drive Type Direct Direct Direct
Motor output Hp 1/3 1/3 1/3
Motor rpm rpm 1080 1080 1080
Dehumidifying l/h 3.6 4.5 4.5
Drain Connection Size inch 3/4 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 1.7(3.75) 1.8(3.97) 3.5(7.72)
Type/Circuit R22/One refrigerant circuit
Refrigerant Control Capillary tube Capillary tube Capillary tube
Dimensions(W*D*H)
Outline inch 53×41.5×25.2 53×41.5×25.2 53×41.5×25.2
mm 1345×1055×640 1345×1055×640 1345×1055×640
Package inch 54.8×43.3×26.2 54.8×43.3×26.2 54.8×43.3×26.2
mm 1392×1100×665 1392×1100×665 1392×1100×665
Weight Net kg (lbs) 185(408) 185(408) 185(408)
Gross kg (lbs) 190(419) 190(419) 190(419)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 24/48/64 24/48/64 24/48/64

5
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 4 5
Model Name GK-C04TC1AF GK-C05TC1AF
Product Code EJ51000470 EJ51000191
Performance
Net Cooling
Capacity
Btu/h 460755 546080
W 135000 160000
Air Circulation CFM (m3/h) 1357(2300) 1650(2800)
Rated ESP In.wg (Pa) 0.2(50) 0.2(50)
EER Btu/h /W 8.44 8.17
Electrical Data
Power Supply V, PH, Hz 220V,3PH,60Hz 220V,3PH,60Hz
M.C.A Amps 32 40
Power Input W 5450 6730
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 3.87(0.28) 3.87(0.36)
Row/FPI 4/16 4/16
Indoor fan
Type Centrifugal
Quantity 1 1
Diameter inch 10.24 10.86
Drive Type Direct
Motor output Hp 0.7 0.7
Motor rpm rpm 1090 1090
Compressor
Type Scroll Scroll
Quantity 1 1
Oil type SAY56T L-DRC/B56
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 8.4(0.78) 10.76(1)
Row/FPI 2/16 2/16
Outdoor Fan
Type Axial fan
Quantity 1 1
Diameter inch 23 23
Drive Type Direct
Motor output Hp 1/3 1/3
Motor rpm rpm 1080 1080
Dehumidifying l/h 4.5 6.2
Drain Connection Size inch 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 3.6(7.9) 4.3(9.5)
Type/Circuit R22/One refrigerant circuit
Refrigerant Control Capillary tube
Dimensions(W*D*H)
Outline inch 53×41.5×25.2 53×41.5×31.1
mm 1345×1055×640 1345×1055×790
Package inch 54.8×43.3×26.2 54.8×43.3×32.1
mm 1392×1100×665 1392×1100×815
Weight Net kg (lbs) 190(419) 210(463)
Gross kg (lbs) 195(430) 220(485)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 24/48/64 16/32/48

6
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 3 4
Model Name GK-C03TC1AK GK-C04TC1AM
Product Code EJ51000200 EJ51000210
Performance
Net Cooling
Capacity
Btu/h 35830 47770
W 10500 14000
Air Circulation CFM (m3/h) 962(1630) 1032(1750)
Rated ESP In.wg (Pa) 0.1(25) 0.1(25)
EER Btu/h /W 9 9
Electrical Data
Power Supply V, PH, Hz 220V,1PH,50Hz 380-415V,50Hz,3Ph
M.C.A Amps 25 14
Power Input W 4700 5400
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 3.01(0.28) 3.01(0.28)
Row/FPI 3/16 3/16
Indoor fan
Type Centrifugal Centrifugal
Quantity 1 1
Diameter inch 9 9
Drive Type Direct Direct
Motor output Hp 1/2 1/2
Motor rpm rpm 1220 1220
Compressor
Type Scroll Scroll
Quantity 1 1
Oil type SAY56T SAY56T
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 7.96(0.74) 7.96(0.74)
Row/FPI 1/16 1/16
Outdoor Fan
Type Axial fan Axial fan
Quantity 1 1
Diameter inch 23 23
Drive Type Direct Direct
Motor output Hp 1/2 1/2
Motor rpm rpm 915 915
Dehumidifying l/h 3.6 4.5
Drain Connection Size inch 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 1.8(3.97) 3.5(7.72)
Type/Circuit R22/One refrigerant circuit
Refrigerant Control Capillary tube Capillary tube
Dimensions(W*D*H)
Outline inch 53×41.5×25.2 53×41.5×25.2
mm 1345×1055×640 1345×1055×640
Package inch 54.8×43.3×26.2 54.8×43.3×26.2
mm 1392×1100×665 1392×1100×665
Weight Net kg (lbs) 185(408) 185(408)
Gross kg (lbs) 190(419) 190(419)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 24/48/64 24/48/64

7
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 5 8
Model Name GK-C05TC1AF GK-C08TC1AF
Product Code EJ51000190 EJ51000151
Performance
Net Cooling
Capacity
Btu/h 59710 95531
W 17500 28000
Air Circulation CFM (m3/h) 2071(3520) 3245(5500)
Rated ESP In.wg (Pa) 0.3(75) 0.4(100)
EER Btu/h /W 9 8
Electrical Data
Power Supply V, PH, Hz 220V,3PH,60Hz 220V,3PH,60Hz
M.C.A Amps 33 45
Power Input W 7660 12700
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 3.88(0.36) 8.83(0.82)
Row/FPI 4/16 3/14
Indoor fan
Type Centrifugal Centrifugal
Quantity 1 1
Diameter inch 10.87 15
Drive Type Direct Belt
Motor output Hp 1 3
Motor rpm rpm 1100 1430
Compressor
Type Scroll Scroll
Quantity 1 2
Oil type SAY56T SAY56T
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 10.75(1.00) 16(1.49)
Row/FPI 2/16 2/16
Outdoor Fan
Type Axial fan Axial fan
Quantity 1 2
Diameter inch 23.03 23
Drive Type Direct Direct
Motor output Hp 1/3 1/3
Motor rpm rpm 1080 1080
Dehumidifying l/h 6.2 7.5
Drain Connection Size inch 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 4.2(9.26) 2×3.6(2×7.94)
Type/Circuit R22/One refrigerant circuit R22/Two independent
refrigerant circuit
Refrigerant Control Capillary tube Capillary tube
Dimensions(W*D*H)
Outline inch 53×41.5×31.1 79.0×56.5×44.0
mm 1345×1055×790 2006×1436×1117
Package inch 54.8×43.3×32.1 80.6×57.7×45.4
mm 1392×1100×815 2046×1466×1152
Weight Net kg (lbs) 205(452) 455(1003)
Gross kg (lbs) 215(474) 485(1069)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 16/32/48 8/16/16

8
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 5 8
Model Name GK-C05TC1AM GK-C08TC1AM
Product Code EJ51000220 EJ51000230
Performance
Net Cooling
Capacity
Btu/h 59710 95531
W 17500 28000
Air Circulation CFM (m3/h) 2076 (3520) 3245(5500)
Rated ESP In.wg (Pa) 0.3(75) 0.4(100)
EER Btu/h /W 9 8
Electrical Data
Power Supply V, PH, Hz 380-415V,50Hz,3Ph 380-415V,50Hz,3Ph
M.C.A Amps 19 32
Power Input W 7200 11800
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 3.87(0.36) 8.83(0.82)
Row/FPI 4/16 3/14
Indoor fan
Type Centrifugal Centrifugal
Quantity 1 1
Diameter inch 11 15
Drive Type Direct Belt
Motor output Hp 1 3
Motor rpm rpm 1370 1410
Compressor
Type Scroll Scroll
Quantity 1 2
Oil type SUNISO 4GSD SAY56T
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 11.3(1.05) 16(1.49)
Row/FPI 2/16 2/16
Outdoor Fan
Type Axial fan Axial fan
Quantity 1 2
Diameter inch 23 23
Drive Type Direct Direct
Motor output Hp 1/2 1/3
Motor rpm rpm 915 915
Dehumidifying l/h 6.2 7.5
Drain Connection Size inch 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 4(8.8) 3.1+2.7(6.83+5.95)
Type/Circuit R22/One refrigerant circuit R22/Two independent
refrigerant circuit
Refrigerant Control Capillary tube Capillary tube
Dimensions(W*D*H)
Outline inch 53×41.5×31.1 78.9×56.5×44.7
mm 1345×1055×790 2006×1436×1117
Package inch 54.8×43.3×32.1 80.5×57.7×45.3
mm 1392×1100×815 2046×1466×1152
Weight Net kg (lbs) 205(452) 455(1003.1)
Gross kg (lbs) 215(474) 485(1069.3)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 16/32/48 8/16/16

9
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 10 10
Model Name GK-C10TC1AF GK-C10TC1AM
Product Code EJ51000061 EJ51000240
Performance
Net Cooling Capacity Btu/h 119420 119420
W35000 35000
Air Circulation CFM (m3/h) 4425(7500) 4425(7500)
Rated ESP In.wg (Pa) 0.4(100) 0.4(100)
EER Btu/h/ W 8 8
Electrical Data
Power Supply V, PH, Hz 220V,3PH,60Hz 380-415V,50Hz,3Ph
M.C.A Amps 41 110
Power Input W 15300 15100
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)8.83(0.82) 8.83(0.82)
Row/FPI 3/14 3/14
Indoor fan
Type Centrifugal
Quantity 1 1
Diameter inch 15 15
Drive Type Belt Belt
Motor output Hp 3 3
Motor rpm rpm 1430 1410
Compressor
Type Scroll Scroll
Quantity 2 2
Oil type SAY56T SUNISO 4GSD
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)19.91(1.85) 19.91(1.85)
Row/FPI 2/16 2/16
Outdoor Fan
Type Axial Fan
Quantity 2 2
Diameter inch 23 23
Drive Type Direct Direct
Motor output Hp 1/3 1/2
Motor rpm rpm 1080 915
Dehumidifying l/h 10 10
Drain Connection Size inch 3/4 3/4
Refrigerant Refrigerant charge kg (lbs) 4+4(8.81+8.81) 4.3+4.3(9.48+9.48) Type/Circuit R22/Two independent refrigerant circuit
Refrigerant Control Capillary tube
Dimensions(W*D*H)
Outline inch 79.0×56.5×44.0 79.0×56.5×44.0
mm 2006×1436×1117 2006×1436×1117
Package inch 80.6×57.7×45.4 80.6×57.7×45.4
mm 2046×1466×1152 2046×1466×1152
Weight Net kg (lbs) 470(1036.2) 470(1036.2)
Gross kg (lbs) 500(1102.3) 500(1102.3)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 8/16/16 8/16/16

10
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 13 15
Model Name GK-C13TC1AF GK-C15TC1AF
Product Code EJ51000300 EJ51000180
Performance
Net Cooling
Capacity
Btu/h 150128 180000
W 44000 50000
Air Circulation CFM (m3/h) 5900(10000) 5900(10000)
Rated ESP In.wg (Pa) 0.8(200) 0.8(200)
EER Btu/h /W 8 8
Electrical Data
Power Supply V, PH, Hz 220V,3PH,60Hz 220V,3PH,60Hz
M.C.A Amps 120 104
Power Input W 23800 22300
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 13.45(1.25) 13.45(1.25)
Row/FPI 4/14 4/14
Indoor fan
Type Centrifugal Centrifugal
Quantity 1 1
Diameter inch 15 15
Drive Type Belt Belt
Motor output Hp / /
Motor rpm rpm / /
Compressor
Type Scroll Scroll
Quantity 2 2
Oil type Mineral-160P SAY56T
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 26.16(2.43) 26.16(2.43)
Row/FPI 2/16 2/16
Outdoor Fan
Type Axial fan Axial fan
Quantity 2 2
Diameter inch 26 26
Drive Type Direct Direct
Motor output Hp 1 1
Motor rpm rpm 820 820
Dehumidifying l/h 15.6 15.6
Drain Connection Size inch 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 5.3+6.0(11.68+13.23) 5.1+5.5(11.24+12.12)
Type/Circuit R22/Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 86.8×63.3×46.8 86.8×63.3×46.8
mm 2205×1610×1190 2205×1610×1190
Package inch 88.3×64.5×48.2 88.3×64.5×48.2
mm 2245×1640×1225 2245×1640×1225
Weight Net kg (lbs) 640(1408) 640(1408)
Gross kg (lbs) 679(1493.8) 679(1493.8)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 3/7/14 3/7/14

11
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 15 20
Model Name GK-C15TC1AF GK-C20TC1AF
Product Code EJ51000181 EJ51000260
Performance
Net Cooling
Capacity
Btu/h 180000 240000
W 50000 70000
Air Circulation CFM (m3/h) 5900(10000) 8260(14000)
Rated ESP In.wg (Pa) 0.8(200) 0.8(200)
EER Btu/h /W 8 8
Electrical Data
Power Supply V, PH, Hz 220V,3PH,60Hz 220V,3PH,60Hz
M.C.A Amps 108 130
Power Input W 23800 28000
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 13.45(1.25) 20.5(1.9)
Row/FPI 4/14 4/14
Indoor fan
Type Centrifugal Centrifugal
Quantity 1 1
Diameter inch 15 18
Drive Type Direct Belt
Motor output Hp 7 7
Motor rpm rpm 1440 1440
Compressor
Type Scroll Scroll
Quantity 2 2
Oil type Mineral-160P Mineral-160P
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 26.16(2.43) 34.11(3.17)
Row/FPI 2/16 2/14
Outdoor Fan
Type Axial fan Axial fan
Quantity 2 2
Diameter inch 26 30
Drive Type Direct Direct
Motor output Hp 1 2.4
Motor rpm rpm 820 850
Dehumidifying l/h 15.6 15.6
Drain Connection Size inch 3/4 1
Refrigerant
Refrigerant
charge
kg (lbs) 5.3+6.0(11.68+13.23) 2×10(2×22.05)
Type/Circuit R22 Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 86.8×63.3×46.8 112.9×83.4×54.1
mm 2205×1610×1190 2870×2120×1375
Package inch 88.3×64.5×48.2 116.1×86.5×61.2
mm 2245×1640×1225 2950×2198×1555
Weight Net kg (lbs) 640(1408) 1005(2211)
Gross kg (lbs) 679(1493.8) 1170(2574)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 3/7/14 1/4/4

12
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 15 20
Model Name GK-C15TC1AM GK-C20TC1AM
Product Code EJ51000250 EJ51000280
Performance
Net Cooling
Capacity
Btu/h 180000 240000
W 50000 70000
Air Circulation CFM (m3/h) 5900(10000) 8260(14000)
Rated ESP In.wg (Pa) 0.8(200) 0.8(200)
EER Btu/h /W 8 8
Electrical Data
Power Supply V,PH ,Hz 380-415V,50Hz,3Ph 380-415V,50Hz,3Ph
M.C.A Amps 116 116
Power Input W 24500 27000
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 10.55(0.98) 20.5(1.9)
Row/FPI 4/16 4/14
Indoor fan
Type Centrifugal Centrifugal
Quantity 1 1
Diameter inch 15 18
Drive Type Belt Belt
Motor output Hp 7 7
Motor rpm rpm 1440 1440
Compressor
Type Scroll Scroll
Quantity 2 2
Oil type Mineral-160P Mineral-160P
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2) 26.16(2.43) 34.11(3.17)
Row/FPI 2/16 2/14
Outdoor Fan
Type Axial fan Axial fan
Quantity 2 2
Diameter inch 26 30
Drive Type Direct Direct
Motor output Hp 3/4 2.4
Motor rpm rpm 940 710
Dehumidifying l/h 15.6 15.6
Drain Connection Size inch 3/4 1
Refrigerant
Refrigerant
charge
kg (lbs) 4.5+5.4(9.92+11.90) 8+8(17.64+17.64)
Type/Circuit R22 Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 86.8×63.3×46.8 112.9×83.4×54.1
mm 2205×1610×1190 2870×2120×1375
Package inch 88.3×64.5×48.2 116.1×86.5×61.2
mm 2245×1640×1225 2950×2198×1555
Weight Net kg (lbs) 640(1408) 1005(2211)
Gross kg (lbs) 679(1493.8) 1170(2574)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 3/7/14 1/4/4

13
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 25 25 30
Model Name GK-C25TC1AF GK-C25TC1AM GK-C30TC1AM
Product Code EJ51000270 EJ51000290 EJ51000450
Performance
Net Cooling
Capacity
Btu/h 300000 300000 360000
W87500 85000 95000
Air Circulation CFM ( m3/h ) 10324(17500) 8534(14500) 9144(15500)
Rated ESP In.wg (Pa) 1(250) 1(250) (1)250
EER Btu/h/ W 888
Electrical Data
Power Supply V, PH, Hz 220V,3PH,60Hz 380-415V,50Hz,3Ph 380V-50Hz-3Ph
M.C.A Amps 152 116 118
Power Input W 44000 33500 43000
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)20.5(1.9) 20.5(1.9) 20.5(1.9)
Row/FPI 4/14 4/14 4/14
Indoor fan
Type Centrifugal fan
Quantity 1 1 1
Diameter inch 18 18 18
Drive Type Belt Belt Belt
Motor output Hp / 7 10
Motor rpm rpm / 1440 1440
Compressor
Type Scroll Scroll Scroll
Quantity 2 2 2
Oil type Mineral-160P POE-160SZ POE-320SZ/Mineral-160P
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)34.11(3.17) 34.11(3.17) 34.11(3.17)
Row/FPI 2/14 2/14 2/14
Outdoor Fan
Type Axial Fan Axial Fan Axial Fan
Quantity 2 2 2
Diameter inch 30 30 30
Drive Type Direct Direct Direct
Motor output Hp 2.4 2.4 2.4
Motor rpm rpm 850 710 710
Dehumidifying l/h 26 18.5 30
Drain Connection Size inch 1 1 1
Refrigerant
Refrigerant
charge
kg (lbs) 12+11.5(26.46+25.35) 10+11(22.05+24.25) 11+10(24+22)
Type/Circuit R22 Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 112.9×83.4×54.1 112.9×83.4×54.1 112.9×83.4×54.1
mm 2870×2120×1375 2870×2120×1375 2870×2120×1375
Package inch 116.1×86.5×61.2 116.1×86.5×61.2 116.1×86.5×61.2
mm 2950×2198×1555 2950×2198×1555 2950×2198×1555
Weight Net kg (lbs) 1049(2307.8) 1049(2307.8) 1115(2453)
Gross kg (lbs) 1214(2670.8) 1214(2670.8) 1280(2816)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 1/4/4 1/4/4 1/4/4

14
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 5 8 10
Model Name GK-H05TC1AM GK-H08TC1AM GK-H10TC1AM
Product Code EJ51000320 EJ51000311 EJ51000331
Performance
Net Cooling/
Heating Capacity
Btu/h 54000/60000 95600/102400 112569/119420
W15500/17500 28000/30000 33000/35000
Air Circulation CFM ( m3/h ) 1413(2400) 3237(5500) 3649(6200)
Rated ESP In.wg (Pa) (0.2)50 (0.4)100 (0.4)100
EER Btu/h/ W 888
Electrical Data
Power Supply V ,Hz,Ph 380-415V-50Hz-3Ph
M.C.A Amps 20 40 40
Power Input W 6500 11500 13600
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)3.87(0.36) 8.83(0.82) 8.83(0.82)
Row/FPI 4/16 3/14 3/14
Indoor fan
Type Centrifugal fan
Quantity 1 1 1
Diameter inch 11 15 15
Drive Type Direct Belt Belt
Motor output Hp 0.45 3 3
Motor rpm rpm 910 1410 1410
Compressor
Type Scroll Scroll Scroll
Quantity 1 2 2
Oil type SAY56T SAY56T SAY56T
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)11.3(1.05) 19.91(1.85) 19.91(1.85)
Row/FPI 2/16 2/16 3/16
Outdoor Fan
Type Axial Fan
Quantity 1 2 2
Diameter inch 23 23 23
Drive Type Direct
Motor output Hp 0.5 0.5 0.5
Motor rpm rpm 915 915 915
Dehumidifying l/h 6.2 7.5 10
Drain Connection Size inch 3/4 3/4 3/4
Refrigerant
Refrigerant
charge
kg (lbs) 4.8(10.6) 4+4.2(8.8+9.3) 5+5(11.0+11.0)
Type/Circuit R22 Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 52.9×41.5×31.1 78.9×56.5×43.9 78.9×56.5×43.9
mm 1345x1055x790 2006X1436X1117 2006X1436X1117
Package inch 54.8×43.3×32.1 80.6×57.7×45.4 80.6×57.7×45.4
mm 1392x1100x815 2046X1466X1152 2046X1466X1152
Weight Net kg (lbs) 220(485) 480(1058) 515(1136)
Gross kg (lbs) 230(507) 510(1124) 545(1202)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 16/32/48 8/16/16 8/16/16

15
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 15 20
Model Name GK-H15TC1AM GK-H20TC1AM
Product Code EJ51000340 EJ51000350
Performance
Net Cooling/
Heating Capacity
Btu/h 170700/170700 240000/240000
W50000/50000 70000/70000
Air Circulation CFM ( m3/h ) 5300(9000) 7080(12000)
Rated ESP In.wg (Pa) (0.8)200 (0.8)200
EER Btu/h/ W 8 8
Electrical Data
Power Supply V ,Hz,Ph 380-415V-50Hz-3Ph
M.C.A Amps 80 80
Power Input W 25000 28000
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)10.55(0.98) 20.50(1.9)
Row/FPI 4/14 4/14
Indoor fan
Type Centrifugal fan
Quantity 1 1
Diameter inch 15 18
Drive Type Belt
Motor output Hp 7.5 7.5
Motor rpm rpm 1440 1440
Compressor
Type Scroll
Quantity 2 2
Oil type Mineral-160P Mineral-160P
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)24.57(2.283) 34.11(3.17)
Row/FPI 3/16 3/16
Outdoor Fan
Type Axial Fan
Quantity 2 2
Diameter inch 26 30
Drive Type Direct
Motor output Hp 1 2.4
Motor rpm rpm 920 710
Dehumidifying l/h 15.6 15.6
Drain Connection Size inch 3/4 1
Refrigerant
Refrigerant
charge
kg (lbs) 6.6+6.6(14.55+14.55) 10+10(22.05+22.05)
Type/Circuit R22 Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 86.8×63.4×46.9 112.9×83.5×54.1
mm 2205x1610x1190 2870×2120×1375
Package inch 80.6×57.7×45.4 116.1×86.5×61.2
mm 2245x1640x1225 2950×2198×1555
Weight Net kg (lbs) 690(1521) 1060(2336.8)
Gross kg (lbs) 729(1607) 1225(2700.6)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 3/7/14 1/4/4

16
Rooftop Packaged
Service Manual
PRODUCT
Nominal Capacity (Ton) 25 30
Model Name GK-H25TH1AM GK-H30TH1AM
Product Code EJ51000361 EJ51000370
Performance
Net Cooling/
Heating Capacity
Btu/h 290000/290000 330000/340000
W85000/85000 97000/100000
Air Circulation CFM ( m3/h ) 8239(14000) 10620(18000)
Rated ESP In.wg (Pa) (1)250 (1)250
EER Btu/h/ W 8 8
Electrical Data
Power Supply V ,Hz, Ph 380-415V-50Hz-3Ph
M.C.A Amps 100 125
Power Input W 34000 42000
Indoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)24.07(2.236) 27.63(2.567)
Row/FPI 4/14 4/14
Indoor fan
Type Centrifugal fan
Quantity 1 1
Diameter inch 17.6 17.6
Drive Type Belt
Motor output Hp 10 15
Motor rpm rpm 1440 1460
Compressor
Type Scroll
Quantity 2 2
Oil type Mineral-160P POE-320SZ/Mineral-160P
Outdoor Coil
Type Aluminum n-copper tube
Face Area sq.ft (m2)40.8(3.79) 46.7(4.34)
Row/FPI 3/16 3/16
Outdoor Fan
Type Axial Fan
Quantity 2 2
Diameter inch 31.69 31.69
Drive Type Direct
Motor output Hp 3 3
Motor rpm rpm 940 940
Dehumidifying l/h 23.1 30
Drain Connection Size inch 1 1
Refrigerant
Refrigerant
charge
kg (lbs) 15.5+14.5(34.17+31.97) 16+17(35.27+37.48)
Type/Circuit R22 Two independent refrigerant circuit
Refrigerant Control Thermal Expansion Valve
Dimensions(W*D*H)
Outline inch 112.9×83.5×69.9 112.9×83.5×89.9
mm 2870×2120×1775 2870×2120×2283
Package inch 116.1×86.5×77.2 116.1×86.5×97.2
mm 2950×2198×1962 2950×2198×2470
Weight Net kg (lbs) 1312(2893.0) 1540(3395.7)
Gross kg (lbs) 1448(3192.8) 1620(3572.1)
Filter Washable synthetic
Stufng Quantity 20ft\40ft\40ft(Hi) 1/1/4 0/0/4
Note:
a. The cooling capacity stated above is measured under following conditions:
Indoor Conditions: 27℃DB/19℃WB (81 ℉DB/67 ℉WB);
Outdoor Conditions: 35℃DB/24℃WB (95 ℉DB/76 ℉WB).
b. The air volume is measured at the relevant standard external static pressure.
c. M.C.A: Minimum Circuit Ampacity.
d. The technical parameters are changed along with the products improvement, please refer to the
nameplate of the unit for actual data.

17
Rooftop Packaged
Service Manual
PRODUCT
4.2 ELECTRICAL DATA
Model
Compressor
Fan Motor
Max.
Fuse
Size
Min
Disconnect
Size
Condenser
Fan Motors
Supply
Blower
Motor
Power
Supply Qty. RLA (each)
LRA
(each)
FLA
(each)
FLA
(each)
(Ph,V,Hz) - (Amps) (Amps) (Amps) (Amps) (Amps) (Amps)
GK-C03TC1AD 1Ph,220V,60Hz 1 18.2 136 2.1 1.65 40 32
GK-C03TC1AD 1Ph,220V,60Hz 1 19.5 150 2.1 1.65 40 32
GK-C04TC1AD 1Ph,220V,60Hz 1 26.3 151 2.1 2.6 60 37.575
GK-C04TC1AF 3Ph,220V,60Hz 1 14.1 115 2.1 3.4 32 26
GK-C05TC1AF 3Ph,220V,60Hz 1 17.5 134 2.1 5.1 32 31
GK-C05TC1AF 3Ph,220V,60Hz 1 17.5 134 2.1 3.4 32 31
GK-C08TC1AF 3Ph,220V,60Hz 2 16.6 134 2.1 8.64 63 55
GK-C10TC1AF 3Ph,220V,60Hz 2 20.5 134 2.1 8.64 63 61
GK-C13TC1AF 3Ph,220V,60Hz 2 27.1 195 3.8 20.38 100 88
GK-C15TC1AF
(Danfoss) 3Ph,220V,60Hz 2 27.1 195 3.8 20.38 100 88
GK-C15TC1AF
(Copeland) 3Ph,220V,60Hz 2 32.1 195 3.8 20.38 100 88
GK-C20TC1AF 3Ph,220V,60Hz 2 36.4 267 8.4 20.3 125 120
GK-C25TC1AF 3Ph,220V,60Hz 2 45.7 255 8.4 26.95 200 190
GK-C03TC1AK 1PH,220V,50Hz 1 17 130 1.9 3.7 32 30
GK-C04TC1AM 3Ph,380V~415V,50Hz 1 8.06 73 1.9 3.7 16 13
GK-C05TC1AM 3Ph,380V~415V,50Hz 2 9.3 69 1.9 4.6 20 18
GK-C08TC1AM 3Ph,380V~415V,50Hz 2 8.9 73 1.9 5.16 40 33
GK-C10TC1AM 3Ph,380V~415V,50Hz 2 9.3 69 1.9 5.16 40 35
GK-C10TC1AM 3Ph,380V~415V,50Hz 2 9.3 69 1.9 5.16 100 100
GK-C15TC1AM 3Ph,380V~415V,50Hz 2 17.9 142 1.6 11.8 63 62
GK-C15TC1AM 3Ph,380V~415V,50Hz 2 17.9 142 1.6 11.8 110 110
GK-C20TC1AM 3Ph,380V~415V,50Hz 2 19.3 147 5 11.8 100 85
GK-C20TC1AM 3Ph,380V~415V,50Hz 2 19.3 147 5 11.8 120 120
GK-C25TC1AM 3Ph,380V~415V,50Hz 2 35 149 5 11.8 130 100.55
GK-C25TC1AM 3Ph,380V~415V,50Hz 2 35 149 5 11.8 120 120
GK-C30TC1AM 3Ph,380VV,50Hz 2 35.7 215 5 15.6 125 103
GK-H05TC1AM 3Ph,380V~415V,50Hz 1 9.4 73 1.9 3.26 20 18.5
GK-H08TC1AM 3Ph,380V~415V,50Hz 2 8.9 73 1.9 5.16 40 32
GK-H10TC1AM 3Ph,380V~415V,50Hz 2 9.4 73 1.9 5.16 40 33
GK-H15TC1AM 3Ph,380V~415V,50Hz 2 17.9 142 2.1 11.2 63 57
GK-H20TC1AM 3Ph,380V~415V,50Hz 2 19.3 147 5 11.2 80 69
GK-H25TH1AM 3Ph,380V~415V,50Hz 2 35 149 5.3 15.6 100 82
GK-H30TH1AM 3Ph,380V~415V,50Hz 2 35.7 215 5.3 22.3 125 107

18
Rooftop Packaged
Service Manual
PRODUCT
5 PIPING DIAGRAM
5.1 COOLING ONLY
3-10Ton:
Evaporator Compressor
Suction Discharge Axial Flow Fan
Refrigerant
Refrigerant
Capillary
Capillary
Centrifugal Fan
Relief Valve
Filter
Condenser
(Refrigerant owing direction is shown as the arrow)
15-30Ton:
Evaporator
Compressor
Suction Discharge Axial Flow Fan
Refrigerant
Refrigerant
Capillary
Centrifugal Fan
Relief Valve
Filter
Condenser
Thermal Expansion Valve
(Refrigerant owing direction is shown as the arrow)
