GREEN BANK XMJ24200 User manual

USER GUIDE
LiFePO4 Battery System for Households
LiFePO4 Battery System for Households
358-010176-00

1 ABOUT THIS MANUAL ..................................................................................... 1
1.1 Purpose .................................................................................................. 1
1.2 Scope ..................................................................................................... 1
1.3 Safety Instructions ................................................................................... 1
2 INTRODUCTION .............................................................................................. 2
2.1 Features................................................................................................. 2
2.2 Product Over View .................................................................................. 2
2.3 Specifications ........................................................................................ 4
2.4 Recommended Settings .......................................................................... 4
3. INSTALLATION ................................................................................................ 5
3.1 Unpacking and Inspection ....................................................................... 5
3.2 Mounting the Unit ............................................................... .................... 5
4. OPERATION ................................................................................................... 8
4.1 Switch On/Off........................................................................................... 8
4.2 Description for LED ................................................................................. 8
4.3 ON / OFF or SOC Led (Mode or SOC) ........................................................ 8
5. EMERGENCY SITUATIONS ............................................................................. 9
5.1 Fire ....................................................................................... . .. . . .......... 9
5.2 Leaking Batteries .................................................................... ... ... . ....... 9
5.3 Wet Batteries ......................................................................................... 9
5.4 Warranty ............................................................................. . . . . .............. 9
Contents
3.3 Connection for Parallel Mode ................................................................... 6
1.1 Purpose
This manual describes the introduction,installation, operation and emergency situations of the battery bank.
Please read this manual carefully before installations and operations. Keep this manual for future reference.
1.2 Scope
This manual provides safety and installation guidelines as well as information on tools and wiring.
1.3 Safety Instructions
WARNING: This chapter contains important safety and operating instructions. Read and keep this
manual for future reference.
1.Before using the unit, read all instructions and cautionary markings on the unit, the batteries and all
appropriate sections of this manual.
2. CAUTION – ,even burst. please use it following using manual. In case -- To reduce risk of injury,damage
of causing personal
3. Do not disassemble the battery. Take it to a qualified service center when service or repair is required.
Incorrect re-assembly may result in a risk of fire.
4. To reduce risk of electric shock, disconnect all wirings before attempting any maintenance or cleaning.
Turning off the unit will not reduce this risk.
5. CAUTION – Only qualified personnel can install this device with inverter.
6. For optimum operation of this battery, please follow required spec to select appropriate cable size.
7. Be very cautious when working with metal tools on or around batteries. A potential risk exists to drop a tool
to spark or short circuit batteries or other electrical parts and could cause an explosion or fire.
8. Please strictly follow installation procedure.
9. To support full output load, at least 2 sets of XMJ24V for inverter larger than 3KVA, and at least 2 sets
of XMJ48V for inverter larger than 6KVA in parallel connection.
10. GROUNDING INSTRUCTIONS - This System should be connected to a permanent grounded wiring
system. Be sure to comply with local requirements.
11. NEVER cause AC outp ut and DC input short circuited. Do not connect to the mains when DC input
short circuits.
12. Warning!! Only qualified service persons are able to service this device.
13. Battery should be installed indoor and kept away from water, high temperature mechanical force and flames.
14. Do not install the battery in any environment of temperature below 0°C or over 55°C,and humidity over 80%.
15. Do not put any heavy objects on the battery.
1 ABOUT THIS MANUAL
01
LiFePO4 Battery System for Households
Special Attention: Due to the built-in protection board of the lithium battery pack is with
over-discharge protection function, it is strongly recommended to stop using the load when
the battery pack is over-discharged. The battery pack cannot be repeatedly activated for
discharge. Therefore, when the battery pack is low power, please charge the battery as
soon as possible when main power or solar energy is available.
1. The batteries can be connected in parallel. Series connection is not allowed.
Use in upright position only.
2. The batteries are not allowed to connected with PWM controller for charging.
1.4 Can be connected in parallel

02
LiFePO4 Battery System for Households
2. INTRODUCTION
The battery system main using Solar power system for Family house.It also have a with to controller the
battery easily and protect our Household application timely.
• Iron phosphate-lithium power battery
• Long warranty period:2 years
• Higher energy density,smaller volumn for household.
• Support connected in parallel mode for expansion
• Photovoltaic system: This battery pack is designed for household photovoltaic systems.
• Battery management system (BMS): The battery packs built-in BMS monitors its
operation and prevents the battery from operating outside design limitations.
• Expandability: This battery pack can be easily expanded by adding expansion battery packs
in parallel connection.
2.2 Product Over View
2.1 Features
24V Front view 48V Front view
1.Power On/Charging indicator 3.Battery Positive +
2. LED display
4.Battery Negative - 5. Earth wire 6.Wall mounted fixing
03
LiFePO4 Battery System for Households
3
4
5
6
1
2
3 4
2
1
7. Handle
7
5
3 4
XMJ24200 &XMJ48200
XMJ24350
XMJ48350
7
5
2
1
L
O
M
W
E
T
V
S
O
Y
L
S
T
A
E
G
G
E
A
E
T
N
T
O
E
R
S
G
Y

LiFePO4 Battery System for Households
0504
LiFePO4 Battery System for Households
Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. You
should have received the following items inside of package.
3.1 Unpacking and Inspection
3.2 Mounting the Unit
Consider the following points before selecting where to install:
• Do not mount the battery on flammable construction materials.
• The ambient temperature should be between 0°C and 45°C to ensure optimal operation.
• The recommended installation position is to be adhered to the wall vertically.
• Be sure to keep other objects and surfaces as shown in the right diagram to guarantee sufficient heat dissipation and
to have enough space for removing wires.
NO NAME SPECIFICATION PICTURE
User manual User manual
Guarantee card Guarantee card
Cables
Screw Mounting screw
Wall mount Wall mount bracket
1
4
5
3
2
Used for battery parallel connection
3. INSTALLATION
2
3
4
5
105
240
111
301
155
140
92.5
320
232.5
401
132.5
240
AB
C
D
EF
XMJ24200 XMJ48200
2.3 Specifications
2.4 Recommended Settings
Lithium battery pack is not same as lead-acid battery, so for the devices which you connect with the battery pack
for charging or discharging, such as inverters, MPPT charger controllers or UPS, please implement pre-settings
as recommended settings as below before you launched them.
Setting
Max. Charging Voltage
Floating charging Voltage
Recommend Charge Current
Cut-off voltage
Notes: “N” means the number of battery packs connected in parallel.
Model
Usable Capacity
Voltage Range
MAX. Charge & Discharge Current
Recommend Discharge Current
MAX. Output Power
Recommend Output Power
DOD
Modules Connection
Ingress Protection
Cycle Life
Working Temperature Range
Net Weight(KG)
Gross Weight(KG)
Product Dimension(MM)
Package Dimension(MM)
≥95%
1~6in parallel
IP21
≥3000,@25°C,@DOD80%
Discharge: -20°C to +60°C, Charge: +0°C to +55°C
XMJ24200
5KWH
XMJ24350
XMJ48200 XMJ48350
10KWH 8.4KWH 16.8KWH
21-28.2 42-56.4 21-28.2 42-56.4
120A @30S 150A @30S
≤60A ≤100A
3000W 6000W 7500W3750W
1500W 3000W 5000W2500W
73.2KG 151.0KG
78.4KG 162.6KG
XMJ24200 XMJ24350 XMJ48200 XMJ48350
28.2V 56.4V
28.2V 56.4V
45A*N 90A*N 45A*N 90A*N
24V 48V
578*578*235MM 380*563*758MM
690*690*347MM 475*668*925MM
50KG
53KG
510*450*213MM
622*562*292MM
88.5KG
93.1KG
800*545*213MM
912*657*292MM
Nominal Voltage
Recommend Charge Current ≤45A ≤90A
NOTE: ① ② ③ in XMJ24350 & XMJ48350 ① ② ③ ④ ⑤ in XMJ24200 & XMJ48200
1
Total capacity
3.75KWH 7.5KWH 7.5KWH 15KWH

LiFePO4 Battery System for Households LiFePO4 Battery System for Households
06 07
The eStrong XMJ series battery support to be connected in parallel for expansion. If you need one more
battery bank work in parallel mode, connect the battery as shown in PIC 2
3.3 Connection for Parallel Mode
Main Circuit
Main Circuit
Schematic diagram of parallel connection of battery packs(XMJ24350)
Main Circuit
Schematic diagram of parallel connection of battery packs(XMJ48350)
Schematic diagram of parallel connection of battery packs(XMJ24200 & XMJ48200)

LiFePO4 Battery System for Households LiFePO4 Battery System for Households
5. EMERGENCY SITUATIONS
GREEN BANK cannot guarantee battery absolute safety.
5.1 Fire
In case of fires, make sure that the following equipment is available near the system.
• SCBA (self-contained breathing apparatus) and protective gear in compliance with the Directive on Personal
Protective Equipment 89/686/EEC.
• NOVEC 1230, FM-200, or dioxide extinguisher
Batteries may explode when heated above 150°C. KEEP FAR AWAY from the battery if it catches fire.
If the battery pack leaks electrolyte,avoid contact with the leaking liquid or gas.If one is exposed the leaked
substance,immediately perform the actions described below.
• Inhalation: Evacuate the contaminated area, and seek medical attention.
• Contact with eyes: Rinse eyes with running water for 5 minutes, and seek medical attention.
• Contact with skin: Wash the affected area thoroughly with soap and water, and seek medical attention.
• Ingestion: Induce vomiting, and seek medical attention.
If the battery pack is wet or submerged in water, do not let people access it, and contact your supplier for help.
Damaged Batteries
Damaged batteries are not fit for use and are dangerous and must be handled with the utmost care. It may
leak electrolyte or produce flammable gas. If the battery pack seems to be damaged, pack it in its original
container, and then return it to your supplier.
Products that are operated strictly in accordance with the user manual are covered by the warranty. Any
violation of this manual may void the warranty.
Limitation of Liability
Any product damage or property loss caused by the following conditions, GREEN BANK does not assume any
direct or indirect liability.
• Product modified, design changed or parts replaced.
• Changed, or attempted repairs and erasing of series number or seals;
• System design and installation are not in compliance with standards and regulations;
• The product has been improperly stored in end user’s premises;
• Transport damage (including painting scratch caused by movement inside packaging during shipping). A
claim should be made directly to shipping or insurance company.
5.2 Leaking Batteries
5.3 Wet Batteries
5.4 Warranty
4.3 ON / OFF or SOC Led (Mode or SOC)
LED Indicator
Messages
On/Off
Red
OnGreen
Flashing
Working in discharge mode
When the following faults occur:
1.Battery voltage is too low;
2.Cell voltage is too low;
3.Cell temperature is too high;
4.Cell temperature is too low;
5.BMS temperature is too high;
The SOC of the battery is shown by the LED.
4.2 Description for LED
Note: The battery need to be fully charged for at least once in one month to ensure the accurate SOC
calculation.
100% 75% 50% 25%
08 09
Once the batteries are connected well, simply press On/Off button to enable the output of the battery pack.
4. OPERATION
24V Front view 48V Front view
1.Switch on: When the On/Off button pops up, the battery will turn on and there will be current output.
The LED will show the SOC.
2.Switch off: Press the On/Off button (recessed state), the battery will shut down and no output current.
4.1 Switch On / Off
